tires Acura RL 2002 3.5 User Guide

µ
µ
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ì
Ì
Ì
Maint enance219
Canadian Owners U.S. Owners
A, B, C, D
A
B
C
D
7,500 mi/12,000 km
15,000 mi/24,000 km/1yr
22,500 mi/36,000 km
30,000 mi/48,000 km/2 yrs
37,500 mi/60,000 km/
45,000 mi/72,000 km/3 yrs
52,500 mi/84,000 km/
60,000 mi/96,000 km/4 yrs
67,500 mi/108,000 km
75,000 mi/120,000 km/5 yrs
82,500 mi/132,000 km
90,000 mi/144,000 km/6 yrs
97,500 mi/156,000 km
105,000 mi/168,000 km/7 yrs
112,500 mi/180,000 km
120,000 mi/192,000 km/8 yrs
120,000 mi/192,000 km/10 yrs
120,000 mi/192,000 km/6 yrs Use the Maintenance Schedule for Severe Conditions.
Refer to page to determine which schedule to use.
Do items in A.
Do items in A, B.
Do items in A.
DoitemsinA,B,C.
Do items in A.
DoitemsinA,B,D.
Do items in A.Replace front differential fluid.
DoitemsinA,B,C.
Do items in A.
Do items in A, B.
Do items in A. Replace front differential fluid.
DoitemsinA,B,C,D.
Do items in A. Replace timing belt, balancer belt, and inspect
water pump. Check idle speed.
Replace spark plugs.
Do items in A, B.
Do items in A. Replace front differential fluid.
DoitemsinA,B,C. Replace engine coolant, then replace every
60,000 mi/96,000 km/5 yrs. Replace transmission fluid, then every 90,000
mi/144,000 km/5 yrs. Replace engine oil.
Rotate tires (follow pattern on page256).
Replace engine oil filter.
Inspect front and rear brakes.
Check parking brake adjustment.
Inspect tie rod ends, steering gear box and boots.
Inspect suspension components.
Inspect driveshaft boots.
Inspect brake hoses and lines (including ABS).
Check all fluid levels, condition of fluids, and check
for leaks.
Inspect cooling system hoses and connections.
Inspect exhaust system.
Inspect fuel lines and connections.
Replace air cleaner element.
Inspect and adjust drive belts.
Replace air conditioning filter.
Replace brake fluid (every 3 years regardless of
mileage).
Service at the indicated distance or time, whichever comes first. Do the items in as required for each distance/time interval.
See information on maintenance and emissions warranty, last
column, page .
Check engine oil and coolant at each fuel stop. :
NOTE: 217
218
Maintenance Schedule for Normal Conditions (listed by distance/time)
01/09/28 20:01:13 31SZ3660_222

µ
Ì
Î
Î
µ
ÌÎÎ
Î
ÌÌ
Follow the Severe Conditions
Maintenance Schedule if you
drive your car under
one or more of the f ollowing
conditions: Driving less than 5 miles (8
km) per trip or, in f reezing
temperatures, driving less
than 10 miles (16 km) per trip.
Driving in extremely hot
[over 90°F (32°C)] conditions.
Extensive idling or long
periods of stop-and-go driving.
Trailer towing, driving with a
roof rack, or driving in
mountainous conditions.
Driving on muddy, dusty, or
de-iced roads.
Follow the Maintenance
Schedule f or Severe Conditions.
MAINLY
Maint enance
U.S. Owners
Canadian Owners
220
Visually inspect the following items: Replace every 3,750 miles (6,000 km) or 6 months
Check oil and coolant at each fuel stop
Service at the indicated
distance or time whichever
comes first.
miles x 1,000
km x 1,000
months
Every 7,500 miles (12,000 km) or 6 monthsRotate tires every 7,500 miles (12,000 km)
Replace engine oil and oil filter
Check engine oil and coolant
Clean ( ) or replace ( ) air cleaner element
Replace spark plugs
Replace timing belt , balancer belt , and
inspect water pump
Inspect and adjust drive belts
Inspect idle speed
Replace engine coolant
Replace transmission fluid
Replace front differential fluid
Inspect front and rear brakes
Replace brake fluid
Check parking brake adjustment
Replace air conditioning filter
Lubricate all hinges, locks, and latches
Rotate tires (Check tire inflation and condition
at least once per month)
Tie rod ends, steering gear box, and boots
Suspension components, Driveshaft boots
Brake hoses and lines (including ABS)
All fluid levels and condition of fluids
Cooling system hoses and connections Exhaust system, Fuel lines and connections
Lights and controls, Vehicle underbody 15
24
12
30
48
2445
72
3660
96
4875
120 60 90
144 72 120
192
96
See information on maintenance and emissions warranty, last column, page .
See timing belt on page for replacement information under special driving conditions.
See Air Conditioning Filter on page for replacement information under special driving conditions. 105
168
84
Every 7,500 miles (12,000 km) or 6 months
120,000 miles (192,000 km) or 10 years, then every 60,000
miles (96,000 km) or 5 years
Every 3 years (independent of mileage)
:
1:
2: 217
253 252
Use normal schedule except in dusty conditions
11
2
60,000 miles (96,000 km) or 3 years, then every 30,000 miles (48,000 km) or 2 years
Maintenance Schedule for Severe Conditions
01/09/28 20:01:35 31SZ3660_223

µ
µ
Ø
Ø
Ø
Ø
Ø
Ø
Ø Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
ÌÎÎ
Ì
Ì
Î
Î
ÎÌ
CONT INUED
Maint enance221
Canadian Owners A, B, C, D, E
U.S. Owners
A
B
C
D
E
Use the Maintenance Schedule for Severe Conditions.
Service at the indicated distance or time, whichever comes first. Do the items in as required for each distance/time.
Refer to page to determine which schedule to use.
3,750 mi/6,000 km
7,500 mi/12,000 km
11,250 mi/18,000 km
15,000 mi/24,000 km/1 yr
18,750 mi/30,000 km
22,500 mi/36,000 km
26,250 mi/42,000 km
30,000 mi/48,000 km/2 yrs
33,750 mi/54,000 km
37,500 mi/60,000 km
41,250 mi/66,000 km
45,000 mi/72,000 km/3 yrs
48,750 mi/78,000 km
52,500 mi/84,000 km
56,250 mi/90,000 km
60,000 mi/96,000 km/4 yrs
60,000 mi/96,000 km/3 yrs Do items in A.
Do items in A, B.
Do items in A.
Clean air cleaner element.
DoitemsinA,B,C.
Do items in A.
Do items in A, B.
Do items in A. Replace front differential fluid.
DoitemsinA,B,C,D.
Do items in A.
Do items in A, B.
Do items in A. Replace front differential fluid.
Clean air cleaner element.
DoitemsinA,B,C,E.
Do items in A.
Do items in A, B.
Do items in A. Replace front differential fluid.Replace timing belt , balancer belt , and
inspect water pump.
DoitemsinA,B,C,D. Replace transmission fluid, then replace every
30,000 mi/48,000 km/2 yrs. Replace engine oil and filter.
Inspect front and rear brakes.
Rotate tires (follow pattern on page256).
Inspect tie rod ends, steering gear box and boots.
Inspect suspension components.
Inspect driveshaft boots.
Check parking brake adjustment.
Lubricate all hinges, locks, and latches with
multipurpose grease.
Inspect brake hoses and lines (including ABS).
Check all fluid levels, condition of fluids, and check
for leaks.
Inspect cooling system hoses and connections.
Inspect exhaust system.
Inspect fuel lines and connections.
Check all lights.
Inspect the underbody.
Replace air cleaner element.
Inspect and adjust drive belts.
Replace air conditioning filter .
Replace brake fluid every 3 years (independent of
mileage).
See timing belt on page for replacement information under special driving conditions.
See Air Conditioning Filter on page for replacement information under special driving
conditions.
See information on maintenance and emissions warranty, last column, page .
Check engine oil and coolant at each fuel stop.
1:
2:
:
NOTE : 220
253 252
217
11 2
Maintenance Schedule for Severe Conditions (listed by distance/time)
01/09/28 20:01:48 31SZ3660_224

µµµ µ
µ
µ
µ
Youshouldcheckthefollowing
items at the specif ied intervals. If
you are unsure of how to perf orm
any check, turn to the page given.
Engine oil level Check every
time you fill the fuel tank. See
page .
Engine coolant level Check the
radiator reserve tank every time
youfillthefueltank.Seepage .
Windshield washer f luid Check
the level in the reservoir monthly.
If weather conditions cause you to
use the washers f requently, check
the reservoir each time you stop
f or f uel. See page .Lights Check the operation of
the headlights, parking lights,
taillights, high-mount brake light,
turn signals, brake lights, and
license plate lights monthly. See
page . Tires Check the tire pressure
monthly. Examine the tread f or
wear and foreign objects. See page
.
Automatic transmission Check
the f luid level monthly. See page .
Brakes Check the f luid level
monthly. See page . 181
182
237
238 240 255
260
Owner Maintenance Checks
Maint enance225
01/09/28 20:02:19 31SZ3660_228

µµWe recommend that you visually
check your tires every day. If you
think a tire might be low, check it
immediately with a tire gauge.
The timing belt and balancer belt
should normally be replaced at the
intervals shown in the maintenance
schedule.
In very high temperatures
(over 110°F, 43°C).
In very low temperatures
(under 20°F, 29°C). To saf ely operate your car, your tires
must be the proper type and size, in
good condition with adequate tread,
and correctly inf lated. The f ollowing
pages give more detailed inf ormation
on how and when to check air
pressure, how to inspect your tires
for damage and wear, and what to do
when your tires need to be replaced.
Replace these belts at 60,000 miles
(U.S.) or 100,000 km (Canada) if you
regularly drive your car in one or
more of these conditions: Keeping the tires properly inf lated
provides the best combination of
handling, tread lif e, and riding
comf ort. Underinf lated tires wear
unevenly, adversely af f ect handling
and f uel economy, and are more
likely to f ail f rom being overheated.
Overinf lated tires can make your car
ride more harshly, are more prone to
damage f rom road hazards, and wear
unevenly.
CONT INUED
Inf lation
Tires
Timing Belt
Timing Belt, Tires
Maint enance253
Using tires that are excessively
worn or improperly inflated can
cause a crash in which you can
be seriously hurt or killed.
Follow all instructions in this
owner’s manual regarding tire
inflation and maintenance.
01/09/28 20:06:49 31SZ3660_256

Use a gauge to measure the air
pressure at least once a month. Even
tires that are in good condition may
lose one to two psi (10 to 20 kPa, 0.1
to 0.2 kgf /cm ) per month.
Remember to check the spare tire at
thesametimeyoucheckallthe
other tires.The following chart shows the
recommended cold tire pressures f or
most normal driving conditions and
speeds. Tire pressures f or high
speed driving are the same as f or
normal driving.
These pressures are also given on
thetireinformationlabelonthe
driver’s doorjamb. Thecompactsparetirepressureis:
If you check the pressure when the
tires are hot (the car has been driven
several miles), you will see readings
4 to 6 psi (30 to 40 kPa, 0.3 to 0.4
kgf /cm ) higher than the cold
reading. This is normal. Do not let
air out to match the specified cold
pressure. The tire will be
underinf lated.
Youshouldgetyourowntire
pressure gauge and use it whenever
you check your tire pressures. This
will make it easier f or you to tell if a
pressure loss is due to a tire problem
and not due to a variation between
gauges.
Check the pressure in the tires when
they are cold. This means the car
has been parked f or at least three
hours. If you have to drive the car
bef ore checking the tire pressure,
the tires can still be considered
‘‘cold’’ if you drive less than 1 mile
(1.6 km).
Tire Size Cold Tire Pressure
for Normal Driving
Front/Rear:
Recommended T ire Pressures f orNormal Driving
Tires
Maint enance254
60 psi (420 kPa , 4.2 kgf/cm)
30 psi (210 kPa , 2.1
kgf/cm
)
P225/55R16 94V
01/09/28 20:07:02 31SZ3660_257

Tubeless tires have some ability to
self -seal if they are punctured.
However, because leakage is of ten
very slow, you should look closely
for punctures if a tire starts losing
pressure.Every time you check inf lation, you
should also examine the tires f or
damage, f oreign objects, and wear.
Youshouldlookfor:
Bumps or bulges in the tread or
side of the tire. Replace the tire if
youfindeitherof theseconditions.
Cuts, splits, or cracks in the side
of the tire. Replace the tire if you
can see f abric or cord.
Excessive tread wear. Your car’s tires have wear indicators
molded into the tread. When the
tread wears down to that point, you
will see a 1/2 inch (12.7 mm) wide
band running across the tread. This
shows there is less than 1/16 inch
(1.6 mm) of tread lef t on the tire. A
tire that is this worn gives very little
traction on wet roads. You should
replace the tire if you can see the
tread wear indicator in three or more
places around the tire.
Inspection
Tires
Maint enance255
I IN
ND DI
ICCA A T
TO
OR R L
LOOC CAA T
TI
IOON N M
MA
AR
RKKSS
T
T R
RE EA
A D
D W
WE EA
A R
R I
INND DI
ICCA A T
TO
OR RSS
01/09/28 20:07:12 31SZ3660_258

In addition to proper inf lation,
correct wheel alignment helps to
decrease tire wear. If you f ind a tire
is worn unevenly, have your dealer
check the wheel alignment.
The tires were properly balanced by
the factory. They may need to be
rebalanced at some time bef ore they
are worn out. Have your dealer
check the tires if you f eel a consis-
tent vibration while driving. A tire
should always be rebalanced if it is
removed f rom the wheel f or repair. To help increase tire lif e anddistribute wear more evenly, you
should have the tires rotated every
7,500 miles (12,000 km). Move the
tires to the positions shown in the
chart each time they are rotated.
Make sure the installer balances the
wheels when you have new tires
installed. This increases riding
comf ort and tire lif e. Your car’s
original tires were dynamic or ‘‘spin’’
balanced at the f actory. For best
results, have the installer perf orm a
dynamic balance.
Maintenance T ire Rotation
Tires
Maint enance256
( (
F
Fo o r
r N
No on
n-
-d
d i
irre ec cttiioo n
na
all
T
T i
irre es s a
ann d
d W
Wh he
eeellss) ) (
(
F
Fo o r
r D
D i
irre ec cttiioo n
na
all
T
T i
irre es s a
ann d
d W
Wh he
eeellss) )
F
Fr
roo n
nt
t F
Frroo n
nt
tImproper wheel weights can damage
your vehicle’s aluminum wheels. Use
only Genuine Acura wheel weights f or
balancing.
01/09/28 20:07:23 31SZ3660_259

When shopping f or replacement
tires, you may find that some tires
are ‘‘directional.’’ This means they
are designed to rotate only in one
direction. If you use directional tires,
they should be rotated only front-to-
back.The tires that came with your car
were selected to match the perform-
ance capabilities of the car while
providing the best combination of
handling, ride comf ort, and long lif e.
Youshouldreplacethemwithradial
tires of the same size, load range,
speed rating, and maximum cold tire
pressure rating (as shown on the
tire’s sidewall). Mixing radial and
bias-ply tires on your car can reduce
its braking ability, traction, and
steering accuracy. It is best to replace all f our tires at
thesametime.If thatisnotpossible
or necessary, then replace the two
f ront tires or the two rear tires as a
pair. Replacing just one tire can
seriously af f ect your car’s handling.
CONT INUED
Replacing T ires and Wheels
Tires
Maint enance257
Installing improper tires on your
car can affect handling and
stability. This can cause a crash
in which you can be seriously
hurt or killed.
Always use the size and type of
tires recommended in this
owner’s manual.
01/09/28 20:07:29 31SZ3660_260

´
Tires that are marked ‘‘M S’’ or
‘‘All Season’’ on the sidewall have an
all-weather tread design. They
should be suitable f or most winter
driving conditions. Tires without
these markings are designed f or
optimum traction in dry conditions.
They may not provide adequate
perf ormance in winter driving.
For the best perf ormance in snowy
or icy conditions, you should install
snow tires or tire chains. They may
be required by local laws under
certain conditions.
Wheels:
Tires:
See page f or inf ormation about
DOT Tire Quality Grading.
If you ever need to replace a wheel,
make sure you use an identical style
aluminum alloy wheel that originally
came on your Acura. Replacement
wheels are available at your Acura
dealer. The ABS and VSA system work by
comparing the speed of the wheels.
When replacing tires, use the same
size originally supplied with the car.
Tire size and construction can af f ect
wheel speed and may cause the
system to work inconsistently.314 Winter Driving
Wheels and T ires
Tires
Maint enance258
16x7JJ
P225/55R16 94V
01/09/28 20:07:38 31SZ3660_261
