Acura RL 2002 3.5 Owner's Manual
Manufacturer: ACURA, Model Year: 2002, Model line: RL, Model: Acura RL 2002Pages: 343, PDF Size: 4.66 MB
Page 271 of 343
Pull the bulb straight out of its
socket. Push the new bulb in until
it bottoms in the socket.
Put the lens back on the bulb
holder and push it until it latches.
Slide the right side of the light
assembly into the hole. Push on
theleftsidetolatchtheassembly
into place. Turn on the parking lights and
check that the new bulb is
working.
Remove the license light assembly
by caref ully prying on the lef t
edge of the lens with a f lat-tip
screwdriver and pulling the
assembly out. Remove the lens f rom the bulb
holder by pulling the lens while
squeezing the tabs on both sides
of the holder.
1. 2. 3.
5. 4.
6.
Replacing a Rear License Plate
Bulb
Lights
Maint enance268
L LI
IGGH HT
T A
AS
SSSEEM
M B
BLLYY
B
BUUL LBB H
HO
OL LDD E
ER
R
B
BU UL LBB
L
LEE N
NS S
01/09/28 20:09:17 31SZ3660_271
Page 272 of 343
Removethelensbycarefully
prying on the edge of the lens with
a f ingernail f ile or a small f lat-tip
screwdriver. Do not pry on the
edge of the housing around the
lens.Door light:
Pry on the top middle of the lens.
Front ceiling light: Pry on the f ront edge of the lens
in the middle. Rear ceiling light:
Pryontherearedgeof thelens
in the middle. Remove the bulb
cover by pulling it straight down.
The courtesy lights in the doors and
roof come apart the same way. They
do not use the same type of bulb.
Vanity mirror light:Pry on the top middle of the lens.
1.
CONT INUED
Replacing Bulbs in the Interior
Courtesy Lights
Maint enance
Lights
269
D D
O
OO ORR L
LIIGGH HT
T F
FRRO ON NTT R
REEA
A R
R
01/09/28 20:09:30 31SZ3660_272
Page 273 of 343
Removethelensbycarefully
prying on the edge of the lens in
the middle with a f ingernail f ile or
a small f lat-tip screwdriver. Do not
pry on the edge of the housing
around the lens.Remove the bulb by pulling it
straight out of its metal tabs.
Push the new bulb into the metal
tabs. Snap the lens back in place.
Push the new bulb into the metal
tabs. Snap the lens back in place. Remove the bulb by pulling it
straight out of its metal tabs. 1. 2.
3.
2.
3. Replacing the T runk L ight Bulb
Maint enance
Lights
270
T T
R
RU UN NKK
V
V A
AN
NI ITT Y
Y M
M I
IRRR ROOR R L
LIIGGH HT
T
01/09/28 20:09:39 31SZ3660_273
Page 274 of 343
Block the rear wheels.
Fill the f uel tank.
Change the engine oil and f ilter
(see page ).
Wash and dry the exterior
completely.
Cleantheinterior.Makesurethe
carpeting, floor mats, etc. are
completely dry.
Leave the parking brake off. Put
the transmission in Park.
If you need to park your car f or an
extended period (more than one
month), there are several things you
should do to prepare it f or storage.
Proper preparation helps prevent
deterioration and makes it easier to
get your car back on the road. If
possible, store your car indoors.
If the car is to be stored for a
longer period, it should be
supported on jackstands so the
tires are of f the ground.
Leave one window open slightly (if
the car is being stored indoors).Coverthecarwitha‘‘breathable’’
cover, one made f rom a porous
material such as cotton.
Nonporous materials, such as
plastic sheeting, trap moisture,
which can damage the paint.
Disconnect the battery.
Support the f ront wiper blade
arms with a f olded towel or rag so
they do not touch the windshield.
To minimize sticking, apply a
silicone spray lubricant to all door
and trunk seals. Also, apply a
vehiclebodywaxtothepainted
surfaces that mate with the door
and trunk seals. If possible, run the engine f or a
while periodically (pref erably once
amonth).
If you store your car f or 12 months
or longer, have your Acura dealer
perf orm the inspections called f or in
the 24 months/30,000 miles (48,000
km) maintenance schedule (Normal
Conditions) as soon as you take it
out of storage (see page ). The
replacements called f or in the
maintenance schedule are not
needed unless the car has actually
reached that time or mileage.
229
218
Maint enance
St oring Your Car
271
01/09/28 20:09:53 31SZ3660_274
Page 275 of 343
272
01/09/28 20:09:55 31SZ3660_275
Page 276 of 343
Regular cleaning and polishing of
your Acura helps to keep it ‘‘new’’
looking. This section gives you hints
on how to clean your car and
preserve its appearance: the paint,
brightwork, wheels and interior. Also
included are several things you can
do to help prevent corrosion..................................
Exterior Care .274
.....................................
Washing .274
.......................................
Waxing .275
....................
Aluminum Wheels .275
..........................
Paint Touch-up .275
..................................
Interior Care .276
...................................
Carpeting .276
.................................
Floor Mats .276
.........................................
Fabric .277
...........................................
Vinyl .277
.......................................
Leather .277
...................................
Seat Belts .277
................................
Wood Trim .278
....................................
Windows .278
..........................
Air Fresheners .278
....................
Corrosion Protection .279
.................................
Body Repairs .280
Appearance Care
Appearance Care273
01/09/28 20:10:00 31SZ3660_276
Page 277 of 343
When you have washed and rinsed
the whole exterior, dry it with a
chamois or sof t towel. Letting it
air-dry will cause dulling and water
spots.
Fill a bucket with cool water. Mix
in a mild detergent, such as
dishwashing liquid or a product
made especially f or car washing.
Only use the solvents and cleaners
recommendedinthisOwner’s
Manual. Wash your car in a shady area, not in
direct sunlight. If the car is parked in
the sun, move it into the shade and
let the exterior cool down bef ore you
start. Wash the car using the water and
detergent solution and a sof t-
bristle brush, sponge, or sof t cloth.
Start at the top and work your way
down. Rinse f requently.
Frequent washing helps preserve
your car’s beauty. Dirt and grit can
scratch the paint, while tree sap and
bird droppings can permanently ruin
the f inish.
Rinse the car thoroughly with cool
water to remove loose dirt.
As you dry the car, inspect it f or
chips and scratches that could allow
corrosion to start. Repair them with
touch-up paint (see page ).
Check the body f or road tar, tree
sap, etc. Remove these stains with
tar remover or turpentine. Rinse it
of f immediately so it does not
harm the f inish. Remember to re-
wax these areas, even if the rest of
the car does not need waxing. 275
Exterior Care
Appearance Care
Washing
274
Chemical solvents and strong cleaners
can damage the paint, metal, and
plastic on your car.
01/09/28 20:10:11 31SZ3660_277
Page 278 of 343
µµ
You should use a quality liquid or
paste wax. Apply it according to the
instructions on the container. In
general, there are two types of
products:
Waxes A wax coats the finish and
protects it f rom damage by exposure
to sunlight, air pollution, etc. You
should use a wax on your Acura
when it is new.
Polishes Polishes and cleaner/
waxes can restore the shine to paint
that has oxidized and lost some of its
shine. They normally contain mild
abrasives and solvents that remove
the top layer of the f inish. You should use a polish on your Acura if
the f inish does not have its original
shine af ter using a wax.
Clean your Acura’s aluminum alloy
wheels as you do the rest of the
exterior.Washthemwiththesame
solution, and rinse them thoroughly.
The wheels have a protective clear-
coat that keeps the aluminum from
corroding and tarnishing. Using
harsh chemicals, including some
commercial wheel cleaners, or stif f
brushes can damage this clear-coat.
Only use a mild detergent and sof t
brush or sponge to clean the wheels.
Your dealer has touch-up paint to
match your vehicle’s color. The color
code is printed on a sticker on the
driver’s doorjamb. Take this code to
your dealer so you are sure to get
the correct color.
Always wash and dry the whole car
bef ore waxing it. You should wax
your car, including the metal trim,
whenever water sits on the surf ace
in large patches. It should f orm into
beads or droplets af ter waxing.
Cleaning tar, insects, etc. with
removers also takes off the wax.
Remember to re-wax those areas,
even if the rest of the car does not
need waxing. Inspect your car f requently f or chips
or scratches in the paint. Repair
them right away to prevent corrosion
of the metal underneath. Use the
touch-up paint only on small chips
and scratches. More extensive paint
damage should be repaired by a
prof essional.
Exterior Care
Appearance Care
Waxing
A luminum WheelsPaint T ouch-up
275
01/09/28 20:10:23 31SZ3660_278
Page 279 of 343
Vacuum the carpeting f requently to
remove dirt. Ground-in dirt will make
the carpet wear out f aster.
Periodically shampoo the carpet to
keep it looking new. Use one of the
foam-type carpet cleaners on the
market. Follow the instructions that
come with the cleaner, applying it
with a sponge or sof t brush. Keep
the carpeting as dry as possible by
not adding water to the f oam.If you remove the f loor mat, make
sure to re-anchor it when you put it
back in your car.
If you replace it, use a genuine Acura
floormatthatisdesignedtobeused
with the f loor mat anchor in your car.
If you use a non-Acura f loor mat in
the driver’s f ootwell, make sure it
f its properly and that it can be used
with the floor mat anchor.
Do not put additional f loor mats on
top of the anchored mat, otherwise
the additional mats may slide
f orward and interf ere with the pedals.
The genuine Acura driver’s f loor mat
that came with your car was
designed to be hooked over the f loor
mat anchor. This keeps the f loor mat
f rom sliding f orward and possibly
interf ering with the pedals.
Carpeting Floor Mats
Appearance Care
Interior Care
276
01/09/28 20:10:32 31SZ3660_279
Page 280 of 343
Remove dirt and dust with a vacuum
cleaner. Wipe the vinyl with a sof t
cloth dampened in a solution of mild
soap and water. Use the same
solution with a soft-bristle brush on
more dif f icult spots. You can also use
commercially-available spray or
f oam-type vinyl cleaners.
Vacuum dirt and dust f rom the
leather f requently. Pay particular
attention to the pleats and seams.
Clean the leather with a sof t cloth
dampened with clear water, then
buf f it with a clean, dry cloth. If
f urther cleaning is needed, use a
soap specif ically f or leather, such as
saddle soap. Apply this soap with a
damp,softcloth.Wipedownand
buf f as described above.If your seat belts get dirty, you can
use a sof t brush with a mixture of
mild soap and warm water to clean
them. Do not use bleach, dye, or
cleaning solvents. They can weaken
the belt material. Let the belts air-
drybeforeyouusethecar.
Vacuum dirt and dust out of the
material f requently. For general
cleaning, use a solution of mild soap
and lukewarm water, letting it air dry.
To clean of f stubborn spots, use a
commercially-available f abric cleaner.
Test it on a hidden area of the f abric
first, to make sure it does not bleach
or stain the f abric. Follow the
instructions that come with the
cleaner.
CONT INUED
Vinyl
Leather
Seat Belts
Fabric
Interior Care
Appearance Care277
L LO OO OPP
01/09/28 20:10:43 31SZ3660_280
