µ To set your AcuraLink pref erences
(thetypesof messagesyouwantto
receive, if any), visit the Owner Link
website at
www.owners.acura.com,
and choose what you would like to
receive. If you do not have internet
access, call Acura Client Services at
(800) 382-2238; they can set your
message pref erences f or you.
Select this button to
delete the current message.
Select this button to hear a
voice read the entire message. This
gives you more inf ormation than the
screen can display at one time. When
you select the Voice button, it
changes to a Stop Reading button.
Select the button again to stop the
voice.
Select this button to call a
phone number embedded in the
message. When you select , the
HandsFreeLink (HFL) dials the
number f or you.
To make a call, your Bluetooth
compatible phone must be paired to
your vehicle’s HandsFreeLink (see
page ).
Select this button to f ind the nearest
Acura dealer using the navigation
system. Select
this button to call the Acura dealer
you purchased your vehicle f rom.
AcuraLink also directs you to this
dealer so you can schedule a
maintenance appointment or receive
inf ormation about a message. If you
visit another dealer f or service two
times within a 14-month period,
AcuraLink will reset to call that
dealer.
Select this button to
get more inf ormation about the
current diagnostic message. To use
this option, your cell phone must be
linked to the HFL and have a
compatible data service available.
Access the Owner Link website to
f ind out which data services are
currently compatible with AcuraLink.
278
AcuraLink
Message Pref erences
Delete
Voice
Call
Call
Find Nearest Acura Dealer Call Your A cura Dealer
More Inf o
Features
259

µ
µ
µ
µ Select
this button to begin the process
required to connect to Acura. This is
used to access the most recent
diagnostic inf ormation when a
problem occurs. Select ON to have
the system automatically read each
message to you. Select OFF to
manually select the Voice button
when you want a message read to
you.
To access the f ollowing f unctions,
press the SETUP button, push the
interf ace dial to the right to select
MORE, then rotate the interf ace dial
to select AcuraLink/Messages.
Select this
button to delete all stored messages
within a category, except f or
diagnostic info and recall campaign
messages. These messages can only
be deleted by a certif ied technician
af ter the recall or problem is done or
corrected, or through a broadcast
message f rom Acura.
Select ON if you want to be notif ied
of new messages (envelope icon
appears on the navigation screen).
Select OFF if you do not want to be
notif ied of new messages (envelope
icon does not appear on the
navigation screen). For the Phone Data
Connection button to be active, you
need a Bluetooth compatible and
enabled cell phone paired to the
HandsFreeLink (HFL), and a
compatible data service (see on page ).283
AcuraLink
AcuraL ink/Message Screen
Phone-Data Connection Auto Reading
Delete Messages
New Message Notif ication
Pairing
Your Phone
260
NOTE:

During the f irst 90 days of
ownership, one of 32 dif f erent
messages appears each day. These
messages help you to use and
understand the technological
f eatures of your vehicle.
These messages, based on updated
vehicle inf ormation and comments
f rom other RL owners, supplement
your Owner’s Manual and Quick
Start Guide. They provide you with
relevant information for a safe and
enjoyable ownership experience. For
additional inf ormation, call Acura
Client Services directly through the
HFL.
There are six message categories in
AcuraLink: Quick Tips, Feature
Guides, Maintenance Minders,
Recalls/Campaigns, Diagnostic Inf o,
and Dealer Appointment Reminders.
The system can store up to 256
messages.
Message categories can be added,
revised, or deleted through
broadcast messages f rom Acura.
AcuraLink
Feature Guide
Quick T ips
Message Categories
Features
261

If your vehicle is af f ected by a recall
or other important saf ety
inf ormation, a letter will be mailed to
you about the issue and how to f ix it.
If you don’t get your vehicle f ixed,
you will also receive a reminder
message through AcuraLink. You
can then use the message options to
call your dealer f or an appointment
or to f ind the nearest dealer.
You can then use the message
options to call your dealer f or an
appointment or to f ind the nearest
dealer.
These messages provide detailed
inf ormation about the service
needed f or your vehicle. When a
maintenance message appears on
the multi-information display, a list of
needed maintenance items also
appearsinanAcuraLinkmessage.
These messages tell you the exact
maintenance needed, helping you to
avoid unnecessary maintenance
costs.
AcuraLink
Recall/Campaigns
Maintenance Minder
262

When you make an appointment
through the Owner’s Link Online
Scheduling Service, you can be
reminded about that appointment
through the AcuraLink two days in
advance. If you need to reschedule,
you can call your dealer directly with
the HFL.
The timing of your reminder is
based on your reminder pref erence
established on Owner Link.
When you select the More Inf o
option, if the HFL is connected to a
cellular data service, AcuraLink
gathers more inf ormation about the
problem, and sends it to Acura.
There, the inf ormation is analyzed
and returned to the vehicle with the
most accurate repair inf ormation.
AcuraLink
Dealer A ppointment Reminder
264

U.S. models only
The OnStarsystem in your vehicle
gives you access to a wide range of
services and information with the
touch of a button. An OnStar advisor
is available 24 hours a day, 7 days a
week.
The Saf e and Sound Plan provides
these f eatures: Roadside Assistance
Emergency Services
Automatic Notif ication of Airbag
Deployment
Accident Assistance
Remote Door Locking/Unlocking
Stolen Vehicle Tracking
Misplaced Vehicle Assistance
Online Concierge Services The Directions and Connections
Plan provides these additional
f eatures:
Route Support
Ride Assist
Inf ormation and Convenience
Services
The OnStar buttons and indicator
are located on the ceiling near the
f ront ceiling light.
OnStar
OnStar Control Panel
Features
265
VOICE
ACTIVATED
KEY PAD
BUTTON
SYSTEM
STATUS
INDICATOR
EMERGENCY
BUTTON
OnStar SERVICES
BUTTON
CALL ANSWER/
CALL END
(WHITE PHONE)
BUTTON

To record a message:
A microphone is located in the base
of the OnStar control panel so you
can speak to the advisor without
taking your hands of f the steering
wheel or diverting your attention
from the road. The OnStar advisor’s
voice comes f rom the audio system’s
speakers. Use the volume control on
the audio system or on the steering
wheel to adjust the volume.
Depending on which service you
request, you may need to give your
Personal Identification Number
(PIN) to the advisor. Your PIN is a
number you make up and provide
when you establish your OnStar
service.
If cellular telephone service is not
available in the area you are driving
in, you will hear a f ast busy signal.
The system will retry the connection
several times bef ore returning to the
ready mode. Press this button to contact an
OnStar advisor. You will hear a
chime, f ollowed by the
announcement, ‘‘Connecting to
OnStar.’’ The connection should take
about 15 seconds. The advisor will
assist you with any of the services
included in your plan. To cancel the retry, press the white
phone button.
During your call to the advisor or
virtual advisor, press and release
the OnStar button. The system
beeps to indicate that it is
recording.
When you are f inished recording,
press and release the OnStar
button again. The system beeps
and stops recording.
When you are f inished listening,
press the white phone button. The
system responds with ‘‘Goodbye.’’ Say ‘‘Advisor playback.’’ The
recorded message is played
through the audio system
speakers. Press the white phone button. The
system responds with ‘‘OnStar
ready.’’
To hear the first playback of a
message:
You can record up to 5 minutes of
inf ormation f rom your OnStar
Advisororthevirtualadvisor.Thisis
helpf ul f or reviewing the route, hotel,
or restaurant information you
receive f rom the OnStar center.
OnStar
OnStar Services Button
Recording an A dvisor or Virtual
Advisor Message
266

Press this button to send dial tones
while communicating with an
automated phone system during an
OnStar personal call (see page ).
The advisor will ask about the nature
of the emergency, locate your
vehicle, and notif y the appropriate
emergency service agencies.
If you press this button accidentally,
do not cancel the call. Wait until the
OnStar advisor answers, then explain
your mistake.
Say ‘‘Advisor playback.’’ The
system responds with ‘‘Play or
Resume.’’
If you say ‘‘Play,’’ the message
plays f rom the beginning. If you
say ‘‘Resume,’’ the message plays
f rom the point you previously
stopped it.
To hear a message again:
Press this button to contact an
OnStar advisor only if you have an
emergency situation. You will hear a
tone, f ollowed by the announcement,
‘‘Connecting to OnStar Emergency.’’
Your call is given highest priority. Press the white phone button. The
system responds with ‘‘OnStar
ready.’’
Recording a new message will delete
the previous message. Press this white phone button to end
a call to the OnStar advisor. If the
OnStar center calls you, press this
button to answer the call.
This button is also used to initiate
the Personal Calling and Virtual
Advisor services, if you have
subscribed. 270
OnStar
Emergency Button Voice A ctivated K eypad
Button
Call A nswer/Call End
Button
Features
267

µ
µ
µ
µ
µ
µ
µ µ
If you are ever in an
accident that causes the airbags to
deploy, the OnStar system
automatically places a call (provided
the OnStar system and your vehicle’s
electrical system are still intact). The
advisor will attempt to speak to you
to evaluate the situation, and contact
the nearest emergency services
provider.
The OnStar system uses the global
positioning system (GPS) to locate
your vehicle whenever you place a
call. This allows the advisor to
quickly contact the nearest services
without requiring you to provide
detailed directions.
Contact
the OnStar advisor if you need
assistance with a problem (f lat tire,
out of f uel, etc.) while traveling. The
advisor will contact an appropriate
agency to come and assist you.
Contact an
OnStar advisor if you have an
emergency situation. The advisor
will contact the nearest emergency
services provider (ambulance, f ire
department, etc.) and advise them of
your situation.
This indicator shows you the status
of the system.
The system is ready
for use.
Acallisin
progress.
There is a problem
with the system. Press the OnStar
button to contact an advisor. If the
call connects, the advisor will assist
you with verif ying the system’s
operation. If you are not able to
contact an advisor, take your vehicle
to an Acura dealer to have the
system diagnosed.
There is a problem
with the system while a call is in
progress. The
OnStar advisor can help you if you
are ever in a minor accident by
asking you f or inf ormation about the
accident. Complete, detailed
inf ormation will make it easier to
complete accident reports and
insurance claims.
OnStar
A utomatic Notif ication of A irbag
Deployment
Saf e and Sound Plan Features
Roadside Assistance
Emergency Services
System Status Indicator
Solid Green
Blinking Green
Solid Red
Blinking Red
Accident Assistance
268

µ
µ
µ
µ
µ
µ
µThe OnStar
advisor can give you verbal
directions f rom your current location
to a desired destination.
If you need a ride
(taxi, limousine service, etc.) the
OnStar advisor can make the
arrangements f or you. Use the
OnStar button, or call
(888) 4-ONSTAR.
If you are unable to locate your
vehicleinalargeparkinglotor
parking structure, contact OnStar at
(888) 4-ONSTAR. The advisor will
remotely activate the exterior lights
and the horn, allowing you to locate
your vehicle.
From your computer, you can log
into www. myonstar.com to make
dinner reservations, purchase tickets
to events, send f lowers, etc.
Using
GPS, OnStar can locate your vehicle
almost anywhere. If your vehicle is
ever stolen, contact OnStar at
(888) 4-ONSTAR. The advisor will
put you in contact with the proper
authorities, and assist them with
locating your vehicle. By sending a signal to your
vehicle, the advisor can lock or
unlock your vehicle’s doors. This is
helpfulif youareawayfromyour
vehicle and realize you f orgot to lock
the doors, or if you have locked the
remote or built-in key in your vehicle.
To get OnStar’s assistance, call
(888) 4-ONSTAR (466-7827). The Directions and Connections
Plan provides these additional
f eatures:
The OnStar advisor can
give you inf ormation on nearby
hotels, restaurants, ATMs, hospitals,
gas stations, and many other
services in any area you are traveling.
The advisor can also help you with
hotel or restaurant reservations.
OnStar
Directions and Connections Plan
Features
Route Support
Ride Assist
Misplaced Vehicle Assistance
Online Concierge Services
Stolen Vehicle T racking Remote Door L ocking/Unlocking
Inf ormation and Convenience
Services
Features
269
