When a problem is detected with
your vehicle, a message will be
shown on the multi-inf ormation
display.
If this happens, refer to the
applicable pages of this owner’s
manual, and f ollow the instructions.
When there are several messages to
be shown, the system switches the
messages every 5 seconds.
The message is shown until you
push the INFO button.
To see the message again, press the
INFO button, 5 seconds af ter the
display disappears.
Here is a list of messages shown on
the multi-information display:See page
63,411
See page 411
See page 62,409
See page 62,410
See page 62,409
See page 312
See page 408 See page
65,339
See page 69,139
See page 68
See page 67, 320
See page 34, 63
See page
312
See page
64,323
Multi-Inf ormation Display
Message Display
78

CONT INUED
See page13
See page
35,63
See page 170
See page 171
See page 368 See page
250
See page 62
See page 298
See page 66
See page 349 See page
335
See page 337
See page 67,337
See page 394
See page 394
See page 394
See page 147
See page
138
See page 172 See page
325
See page 69,325
Multi-Inf ormation Display
Inst rument s and Cont rols
79
U.S.
Canada

See page147
Multi-Inf ormation Display
80

ÛÝÛÝ
With the multi-information display
and the INFO ( / ) and SEL/
RESET buttons on the right side of
the steering wheel, you can
customize some vehicle control
settings f or ‘‘DRIVER 1’’ or
‘‘DRIVER 2’’. If ‘‘DRIVER 1’’ or
‘‘DRIVER 2’’ is not displayed,
customizing is not possible.
To have the driver’s ID detected,
make sure your remote is linked to
the system (see
on page ). Then use your
remote to unlock the doors (see on page
). To enter the customizing mode,
press and hold the INFO ( / )
button for more than 3 seconds while
the multi-information display is in its
normal mode.
If you turn the ignition switch to the
ACCESSORY (I) or the LOCK (0)
position, or move the shif t lever out
of Park, the display will change to
the normal screen.
When the multi-information
display does not show the driver’s
ID. The f irst customizing menu is:
CHG SETTING (see page )
If you disconnect the battery, and
then do not unlock the door. When the keyless memory
settings are of f (see page ). DEFAULT ALL (see page )
You cannot customize the settings
under these conditions:
To change the settings, the ignition
switch must be in the ON (II)
position, and the vehicle must be
stopped with the transmission in
Park. 82
84
166
100
105
CONT INUED
Customized Settings
Memory Position
Link
K eyless A ccess Setup
Multi-Inf ormation Display
Inst rument s and Cont rols
81

ÛÝÛÝ
UsetheINFO( / )buttononthe
steering wheel to select the settings
and the SEL/RESET button to enter
your selections. If you want the settings as they were
when the vehicle lef t the f actory,
select DEFAULT ALL, as described
on this page.
If you want to set the def ault setting,
press the INFO ( / ) button to
select DEFAULT ALL, then press
the SEL/RESET button.If you want to cancel DEFAULT
ALL, select CANCEL, then press the
SEL/RESET button. The screen
goes back to CUSTOMIZE ENTRY.
If you want to change any vehicle
control settings, select ‘‘CHG
SETTING,’’ then press the SEL/
RESET button.
Multi-Inf ormation Display
DEFAUL T AL L
82

To set the def ault settings again,
select DEFAULT ALL, and press the
SEL/RESET button. Then select
SET, and press the SEL/RESET
button.When DEFAULT ALL is set, you will
see the above display for several
seconds, then the screen returns to
CUSTOMIZE ENTRY.
If DEFAULT ALL is not set, you will
see the above display for several
seconds, then the screen goes back
to the normal message mode. Repeat
theproceduretoselectDEFAULT
ALL.
Multi-Inf ormation Display
Inst rument s and Cont rols
83

Û
Ý
ÛÝ
You can customize some of the
vehicle control settings to your
pref erence. Here are the settings
you can customize:
While the multi-information display
is in the CUSTOMIZE ENTRY
screen, press the SEL/RESET
button. The screen changes to the
initial CUSTOMIZE GROUP display.
METER SET UP ADAPTIVE CRUISE CONTROL
SETUP
Each time you press the INFO ( /) button, the screen changes as
shownonthenextpage.Pressthe
INFO ( / ) button, until you see
the setup you want to customize,
then press the SEL/RESET button
to enter your selection.
POSITION SET UP
LIGHTING SET UP
DOOR/WINDOW SET UP
WIPER SET UP
Multi-Inf ormation Display
Customize Settings
84

ÛÝ
Multi-Inf ormation Display
Inst rument s and Cont rols
85
Press the or button.
Press the SEL/RESET button.ADAPTIVE CRUISE
CONTROL SET UP
seepage86
METER SET
UP
seepage91
POSITION
SET UP
see page100
KEYLESS
ACCESS SET UP
see page105
LIGHTING
SET UP
see page112
DOOR/WINDOW
SET UP
see page119
WIPER SET
UP
see page130

ÛÝÛ
Ý
ÛÝ
ÛÝ
If equipped
Here are the two custom settings for
adaptive cruise control (ACC):PRE-RUNNING CAR DETECT
BEEP
ACC DISPLAY SPEED UNIT
While the multi-information display
is in the CUSTOMIZE GROUP
screen, select ACC SETUP by
pressing the INFO ( / ) button,
then press the SEL/RESET button.
Each time you press the INFO ( / ) button, the display changes as
shown in the illustration. Press the
INFO ( / ) button until you see
the setting you want to customize,
then press the SEL/RESET button
to enter your selection.
Multi-Inf ormation Display
A daptive Cruise Control Setup
86
Press the or button.
Press the SEL/RESET button. seepage87
seepage89

ÛÝ
While the multi-information display
is in the ACC SETUP of the
CUSTOMIZE GROUP, press the
SEL/RESET button. The screen
changes to the above display. Press the SEL/RESET button. The
screen changes as shown above.
Select ON or OFF by pressing the
INFO ( / ) button, then press the
SEL/RESET button to enter your
selection.
When PRE-RUNNING CAR
DETECT BEEP is set to ON, one
beep sounds when the ACC detects a
vehicle in f ront of you. You also hear
a beep when that vehicle goes out of
the range of your vehicle’s radar
sensor.
CONT INUED
Multi-Inf ormation Display
Pre-Running Car Det ect Beep
Inst rument s and Cont rols
87
