ignition Acura RL 2006 Service Manual

The engine may not run, and some
malf unctions may occur, if the
remote is:The engine may not start if the
remote is subjected to strong radio
waves.
Also, the engine may not start if the
remote is too close to the windows.
Outside the vehicle.
On the dashboard.
On the rear interior panel.
In the glove box.
In the door pockets.
In the trunk, etc.
K eyless A ccess System
Ignition Switch Operating Range
168
Make sure you know where the remote
is when you are inside the vehicle.
Remember that you can start the engine
without using the built-in key when the
remote is inside the vehicle.
Make sure you always carry the remote
with you.
If you lose your remote, call Acura
Client Services at (800) 382-2238 (U.S.
models).

When you push the ignition switch,
theremoteandthevehiclerecognize
each other. Af ter the recognition,
the remote indicator f lashes, and a
beeper sounds once. Af ter the beep,
turn the ignition switch.
When the remote is out of the
operating range, the ignition switch
is locked.
If the ignition switch cannot be
turned f rom the LOCK (0) position
to the ACCESSORY (I) position afterthe beep, the steering wheel is
locked. To unlock the steering wheel,
turn it right and lef t while turning
the ignition switch at the same time.
If theremoteandthevehicledonot
recognize each other, turn the
ignition switch to the LOCK (0)
position, remove the ignition switch
cover, insert the built-in key, and
turn the switch (see pages and
). Bef ore leaving the vehicle, make
sure the ignition switch is in the
LOCK (0) position.
You will also see a ‘‘RETURN
IGNITION SWITCH TO LOCK (0)
POSITION’’ message on the multi-
inf ormation display. To turn the ignition switch to the
LOCK (0) position, put the
transmission in Park, press the
switch in, and turn it to the LOCK
(0) position. When the transmission
is not in Park, you cannot turn the
ignition switch to the LOCK (0)
position.
If you open the driver’s door with the
ignition switch in the ACCESSORY
(I) position, a beeper will sound.
147
170
CONT INUED
Ignition Switch
K eyless A ccess System
Inst rument s and Cont rols
169

When you are pressing the ignition
switch, or when the ignition switch is
in the ON (II) position, the beeper
sounds if you take the remote out of
the vehicle and close the door.
To remove the ignition switch cover,
insert the built-in key (see page ),
then pull the cover out by pulling the
built-in key while pushing it.
Also, if you close the door when the
ignition switch is not in the LOCK
(0) position and the remote is not
inside the vehicle, the keyless access
alarm sounds outside the vehicle, a
message appears on the multi-
inf ormation display, and the beeper
sounds if the ignition switch is in the
ON (II) position.
When the beeper sounds af ter you
close the driver’s door outside the
vehicle, check the position of the
ignition switch and the location of
the remote.
If the engine is running and you
removetheremotefromthevehicle,
it will continue to run. But once
turned to the LOCK (0) position, the
engine will not restart until a remote
is brought back into the vehicle.
173
K eyless A ccess System
Beeper and Message
Removing the Ignition Switch
Cover
K eyless Remot e Not Det ect ed
170
BUILT-IN KEY
IGNITION SWITCH COVER
pushpull

Thebatteriesintheremotenormally
lasts about 2 years. To ensure
maximum battery life, do not store
the remote close to electrical devices
such as computers or TVs. When the
multi-inf ormation display shows
‘‘KEYLESS REMOTE LOW
BATTERY,’’ replace the batteries as
soon as possible (see page ).
The engine does not restart if you
turn the ignition switch to the LOCK
(0) position when the remote is
outside the vehicle. Check where the
remote is. Make sure that you carry
the remote or built-in key with you
when you operate the ignition switch.
When the ignition switch is in the
ON (II) position, the multi-
inf ormation display shows
‘‘KEYLESS REMOTE NOT
DETECTED,’’ and the inside and
outside beepers sound.
The multi-inf ormation display
message goes away when you
bring the remote back inside the
vehicle, and close the door or
apply the parking brake. The outside beeper sounds when
the ignition switch is in the
ACCESSORY (I) or the ON (II)
position.
If the engine is running and you
removetheremotefromthe
vehicle, it will continue to run.
Once turned to the LOCK (0)
position, the engine will not restart
until a remote is brought back into
the vehicle. If you pass the remote through an
open window, the system does not
respond.Also,evenwhentheremote
is inside the vehicle, the beeper may
sound when the location of the
remote is not detected due to
surrounding conditions. It is not a
f ailure. Make sure that you carry the
remote with you.
167
CONT INUED
K eyless A ccess System
K eyless Remot e L ow Bat t ery
Inst rument s and Cont rols
171

The indicator stays on while you
are driving.
The indicator comes on with the
ignition switch in the ON (II)
position.
The indicator comes on f or several
seconds when you turn the ignition
switch to the ON (II) position. Have
your vehicle checked by your dealer
if : The multi-inf ormation display
shows ‘‘CHECK KEYLESS
ACCESS SYSTEM.’’
In this case, use the built-in key to
lock/unlock the doors and start the
engine.
If you lose or drop your remote, and
the beeper sounds, contact Acura
Client Services at (800) 382-2238
(U.S. models)
K eyless A ccess System
Check K eyless A ccess Syst em
172
KEYLESS ACCESS SYSTEM
INDICATOR

In HI, the heater turns of f when the
seat gets warm, and turns back on
after the seat temperature drops.
In LO, the heater runs continuously.
It does not cycle with temperature
changes.
Follow these precautions whenever
you use the seat heaters:Use the HI setting only to heat the
seats quickly, because it draws
large amounts of current f rom the
battery.
Both f ront seats are equipped with
seat heaters. The passenger seat
only has heaters in the seat bottom
because of the side airbag system.
The ignition switch must be in the
ON (II) position to use the heaters.
Push the top of the switch, HI, to
rapidly heat up the seat. Af ter the
seat reaches a comfortable
temperature, select LO by pushing
the bottom of the switch. This will
keep the seat warm. If the engine is lef t idling f or an
extended period, do not use the
seat heaters, even on the LO
setting. It can weaken the battery,
causing hard starting.
Seat Heaters (U.S. models)
174
SEAT HEATER SWITCHES

ÛÝÛ
Û
µ
µ
µ µ
µ
µ
µ µ
Û
Ý Ý ÝÛ
ÝTo use the heaters, press the
button. The indicator next to the
button will come on. There are three
settings in the heaters:
Both f ront seats are equipped with
seat heaters and an air ventilation
system. The passenger seat only has
heaters in the seat bottom because
of thesideairbagsystem.The
ignition switch must be in the ON
(II) position to use the heaters and
the air ventilation system. In LOW, the heater runs
continuously.
When you press the button once,
the system is set to HI. To change to
the lower mode, press the button.
To turn the air ventilation off, press
the button until the indicators go
of f . HI Three indicators on.
MID Two indicators on.
LO One indicator on.
OFF All indicators of f .
HI Three indicators on.
MID Two indicators on.
LO One indicator on.
OFF All indicators of f .
When you press the button once,
the heater is set to HI. Af ter the seat
reaches a comf ortable temperature,
select MID or LOW by pressing the
button. This will keep the seat
warm. To shut down the heater,
press the button until the
indicators go of f .
In HI, when the seat gets warm, the
heater will change to MID af ter
about 5 minutes.
In MID, the heater will change to
LOW af ter about 60 minutes. To ventilate the seat, press the
button. The indicator next to the
button will come on. The air
ventilation system has four settings:
CONT INUED
Seat Heaters and Seat Ventilation (Canadian models)
Inst rument s and Cont rols
175
BUTTON
BUTTON
INDICATORS

If the MAIN switch is pushed down
(OFF), the passenger windows
cannot be raised or lowered. Keep
the MAIN switch off when you have
children in the vehicle so they do not
injure themselves by operating the
windows unintentionally.
Turn the ignition switch to the ON
(II) position bef ore operating any of
the window switches. To open a
window, push the switch down and
hold it. To close the window, pull the
switchupandholdit.Releasethe
switch to stop the window.
CONT INUED
Power Windows
Inst rument s and Cont rols
177
DRIVER’S WINDOW SWITCH
MAIN SWITCH
Closing a power window on
someone’s hands or fingers can
cause serious injury.
Make sure your passengers are
away from the windows before
closing them.

µAuto reverse stops sensing when the
window is almost closed. You should
always check that all passengers and
objects are away from the window
bef ore closing it.
To open the window f ully,
push the window switch firmly down
to the second detent, then release it.
The window automatically goes
down all the way. To stop the
window f rom going all the way down,
pull back on the window switch
brief ly.
To close the window f ully, pull back
the window switch firmly to the
second detent, then release it. The
window automatically goes all the
way up. To stop the window f rom
going all the way up, push down on
the window switch briefly. To open or close the window
partially, push down or pull back on
the window switch lightly to the first
detent, and hold it. The window will
stop when you release the switch.
All window switches also have the
AUTO feature.
If the window runs into any obstacle
while it is closing automatically, it
will reverse direction, and then stop.
To close the window, remove the
obstacle, then use the window switch
again.The indicators in the switches come
on when you turn the ignition switch
to the ON (II) position.
The power windows have a key-of f
delay. You can still open and close
the windows f or up to 10 minutes
after you turn off the ignition switch.
The key-of f delay cancels as soon as
you open either f ront door. You must
then turn the ignition switch to the
ON (II) position f or the power
windows to operate.
Auto Reverse
AUTO
Power Windows
178

To close:Insert the built-in key in the driver’s
door lock.
NOTE: If the windows and moonroof
stop bef ore the desired position,
repeat steps 2 and 3. To close the windows and
moonroof f urther, turn and hold
the key again (within 15 seconds). Turn the key counterclockwise
again, and hold it. All four
windows and the moonroof start to
close. To stop the windows and
moonroof , release the key. Turn the key counterclockwise,
then release it.
Turn the ignition switch to the ON
(II) position bef ore operating the
moonroof switch on the ceiling
console. To open the moonroof , pull
back the moonroof switch. To close
the moonroof , push the moonroof
switch f orward. Release the switch
to stop the moonroof .
To open the moonroof f ully, pull
back the moonroof switch f irmly.
The moonroof opens all the way. To
stop the moonroof f rom opening
f ully, push the switch brief ly.
1.
2.
3.
4.
Power Windows, Moonroof
Opening/Closing the Moonroof
with the Ceiling Console Switch
180
MOONROOF SWITCH
