display Acura RL 2007 Owner's Manual

The set speed can be decreased
using the SET/DECEL button or the
brake pedal.
To decrease the set speed with the
SET/DECEL button, do this:
Press and hold the SET/DECEL
button. Release the button when you
reach the speed you want.
To slow down in small amounts, tap
the SET/DECEL button repeatedly.Each time you do this, your vehicle
slows down about 1 mph (1 km/h).
When the system detects a vehicle
ahead of you, a beeper sounds once
and a solid-line vehicle icon appears
on the multi-information display.
The set cruising speed will be shown
on the multi-information display.
On a steep downhill, the vehicle
speed may exceed the set cruising
speed.
To decrease the set speed with the
brake pedal, do this:
Tap the brake pedal. When the
vehicle slows down to the speed you
want, press the SET/DECEL button.
The set speed will be shown on the
multi-inf ormation display. If you use
the brake pedal to decrease speed,
andthenpresstheRES/ACCEL
button, your vehicle will return to the
previously set speed.
Decreasing the Set Speed
Detecting a Vehicle A head of You
A daptive Cruise Control (A CC)
286
SET/DECEL BUTTONU.S.
CANADA
——
y
y
(y
y

With ACC on, the distance between
your vehicle and the vehic le ahead of
you is controlled and maintained.
You can change this distance to one
of three ranges: long, middle, or
short. To
change the range, press the
DISTANCE button. Each time you
press the button, the range changes
from Long, to Middle, and then to
Short.
The higher your vehicle speed is, the
longer the distan ce between the
vehicle in front will be set as shown
below.
When that vehicle changes lanes or
goes out of ACC range, a beeper
sounds once. If there is no vehicle
ahead of you within ACC range, a
dotted-line vehicle icon will be on the
multi-inf ormation display.
To set the ACC beeper on or of f , see
page . 90
CONT INUED
Speed
Vehicle
Distance Long
Middle Short 50 mph
(80 Km/h)
154 feet
47 meters 111 feet
34 meters 85 feet
26 meters 65 mph
(104 Km/h)
200 feet
61 meters 173 feet
42 meters 101 feet
31 meters
Changing Vehicle Distance
A daptive Cruise Control (A CC)
Features
287
DISTANCE BUTTON
U.S.
CANADA
——
y

y
(yy

Press the ACC button. The ACC
indicator in the instrument panel
goes off. Tap the brake pedal. Push the CANCEL button on the
steering wheel.If you cancel ACC by pressing the
ACC button, the previously set
cruising speed is erased f rom
memory.
The distance you select is also
shown on the multi-inf ormation
display.
ACC is canceled whenever you do
any of these actions:When you push the CANCEL button
or tap the brake pedal to cancel ACC,
the set cruising speed stays in
memory. When you turn on ACC
again, the speed is shown on the
multi-inf ormation display. To return
to that speed, accelerate to over 25
mph (40 km/h), then press the RES/
ACCEL button.
Canceling the A CC
A daptive Cruise Control (A CC)
288
LONG
RANGE
MIDDLE
RANGE
SHORT
RANGE CANCEL BUTTON
U.S.
CANADA
U.S. CANADA
U.S.
CANADA
——
y
y
(yy

This indicator normally comes on for
a few seconds when you turn the
ignition switch to the ON (II)
position. If it comes on at any other
time, there is a problem in the ACC
system. If this happens, take the
vehicle to your dealer to have it
checked.
The ACC system cannot be used
while this indicator is on.
When
ACC is automatically
cancelled, the beeper sounds three
times, and an ACC OFF message
appears on the multi-info rmation
display for 3 seconds.
Any of these conditions may cause
ACC to cancel:
The vehic le speed decreases
below22mph(35km/h). Driving
on a mountainous road, or
driving off road for extended
periods.
When the VSA indicator comes on.
When
the ABS or VSA is activated.
Abrupt
steering wheel movement.
If ACC is cancelled by any these
conditions, wait until the condition
improves, then press the RES/
ACCEL button to restore ACC.
When you do this, the vehicle will
resume its set cruising speed.
If you turn the ignition switch to the
ACCESSORY (I) or LOCK (0)
position af ter ACC was automatically
cancelled, the set speed is erased,
and you must enter it again (see
page ).
Poor weather (rain, f og, snow, etc.)
When the radar sensor in the front
grille gets dirty.
The vehicle ahead of you cannot
be detected.
An abnormal tire condition is
detected, or the tires are skidding.
283
Automatic ACC Cancellation
ACC Indicator
A daptive Cruise Control (A CC)
Features
289
ACC INDICATOR
——
y
y
(yy

The multi-inf ormation display shows
various messages related to ACC.
For a description of each ACC
message you may see, ref er to the
chart on this and the f ollowing page.
MessageDescription
ACC is on.
ACC is on and in standby mode.
A cruising speed can be set by
pressing the SET/DECEL button.
ACC is in standby mode, and the
previously set cruising speed is in
memory.
The previously set speed can be
resumed by pressing the RES/
ACCEL button.
Messages on the
Multi-Inf ormation Display
A daptive Cruise Control (A CC)
290
U.S.
CANADA
——
y
y
(yy

To switch f rom ACC to cruise
control, press the distance button on
the steering wheel, and hold it f or 1
second.Always be aware which mode is
selected. When the cruise control is selected,
ACC does not sound a beeper or
display a message on the multi-
inf ormation display. Make sure to
keepasafedistancefromthevehicle
ahead of you.
When you press the button, you will
see CRUISE MODE SELECTED on
the multi-information display for 2
seconds.ToswitchbacktoACC,
press and hold the distance button
again for 1 second.
Switching to Cruise Control
A daptive Cruise Control (A CC)
292
DISTANCE BUTTON
Press the distance button.
——
y
y
(yy

Most AcuraLink f unctions are
controlled by the interf ace dial. The
interface dial has two parts, a knob
and a selector.
The knob turns lef t and right. Use it
to make selections or adjustments to
a list or menu on the screen.The selector can be pushed lef t,
right, up, down, and in. Use the
selector to scroll through lists, to
select menus, and to highlight menu
items. When you make a selection,
push the center of the selector
(ENTER)togotothatselection.
AcuraLink enhances your ownership
experience by providing a direct
communication link between your
vehicleandtheAcuraServer.
Working through the XM radio
satellite, AcuraLink works in
conjunction with the navigation
system, HandsFreeLink (HFL), and
audio system in your vehicle. It
displays and receives several kinds
of messages, including:
Operating tips and inf ormation on
your vehicle’s f eatures.
Important recall and safety
inf ormation.
Maintenance inf ormation to keep
your vehicle in top condition.
Diagnostic inf ormation to provide
inf ormation about any problems
with your vehicle.
RL Technology Package and RL CMBS/PAX modelsInterf ace Dial
AcuraLink
Features
297
ENTER
SELECTOR
KNOB
——
y
y
(yy

µ
µ
µ
µ µ
µ To
set your AcuraLink preferences
(thetypesofmessagesyouwantto
receive, if any), visit the Owner Link
website at
www.owners.acura.com,
and choose what you would like to
receive. If you do not have internet
access, call Acura Client Services at
(800) 382-2238; they can set your
message preferences for you.
Select
this button to
delete the current message.
Select this button to hear a
voice read the entire message. This
gives you more information than the
screen can display at one time. When
you select the Voice button, it
changes to a Stop Reading button.
Select the button again to stop the
voice.
Select this button to call a
phone number embedded in the
message. When you select , the
HandsFreeLink (HFL) dials the
number for you.
To make a call, your Bluetooth
compatible phone must be pai red to
your vehicle’s HandsFreeLink
system, have its power on, and be
inside the vehicle (see page ).
Select this button to f ind the nearest
Acura dealer using the navigation system.
Select
this button to call the Acura dealer
you purchased your vehicle f rom.
AcuraLink also directs you to this
dealer so you can schedule a
maintenance appointment or receive
inf ormation about a message. If your
assigned servicing dealer changes,
AcuraLink will be updated to call
that dealer.
Select this button to
get more inf ormation about the
current diagnostic message. To use
this option, your cell phone must be
paired to the HFL. In addition, the
paired phone must have a compatible
data service and be set up with the
AcuraLink system to make a data
connection. Access the
handsf reelink.com website to f ind
out which data services are currently
compatible with AcuraLink.
306 Message Pref erences
Delete
Voice
Call
Call
Find Nearest Acura Dealer Call Your A cura Dealer
More Inf o
AcuraLink
300
——
y

y
(yy

These messages provide detailed
inf ormation about the service
needed f or your vehicle. When a
maintenance message appears on
the multi-information display, a list of
needed maintenance items is
provided through in an AcuraLink
message. These messages tell you
the exact maintenance needed,
helping you to avoid unnecessary
maintenance costs.
These messages, based on updated
vehicle inf ormation and comments
f rom other RL owners, supplement
your Owner’s Manual and Quick
Start Guide. They provide you with
relevant information for a safe and
enjoyable ownership experience. For
additional inf ormation, call Acura
Client Services directly through the
HFL.
During the f irst 90 days of
ownership, one of up to 32 dif f erent
messages appears each day. These
messages help you to use and
understand the technological
f eatures of your vehicle.
CONT INUED
AcuraLink
Maintenance Minder
Quick T ips Feature Guide
Features
303
——
y
y
(yy

When an indicator comes on or a
message is displayed on the multi-
inform ation display (MID),
AcuraLink can provide information
about the cause of indicator or
message and the recommended
action to take. This helps you handle
the problem as it occurs, preventing
or limiting costly repairs.
The AcuraLink system cannot
determinesomemechanical
problems (such as squeaks or
rattles) that are not triggered by the
diagnostic indicator monitors.
If
your vehicle is affected by a recall
or other important safety
info rmation, a letter will be mailed to
you about the issue and how to fix it.
If you don’t get your vehicle fixed,
you will also receive a reminder
message through AcuraLink. You
can then use the message options to
call your dealer for an appointment
or to find the nearest dealer.
You
can then use the message
options to call your dealer for an
appointment or to f ind the nearest
dealer.
For more inf ormation on the
instrument panel indicators, see page.
61
AcuraLink
Diagnostic Inf o
Recall/Campaigns
304
——
y
y
(yy
