When you push the ignition switch,
theremoteandthevehiclerecognize
each other. After the recognition,
the remote indicator flashes, and a
beeper sounds once. After the beep,
turn the ignition switch.
When the remote is out of the
operating range, the ignition switch
is locked.
If the ignition switch cannot be
turned from the LOCK (0) position
to the ACCESSORY (I) position afterthe
beep, the steering wheel is
locked. To unlock the steering wheel,
turn it right and left while turning
the ignition switch at the same time.
Iftheremoteandthevehicledonot
recognize each other, turn the
ignition switch to the LOCK (0)
position, remove the ignition switch
co ver, insert the built-in key, and
turn the switch (see pages and
). Before leaving the vehicle, make
sure the ignition switch is in the
LOCK (0) position.
You will also see a ‘‘RETURN
IGNITION SWITCH TO LOCK (0)
POSITION’’ message on the multi-
inf ormation display. To turn the ignition switch to the
LOCK (0) position, put the
transmission in Park, press the
switch in, and turn it to the LOCK
(0) position. When the transmission
is not in Park, you cannot turn the
ignition switch to the LOCK (0)
position.
If you open the driver’s door with the
ignition switch in the ACCESSORY
(I) position, a beeper will sound.
151
174
CONT INUED
Ignition Switch
K eyless A ccess System
Inst rument s and Cont rols
173
——
y

y
(y
y

When you are pressing the ignition
switch, or when the ignition switch is
in the ON (II) position, the beeper
sounds if you take the remote out of
the vehicle and close the door.
To
remove the ignition switch cover,
insert the built-in key (see page ),
then pull the cover out by pulling the
built-in key while pushing it.
Also, if you close the door when the
ignition switch is not in the LOCK
(0) position and the remote is not
inside the vehicle, the keyless access
alarm sounds outside the vehicle, a
message appears on the multi-
inf ormation display, and the beeper
sounds if the ignition switch is in the
ON (II) position.
When the beeper sounds af ter you
close the driver’s door outside the
vehicle, check the position of the
ignition switch and the location of
the remote.
If the engine is running and you
removetheremotefromthevehicle,
it will continue to run. But once
turned to the LOCK (0) position, the
engine will not restart until a remote
is brought back into the vehicle.
177
K eyless A ccess System
Beeper and Message
Removing the Ignition Switch
Cover
K eyless Remot e Not Det ect ed
174
BUILT-IN KEY
IGNITION SWITCH COVER
pushpull
——
y


y
(y
y

Thebatteriesintheremotenormally
lasts about 2 years. To ensure
maximum battery life, do not store
the remote close to electrical devices
such as computers or TVs. When the
multi-info rmation display shows
‘‘KEYLESS REMOTE LOW
BATTERY,’’ replace the batteries as
soon as possible (see page ).
The engine does not restart if you
turn the ignition switch to the LOCK
(0) position when the remote is
outside the vehicle. Check where the
remote is. Make sure that you carry
the remote or built-in key with you
when you operate the ignition switch.
When the ignition switch is in the
ON (II) position, the multi-
inf ormation display shows
‘‘KEYLESS REMOTE NOT
DETECTED,’’ and the inside and
outside beepers sound.
The multi-inf ormation display
message goes away when you
bring the remote back inside the
vehicle, and close the door or
apply the parking brake. The outside beeper sounds when
the ignition switch is in the
ACCESSORY (I) or the ON (II)
position.
If the engine is running and you
removetheremotefromthe
vehicle, it will continue to run.
Once turned to the LOCK (0)
position, the engine will not restart
until a remote is brought back into
the vehicle. If you pass the remote through an
open window, the system does not
respond.Also,evenwhentheremote
is inside the vehicle, the beeper may
sound when the location of the
remote is not detected due to
surrounding conditions. It is not a
f ailure. Make sure that you carry the
remote with you.
171
CONT INUED
K eyless A ccess System
K eyless Remot e L ow Bat t ery
Inst rument s and Cont rols
175
——
y


y
(y
y

The indicator stays on while you
are driving.
The indicator comes on with the
ignition switch in the ON (II)
position.
The indicator comes on f or several
seconds when you turn the ignition
switch to the ON (II) position. Have
your vehicle checked by your dealer
if : The multi-inf ormation display
shows ‘‘CHECK KEYLESS
ACCESS SYSTEM.’’
In this case, use the built-in key to
lock/unlock the doors and start the
engine.
K eyless A ccess System
Check K eyless A ccess Syst em
176
KEYLESS ACCESS SYSTEM
INDICATOR
——
y

y
(y

y

Thebuilt-inkeycanbeinsertedinto
the remote.
As shown above, keep inserting the
built-in key until it is locked. To
remove the built-in key, pull it out
while you press the release button.
To avoid damaging the remote and
the built-in key, never pull on the
built-in key unless you are pressing
the release button.The trunk and glove box cannot be
opened when you turn the trunk
main switch of f and lock the glove
box and trunk pass-through cover
with the built-in key. Also, the trunk
cannot be opened by using the
remote.
The keyless access system uses
electric current to identify the
remote with the vehicle.
If you use medical equipment such
as a cardiac pacemaker, ask your
doctor if the electric current used by
the remote will af f ect it.
K eyless A ccess System
Valet Function
Built-in key and Remote
Inst rument s and Cont rols
177
RELEASE BUTTON BUILT-IN KEY
——
y


y
(y
y

µAuto reverse stops sensing when the
window is almost closed. You should
always check that all passengers and
objects are away from the window
bef ore closing it.
To open the window f ully,
push the window switch firmly down
to the second detent, then release it.
The window automatically goes
down all the way. To stop the
window f rom going all the way down,
pull back on the window switch
brief ly.
To close the window f ully, pull back
the window switch firmly to the
second detent, then release it. The
window automatically goes all the
way up. To stop the window f rom
going all the way up, push down on
the window switch briefly. To open or close the window
partially, push down or pull back on
the window switch lightly to the first
detent, and hold it. The window will
stop when you release the switch.
All window switches also have the
AUTO feature.
If the window runs into any obstacle
while it is closing automatically, it
will reverse direction, and then stop.
To close the window, remove the
obstacle, then use the window switch
again.The indicators in the switches come
on when you turn the ignition switch
to the ON (II) position.
The power windows have a key-of f
delay. You can still open and close
the windows f or up to 10 minutes
after you turn off the ignition switch.
The key-of f delay cancels as soon as
you open either f ront door. You must
then turn the ignition switch to the
ON (II) position f or the power
windows to operate.
Auto Reverse
AUTO
Power Windows
182
——
y
y
(y
y

You can open all of the windows and
the moonroof f rom outside with the
remote.Press the UNLOCK button once
to unlock the driver’s door.
To open the windows and
moonroof f urther, press the
button again and hold it. If the
windows and the moonroof stop
bef ore the desired position, repeat
steps 1 and 2.
You cannot close the windows or the
moonroof with the remote. You can open and close the windows
and moonroof with the built-in key in
the driver’s door lock.
Insert the built-in key in the driver’s
door lock.
To open: Turn the key clockwise, then
release it.
Turn the built-in key clockwise
again, and hold it. All four
windows and the moonroof start to
open. To stop the windows and
moonroof , release the built-in key.
Press the UNLOCK button a
second time, and hold it. All the
doors unlock, and all f our windows
and moonroof start to open. To
stop the windows and moonroof ,
release the button. When the windows or moonroof
stops bef ore opening f ully, to open
the windows and moonroof f urther,
turnandholdthekeyagain
(within 10 seconds).
1.
2.
3.
1.2.
3.
4.
CONT INUED
Opening the Windows and
Moonroof with the Remote
Opening/Closing the Windows
and Moonroof with the Built-in
Key
Power Windows, Moonroof
Inst rument s and Cont rols
183
Open
Close
UNLOCK BUTTON
——
y

y
(y
y

To close:Insert the built-in key in the driver’s
door lock.
NOTE: If the windows and moonroof
stop bef ore the desired position,
repeat steps 2 and 3. Turn the key counterclockwise
again, and hold it. All four
windows and the moonroof start to
close. To stop the windows and
the moonroof , release the key. Turn the key counterclockwise,
then release it.
Turn the ignition switch to the ON
(II) position bef ore operating the
moonroof switch on the ceiling
console. To open the moonroof , pull
back the moonroof switch. To close
the moonroof , push the moonroof
switch f orward. Release the switch
to stop the moonroof .
To open the moonroof f ully, pull
back the moonroof switch f irmly.
The moonroof opens all the way. To
stop the moonroof f rom opening
f ully, push the switch brief ly.
To close the windows and
moonroof f urther, turn and hold
the key again (within 10 seconds).
1.
2.
3.
4.
Power Windows, Moonroof
Opening/Closing the Moonroof
with the Ceiling Console Switch
184
MOONROOF SWITCH
——
y
y
(y
y

You can use the remote transmitter
or the key to operate the moonroof
from the outside. Refer to page
f or details.
The moonroof has a key-of f delay.
You can still open and close the
moonroof f or up to 10 minutes af ter
you turn of f the ignition switch. The
key-of f delay cancels as soon as you
open either f ront door. You must
then turn the ignition switch to the
ON (II) position f or the moonroof to
operate.
If the moonroof runs into any
obstacle while it is closing
automatically, it will reverse
direction, and then stop. To close the
moonroof , remove the obstacle, then
use the moonroof switch again.
Auto reverse stops sensing when the
moonroof is almost closed. You
should always check that all
passengers and objects are away
f rom the moonroof bef ore closing it. 183
Moonroof
Operating the Moonroof with the
Remote Transmitter or the Key
Auto Reverse
186
If you try to open the moonroof in
below-f reezing temperatures, or when
it is covered with snow or ice, you can
damage the moonroof panel or its
motor.
——
y
y
(y

y

Your vehicle has an owner’s manual
tray inside the glove box. To open
the tray, push the release button up.
Open the glove box by pulling the
handle. Close it with a f irm push.
Lock or unlock the glove box with
the built-in key.
To close the tray, push it up.
The glove box light comes on only
when the parking lights are on.
Interior Convenience Items
Glove Box
Inst rument s and Cont rols
189
RELEASE BUTTON
An open glove box can cause
serious injury to your passenger
inacrash,evenifthe
passenger is wearing the seat
belt.
Always keep the glove box
closed while driving.
——
y
y
(y
y
