CONT INUED
Herearesomeguidelinesforusing
voice control:To enter a command, press the
Talk button. Then, af ter the beep,
say your command in a clear,
natural tone.
For best system operation, set the
climate control f an speed to low,
and direct the center vents away
f rom the microphone in the ceiling.
If the HFL does not recognize a
command, its response is, ‘‘Pardon.’’
If it doesn’t recognize the
command a second time, its
response is, ‘‘Please repeat.’’ If it
doesn’t recognize the command a
third time, it plays the Help
prompt.
TheHFLisoperatedbytheHFL
Talk and Back buttons on the left
side of the steering wheel. The next
f ew pages provide instructions f or all
basic f eatures of the HFL.
All phones may not
operate identically, and some may
cause inconsistent operation of the
HFL.
With the HFL system activated, you
will also see ‘‘HF LINK’’ on the upper
display.
When you are dialing or receiving
calls with the audio system in use,
you will see the HFL screen on the
navigation display.
HandsFreeL ink
Using Voice Control
How to Use the HFL
Features
309
NOTE:
TM
——
y
y
(y
y

The HFL system response
continues ‘‘A security option is
available to lock the hands f ree
system. Each time the vehicle is
turned on, a password would be
required to use this system. Would
you like this security option turned
on?’’
Press and release the Talk button.
If you say ‘‘No’’ af ter the beep, the
HFL system response is, ‘‘Security
willnotbeused.Thesystemsetup
is complete.’’
If you say ‘‘Yes,’’ you can set your
password. Ref er to the setting
procedure in the next column.
Press and release the Talk button.
If you say ‘‘Yes’’ af ter the beep, the
HFL system response is, ‘‘Would
you like the notification to be a
ring tone or a prompt?’’ If you say
‘‘No’’ af ter the beep, the HFL
system returns to its main menu.
Saying ‘‘No’’ will result in no ring
tone or prompt playback during an
incoming call. The audio system
will be mute, and a message will
be displayed.
Press and release the Talk button.
Af ter the beep, say ‘‘Ring tone’’ or
‘‘Prompt.’’ The HFL system
response is ‘‘A ring tone will be
used.’’ or ‘‘An incoming call
prompt will be used.’’
If you choose ‘‘Ring tone,’’ you will
hear a ring tone through the audio
speakers to announce an incoming
call. If you choose ‘‘Prompt,’’ you
will hear this message to
announce an incoming call: ‘‘You
have an incoming call.’’
Thevoiceof theHFLcanbesetto
male or f emale (U.S. models only).
Also, the incoming notif ication can
be set to a ring tone, a prompt, or no
notification.
Press and release the Talk button.
Af ter the beep, say ‘‘System.’’ The
HFL response is, ‘‘System options
are setup and clear.’’
Press and release the Talk button.
Af ter the beep, say ‘‘Setup.’’ The
HFL response is ‘‘Would you like
male or f emale prompts?’’
Press and release the Talk button.
Af ter the beep, say ‘‘Male’’ or
‘‘Female,’’ depending on the
system voice you want. The HFL
response is, ‘‘Male (Female)
prompts have been selected.
Would you like an audible
notif ication of an incoming call?’’ 4.
5.
6.
7.
1.
2.
3.
To set up the system, do this:
HandsFreeL ink
Setting Up the System
Features
311
TM
——
y
y
(y
y

Press and release the Talk button.
Af ter the beep, say ‘‘Call’’ or ‘‘Dial.’’
The HFL response is ‘‘Calling’’ or
‘‘Dialing.’’ Once connected, you
will hear the person you called
through the audio speakers. To
change the volume, use the audio
system volume knob.
You can make calls using any phone
number, or by using a name in the
HFL phonebook. You can also redial
the last number called. During a call,
theHFLallowsyoutotalkupto30
minutes af ter you remove the key
from the ignition switch.
With your phone on and the
ignition in the ACCESSORY (I) or
ON (II) position, press and release
the Talk button. After the beep,
say ‘‘Call’’ or ‘‘Dial.’’ The HFL
response is, ‘‘What name or
number would you like to call/
dial?’’
Press and release the Talk button.
Af ter the beep, say the number
you want to call. For example, say
‘‘123 456 7891.’’ The HFL response
is ‘‘123 456 7891. Say call, dial, or
continue to add numbers.’’ To end the call, press the Back
button.
With your phone on and the
ignition in the ACCESSORY (I) or
ON (II) position, press and release
the Talk button. After the beep,
say ‘‘Call’’ or ‘‘Dial.’’ The HFL
response is ‘‘What name or
number would you like to call/
dial?’’
Press and release the Talk button.
After the beep, say the name you
want to call. For example, say‘‘Eric.’’ The HFL response is
‘‘Would you like to call Eric?’’
Press and release the Talk button.
Af ter the beep, say ‘‘Yes.’’ The
HFL response is ‘‘Calling’’ or
‘‘Dialing.’’ Once connected, you
will hear the person you called
through the audio speakers. To
change the volume, use the audio
system volume knob.
To end the call, press the Back
button.
To redial the last number called by
the phone, press and release the
Talk button. After the beep, say
‘‘Redial.’’ The HFL response is,
‘‘Redialing.’’ Once connected, you
will hear the person you called
through the audio speakers. To
change the volume, use the audio
system volume knob.
1. 3.
3.
1.
2. 2. 4.4.
To make a call using a phone number,do this:
To make a call using a name in the HFLphonebook, do this:
Making a Call
HandsFreeL ink
Features
317
TM
——
y
y
(yy

If you receive a call when you are not
on the phone, the HFL interrupts the
audio system (if it is on), and plays
the incoming call notif ication, if
activated. To answer the call, press
the Talk button and begin speaking.
If you don’t want to answer the call,
press the Back button.
The HFL allows you to send
numbers or names during a call. This
is usef ul when you call a menu-
driven phone system. You can also
program account numbers into the
HFL phonebook for easy retrieval
during menu-driven calls.
Press and release the Talk button.
Af ter the beep, say ‘‘Send.’’ The
HFL response is, ‘‘What name or
number would you like to send?’’
Press and release the Talk button.
Af ter the beep, say the number
you want to send. For example,
say‘‘1,2,3.’’TheHFLresponseis
‘‘1, 2, 3. Say send, or continue to
add numbers.’’ Press and release the Talk button.
Af ter the beep, say ‘‘Send.’’ The
dial tones will be sent, and the call
will continue.
Press and release the Talk button.
Af ter the beep, say ‘‘Send.’’ The
HFL response is ‘‘What name or
number would you like to send?’’
Press and release the Talk button.
After the beep, say the name you
want to send. For example, say
‘‘Account number.’’ The HFL
response is ‘‘Would you like to
send account number?’’
Press and release the Talk button.
Af ter the beep, say ‘‘Send.’’ The
dial tones will be sent, and the call
will continue.
If your phone has Call Waiting, and
you receive a call when you are on
the phone, press and release the
Talk button to answer it. When you
do this, the original call is placed on
hold. To return to the original call,
press the Talk button again. If you
don’t want to answer the new call,
disregard it, and continue with your
original call. If you want to hang up
the original call and answer the new
call, press the Back button.
1.
2.
1.
2. 3.
3.
To send a number during a call, do this:
To send a name during a call, do this:
Receiving a Call
Sending Numbers or Names
During a Call
HandsFreeL ink
318
TM
——
y
y
(yy

During a call, you can transfer it
f rom the HFL to your phone, or f rom
your phone to the HFL.Press and release the Talk button.
Af ter the beep, say ‘‘Transf er.’’
The audio switches f rom the HFL
to the phone.
Press and release the Talk button.
Af ter the beep, say ‘‘Transf er.’’
The audio switches f rom your
phone to the HFL.
During a call, you can mute or
unmute your voice to the person you
are talking to. Press and release the Talk button.
Af ter the beep, say ‘‘Mute.’’ The
HFL response is, ‘‘Mute is active.’’
Press and release the Talk button.
Af ter the beep, say ‘‘Mute.’’ The
HFL response is, ‘‘Mute is
canceled.’’
The HFL phonebook can store up
to 50 names with their associated
numbers. These can be any types
of numbers. For example, you can
store a phone number and use it to
make a call, or you can store an
account number and use it during
a call to a menu-driven phone
system.
Press and release the Talk button.
Af ter the beep, say ‘‘Phonebook.’’
The HFL response is ‘‘Phonebook
options are store, edit, delete,
receive contact, and list.’’
Press and release the Talk button.
After the beep, say ‘‘Store.’’ The
HFL response is, ‘‘What name
would you like to store?’’
Press and release the Talk button.
After the beep, say the name you
would like to store. For example,
say ‘‘Eric’’ or say ‘‘account number.’’
The HFL response is ‘‘What is the
number f or Eric,’’ or ‘‘What is the
number f or account number?’’
Press and release the Talk button.
After the beep, say the number.
For example, say ‘‘123 456 7891.’’
The HFL response is ‘‘123 456
7891.’’
2.
3.
1. 1.
2.
4.
2. 1.
To transfer a call from the HFL to your
phone, do this:
To transfer a call from your phone to theHFL, do this: To mute your voice, do this:
To unmute your voice, do this: To add a name, do this:
CONT INUED
Transf erring a Call
Muting a CallSetting up the Phonebook
HandsFreeL ink
Features
319
TM
——
y


y
(yy

Press and release the Talk button.
After the beep, say ‘‘Clear.’’ The
HFL response is, ‘‘This process
will clear all paired phones, clear
all entries in the phonebook, and
clear the passcode. Is this what
you would like to do?’’
Press and release the Talk button.
Af ter the beep, say ‘‘Yes.’’ The
HFL response is ‘‘Preparing to
clear all paired phones, all
phonebook entries, and the
passcode. This may take up to 2
minutes to complete.’’ Press and
release the Talk button. After the
beep, say ‘‘OK’’ to proceed, or say
‘‘Go back’’ or ‘‘Cancel.’’
If you said ‘‘OK,’’ af ter a short
period of time, the HFL response
is, ‘‘System has been cleared.
Returning to the main menu.’’
Press and release the Talk button.
Af ter the beep, say ‘‘List.’’ The
HFL responds by listing the
names in the phonebook. When
the end of the list is reached, the
HFL response is, ‘‘The entire list
has been read. Returning to the
main menu.’’
Press and release the Talk button.
Af ter the beep, say ‘‘List.’’ The
HFL responds by listing the
names in the phonebook. When it
saysthenameyouwanttocall,for
example, Eric, press the Talk
button, and then say ‘‘Call.’’ The
HFL response is, ‘‘Would you like
to call Eric?’’ Press and release the Talk button.
Af ter the beep, say ‘‘Yes.’’ The
HFL response is ‘‘Calling.’’ Once
connected, you will hear the
person you called through the
audio speakers. To change the
volume, use the audio system
volume knob.
This operation clears the HFL of
your passcode, your paired phones,
andallnamesintheHFLphonebook.
Clearing is recommended bef ore you
sell your vehicle. Press and release the Talk button.
Af ter the beep, say ‘‘System.’’ The
HFL response is, ‘‘System options
are setup and clear.’’
Press and release the Talk button.
Af ter the beep, say ‘‘Phonebook.’’
The HFL response is ‘‘Phonebook
options are store, edit, delete,
receive contact, and list.’’
2. 3.
4.
1.
1.2.
3.
2.
To call a name f rom the phonebook list,
do this:
To clear the system, do this:Clearing the System
HandsFreeL ink
Features
321
TM
——
y

y
(yy

When properly installed, cellular
phones, alarms, two-way radios, and
low-powered audio systems should
not interfere with your vehicle’s
computer controlled systems, such
as your airbags and anti-lock brakes. Before
installing any accessory:
Make sure the accessory does not
obscure any lights, or interfere
with proper vehicle operation or
performance.
Modifying
your vehicle, or installing
some non-Acura accessories, can
make your vehicle unsafe. Before
you make any modifi cations or add
anyaccessories,besuretoreadthe
following information.
Your dealer has Acura accessories
that allow you to personalize your
vehicle. These accessories have
been designed and approved for your
vehicle, and are covered by warranty.
Before installing any electronic
accessory, have the installer
contact your dealer. If possible,
have your dealer inspect the final
installation. Be sure electronic accessories do
not overload electrical circuits
(see page ) or interf ere with
the proper operation of your
vehicle.
Do not install accessories on the
side pillars or across the rear
windows. In these areas,
accessories may interf ere with
proper operation of the side
curtain airbags.
Although non-Acura accessories may
f it on your vehicle, they may not
meet f actory specif ications, and
could adversely af f ect your vehicle’s
handling and stability.
447
A ccessories
A ccessories and Modif ications
Bef ore Driving
333
Improper accessories or
modifications can affect your
vehicle’s handling, stability, and
performance, and cause a
crash in which you can be hurt
or killed.
Follow all instructions in this
owner’s manual regarding
accessories and modifications.
——
y
y
(yy

If your vehicle’s battery is
disconnected or goes dead, all stored
driving positions will be lost. To
store the driving positions again, see
the sto ring procedure on p age .
The navigation system will also
disableitself.Thenexttimeyouturn
on the ignition switch, the system
will require you to enter a PIN
before it can be used. Refer to the
navigation system manual. Turn the knob of the battery cover
toUNLOCKasshowninthe
illustration.
If your ve
hicle’s battery is
disconnected or goes dead, the audio
system will disable itself. The next
timeyouturnontheradioyouwill
see ‘‘ ’’ in the frequency
display. Use the preset buttons to
enter the fi ve-digit code (see page
).
If your ve hicle’s battery is
disconnected or goes dead, the
power tilt and telescopic steering
wheel system will be disabled. The
system needs to be reset after
reconnecting the battery (see page ).
The c ompass System will also
disableitself.Thenexttimeyouturn
on the ignition switch, the system
will require you to enter a PIN
before it can be used. Enter the four-
digit anti-theft security code (see
page ). You will also need reset
the c lock according to the
instru ction of setting the clock (see
page ). 1.
160
239
147
272
257
On vehicles with navigation system
On vehicles without navigation system
Checking the Battery
Removing the Battery Cover
424
KNOB TABLOCK
UNLOCK
——
y

y
(yy

Ifthefuseforthedrivingposition
memory system is removed, all
stored driving positions will be lost.
To store the driving positions again,
see page .
If the navigation system fuse is
removed, the navigation system will
disableitself.Thenexttimeyouturn
on the ignition switch, the system
will require you to enter a PIN
before it can be used. Refer to the
navigation system manual.
If the compass system fuse is
removed, the compass system will
disableitself.Thenexttimeyouturn
on the ignition switch, the system
will require you to enter a PIN
before it can be used. Enter the four-
digit anti-th eft security code (see
page ). You will also need reset
the clock according to the
instruction of the clock setting (see page
).
If the radio fuse is removed, the
audio system will disable itself. The
next time you turn on the audio
system you will see ‘‘ ’’ in the
frequency display. Use the preset
buttons to enter the five-digit code
(see page ).
Ifthefuseforthepowertilt
telescopic steering is removed, the
system will be disabled. The system
needs to be reset after reinstalling
thefuse(seepage ).
160
257 239
148
272
On vehicles with navigation system
On vehicles without navigation system
Fuses
T aking Care of t he Unexpect ed
451
——
y


y
(yy

CONT INUED
BatteryCharging System ...........................
Indicator . 62, 443
............................
Jump Starting .437
..............................
Maintenance .423
..........................................
Cover .424
............................
Specif ications .461
..............................
Bef ore Driving .325..................................
Belts, Seat . 10, 21
.........................
Beverage Holders .190
..................................
Booster Seats .53
Brakes Anti-lock Brake System .....................................
(ABS) .353
.............
Break-in, New Linings . 326
...........................................
Fluid .402
.......................................
Parking .187
.................
System Indicator . 63, 445
........................
Wear Indicators .352
.............................
Braking System .352
.................
Break-in, New Vehicle . 326
Brightness Control, ...............................
Instruments .145
......................
Brights, Headlights .140
Bulb Replacement ..........................
Back-up Lights .410
.................................
Fog Lights .408
...............
Front Position Lights . 407
........
Front Side Marker Lights . 407
.................................
Headlights .404
............................
Specif ications .461
....................
Turn Signal Lights . 406
....................................
Accessories .333
ACCESSORY (Ignition Switch .....................................
Position) .151
............
Accessory Power Sockets . 192
......................................
AcuraLink .297
Adaptive Cruise Control (ACC) .....................................
Indicator .278
...................................
Operation .280
Adaptive Front Lighting System ..........................................
(AFS) .143
....................
Additives, Engine Oil . 395
.............................
Airbag (SRS) . 11, 27
............................
Air Conditioning .198
.......................
Air Pressure, Tires .417
.......................
Alcohol in Gasoline .326
......................................
Antif reeze .398
Anti-lock Brakes (ABS) ...............................
Indicator . 64, 353
...................................
Operation .353
..............
Anti-thef t, Audio System . 239
Anti-thef t Steering Column ............................................
Lock .151
.........................................
Ashtrays .193
................................
Audio System .207 Auto Control Mode, Starting
........................................
Engine .341
..........
Automatic Climate Control . 205
.......................
Automatic Lighting .141
...
Automatic Seat Belt Tensioners . 23
.............
Automatic Speed Control . 275
..............
Automatic Transmission . 343
..........................
Capacity,Fluid .460
...............
Checking Fluid Level . 400
.......................................
Shif ting .343
Shif t Lever Position ...............................
Indicators .343
................
Shif t Lever Positions . 343
....................
Shif t Lock Release . 348
......................
Auxiliary Input Jack .236
Index
A
B
INDEX
I
——
y

y
(yy
