buttons Acura RL 2008 Owner's Guide

Make sure you have properly
completed the ‘‘Training
HomeLink’’ procedure.
Find the ‘‘learn’’ button on your
garage door opener unit. The
location will vary, depending on
the manufacturer.
Pressthelearnbuttononthe
garage door opener unit until the
indicator next to the button comes
on. The indicator may blink, or
comeonandstayon.Youthenhave approximately 30 seconds to
complete the following steps.
Press and hold the button on
HomeLink f or 3 to 4 seconds.
Press the HomeLink button again
f or about 1 second. It should
operate the garage door.
Repeat these steps to train the
other two HomeLink buttons to
operate any other compatible
remotely controlled devices
around your home (lighting,
automatic gate, security system,
etc.).
The ‘‘Training HomeLink’’
procedure trains HomeLink to the
proper garage door opener code.
The f ollowing procedure
synchronizes HomeLink to the
garage door opener so it sends and
receives the correct codes.
For security purposes, newer garage
door opening systems use a ‘‘rolling’’
or variable code. Information from
the remote control and the garage
door opener is needed bef ore
HomeLink can operate the garage
door opener. 2.
4.
5.
1.
3.
6.
HomeL inkUniversal Transceiver
T raining With a Rolling Code
System
Features
297
LEARN BUTTON
\f—\f—
y\f\fy
(\fy\f\fy
2008 RL

Youshoulderaseallthreecodes
bef ore selling the vehicle.
Toerasethecodesstoredinallthree
buttons, press and hold the two
outside buttons until the red
indicator begins to f lash, then
release the buttons.
If you want to retrain a programmed
button f or a new device, you do not
have to erase all button memory.
You can replace the existing memory
code using this procedure:If a standard transmitter was
programmed, the indicator will
stay on f or about 25 seconds.
HomeLink
is a registered
trademark of Johnson Controls, Inc.
If you have problems with training
the HomeLink Universal Transceiver,
or would like inf ormation on home
products that can be operated by
HomeLink, call (800) 355-3515. On
the Internet, go to
If a rolling code transmitter was
previously programmed, the
indicator will f lash rapidly f or 2
seconds, and then stay on f or
about 23 seconds.
Press and hold the HomeLink
button to be trained until the
HomeLink indicator begins to
flash slowly. Once the HomeLink indicator
begins to f lash slowly, continue to
hold the HomeLink button, and
f ollow steps 2 thru 5 under
‘‘Training HomeLink’’ (see page
).
1. 2.
295
As required by the FCC:This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.
www.home
link.com.Erasing Codes
Retraining a Button
Client Assistance
HomeL inkUniversal Transceiver
298
\f—\f—
y\f
\f
y
(\fy\f\fy
2008 RL

To operate the HFL, use the HFL
Talk and Back buttons on the left
side of the steering wheel. Below the
HFL buttons is another set of voice
control buttons f or the navigation,
climate control, and audio systems.
With a linked phone, the HFL allows
you to send and receive calls in your
vehicle without holding the phone.
The HFL can store up to 50 names
and phone numbers in its phonebook.
Withalinkedphone,youcanthen
automatically dial any name or
number in the phonebook.
Here are the main components of
the HFL system:
The HFL microphone is on the
ceiling console. The microphone is
shared with the navigation system (if
equipped). When the HFL is in use, the sound
comes through the vehicle’s f ront
audio system speakers. If the audio
system is in use while operating
either of the HFL buttons or making
a call, the HFL over-rides the audio
system. To change the volume level,
use the audio system volume knob,
or the steering wheel volume
controls.
CONT INUED
HFL Buttons
Audio System
Incoming/Outgoing Calls
Phonebook
Microphone
BluetoothHandsFreeL ink
Features
309
HFL TALK
BUTTON
HFL BACK
BUTTON
VOICE CONTROL
BUTTONS
\f—\f—
y\f\fy
(\fy\f
y
2008 RL

CONT INUED
Herearesomeguidelinesforusing
voice control:To enter a command, press the
Talk button. Then, af ter the beep,
say your command in a clear,
natural tone.
For best system operation, set the
climate control f an speed to low,
and direct the center vents away
f rom the microphone in the ceiling.
If the HFL does not recognize a
command, its response is, ‘‘Pardon.’’
If it doesn’t recognize the
command a second time, its
response is, ‘‘Please repeat.’’ If it
doesn’t recognize the command a
third time, it plays the Help
prompt.
TheHFLisoperatedbytheHFL
Talk and Back buttons on the left
side of the steering wheel. The next
f ew pages provide instructions f or all
basic f eatures of the HFL.
All phones may not
operate identically, and some may
cause inconsistent operation of the
HFL.
With the HFL system activated, you
will also see ‘‘HF LINK’’ on the upper
display.
When you are dialing or receiving
calls with the audio system in use,
you will see the HFL screen on the
navigation display. Using Voice Control
How to Use the HFL
BluetoothHandsFreeL ink
Features
311
NOTE:
\f—\f—
y\f\fy
(\fy\f
y
2008 RL

If your vehicle’s battery is
disconnected or goes dead, all stored
driving positions will be lost. To
store the driving positions again, see
the storing procedure on page .
The navigation system will also
disableitself.Thenexttimeyouturn
on the ignition switch, the system
will require you to enter a PIN
bef ore it can be used. Ref er to the
navigation system manual.Turn the knob of the battery cover
toUNLOCKasshowninthe
illustration.
If your vehicle’s battery is
disconnected or goes dead, the audio
system may disable itself . The next
timeyouturnontheradioyouwill
see ‘‘ ’’ in the f requency
display. Use the preset buttons to
enter the code (see page ).
The compass System will also
disableitself.Thenexttimeyouturn
on the ignition switch, the system
will require you to enter a PIN
bef ore it can be used. Enter the f our-
digit anti-thef t security code (see
page ). You will also need reset
the clock according to the
instruction of setting the clock (see
page ). If your vehicle’s battery is
disconnected or goes dead, the
power tilt and telescopic steering
wheel system will be disabled. The
system needs to be reset af ter
reconnecting the battery (see page
). 1.
160
259 274 241
148
On vehicles with navigation system
On vehicles without navigation system
Checking the Battery
Removing the Battery Cover
428
KNOB TABUNLOCK
LOCK
\f—\f—
y\fy
(\fy\fy
2008 RL

If thefuseforthedrivingposition
memory system is removed, all
stored driving positions will be lost.
To store the driving positions again,
see page .
If the navigation system f use is
removed, the navigation system will
disableitself.Thenexttimeyouturn
on the ignition switch, the system
will require you to enter a PIN
bef ore it can be used. Ref er to the
navigation system manual.
If the compass system f use is
removed, the compass system will
disableitself.Thenexttimeyouturn
on the ignition switch, the system
will require you to enter a PIN
bef ore it can be used. Enter the f our-
digit anti-thef t security code (see
page ). You will also need reset
the clock according to the
instruction of the clock setting (seepage ).
If the radio f use is removed, the
audio system will disable itself . The
next time you turn on the audio
system you will see ‘‘ ’’ in the
f requency display. Use the preset
buttons to enter the five-digit code
(see page ).
If thefuseforthepowertilt
telescopic steering is removed, the
system will be disabled. The system
needs to be reset af ter reinstalling
thefuse(seepage ).
160
148
259 274
241
On vehicles with navigation system
On vehicles without navigation system
Fuses
T aking Care of t he Unexpect ed
455
\f—\f—
y\f
y
(\fy\f\fy
2008 RL

CONT INUED
Steering Wheel Buttons/.....................................
Switches .136
...................
Stereo Sound System .207
....................
Storing Your Vehicle .429
......................................
Sun Visors .192
Supplemental Restraint
................................
System .11,26
......................................
Servicing .36
.........................
SRS Indicator .34,63
...................
System Components .26
..................................
Synthetic Oil .400
.
Taking Care of the Unexpected .431
Technical Descriptions
......
DOT Tire Quality Grading .466
.....
Emissions Control Systems .472
Three Way Catalytic
.............................
Converters .474
.......................
Temperature Gauge .70
........
Temperature, Inside Sensor .206
....................
Temperature, Outside .73
..............
Tether Anchorage Points .51
Three Way Catalytic
.................................
Converters .474 Tilt/Telescopic Steering
.........................................
Wheel .147
....................................
Timing Belt .407
....................................
Tire Chains .424
.........
Tire, How to Change a Flat .436
Tire Pressure Monitoring System
..........................
(TPMS) .372,470
Monitoring Tire Pressure
..................................
Reading .419
...........
TPMS System Warning .371
...............................................
Tires .419
..............................
Air Pressure .421
........................................
Chains .424
.........................
Checking Wear .421
..........................
Compact Spare .435
......
DOT Tire Quality Grading .466
......................................
Inf lation .419
..................................
Inspection .421
.............................
Labeling .468,469
Low Tire Pressure
...........................
Indicator .67,371
..............
Michelin PAX System .426
......................
Pressure Monitor .373
........
Pressure Monitor System .371
...................................
Replacing .423
......................................
Rotating .422 ...........................................
Snow .424
............................
Specif ications .465
...................
Tools, Tire Changing .436
Torque Distribution Monitor
.................................
(SH-AWD) .356
Towing .....................................
A Trailer .379
....
Equipment and Accessories .380
.............................
Weight Limit .379
TPMS (Tire Pressure Monitoring ..................................
System) .371
Required Federal ............................
Explanation .470
.....................
Warning Message .375
.............................
Trailer Loading .379
......................
Trailer Towing Tips .382
Transmission
Checking Fluid Level, ..............................
Automatic .404
...........................
Fluid Selection .405
..............
Identif ication Number .462
.............
Shif ting the Automatic .349
.............................
Treadwear .422,435
.......................................
Trip Meter .72
