AUTO DOOR LOCK
AUTO DOOR UNLOCK
There are five settings to choose
f rom in the door/window setup:
While CUSTOMIZE GROUP is
shown on the multi-inf ormation
display, select DOOR/WINDOW
SETUP by pressing the INFO ( /
) button, and then press the SEL/
RESET button.
Each time you press the INFO ( / ) button, the screen changes as
shown in the illustration. Press the
INFO ( / ) button, until you see
the setting you want to customize,
then press the SEL/RESET button
to enter your selection. SECURITY RELOCK TIMER
DOOR LOCK MODE
KEYLESS LOCK
ACKNOWLEDGMENT
Door/Window Setup
Multi-Inf ormation Display
122
seepage123
seepage125
seepage127
seepage129
see page131
Press the or button.
Press the SEL/RESET button.
2009 RL

ÛÝ
When your choice is set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE ENTRY. If your choice is not set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE SETUP. If this
happens, you need to repeat the
keyless lock acknowledgment setup.To exit KEYLESS LOCK
ACKNOWLEDGMENT without
changing the current setting, select
EXIT by pressing the INFO ( / )
button, then press the SEL/RESET
button. The screen goes back to
CUSTOMIZE MENU.
Multi-Inf ormation Display
130
2009 RL

µ
µ µ
Push down on the
lever to signal a lef t turn and up to
signal a right turn. To signal a lane
change, push lightly on the lever,
and hold it. The lever will return to
center when you release it or
complete a turn.
Turn signal
Of f
Parking and indicator lights
AUTO
Headlights on
High beams
Flashhighbeams
Fog lights of f
Fog lights on The rotating switch
on the lef t lever controls the lights.
Turning this switch to the ‘‘ ’’
position turns on the parking lights,
taillights, instrument panel lights,
side-marker lights, and rear license
plate lights.
Turning the switch to the ‘‘ ’’
position turns on the headlights. If
you leave the lights on with the
ignition switch released af ter turned
to the LOCK (0) position or when
the built-in key is removed f rom the
ignition switch, you will hear a
reminder chime when you open the
driver’s door. When the light switch is in the
‘‘ ’’ or ‘‘ ’’ position, the
lights on indicator comes on as a
reminder. This indicator stays on if
you leave the light switch on and
turn the ignition switch to the
ACCESSORY (I) or the LOCK (0)
position.
To switch f rom low
beams to high beams, push the lef t
lever f orward until you hear a click.
The blue high beam indicator will
come on (see page ). Pull it back
to return to low beams. To flash the
high beams, pull the lever back
lightly, then release it. The high
beamsstayonaslongasyouhold
the lever back.
1.
2.
3.
4.
5.
6.
7.
8.
9. 65
Turn Signal
Headlights
High Beams
Turn Signals and Headlights
140
2009 RL

When you turn the ignition switch to
the LOCK (0) position and release it,
or remove the built-in key f rom the
ignition switch, the steering wheel
automatically moves f ully in and up.
Steering wheel movement is also
controlled by the driving position
memory system (see page ).
To change the ‘‘AUTO TILT &
TELESCOPIC’’ setting, see page. If your vehicle’s battery is
disconnected or goes dead, or the
f use f or the power tilt and telescopic
steering wheel is removed, the
power tilt and telescopic steering
wheel system needs to be reset
when you reconnect the battery or
install the f use.
The steering wheel returns to its
original position when you push the
ignition switch or insert the built-in
key back in the ignition switch. Push the ignition switch f or more
than 1 second and release it, or
insert the built-in key into the
ignition switch, and remove it. The
steering wheel automatically moves
f ully in and up to let you know the
system is reset.
106 163
Steering Wheel A djustments
Inst rument s and Cont rols
149
2009 RL

Youshouldhavereceivedakey
number tag with your keys. You will
need this key number if you ever
have to get a lost key replaced. Use
only Acura-approved key blanks.Protect the keys f rom direct
sunlight, high temperature, and
high humidity.
Donotdropthekeysorsetheavy
objects on them.
Keep the keys away f rom liquids.
If they get wet, dry them
immediately with a sof t cloth.
The keys do not contain batteries.
Do not try to take them apart.
The built-in key (see page ) f its
all the locks on your vehicle. These keys contain electronic
circuits that are activated by the
immobilizer system. They will not
work to start the engine if the
circuits are damaged.
180
Keys and Locks
150
KEY NUMBER TAG
BUILT-IN KEYS
2009 RL

As required by the FCC:This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.
When you turn the ignition switch to
the ON (II) position, the immobilizer
system indicator should come on f or
a f ew seconds, then go out. If the
indicator starts to blink, it means the
system does not recognize the
coding of the Honda smart key or
built-in key. Turn the ignition switch
to the LOCK (0) position, release the
ignition switch and push it, or
remove the built-in key, and reinsert
it.ThenturntheswitchtotheON
(II) position again. The system may not recognize your
key’s coding if another immobilizer
key or other metal object (i.e. key
f ob) is near the ignition switch when
you turn the ignition switch to the
ON (II) position.
If the system repeatedly does not
recognize the coding of your remote
or built-in key, contact your dealer.
Do not attempt to alter this system
or add other devices to it. Electrical
problems could result that may make
your vehicle inoperable.
If you have lost your remote or
built-in key and cannot start the
engine, contact your dealer.
The immobilizer system protects
your vehicle f rom thef t. If an
improperly-coded key (or other
device) is used, the engine will not
start.
Immobilizer System
Inst rument s and Cont rols
151
Always take the keyless access remote
and built-in key with you whenever you
leave the vehicle alone.
2009 RL

µ
µ
µ µ
The ignition switch has f our
positions: LOCK (0), ACCESSORY
(I), ON (II), and START (III). Use this position
only to start the engine. The switch
returns to the ON (II) position when
you let go of the ignition switch.
To use the built-in key, you have to
remove the cover (see page ). This is the normal
ignition switch position when driving.
Several of the indicators on the
instrument panel come on as a test
when you turn the ignition switch
f rom the ACCESSORY (I) to the ON
(II) position.
If the f ront wheels are turned, the
anti-thef t lock may make it dif f icult
to turn the ignition switch. Firmly
turn the steering wheel to the left or
right as you turn the ignition switch.
You can insert or
remove the built-in key only in this
position. To turn the ignition switch
to the LOCK (0) position, the shift
lever must be in Park, and you must
push the knob or built-in key in slightly.
TheshiftlevermustbeinPark
bef ore you turn the ignition switch
knob to the LOCK (0) position or
remove the built-in key from the
ignition switch.
You can
operate the audio system and the
accessory power sockets in this
position.
When you turn the ignition switch to
the ACCESSORY (I) position, an
‘‘ACCESSORY (I) POSITION’’
message is shown on the multi-
inf ormation display. If you open the driver’s door and
leave the key in the ignition switch,
you will hear a reminder beeper, and
a message appears on the multi-
inf ormation display according to the
ignition switch position. When the
ignition switch is in the ACC (I)
position, a ‘‘RETURN IGNITION
SWITCH TO LOCK (0) POSITION’’
message is shown on the multi-
inf ormation display. When the
ignition switch is in the LOCK (0)
position, a ‘‘REMOVE KEY’’
message is shown on the multi-
inf ormation display.
180 ST A RT (III)
ON (II)
LOCK (0) A CCESSORY (I)
Ignition Switch
152
IGNITION SWITCH
COVER BUILT-IN KEY
2009 RL

Each door has a lock tab above the
inside door handle. Pull the tab to
lock the door and push it to unlock.
Whenyoupullthetabonthedriver’s
door, all the doors lock.To lock any door when getting out of
the vehicle, pull the lock tab and
close the door.
All doors can be locked f rom the
outsidebyusingthebuilt-inkeyin
the driver’s door. To unlock only the
driver’s door, insert the built-in key,
turn it clockwise, and release it. The
remaining doors unlock when you
turn the built-in key a second time
within a f ew seconds.
Each f ront door has a power door
lock master switch. Either switch
locks and unlocks all doors. Push the
switch down to lock all doors and up
to unlock them. To change the ‘‘DOOR UNLOCK
MODE’’ setting, see page .
When the vehicle speed reaches
about 10 mph (15 km/h) or more, all
the doors lock automatically.When you shif t to P af ter driving, the
driver’s door unlocks.
To change the ‘‘AUTO DOOR
UNLOCK’’ setting, see page .
With the driver’s door open and the
built-in key in the ignition, both
master door lock switches are
disabled. They are not disabled if the
driver’s door is closed. Pushing the
switch down on the open f ront
passenger’s door will lock all doors.
If you try to lock an open driver’s
door by pulling the lock tab rearward
withtheremoteinsidethevehicle
and closing the driver’s door, the
driver’s door will unlock.
To change the ‘‘AUTO DOOR
LOCK’’ setting, see page . 109 125
123
L ockout Prevent ion
Door L ocks
Inst rument s and Cont rols
153
POWER DOOR LOCK
MASTER SWITCH
2009 RL

If your vehicle’s battery goes dead or
is disconnected, you can open the
trunk f rom the rear seat by pulling
the trunk release handle. Reach the
handle through the trunk pass-
through.
Keep the trunk lid closed at all times
while driving to avoid damaging the
lid, and to prevent exhaust gas f rom
getting into the interior. Seeon page .
Youcanopenthetrunkinanyof
f our ways: If the doors are locked, press the
trunk release switch on the trunk
lid with the remote in keyless
access operating range.
To close the trunk, press down on
the trunk lid.
Press the trunk release button on
the driver’s door.
Press and hold the trunk release
button on the remote.
If the doors are unlocked, press
thetrunkreleaseswitchonthe
trunk lid. 56Carbon
Monoxide Hazard
Trunk
154
TRUNK RELEASE BUTTON TRUNK RELEASE HANDLE
2009 RL

As a saf ety f eature, your vehicle has
a release lever on the right corner in
the trunk so the trunk can be opened
f rom the inside. To open the trunk,
push the release lever to the lef t.
Parents should decide if their
children should be shown how to use
this feature.
For more inf ormation about child
saf ety, see page .
To protect items in the trunk, you
can disable the trunk-release button
on the driver’s door, the trunk lid,
andtheremote.Todothis,turnoff
the trunk main switch in the glove
box, lock the glove box, and lock the
trunk pass-through cover with the
built-in key.
The childproof door locks are
designed to prevent children seated
in the rear f rom accidentally opening
the rear doors. Each rear door has a
lock lever near the edge. With the
lever in the LOCK position, the door
cannot be opened f rom the inside
regardless of the position of the lock
tab. To open the door, push the lock
tab in, and use the outside door
handle.
42 Childproof Door L ocks
Emergency T runk Opener
T runk, Childproof Door L ocks
Inst rument s and Cont rols
155
LEVER
TRUNK MAIN SWITCH
lock
unlock
RELEASE LEVER
2009 RL
