navigation system Acura RL 2010 Owner's Guide

The vehicle ‘‘senses’’ the driver
number, based on which keyless
remote is used to unlock the vehicle.
If two drivers with remotes approach
thevehicleatthesametime,the
welcome display and related settings
are based on which remote the
vehicle f irst ‘‘senses.’’If both remotes come within
range simultaneously, the
‘‘Welcome’’ display may be
unpredictable.
The compass system uses the driver
number (as recognized by the multi-
inf ormation display) to personalize
the compass system. For example, if
Driver 1 unlocks the vehicle, the
‘‘Driver 1’’ personal address book
and other navigation settings are
automatically loaded when the
vehicle is started. There is no way to
change f rom one driver’s settings to
another while driving. For inf ormation on ‘‘linking’’ and
‘‘unlinking’’ the keyless access
remotes, see page .
When the keyless access remote is
deliberately ‘‘unlinked,’’ (as when
giving the key to a valet) the multi-
inf ormation display will display
‘‘Welcome.’’ Then the f ollowing
occurs:
The calendar f eature is not
selectable (buttons grayed out).
Setup values (like volume,
brightness, etc.) can be changed
but are not remembered the next
time you restart the vehicle. 173
K eyless Memory Settings
Compass System (U.S. model without navigation system)
Features
285
NOTE:
TM
——y

y
(yy
2010 RL

You can see the current latitude,
longitude, and elevation at any time
when you press the COMPASS
button or say ‘‘Display map guide.’’
Thedateandtimeisalsodisplayed.If the battery is disconnected
or the f use f or the compass system
is removed, the system may require
GPS initialization (see page ). If the system does not receive the
elevation inf ormation, the display
shows only current latitude and
longitude.
If the GPS reception is low, the
display shows a ‘‘Low GPS
reception’’ message.
299
T he Compass Screen
Compass System (U.S. model without navigation system)
286
NOTE:
——y

y
(y
y
2010 RL

The voice command help screen
displays several topics that help you
to understand your vehicle’s voice
control system. To go to the voice
command help screen, say or select
‘‘Voice command help.’’ Then select
a topic by saying either the topic
name or its line number.Tousethevoicecommandtutorial,
say or select ‘‘Getting started.’’ The
display changes to the Getting
started screen.
When you say ‘‘Display menu’’ or
press the MENU button, the display
changes to the
screen.
To select a menu item, turn the
interf ace knob to highlight the item,
then press the interf ace selector.
If some items appear grayed
out and cannot be selected, the
vehicle does not sense the driver’s
IDof theremote(seepage ). Select the line number of the tutorial
you want to view, and the tutorial will
automatically be read out. To stop
the system from reading the tutorial,
move the interface knob to the right.
173
CONT INUED
Main Menu
Main menuVoice Command Help
Compass System (U.S. model without navigation system)
Features
287
NOTE:
——y

y
(yy
2010 RL

When you make a selection (such as
Navigation general command help),
you will see the help commands that
canbeusedwiththevoicecontrol.
To have the system read the list, say
‘‘Read list,’’ or select by
moving the interface selector to the
right, and the system will read the
list to you.The
screens display
the trip information from the multi-
inf ormation display in the gauge
assembly.
For a listing of all voice commands,
see
on page
.
To go to the trip computer, say ‘‘Trip
Computer,’’ select Trip computer
f rom the main menu, or press the
TRIP button on the center console
panel.
307
Voice Command Index
T rip Comput er
trip computer
Compass System (U.S. model without navigation system)
288
——y

y
(yy
2010 RL

The calendar f eature allows you to
enter events and be reminded of
them in the future.
When you say ‘‘Calendar’’ or select
the on the
screen, the display changes to thescreen.
Dates with an icon indicate there is a
schedule entry f or that date.
Shows the estimated distance you
cantravelonthefuelremainingin
the tank. This distance is estimated
f rom the average f uel economy over
the last several miles, so it will vary
withchangesinspeed,traffic,etc.
The average fuel, average speed, and
elapsed time meters can be reset
automatically (see page ).
The ‘‘Range’’ value is approximate,
and may vary from actual range. The ‘‘Average Fuel’’ and ‘‘MPG’’
may vary f rom actual f uel
consumed. These values are
estimates only.
Shows the instantaneous f uel
economy in miles per gallon.
Shows you the current f uel economy
in miles per gallon.
Shows you the average f uel economy
in miles per gallon since the display
was last reset.
Shows the elapsed time that the
ignition has been on since the display
was last reset.
Shows you the average speed in
miles per hour since the display was
last reset.
75
Range
MPG
Instant FuelAverage Fuel
Elapsed TimeAverage Speed
CONT INUED
Calendar
Resetting the Display
Calendar Main Menu
calendar
Compass System (U.S. model without navigation system)
Features
289
NOTE:
——y

y
(yy
2010 RL

You can scroll through the calendar
daybydaybyturningtheinterface
knob, or select the day by voice.
When you push the interf ace
selector up or down, you can also
scroll through the calendar week by
week. When you say ‘‘Next month’’
or ‘‘Previous month,’’ or when you
push the interface selector to the
right or left, the system displays the
next or previous month.Set your schedule by selecting the
day on the calendar, and the display
changes to the
screen.The def ault f or the reminder is .
This allows the system to remind
you of the calendar item the next
time you start the vehicle. See
on page .
Say or select ‘‘ ,’’ then enter
thenameof yourtitleusingthe
interf ace selector. Once you enter
the title, say or select ‘‘ .’’ The
title will be displayed on the
specif ied date of the Calendar screen.
Say or select ‘‘ ,’’ and
the system will show the Enter
Message screen. You can enter a
message on two lines. Use to
change the line. Once you have
entered the message, say or select
‘‘Done.’’ The message will be
displayed on the specif ied date of the
calendar screen. 283Reminder
System Start-upTitle
Message
Ent ering Your Schedule
Edit schedule
ON
Edit title Done
Edit message
Compass System (U.S. model without navigation system)
290
——y


y
(yy
2010 RL

Message IconDeleteDone
Say or select ‘‘ ,’’ and
the system displays a list of icons
you can select to help identif y the
type of message you entered. The
message icon you choose will be
displayed alongside the specif ied
date on the calendar screen.
From the screen, select
thedateof thescheduleyouwishto
remove. To remove the schedule,
say or select ‘‘ .’’
Once you have f inished entering the
schedule, say or select ‘‘ .’’ The screen is redisplayed and a
category icon appears. You can only enter one message
per day.
To re-activate a previous message,
turn the reminder setting from
to . If it is not turned on,
the reminder will not be displayed
when you start the vehicle.
For more inf ormation, ref er to
System Start-up on page .
This allows you to move your
calendar entry to a dif f erent date. If
you say or select ‘‘ ,’’ thescreen is displayed with
existing entries grayed out. Select a
new day and the
screen is redisplayed with the new
date.
283
CONT INUED
Message icon
calendar Delete
Done
calendar OFF ON
Edit date
calendar
edit schedule
Edit Dat e
Compass System (U.S. model without navigation system)
Features
291
NOTE:
——y

y
(yy
2010 RL

When you say or select ‘‘Calculator,’’
the display changes to thescreen.
Enter the digits and operation
symbols with the interf ace selector. Use the interface selector to control
the calculator, and calculator
‘‘conversion’’ f eature.
To convert a unit of measurement,
do this:
Enter a numeric value to be
converted (f or example, 100).
Push the interf ace selector down
to select Unit conversion. The
screen above appears. Turn the interface knob until the
conversion you want is highlighted
(weight, for example), then push
the selector in to select it. The
screen f or that conversion type
appears (see illustration in step
4).
1.
2. 3.
Calculat or
Convert
Calculator
Compass System (U.S. model without navigation system)
292
——y

y
(yy
2010 RL

Turn the interf ace knob until the
unit you want to convert f rom is
highlighted (kilogram, f or
example), then push the selector
in to select it as it the example
above.The set-up f unctions consist of three
dif f erent screens that allow you to
change and update inf ormation in
the system. To display the
, say ‘‘Set up’’ or press the
SET UP button, and then select an
item. To select more setup items, say
‘‘More,’’ or select MORE at the top
right corner of the screen.
The f irst setup screen allows you to
change the system’s brightness,
contrast, black level, volume,
interf ace dial f eedback, and clock
adjustment. To select a setup item,
turn the interf ace knob until it is
highlighted, then push the interf ace
selector in to select it.
4.
CONT INUED
System Set-up
set up
screenFirst Set up Screen
Compass System (U.S. model without navigation system)
Features
293
——y

y
(yy
2010 RL

µ
µ
Brightness Black LevelVolume
If you are having trouble viewing
the screen in bright lighting conditions, try increasing the brightness.
Contrast
There are 11 possible brightness
settings. To change the brightness,
say ‘‘Brightness up’’ or ‘‘Brightness
down.’’ You can also select and change the setting
by turning the interf ace knob. There are 11 possible black level
settings. To change the black level,
say ‘‘Black level up’’ or ‘‘Black level
down.’’ You can also select
and change the setting by
turning the Interf ace knob. Changes
tothedisplayareverysubtle this
is normal. Say ‘‘Volume up’’ or ‘‘Volume down.’’
There are 11 possible contrast
settings. To adjust the contrast, say
‘‘Contrast up’’ or ‘‘Contrast down.’’
You can also select and
change the setting by turning the
interf ace knob. Changes to the
display are very subtle this is
normal. You can have separate
daytime and nighttime settings f or
brightness, contrast, and black level.
Adjust each setting when the display
is in either daytime or nighttime
mode. Use the Display mode button
(see page ) to select daytime or
nighttime mode. Toadjustthevolumeof thesystem
voice, do one of these actions:
Select volume off. If youturnthevolumeoff,
you will not hear voice command
conf irmations. Select , then change the
setting by turning the interface
knob.
282
Brightness
Black
Level
Contrast Volume
Tip:
Compass System (U.S. model without navigation system)
294
NOTE:
NOTE:
——y

y
(yy
2010 RL
