Acura RL 2010 Owner's Manual

Each torque indicator is displayed as
a bar graph divided into 5 segments.
The number of segments represents
the amount of torque distributed to
each wheel.
When there is only a slight change in
torque distribution while driving,
such as cruising on level roads at the
same speed, the torque distribution
monitor may stop displaying the
amount of torque. This is not a
system problem. The monitor will
show the amount if the system
senses any change in torque
distribution.If the SH-AWD indicator blinks while
driving, it indicates the dif f erential
temperature is too high. You will also
see an ‘‘SH-AWD DIFF TEMP.
HIGH’’ message on the multi-
inf ormation display. If this happens,
pull to the side of the road when it is
saf e, shif t to Park, and let the engine
idle until the indicator goes out. If
the indicator does not go out, take
your vehicle to a dealer to have it
checked.
If the SH-AWD indicator on the
instrument panel stays on, and the
‘‘CHECK SH-AWD SYSTEM’’
message also appears on the multi-
inf ormation display, there is problem
with the SH-AWD system.
Your vehicle still has normal f ront-
wheel drive with vehicle stability
assist (VSA), but does not have the
advantages of SH-AWD. Have your
vehicle checked by a dealer as soon
as possible.
Super Handling-A ll Wheel Drive (SH-A WD)System
408
TM
——y

y
(y
y
2010 RL

Check the indicator on the
instrument panel to verif y that the
security system is set. If the vehicle is f acing downhill,
turn the front wheels toward the
curb. If the vehicle is f acing uphill, turn
the front wheels away from the
curb. Never park over dry leaves, tall
grass, or other f lammable
materials. The hot three way
catalytic converter could cause
these materials to catch on fire.
Make sure the parking brake is
f ully released bef ore driving away.
Driving with the parking brake
partially set can overheat or
damage the rear brakes.
Always use the parking brake when
you park your vehicle. Make sure
the parking brake is set f irmly or
your vehicle may roll if it is on an
incline.
Set the parking brake bef ore you put
the transmission in Park. This keeps
the vehicle from moving and putting
pressure on the parking mechanism
in the transmission.
Make sure the moonroof and the
windows are closed.
Turn of f the lights.
Place any packages, valuables, etc.,
in the trunk or take them with you.
Lock the doors.
Parking T ips
Parking
Driving
409
——y

y
(y
y
2010 RL

Your vehicle is equipped with disc
brakes at all f our wheels. A power
assist helps reduce the ef f ort needed
on the brake pedal. The brake pedal
assist f unction increases the f orce
you apply to the brake pedal during
an emergency stop. When the brake
pedal assist is activated, the e-
pretensioners (if equipped) tighten
f ront seat belts (see page ). The
anti-lock brake system (ABS) helps
you retain steering control when
braking very hard (see page ).
Resting your f oot on the pedal keeps
the brakes applied lightly, builds up
heat, reduces their ef f ectiveness and
reduces brake pad lif e. In addition,
f uel economy can be reduced. It also
keeps your brake lights on all the
time, conf using drivers behind you.The hydraulic system that operates
the brakes has two separate circuits.
Each circuit works diagonally across
the vehicle (the lef t-f ront brake is
connected with the right-rear brake,
etc.). If one circuit should develop a
problem, you will still have braking
at two wheels.
Constant application of the brakes
when going down a long hill builds
up heat and reduces their ef f ective-
ness. Use the engine to assist the
brakes by taking your f oot of f the
accelerator and downshif ting to a
lower gear.
Check the brakes after driving
through deep water. Apply the
brakes moderately to see if they f eel
normal. If not, apply them gently and
f requently until they do. Be extra
cautious in your driving.
If the brake pads need replacing, you
will hear a distinctive, metallic
screeching sound when you apply
the brake pedal. If you do not have
the brake pads replaced, they will
screech all the time. It is normal f or
the brakes to occasionally squeal or
squeak when you apply them.
24
411 Braking System Design
Brake Pad Wear Indicators
Braking System
410
——y

y
(y
y
2010 RL

The anti-lock brake system (ABS)
helpspreventthewheelsfrom
locking up, and helps you retain
steering control by pumping the
brakes rapidly, much f aster than a
person can do it.If this indicator comes on, the anti-
lock f unction of the braking system
has shut down. The brakes still work
like a conventional system, but
without anti-lock. You should have
your dealer inspect your vehicle as
soon as possible.
You will f eel a pulsation in the brake
pedal when the ABS activates, and
you may hear some noise. This is
normal: it is the ABS rapidly
pumpingthebrakes.Ondry
pavement, you will need to press on
thebrakepedalveryhardbeforethe
ABS activates. However, you may
feel the ABS activate immediately if
you are trying to stop on snow or ice.
Let the ABS work f or you by always
keeping f irm, steady pressure on the
brake pedal. This is sometimes
ref erred to as ‘‘stomp and steer.’’ The electronic brake distribution
(EBD) system, which is part of the
ABS, also balances the f ront-to-rear
braking distribution according to
vehicle loading. When the ABS indicator comes on,
you will also see a ‘‘CHECK ABS
SYSTEM’’ message on the multi-
inf ormation display.
You should never pump the brake pedal.
CONT INUED
ABS Indicator
Anti-lock Brakes (ABS)
Driving
411
——y

y
(y
y
2010 RL

on loose or
uneven surfaces, such as gravel or
snow, than a vehicle without anti-
lock.
It only helps with steering
control during braking.
such as trying to take a
corner too f ast or making a sudden
lane change. Always drive at a safe
speed f or the road and weather
conditions.
Always steer moderately
when you are braking hard. Severe
or sharp steering wheel movement
can still cause your vehicle to veer
into oncoming traffic or off the road.
If the ABS indicator and the brake
system indicator come on together,
and the parking brake is f ully
released, the EBD system may also
be shut down.
Test your brakes as instructed on
page . If the brakes f eel normal,
drive slowly and have your vehicle
repaired by your dealer as soon as
possible. Avoid sudden hard braking
which could cause the rear wheels to
lock up and possibly lead to a loss of
control.
The VSA indicator will come on
alongwiththeABSindicator.
502
A vehicle with A BS may require a
longer distance to stop
Important Saf ety Reminders
A BS does not reduce the time or
distance it takes to stop the
vehicle.
A BS will not prevent a skid that
results f rom changing direction
abruptly,
A BS cannot prevent the loss of
stability.
Anti-lock Brakes (ABS)
412
——y

y
(y
y
2010 RL

The CMBS does not activate if the
speed dif f erence between the two
vehicles is less than 10 mph (15
km/h). CMBS may also not
activate if you turn the steering
wheel to avoid the collision.
When the CMBS activates, the brake
lights also come on.
The collision mitigation brake
system (CMBS) can assist you when
there is a possibility of your vehicle
hitting the vehicle in f ront of you. It
is designed to reduce the speed of
your vehicle before an unavoidable
collision occurs and, if possible, to
alert you to a potential collision while
thereistimetopreventit.Hereisa
brief description of what the CMBS
can do:
When your speed is above 10 mph
(15 km/h), the CMBS radar
sensor in the f ront grille can sense
a vehicle ahead of you. When your
vehicle gets too close to the
vehicle ahead of you, the system
mayactivateawarningbeep,
causing automatic application of
the brakes, and causing the
e-pretensioners to tighten the
f ront seat belts (see page ). The CMBS consists of a radar
sensor in the f ront grille, a brake
actuator in the engine compartment,
an indicator on the instrument panel,
seat belt e-pretensioners on the f ront
seats,andanon/off switchonthe
dashboard.
24
If equipped
Overview
Collision Mitigation Brake System (CMBS)
Driving
413
RADAR SENSOR
BRAKE
ACTUATOR SEAT BELT
e-PRETENS
IONERS
——y

y
(y
y
2010 RL

The radar sensor is located under
the Acura emblem in the f ront grille.
If the radar sensor cover is covered
with mud, dirt, dead leaves, wet
snow, etc., or if you put a sticker on
it, the CMBS will automatically shut
of f , and the CMBS indicator on the
instrument panel will come on. You
will also see a ‘‘CHECK CMBS
RADAR SENSOR’’ message on the
multi-inf ormation display f or about 5
seconds.Always keep the radar sensor cover
clean. If it gets dirty, clean it with
water or a mild detergent. Never use
chemical solvents or polishing
powder.Do not allow anything to impact the
radarsensorortheradarsensor
cover. If either of these parts
receives a strong impact, turn off the
system by pressing the CMBS of f
switch, and have your vehicle
checked by a dealer. If the f ront
grille ever needs to be repaired,
consult a dealer f irst.
If the radar sensor cover or the radar
sensor ever needs to be removed,
take your vehicle to a dealer.
There are three bolts on the sides of
the radar sensor. Do not tamper with
these bolts, or you may cause the
system to malf unction.
Radar Sensor
Collision Mitigation Brake System (CMBS)
414
RADAR SENSOR COVER
BOLTS
(Do not tamper)
——y
y
(y
y
2010 RL

The radar sensor may not always
scan as intended. Here are two
examples:Thetiresarenotcorrectly
maintained. Always make sure the
tire pressures are correct (see
page ), and that the tires are
the correct size and in good
condition (see Tires on page ). Your vehicle is tilted because of a
heavy load in the rear or from
modif ications to the suspension.
Do not overload your vehicle (see
Carrying Cargo on page ), and
do not make any modif ications to
the suspension (see Accessories
and Modif ications on page ). 474
474 387
389
Collision Mitigation Brake System (CMBS)
Driving
415
When the CMBS is on, the radar sensor
constantly scans f or vehicles ahead of
you. This means that driving on a road
with a f ew or no vehicles could cause a
CHECK CMBS RADAR SENSOR
message to appear on the multi-
inf ormation display. This is normal
and not a cause f or concern.
——y

y
(yy
2010 RL

If the system senses a likely collision
with a vehicle or object ahead of you,
it alerts you with an audible and a
visual alarm.The audible alarm is a constant
beeping sound; the visual alert is an
amber colored BRAKE message that
f lashes on the multi-inf ormation
display. If these alarms come on,
take the appropriate means to
prevent a collision (apply the brakes,
change lanes, etc.).To turn the CMBS off, press the
CMBS OFF switch on the dashboard
f or about 1 second. When you do this,
a beeper sounds, a CMBS indicator
on the instrument panel comes on,
and a CMBS OFF message appears
on the multi-information display. To
turn the system back on, press the
switch again for about 1 second.
Collision Alarm
CMBS OFF Switch
Collision Mitigation Brake System (CMBS)
416
CMBS OFF SWITCH
——y

y
(y
y
2010 RL

The CMBS will automatically
recover when these conditions are
improved.
Any of the conditions below can
cause the CMBS to shut of f . When
the system shuts off, the CMBS
indicator in the instrument panel
comes on, and a CHECK CMBS
SYSTEM message appears on the
multi-inf ormation display f or about 5
seconds.
An abnormal tire condition is
detected (wrong tire size, f lat tire,
etc.).
Extended of f -road or mountainous
driving.
Driving your vehicle with the
parking brake applied.
Driving your vehicle in bad
weather(rain,fog,snow,etc.).
A dirty emblem on the f ront grille.
When you turn the ignition switch to
the ON (II) position, the CMBS is
turned on if it was on previously.
Automatic Shut Of f
Collision Mitigation Brake System (CMBS)
Driving
417
——y
y
(yy
2010 RL
