This indicator normally comes on
when you turn the ignition to the ON
(II) position and goes of f af ter the
engine starts. If it comes on at any
other time, there is a problem with
the power steering system. You will
also see a ‘‘CHECK POWER
STEERING SYSTEM’’ message on
the multi-information display (see
page ). If this happens, stop the
vehicle in a safe place, and turn off
the engine. Reset the system by
restarting the engine, and watch this
indicator. If it does not go of f or
comes back on again while driving,
take the vehicle to your dealer to
have it checked. With the indicator
on, the ECPS is turned of f , which
could make the vehicle harder to
steer.This indicator comes on when there
is a system message on the multi-
inf ormation display. Press the INFO
button on the steering wheel (see
page ) to see the message (see
page ).
Most of the time, this indicator
comes on along with other indicators
in the instrument panel such as the
seat belt reminder indicator, SRS
indicator, VSA system indicator, etc.
The indicator comes on when you
run the engine while the vehicle is
not moving. To turn the indicator of f ,
restart the engine.
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. If it comes on at any other
time, it indicates that there is a
problem with the system. You will
also see a ‘‘CHECK KEYLESS
ACCESS SYSTEM’’ message on the
multi-inf ormation display (see page
). For more inf ormation, see page.
78 71
78
79 179
Instrument Panel Indicators
Message Indicator
Electronically Controlled
Power Steering System
(ECPS) Indicator
K eyless Access System
Indicator
68
——y
y
(yy
2010 RL

This indicator comes on when the
security system is set. For more
inf ormation, see page .
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.
Itcomesonasareminderthatyou
have turned off the adaptive front
lighting system (AFS).
This indicator blinks when there is a
problem with the AFS system; you
will also see a ‘‘CHECK ADAPTIVE
FRONT LIGHTING SYSTEM’’
message on the multi-inf ormation
display (see page ). If this
happens, stop the vehicle in a saf e
place, turn the ignition switch to the
ACCESSORY (I) or the LOCK (0)
position, and restart the engine. If
the indicator does not go of f or
blinks again, take your vehicle to a
dealer to have it checked. For more
inf ormation, see page .
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. It also comes on as areminder that you have turned of f
the collision mitigation brake system
(CMBS).
The CMBS indicator also comes on
if dirt or other debris blocks the
radar sensor in the f ront grille. You
will also see a ‘‘CHECK CMBS
RADAR SENSOR’’ message on the
multi-inf ormation display. When you
clean the radar sensor, the indicator
should go of f the next time you turn
the ignition switch to the ON (II)
position.
If the indicator comes on at any
other time, there is a problem with
the CMBS. You will also see a
‘‘CHECK CMBS SYSTEM’’ message
on the multi-information display. If
this happens, take your vehicle to a
dealer, and have it checked. For
more information, see page .
When this indicator is on, the CMBS
is not working.
78
144 315
418
If equipped
If equipped
A daptive Front L ighting
System (A FS) IndicatorSecurity System Indicator
Collision Mitigation
Brake System (CMBS)
Indicator
Instrument Panel Indicators
Inst rument s and Cont rols
69
SECURITY SYSTEM INDICATOR
——y
y
(yy
2010 RL

This shows the temperature of the
engine’s coolant. During normal
operation, the pointer should rise
from the bottom white mark to about
the middle of the gauge. In severe
driving conditions, such as very hot
weather or a long period of uphill
driving, the pointer may rise to theupper end of the white section of the
gauge. If it reaches the red (hot)
mark, pull saf ely to the side of the
road. For more information, see page
. This shows how much f uel you
have. It may show slightly more
or less than the actual amount.
The needle returns to the
bottom after you turn off the
ignition.
497
Gauges
Temperature Gauge Fuel Gauge
70
U.S. model is shown.TACHOMETER
TEMPERATURE GAUGE
SPEEDOMETER
FUEL GAUGE
Avoid driving with an extremely low
f uel level. Running out of f uel could
cause the engine to misf ire, damaging
the catalytic converter.
——y
y
(yy
2010 RL

ÛÝ
The multi-inf ormation display in the
instrument panel displays various
inf ormation and messages when the
ignition switch is in the ON (II)
position. Some of the messages help
you operate your vehicle more
comf ortably. Others help to keep
you aware of the periodic
maintenance your vehicle needs f or
continued trouble-f ree driving.You can change the display and
customize your vehicle control
settings by pressing the SEL/RESET
or INFO buttons on the right side of
the steering wheel.With the ignition switch in the ON
(II) position, the lower part of the
multi-inf ormation display changes as
shown in the illustration, each time
you press the SEL/RESET button.
When you open the driver’s door, a
‘‘Welcome’’ message is shown on the
multi-inf ormation display. When you
turn the ignition switch from the ON
(II) position to the ACCESSORY (I)
position, a ‘‘Goodbye’’ message is
shownonthedisplay.
Multi-Inf ormation Display
Inst rument s and Cont rols
71
U.S.
CANADA
INFO ( / )
BUTTONS
SEL RESET BUTTON
——y

y
(yy
2010 RL

The odometer shows the total
distance your vehicle has been
driven. It measures miles in U.S.
models and kilometers in Canadian
models. It is illegal under U.S.
federal law and Canadian provincial/
territorial regulations to disconnect,
reset, or alter the odometer with the
intent to change the number of miles
or kilometers indicated.This meter shows the number of
miles (U.S.) or kilometers (Canada)
driven since you last reset it. There
are two trip meters: Trip A and Trip
B. Each trip meter works
independently, so you can keep track
of two dif f erent distances.
To reset a trip meter, display it, then
press and hold the SEL/RESET
button until the number resets to
‘‘0.0’’.When you reset Trip A, average f uel
economy A is reset at the same time.
When you reset Trip B, average f uel
economy B is reset.
In the customizing mode, you can set
Trip A, average f uel economy A, and
average speed to reset at the same
time when you ref uel your vehicle
(see page ).
99
Multi-Inf ormation Display
Odometer T rip Meter
72
ODOMETER
TRIP METER
——y
y
(yy
2010 RL

This shows the outside Fahrenheit
temperature in U.S. models, and
Celsius temperature in Canadian
models.The temperature sensor is in the
f ront bumper. The temperature
reading can be affected by heat
ref lection f rom the road surf ace,
engine heat, and the exhaust f rom
surrounding traf f ic. This can cause
an incorrect temperature reading
when your vehicle speed is under
19 mph (30 km/h). When you start
your trip, the sensor is not f ully
acclimatized, theref ore it may take
several minutes until the proper
temperature is displayed.
This shows the remaining lif e of the
engine oil. It shows 100% af ter the
engine oil is replaced and the display
is reset. The engine oil lif e is
calculated based on engine operating
conditions and accumulated engine
revolutions. For more inf ormation,
see page .
You can adjust the outside
temperature display (see page ) .
In certain weather conditions,
temperature readings near f reezing
(32°F, 0°C) could mean that ice is
f orming on the road surf ace.
439
97
Outside Temperature
Engine Oil Lif e
Multi-Inf ormation Display
Inst rument s and Cont rols
73
OUTSIDE TEMPERATURE
U.S.
CANADA ENGINE OIL LIFE
——y
y
(yy
2010 RL

ÝÛ
Ý
Û
With the ignition switch in the ON
(II) position, the upper part of the
display changes, as shown in the
illustration, each time you press the
button. If you press the button,
the display returns to the previous
message.
Multi-Inf ormation Display
Normal Display Messages
74
U.S. CANADA If ON
Press the button
Press the button
——y
y
(yy
2010 RL

When you turn of f the engine, INST.
MPG or INST. L/100 km is also
reset. This shows your instant f uel
economy. Along with the trip meter, the trip
computer calculates these values:Instantaneous f uel mileage
Range
Elapsed Time
Average Fuel Economy Average Vehicle Speed
This shows the estimated distance
you can travel on the fuel remaining
in the f uel tank. This distance is
estimated f rom the f uel economy
you received over the last several
miles(U.S.) or kilometers (Canada), so it will vary with changes in speed,
traf f ic, etc.
When the battery is disconnected, or
you ref uel, RANGE is also reset.
This shows the accumulated
traveling time since you last reset it.
When you turn the ignition switch to
the ON (II) position, ELAPSED
TIME is reset.
You can customize the ELAPSED
TIME reset conditions on the multi-
inf ormation display (see page ).
This shows the average speed you
are traveling in miles per hour (mph)
f or U.S. models or kilometers per
hour (km/h) f or Canadian models.
When you reset Trip A, average
speed is also reset.
You can customize the average
speed reset condition on the multi-
inf ormation display (see page ).
This shows your vehicle’s average
f uel economy in mpg (U.S. models)
or liter/100 km (Canadian models)
since you last reset Trip A or Trip B.
The average f uel economy will be
reset when you reset the trip meter,
or if the vehicle’s battery goes dead
or is disconnected.
You can customize the average fuel
A reset condition on the multi-
inf ormation display (see page ).
101 99
99
Multi-Inf ormation Display
INST.MPG(U.S.models)/INST.
L /100km (Canadian models) Trip Computer
RANGE EL A PSED T IME
A VERA GE SPEED
AVERAGE FUEL A/B
Inst rument s and Cont rols
75
——y

y
(yy
2010 RL

This monitor shows how much
torque is being delivered to each
wheel. For more inf ormation, see
page .Whenthetirepressuremonitoris
shown on the multi-inf ormation
display, press the SEL/RESET
button. The display changes as
shown.
You can see the pressure of each tire
in this monitor. If one or more tires
are low, inflate them to the correct
pressure. For more inf ormation, see
page .You can receive or make phone calls
f rom your cell phone through your
vehicle’s
HandsFreeLink
(HFL) system without touching your
cell phone.
407
423
Bluetooth
Multi-Inf ormation Display
SH-AWD T orque Distribution
MonitorTire Pressure MonitorHandsFreeL inkBluet oot h
76
U.S.
Canada
——y
y
(y
y
2010 RL

When the engine oil lif e reaches 15%,
the display shows ‘‘SERVICE DUE
SOON’’ and the code f or the
maintenance items to be perf ormed.Have your dealer do the indicated
maintenance as soon as you see this
message, and have them reset the
display af ter completing the service.
If you do not perf orm the indicated
maintenance or do not reset the
display, the message changes to
‘‘SERVICE PAST DUE’’ when the
engine oil lif e becomes 0%.
These messages appear on the multi-
inf ormation display each time you
turn the ignition switch to the ON
(II) position.
For details on engine oil lif e and
maintenance messages, ref er to page
.
Also ref er to page f or important
maintenance saf ety precautions.
When the engine oil lif e reaches 5%,
the display shows ‘‘SERVICE DUE
NOW’’ along with the same
maintenance items.
To use the system, your cell phone
and the HFL system must be linked.
Not all cell phones are compatible
with this system. Ref er to page
for instructions on how to link
your cell phone to HFL and how to
receive or make phone calls, or visit
the acura.com/handsf reelink
website.
439438
354
Maintenance Messages
Multi-Inf ormation Display
Inst rument s and Cont rols
77
——y
y
(yy
2010 RL
