CONT INUED
Use neutral if you
need to restart a stalled engine, or if
it is necessary to stop brief ly with
the engine idling. Shif t to the Park
position if you need to leave your
vehicle for any reason. Press on the
brake pedal when you are moving
the shift lever from neutral to
another gear.
If you exceed the maximum speed
f or the gear you are in, the engine
speed will enter into the tachometer’s
red zone. If this occurs, you may f eel
the engine cut in and out. This is
caused by a limiter in the engine’s
computer controls. The engine will
run normally when you reduce the
rpm below the red zone. With the shift lever in D or S, you
canalsousethepaddleshiftersto
shif t the transmission up or down.
With the paddle shifters, you can
operate the transmission much like a
manual transmission without a
clutch pedal. For more inf ormation
on driving with the paddle shif ters,
see page .
To shift into the S
position, press the release button on
the top of the shif t lever, and move
the lever to S. This position is similar
to D, except only gears f rom f irst to
fifth are selected. (When shifting up
automatically, the vehicle speed is
higher than when in the D position.)
The S position keeps the transmission f rom cycling between
fourth, fifth and sixth gears in stop-
and-go driving.
Use this position f or
your normal driving. The
transmission automatically selects a
suitable gear (1 through 6 gear) to
keep the engine at the best speed f or
the driving conditions. This allows you to move the shif t
lever out of Park if the normal
method of pushing on the brake
pedal and pressing the release
button does not work.
Make sure the ignition switch is in
the LOCK (0) position. Set the parking brake.
Remove the built-in key from the
keyless access remote (see page ).
1.
2.
407 181
Shif t L ock Release
Neutral (N)
Engine Speed L imiter
S Position (S) Drive (D)
Automatic Transmission
Driving
405
10/08/04 19:53:12 31SJA660_410
ProCarManuals.com

If you need to use the shif t lock
release, it means your vehicle is
developing a problem. Have the
vehicle checked by a dealer.
Push down on the built-in key
while you press the release button
and move the shif t lever out of
Park to neutral. Remove the built-in key from the
shif t lock release slot, then
reinstall the cover. Make sure the
notchonthecoverisonthedriver’s
side. Press the brake pedal, and
restart the engine.
Insert the built-in key into the shift
lock release slot.
Put a cloth on the edge of the shif t
lock release slot cover to prevent
scratches. Use a small f lat-tip
screwdriver or metal f ingernail f ile
to caref ully pry up the edge of the
cover and remove it from the slot.
3. 4.
5.6.
Automatic Transmission
406
COVER
SHIFT LOCK RELEASE SLOT
10/08/04 19:53:20 31SJA660_411
ProCarManuals.com

´
µ ´
µ
CONT INUED
WhenyouaredrivingintheD
position, you can shif t the
transmission up or down manually
with the paddle shifters.
To shif t up or down, use the
(right) or (lef t) paddle shif ter on
either side of the steering wheel. Each time you pull (right), the
transmission shif ts to a higher gear.
Pull (lef t) to downshif t. You will
see the selected gear number on the
instrument panel.
When you pull either paddle shif ter,
the gear position indicator shows you
the selected gear number.
Downshifting with the paddle shifter
allows you to increase the engine
brakingwhengoingdownsteepor
long hills, and provides more power
when climbing uphills. You can
upshif t the transmission manually to
reduce the rpm.
Using the Paddle Shif ters in the
D position (D-Paddle Shif t Mode)
Driving with the Paddle Shif ters
Driving
407
GEAR POSITION INDICATOR
PADDLE SHIFTERS
10/08/04 19:53:30 31SJA660_412
ProCarManuals.com

´
The transmission control system
monitors the accelerator pedal use
and your driving conditions. When
you press the accelerator pedal as in
normal driving, the system judges
that you are driving at a constant
cruising speed without using the
paddle shif ters. Under these
conditions, D-paddle shif t mode is
canceled, and the transmission
automatically returns to drive mode
(D).
The automatic transmission will not
allow you to shif t up or down if :
You downshif t bef ore the engine
speed reaches the highest
threshold of the lower gear.
If you try to do this, the gear
position indicator will f lash the
number of the lower gear several
times, then return to a higher gear.
You upshif t bef ore the engine
speed reaches the lowest
threshold of the higher gear.
You pull both paddle shif ters at
thesametime.
You pull one of the two paddle
shifters with another paddle
shif ter being pressed.
Each time you pull either paddle
shifter, the transmission shifts one
gear up or down.
The transmission remains in the
selected gear if you do not accelerate. When the transmission returns to
drive mode (D), the displayed gear
number disappears. Hold the paddle shifter for 2
seconds to return to drive mode (D). You can also shift down two gears at
a time if the selected gear is between
the second and sixth, and the engine
speed is within the appropriate range.
Pull the paddle shif ter twice to select
agear.
If you want to shif t up or down more
than two gears, pull the paddle
shif ter twice, pause, and then pull it
again.
Driving with the Paddle Shif ters
408
10/08/04 19:53:42 31SJA660_413
ProCarManuals.com

CONT INUED
With the shif t lever in the S position,
you can select the sequential shif t
mode to shif t gears; much like a
manual transmission using the
paddle shif ters, but without a clutch
pedal.
You are trying to downshift from
second to f irst with the accelerator
pedal off.
The transmission downshif ts to f irst
gear and returns to drive mode (D)
when the vehicle comes to a
complete stop or the vehicle speed is
about 6 mph (10 km/h).
If there is a problem in the
transmission while you are driving
with the paddle shifters, the D
indicator f lashes, the D-paddle shif t
mode is canceled, and the
transmission returns to drive mode
(D). When you depress the accelerator
pedal to the f loor, the transmission
will downshif t f rom second to f irst. Shif ting between f irst and second
gears may occur automatically.
Downshif ting f rom second to f irst
with the accelerator pedal off is not
allowed.When you move the shif t lever f rom
‘‘D’’ to ‘‘S’’ and pull either paddle
shif ter, the gear position indicator
displays ‘‘M’’ along with the selected
gear number.
To enter the sequential shif t mode,
press the release button on the top
of the shift lever, move the lever to
the S position, then pull either paddle
shif ter. To cancel the sequential shif t
mode and return to the ordinary
automatic transmission, move the
shif t lever f rom the S position. When
moving the shift lever, be careful not
to operate incorrectly. While you are
driving in the sequential shif t mode, the transmission will not
automatically return to ordinary
automatic transmission.
Driving with the Paddle Shif ters
Using the Paddle Shif ters in the S
position (Sequential Shif t Mode)
Driving
409
GEAR POSITION INDICATOR
‘‘M’’ INDICATOR
10/08/04 19:53:52 31SJA660_414
ProCarManuals.com

´µ The automatic transmission will not
allow you to shif t up or down if :
You downshif t bef ore the engine
speed reaches the highest
threshold of the lower gear.
If you try to do this, the gear
position indicator will f lash the
number of the lower gear several
times, then return to a higher gear.
If the vehicle speed decreases
below the redline of the selected
lowergearwhiletheindicatoris
f lashing, the transmission
downshif ts, and the indicator
displays the selected gear.
You upshif t bef ore the engine
speed reaches the lowest
threshold of the higher gear.
The transmission also shif ts
automatically as the vehicle comes to
a complete stop. It downshif ts to f irst
gear when the vehicle speed reaches
6mph(10km/h)orless. Downshifting with the paddle shifter
allows you to increase the engine
braking when going down steep or
long hills, and provides more power
when climbing uphills. You can
upshif t the transmission manually to
reduce the rpm. When you are driving, the
transmission downshifts to the lower
gear under the f ollowing conditions:
The vehicle slows down to a
certain speed.
You press the brake pedal.
The vehicle detects that you are
driving uphill or downhill.
To upshif t, pull the (right) paddle
shif ter. To downshif t, pull the
(lef t) paddle shif ter.
When you accelerate f rom a stop,
the transmission starts in f irst gear,
and shif ts f rom f irst to second
automatically. You must manually
upshif t between second and sixth
gears. Make sure you upshif t bef ore
the engine speed reaches the
tachometer’s red zone.
The transmission remains in the
selectedgear(6,5,4,3,or2).There
is no automatic downshif t when you
push the accelerator pedal to the
f loor.
Driving with the Paddle Shif ters
410
10/08/04 19:54:06 31SJA660_415
ProCarManuals.com

´Drive in the highest gear that lets
the engine run and accelerate
smoothly. This will give you good
f uel economy and ef f ective
emissions control. The f ollowing
shif t points are recommended:
When you are in sequential shif t
mode, and the vehicle is stopped,
pull the (right) paddle shifter to
shif t to second gear. You will see
‘‘M2’’ in the display. Starting in
second gear helps to reduce
wheelspin in deep snow or on a
slippery surf ace.
You pull both paddle shif ters at
thesametime.
You pull one of the two paddle
shifters with another paddle
shif ter being pressed.
Shif t up
1st to 2nd
2nd to 3rd 3rd to 4th4th to 5th
5th to 6th Normal acceleration
15 mph (24 km/h)
25 mph (40 km/h)
40 mph (64 km/h)
45 mph (72 km/h)
50 mph (81 km/h)
Driving with the Paddle Shif ters
Recommended Shif t Point s
St art ing in Second Gear
Driving
411
10/08/04 19:54:15 31SJA660_416
ProCarManuals.com

µ
µ
The super handling-all wheel drive
(SH-AWD) system is a f ull time all-
wheel-drive system that
automatically controls and transfers
varying amounts of engine torque to
all wheels independently, according
to the driving conditions.
While the SH-AWD system helps to
enhance the vehicle’s driving
stability in all situations, it is still
your responsibility to drive and
corner at reasonable speeds and to
leave a sufficient margin of safety.
The SH-AWD torque distribution
monitor on the multi-inf ormation
display shows you the amount of
torque being sent to the wheels.
Each wheel right f ront (RF), lef t
front(LF),rightrear(RR),andleft
rear (LR) has its own torque
indicator.Each torque indicator is displayed as
a bar graph divided into 5 segments.
The number of segments represents
the amount of torque distributed to
each wheel.
When there is only a slight change in
torque distribution while driving,
such as cruising on level roads at the
same speed, the torque distribution
monitor may stop displaying the
amount of torque. This is not a
system problem. The monitor will
show the amount if the system
senses any change in torque
distribution.
Super Handling-A ll Wheel Drive (SH-A WD)System
SH-AWD T orque Distribution
Monitor
412
TORQUE INDICATOR
TORQUE INDICATOR
TM
10/08/04 19:54:24 31SJA660_417
ProCarManuals.com

If the SH-AWD indicator blinks while
driving, it indicates the dif f erential
temperature is too high. You will also
see an ‘‘SH-AWD DIFF TEMP.
HIGH’’ message on the multi-
inf ormation display. If this happens,
pull to the side of the road when it is
saf e, shif t to Park, and let the engine
idle until the indicator goes out. If
the indicator does not go out, take
your vehicle to a dealer to have it
checked.If the SH-AWD indicator on the
instrument panel stays on, and the
‘‘CHECK SH-AWD SYSTEM’’
message also appears on the multi-
inf ormation display, there is problem
with the SH-AWD system.
Your vehicle still has normal f ront-
wheel drive with vehicle stability
assist (VSA), but does not have the
advantages of SH-AWD. Have your
vehicle checked by a dealer as soon
as possible.
Super Handling-A ll Wheel Drive (SH-A WD)System
Driving
413
TM
10/08/04 19:54:29 31SJA660_418
ProCarManuals.com

Always use the parking brake when
you park your vehicle. Make sure
the parking brake is set f irmly or
your vehicle may roll if it is on an
incline.
Set the parking brake bef ore you put
the transmission in Park. This keeps
the vehicle from moving and putting
pressure on the parking mechanism
in the transmission.Make sure the moonroof and the
windows are closed.
Turn of f the lights.
Place any packages, valuables, etc.,
in the trunk or take them with you.
Lock the doors.
Never park over dry leaves, tall
grass, or other f lammable
materials. The hot three way
catalytic converter could cause
these materials to catch on fire.
If the vehicle is f acing uphill, turn
the front wheels away from the
curb.
If the vehicle is f acing downhill,
turn the front wheels toward the
curb.Check the indicator on the
instrument panel to verif y that the
security system is set.
Make sure the parking brake is
f ully released bef ore driving away.
Driving with the parking brake
partially set can overheat or
damage the rear brakes.
Parking T ips
Parking
414
10/08/04 19:54:41 31SJA660_419
ProCarManuals.com
