ACURA RL 2011 Owners Manual

ÎÎ
Î
Fluid Locations
Maint enance
455
ENGINE OIL DIPSTICK
(Orange loop)WASHER FLUID
(Black cap)
POWER STEERING FLUID
(Red cap)
ENGINE COOLANT
RESERVOIR BRAKE FLUID
(Black cap)
ENGINE OIL
FILL CAP
AUTOMATIC
TRANSMISSION
FLUID DIPSTICK
(Yellow loop)
RADIATOR CAP
: Located under the cover.
10/09/08 21:19:03 31SJA660_460
ProCarManuals.com

The component parts in the engine
compartment are protected by
several covers. You may need to
remove the covers when you
perf orm some simple maintenance
work.
All of the covers are secured by
holding clips.
To remove the battery cover, turn
the knob of the f astener and remove
the holding clips by pushing on the
center of each f astener head.
To remove the f ront bulkhead cover:Remove the battery cover.
Remove the holding clips by
pushingonthecenterof each
f astener head.
1.
2.
Engine Compartment Covers
456
FRONT BULKHEAD COVER
BATTERY COVER
:
: CLIPS
KNOB
Push to remove clip
Push to reset/install clip CLIPS
Unlock
Lock
CLIPS
10/09/08 21:19:11 31SJA660_461
ProCarManuals.com

To remove the lef t engine
compartment cover:
To remove the right engine
compartment cover:Remove the battery and front
bulkhead covers (see page ).
Remove the holding clips by
pushingonthecenterof each
f astener head.
Take the windshield washer hose
out f rom the holder on the bottom
side of the cover.
When reinstalling the covers, make
sure the pins and tabs are in their
proper positions. Remove the holding clips by
pushingonthecenterof each
f astener head. Remove the battery cover (see
page ).
1.
2.
1.
2.
3. 492
456
Engine Compartment Covers
Maint enance
457
RIGHT ENGINE COMPARTMENT LEFT ENGINE COMPARTMENT
:
: Push to remove clip
Push to reset/install clip CLIPS CLIPS
CLIP
10/09/08 21:19:19 31SJA660_462
ProCarManuals.com

Install the engine oil f ill cap, and
tighten it securely. Wait a f ew
minutes, and recheck the oil level.
Do not f ill above the upper mark; you
could damage the engine. Unscrew and remove the engine oil
fill cap on top of the valve cover.
Pour in the oil slowly and caref ully so
you do not spill any. Clean up any
spills immediately. Spilled oil could
damage components in the engine
compartment.Oil is a major contributor to your
engine’s perf ormance and longevity.
Always use a premium-grade 5W-20
detergent oil displaying the API
Certif ication Seal. This seal indicates
the oil is energy conserving, and that
it meets the American Petroleum
Institute’s latest requirements.
Acura Motor Oil is the pref erred
5W-20 lubricant f or your vehicle. It is
highly recommended that you use
Acura Motor Oil in your vehicle f or
optimum engine protection. Make
sure the API Certif ication Seal says
‘‘For Gasoline Engines.’’
The oil viscosity or weight is
provided on the container’s label.
5W-20 oil is f ormulated f or year-
round protection of your vehicle to
improve cold weather starting and
f uel economy.
Recommended Engine Oil
A dding Engine Oil
458
API CERTIFICATION SEAL
ENGINE OIL FILL CAP
Ambient Temperature
10/08/04 20:02:01 31SJA660_463
ProCarManuals.com

Your vehicle does not require any oil
additives. Additives may adversely
af f ect the engine or transmission
perf ormance and durability.Open the hood, and remove the
engine oil f ill cap. Remove the oil
drain bolt and washer f rom the
bottom of the engine. Drain the oil
into an appropriate container.
Run the engine until it reaches
normal operating temperature,
then shut it off.
Always change the oil and f ilter
according to the maintenance
messages shown on the multi-
inf ormation display. The oil and f ilter
collect contaminants that can
damage your engine if they are not
removed regularly.
You may use a synthetic motor oil if
it meets the same requirements
given f or a conventional motor oil: it
displays the API Certif ication Seal
and it is the proper weight. You must
f ollow the oil and f ilter change
intervals shown on the multi-
inf ormation display.
Changing the oil and f ilter requires
special tools and access f rom
underneath the vehicle. The vehicle
should be raised on a service station-
type hydraulic lif t f or this service.
Unless you have the knowledge and
proper equipment, you should have
this maintenance done by a skilled
technician.
1.2.
CONT INUED
Synthetic Oil
Engine Oil A dditivesChanging the Engine Oil and
Filter
A dding Engine Oil, Changing the Engine Oil and Filter
Maint enance
459
OIL DRAIN BOLT WASHER
10/08/04 20:02:11 31SJA660_464
ProCarManuals.com

Remove the oil f ilter, and let the
remaining oil drain. A special
wrench (available from your
dealer) is required.
Make sure the oil f ilter gasket is
not stuck to the contacting surface
of the engine. If it is, remove it
bef ore installing a new oil f ilter.Let the engine run f or several
minutes, then check the drain bolt
and oil f ilter f or leaks.
Turn of f the engine and let it sit
f or several minutes, then check
the oil level on the dipstick. If
necessary, add more oil.
Install a new oil f ilter according to
the instructions that come with it.
Make sure to clean of f any dirt
and dust on the contacting surf ace
of a new oil f ilter.
Put a new washer on the drain bolt,
then reinstall the drain bolt.
Tighten the drain bolt to:
Refill the engine with the
recommended oil.
Engine oil change capacity
(including f ilter):
Reinstall the engine oil f ill cap.
Start the engine. The oil pressure
indicator should go out within 5
seconds. If it does not, turn of f the
engine and check your work.
3.
6.
7.8.
9.
5. 4.
Changing the Engine Oil and Filter
460
OIL FILTER
29 lbf·ft (39 N·m , 4.0 kgf·m)
4.5 US qt (4.3
) Improper disposal of engine oil can be
harmf ul to the environment. If you
change your own oil, please dispose of
the used oil properly. Put it in a sealed
container, and take it to a recycling
center. Do not discard it in a trash bin
or dump it on the ground.
10/08/04 20:02:25 31SJA660_465
ProCarManuals.com

If the coolant level in the reserve
tank is at or below the MIN line, add
coolant to bring it up to the MAX line.
Inspect the cooling system f or leaks.If the reserve tank is completely
empty, you should also check the
coolant level in the radiator.
If Honda antif reeze/coolant is not
available, you may use another
major-brand non-silicate coolant as a
temporaryreplacement.Makesureit
is a high-quality coolant
recommended f or aluminum engines.
Continued use of any non-Honda
coolant can result in corrosion,
causing the cooling system to
malf unction or f ail. Have the cooling
system f lushed and ref illed with
Honda antif reeze/coolant as soon as
possible. Always use Honda Long-lif e Anti-
f reeze/Coolant Type 2. This coolant
is pre-mixed with 50 percent
antif reeze and 50 percent distilled
water. Never add straight antif reeze
or plain water.
CONT INUED
A dding Engine Coolant
Engine Coolant
Maint enance
461
RESERVE TANK
Removing the radiator cap
while the engine is hot can
cause the coolant to spray out,
seriously scalding you.
Always let the engine and
radiator cool down before
removing the radiator cap.
10/08/04 20:02:36 31SJA660_466
ProCarManuals.com

When the radiator and engine are
cool, relieve any pressure in the
cooling system by turning the
radiator cap counterclockwise,
without pressing down.
Remove the radiator cap by
pushing down and turning
counterclockwise.
Lift up the lid on the front
bulkhead cover f rom the f ront. The coolant level should be up to
the base of the f iller neck. Add
coolant if it is low.
Pourthecoolantslowlyand
caref ully so you do not spill any.
Clean up any spill immediately; it
could damage components in the
engine compartment.
Put the radiator cap back on, and
tighten it fully.
3. 2.
1. 4.
5.
Engine Coolant
462
LID
RADIATOR CAP
10/08/04 20:02:45 31SJA660_467
ProCarManuals.com

Do not add any rust inhibitors or
other additives to your vehicle’s
cooling system. They may not be
compatible with the coolant or
engine components.Check the f luid level in the
windshield washer reservoir at least
monthly during normal use.
If the washer f luid is low, a
‘‘WASHER FLUID LOW’’ message
appears on the multi-information
display.
Fill the reservoir with a good-quality
windshield washer f luid. This
increases the cleaning capability and
prevents f reezing in cold weather.
Reinstall the lid. Pour coolant into the reserve tank.
Fill it to half way between the MAX
and MIN marks. Put the cap back
on the reserve tank.
6.
7.
CONT INUED
Windshield Washers
Engine Coolant, Windshield Washers
Maint enance
463
RESERVE TANK
10/08/04 20:02:55 31SJA660_468
ProCarManuals.com

Check the f luid level with the engine
at normal operating temperature.Remove the dipstick (yellow loop)
f rom the transmission, and wipe it
with a clean cloth.
Park the vehicle on level ground.
Start the engine, let it run until the
radiator f an comes on, then shut
of f the engine. For accurate
results, wait about 60 seconds (but
no longer than 90 seconds) bef ore
doing step 2.
When you ref ill the reservoir, clean
the edges of the windshield wiper
blades with windshield washer f luid
on a clean cloth. This will help to
condition the blade edges. 1.
2.
Windshield Washers, A utomatic T ransmission Fluid
Automatic Transmission Fluid
464
DIPSTICK
Do not use engine antif reeze or a
vinegar/water solution in the
windshield washer reservoir. Antif reeze
can damage your vehicle’s paint, while
a vinegar/water solution can damage
the windshield washer pump. Use only
commercially-available windshield
washer f luid.
