The ventilation system draws in
outside air, circulates it through the
interior, then releases it through
vents near the rear window.The heater uses engine coolant to
warm the air. If the engine is cold, it
will be several minutes bef ore you
f eel warm air coming f rom the
system.
Select and fresh air mode.
Set the f an to the desired speed.
Adjust the warmth of the air with
the temperature control bar.
Air conditioning places an extra load
on the engine. Watch the engine
coolant temperature gauge (see page
). If it moves near the red zone,
turn of f the A/C until the gauge
reading returns to normal.
you can
cool it down more rapidly by partially
opening the windows, turning on the
air conditioning, and setting the fan
to maximum speed in f resh air mode. Set the temperature to the lower
limit.
Make sure the A/C is of f .
Select and fresh air mode.
Set the f an to the desired speed.Press the A/C button to view the
climate control display.
Turn on the A/C by pushing
ENTER on the interf ace selector.
You will see A/C ON in the display.
Make sure the temperature is set
to maximum cool.
Select .
If the outside air is humid, select
recirculation mode. If the outside
air is dry, select f resh air mode.
Set the f an to the desired speed by
turning the interface knob. 1.
2.
3.
4.1.
2.
3.1.
2.
3.
4.
5.
6.
70
If the interior is very warm,
Climat e Cont rol Syst em
Ventilation Using the Heater
Using the A /C
Features
209
11/07/20 18:26:54 31SJA670_214
ProCarManuals.com

Air conditioning, as it cools, removes
moisture from the air. When used in
combination with the heater, it
makes the interior warm and dry.
Switch the f an on.
Turn on the air conditioning.
Select and fresh air mode.
Adjust the temperature to your
pref erence.
This setting is suitable f or all driving
conditions whenever the outside
temperature is above 32°F (0°C).To remove f og f rom the inside of the
windows:
Set the f an to the desired speed, or
high f or f aster def rosting.
Select . The system
automatically switches to f resh air
mode and turns on the A/C.
Adjust the temperature so the
airf low f eels warm.
Select to help clear the
rear window.
To increase airf low to the
windshield, close the corner vents.
When you switch to another mode
from , the A/C setting
returns to the previous setting (on or
of f ). Select A/C, then press ENTER
on the interface selector to turn the
A/C of f if it is on.Select . The system
automatically switches to fresh air
mode and turns on the A/C.
Select .
Set the f an and temperature
controls to maximum level.
To clear the windshield f aster, you
can close the dashboard corner vents
by rotating the wheel next to it. This
sends more warm air to the
windshield def roster vents. Once the
windshield is clear, select the f resh
air mode to avoid fogging the
windows.
For your saf ety, make sure you have
a clear view through all the windows
bef ore driving. 1.
2.
3.
4.1.
2.
3.
4.
5.1.
2.
3.
Climat e Cont rol Syst em
Dehumidif y the Interior T o Def og and Def rost T o Remove Exterior Frost or Ice
From the Windows
210
11/07/20 18:27:04 31SJA670_215
ProCarManuals.com

The automatic climate control
system adjusts the f an speed and
airflow levels to maintain the interior
temperature you select.
In AUTO mode, the vehicle’s interior
temperature is independently
regulated f or the driver and
passenger. If the driver’s side of the
vehicle is getting too much sun, the
system will adjust to a lower
temperature.
Press the AUTO button.
Set the desired temperature with
the temperature control bars.
You will see AUTO in the display
if theclimatemodeisselected.
The system automatically selects the
proper mix of conditioned and/or
heated air that will, as quickly as
possible, raise or lower the interior
temperature to your pref erence.When you set the temperature to its
lower or its upper limit, the system
runs at f ull cooling or heating only. It
does not regulate the interior
temperature.
When you change the f an speed, the
f an is taken out of AUTO mode and
starts to run at the selected speed.
You can manually select various
f unctions of the climate control
system when it is in f ully automatic
mode. All other f eatures remain
automatically controlled. Making any
manual selection causes the word
AUTO in the display to go out.The airf low f rom the rear vents can
be adjusted when the f an mode is in
the or position.
You can adjust the direction of the
airflowbymovingthetaboneach
vent up-and-down and side-to-side.
You can also open or close the vents
with the dial between them.
Press the OFF button. However, a
lack of airf low can cause the
windowstofogup.Youshouldkeep
the fan on at all times so stale air and
moisture do not build up in the
interior and cause f ogging. 1.
2.
Climat e Cont rol Syst em
Automatic Climate Control
Semi-automatic OperationRear Ventilation
To Turn Everything Of f
Features
211
11/07/20 18:27:15 31SJA670_216
ProCarManuals.com

Close the windows and the
moonroof .
The f an speed will be
automatically adjusted to low.
Make sure the airf low f rom the
A/C vents does not interf ere with
the system microphone in the
ceiling console. Place your hand
over the microphone; if you f eel
any airf low, adjust the vents.
After pressing the button,
wait f or the beep, then give a voice
command.
Give a voice command in a clear,
natural speaking voice without
pausing between words. To achieve optimum voice
recognition, the f ollowing guidelines
should be f ollowed:
Make sure the correct screen
is displayed f or the voice command
that you are using. See Voice
Command Index on page . When you speak a command, the
system generally either repeats the
command as a confirmation or asks
you f or f urther inf ormation. If you do
not wish to hear this f eedback, you
canturnitoff.Seethe
setting in
Setup (see page ).
If you hear a prompt such as ‘‘Please
use the interf ace dial to...’’ or ‘‘Please
choose an area with the interf ace
dial.’’ the system is asking f or input
thatcannotbedonebyvoice.307 296
Talk Improving Voice Recognition
Voice
Recognition Feedback
Compass Syst em (U.S. model wit hout navigat ion syst em)
306
NOTE:
11/07/20 18:39:42 31SJA670_311
ProCarManuals.com

µ
µ
Bluetooth
www.acura.com/
handsf reelink
www.handsfreelink.ca,HandsFreeLink(HFL)
allows you to place and receive
phone calls using voice commands,
without handling your cell phone.
To use HFL, you need a Bluetooth-
compatible cell phone. For a list of
compatible phones, pairing
procedures, and special f eature
capabilities:
In the U.S., visit
, or call (888) 528-7876.
Press and
release to give a command or answer
a call.
Press and
release to end a call, go back to the
previous command, or cancel the
command.Airorwindnoisefromthe
dashboard and side vents and all
windows may interfere with the
microphone. Adjust or close them
as necessary. In Canada, visit
or call (888) 528-7876.
BluetoothHandsFreeL ink
Using HFL
HFL Talk button
HFL Back button
HFL ButtonsVoice Cont rol T ips
354
HFL TALK
BUTTON
HFL BACK
BUTTON
NAVI VOICE CONTROL
BUTTONSMICROPHONE
(on the ceiling)
11/07/20 18:45:59 31SJA670_359
ProCarManuals.com

Bef ore installing any accessory:
Make sure the accessory does not
obscure any lights, or interf ere
with proper vehicle operation or
perf ormance. Modif ying your vehicle, or installing
non-Acura accessories, may make
your vehicle unsaf e. Bef ore you
make any modif ications or add any
accessories,besuretoreadthe
f ollowing inf ormation.
Your dealer has Acura accessories
that allow you to personalize your
vehicle. These accessories have
been designed and approved f or your
vehicle, and are covered by warranty.Be sure electronic accessories do
not overload electrical circuits
(see page ) or interf ere with
the proper operation of your
vehicle.
Do not install accessories on the
side pillars or across the rear
windows. Accessories installed in
theseareasmayinterferewith
proper operation of the side
curtain airbags. When properly installed, cellular
phones, alarms, two-way radios, and
low-powered audio systems should
not interf ere with your vehicle’s
computer controlled systems, such
as your airbags, anti-lock brakes, and
tire pressure monitoring system. Although non-Acura accessories may
f it on your vehicle, they may not
meet f actory specif ications, and
could adversely af f ect your vehicle’s
handling, stability, and reliability.Bef ore installing any electronic
accessory, have the installer
contact your dealer for assistance.
If possible, have your dealer
inspect the f inal installation.512 A ccessories
A ccessories and Modif ications
Bef ore Driving
391
Improper accessories or
modifications can affect your
vehicle’s handling, stability, and
performance, and cause a
crash in which you can be hurt
or killed.
Follow all instructions in this
owner’s manual regarding
accessories and modifications.
11/07/20 18:51:49 31SJA670_396
ProCarManuals.com

Store or secure all items that could
be thrown around and hurt
someone during a crash.
Do not put any items on top of the
rear shelf . They can block your
view and be thrown around the
vehicle during a crash.
Be sure items placed on the f loor
behind the f ront seats cannot roll
underneath and interf ere with the
proper operation of the seats, the
sensors under the seats, or the
driver’s ability to operate the
pedals.Distribute cargo evenly on the
f loor of the trunk, placing the
heaviest items on the bottom and
as far forward as possible.
If you carry large items that
prevent you f rom closing the trunk
lid, exhaust gas can enter the
passenger area. To avoid the
possibility of
, f ollow the instructions
on page .
If you carry any items on a roof
rack,besurethetotalweightof
the rack and the items does not
exceed 121 lbs (55 kg).
If you use an accessory roof rack,
the roof rack weight limit may be
lower. Ref er to the inf ormation
that came with your roof rack. Keep the glove box closed while
driving. If it is open, a passenger
could injure their knees during a
crash or sudden stop.
Keep all cargo below the bottom
of the windows. If it is higher, it
could interf ere with the proper
operation of the side curtain
airbags.56 Carrying Items in the Passenger
CompartmentCarrying Cargo in the T runk or on
a Roof Rack
carbon monoxide
poisoning
Carrying Cargo
396
11/07/20 18:52:31 31SJA670_401
ProCarManuals.com

Make sure all windows, mirrors,
and outside lights are clean and
unobstructed. Remove f rost, snow,
or ice.
Check that the hood is f ully closed.
Check that any items you may be
carrying are stored properly or
f astened down securely.Check the seat adjustment (see
page ).
Check the steering wheel
adjustment (see page ).
Make sure the doors and the
trunk are securely closed and
locked.
Fasten your seat belt. Check that
your passengers have f astened
their seat belts (see page ). Youshoulddothefollowingchecks
and adjustments bef ore you drive
your vehicle.
When you start the engine, check
the gauges and indicators in the
instrument panel, and the
messages on the multi-inf ormation
display (see pages , and
). Check the adjustment of the
inside and outside mirrors (see
page ).
Visually check the tires. If a tire
looks low, use a gauge to check its
pressure. 1.
2.
3.
4.5.
6.
7.
8.
9.
10.17
7861 70 156
148 161
Preparing to Drive
400
11/07/20 18:52:53 31SJA670_405
ProCarManuals.com

Always use the parking brake when
you park your vehicle. Make sure
the parking brake is set f irmly or
your vehicle may roll if it is on an
incline.
Set the parking brake bef ore you put
the transmission in Park. This keeps
the vehicle from moving and putting
pressure on the parking mechanism
in the transmission.Make sure the moonroof and the
windows are closed.
Turn of f the lights.
Place any packages, valuables, etc.,
in the trunk or take them with you.
Lock the doors.
Never park over dry leaves, tall
grass, or other f lammable
materials. The hot three way
catalytic converter could cause
these materials to catch on fire.
If the vehicle is f acing uphill, turn
the f ront wheels away f rom the
curb.
If the vehicle is f acing downhill,
turn the front wheels toward the
curb.Check the indicator on the
instrument panel to verif y that the
security system is set.
Make sure the parking brake is
f ully released bef ore driving away.
Driving with the parking brake
partially set can overheat or
damage the rear brakes. Parking T ips
Parking
414
11/07/20 18:54:43 31SJA670_419
ProCarManuals.com

µ
Check the condition of the battery
monthlybylookingatthetest
indicator window. The label on the
battery explains the test indicator’s
colors.Battery posts,
terminals, and related accessories
contain lead and lead compounds. Check the terminals f or corrosion (a
white or yellowish powder). To
remove it, cover the terminals with a
solution of baking soda and water. It
will bubble up and turn brown. When
this stops, wash it of f with plain
water. Dry off the battery with a
cloth or paper towel. Coat the
terminals with grease to help prevent
f uture corrosion.
If additional battery maintenance is
needed, see your dealer or a
qualif ied technician.If you need to connect the battery to
a charger, disconnect both cables to
prevent damaging your vehicle’s
electrical system. Always disconnect
the negative ( ) cable first, and
reconnect it last.
To see the label, remove the battery
cover (see page ).492WARNING:
Wash your hands af ter handling.
Checking the Battery
490
TEST INDICATOR WINDOW
The battery gives off explosive
hydrogen gas during normal
operation.
A spark or flame can cause the
battery to explode with enough
force to kill or seriously hurt you.
Wear protective clothing and a
face shield, or have a skilled
technician do the battery
maintenance.
11/07/20 19:04:41 31SJA670_495
ProCarManuals.com
