clock ACURA RL 2012 Owners Manual

All doors can be locked f rom the
outsidebyusingthebuilt-inkeyin
the driver’s door. To unlock only the
driver’s door, insert the built-in key,
turn it clockwise, and release it. The
remaining doors unlock when you
turn the built-in key a second time
within a f ew seconds.
Each f ront door has a power door
lock master switch. Either switch
locks and unlocks all doors. Push the
switch down to lock all doors and up
to unlock them.To change the ‘‘DOOR UNLOCK
MODE’’ setting, see page .
When the vehicle speed reaches
about 10 mph (15 km/h) or more, all
the doors lock automatically.When you shif t to P af ter driving, the
driver’s door unlocks.
To change the ‘‘AUTO DOOR
UNLOCK’’ setting, see page .
With the driver’s door open and the
built-in key in the ignition, both
master door lock switches are
disabled. They are not disabled if the
driver’s door is closed. Pushing the
switch down on the open f ront
passenger’s door will lock all doors.
If you try to lock an open driver’s
door by pulling the lock tab rearward
withtheremoteinsidethevehicle
and closing the driver’s door, the
driver’s door will unlock.
To change the ‘‘AUTO DOOR
LOCK’’ setting, see page . Each door has a lock tab above the
inside door handle. Pull the tab
rearward to lock the door and push it
f orward to unlock. When you pull the
tabrearwardonthedriver’sdoor,all
the doors lock.To lock any door when getting out of
the vehicle, pull the lock tab
rearward and close the door.
109125
123
L ockout Prevent ion
Door L ocks
Inst rument s and Cont rols
153
POWER DOOR LOCK
MASTER SWITCH
11/07/20 18:19:04 31SJA670_158
ProCarManuals.com

The rear seat armrest is in the
center of the rear seat. Pivot it down
to use it.To open the cover, pull down the
rear seat armrest. Pull on the tab at
the top of the inner partition, and
press on the button to f ully release
the cover. To close the cover, swing
it up, and push f irmly on the top.
Make sure it latches properly.Make sure all items in the trunk and
those extending through the pass-
through are secured.
For security, this cover can be
locked and unlocked only with the
built-in key. To lock the cover, insert
thekey,andturnitclockwise.
Never drive with this cover open and
the trunk lid open.
See on
page .
A beverage holder is located in the
armrest.56 Rear Seat Armrest Trunk Pass-through Cover
Carbon Monoxide Hazard
Seats
160
BUTTON
LOCK
INNER PARTITION
11/07/20 18:20:06 31SJA670_165
ProCarManuals.com

You can open and close the windows
and moonroof with the built-in key in
the driver’s door lock.
To open:
Insert the built-in key in the driver’s
door lock.
Turn the key clockwise, then
release it. Press the UNLOCK button a
second time, and hold it. All the
doors unlock, and all f our windows
and moonroof start to open. To
stop the windows and moonroof ,
release the button.
To open the windows and
moonroof f urther, press the
button again (within 10 seconds of
step 1) and hold it. If the windows
and the moonroof stop bef ore the
desired position, repeat steps 1
and 2.
You cannot close the windows or the
moonroof with the remote. You can open all of the windows and
the moonroof f rom outside with the
remote.
Press the UNLOCK button once
to unlock the driver’s door.
1.
2. 2.
3.
1.
Power Windows
Opening/Closing the Windows
and Moonroof with the Built-in
Key Opening the Windows and
Moonroof with the Remote
188
Open
Close UNLOCK BUTTON
11/07/20 18:24:15 31SJA670_193
ProCarManuals.com

CONT INUED
Turn the ignition switch to the ON
(II) position bef ore operating the
moonroof switch on the ceiling
console. To open the moonroof , pull
back the moonroof switch. To close
the moonroof , push the moonroof
switch f orward. Release the switch
to stop the moonroof . To close the windows and the
moonroof f urther, turn and hold
the key again (within 10 seconds
of step 2).
If the windows and the
moonroof stop bef ore the desired
position, repeat steps 2 and 3. Turn the built-in key clockwise
again, and hold it. All four
windows and the moonroof start to
open. To stop the windows and
moonroof , release the built-in key.
To open the windows and the
moonroof f urther, turn and hold
the key again (within 10 seconds
of step 2).
To close:
Insert the built-in key in the driver’s
door lock.
Turn the key counterclockwise,
then release it.
Turn the key counterclockwise
again, and hold it. All four
windows and the moonroof start to
close. To stop the windows and
the moonroof , release the key.4.
4. 3.
1.
2.
3.
Power Windows, Moonroof
Opening/Closing the Moonroof
with the Ceiling Console Switch
Inst rument s and Cont rols
189
NOTE:
MOONROOF SWITCH
Open
CloseTilt
11/07/20 18:24:25 31SJA670_194
ProCarManuals.com

The climate control system in your
vehicle provides a comfortable
driving environment in all weather
conditions.
The standard audio system has
many f eatures. This section
describes those f eatures and how to
use them.
Theclimatecontrolsystemandthe
audio system have a voice control
feature.
Your vehicle has an anti-theft audio
system that requires a code number
to enable it.
The security system helps to
discourage vandalism and thef t of
your vehicle................ Climate Control System . 204
.............. Climate Control Sensors . 212
................................ Audio System . 213
...... Playing the AM/FM Radio . 214
.... AM/FM Radio Frequencies . 224
........ AM/FM Radio Reception . 224
................. Adjusting the Sound . 226
............ Playing the XM
Radio . 229
............................. Playing Discs . 236
....................... PlayinganiPod
. 247
Playing a USB Flash Memory
.................................... Device . 256
......... Playing
Audio . 265
... Disc Changer Error Messages . 271
................. iPod
Error Messages . 272
USB Flash Memory Device
........................ Error Messages . 273
.................. Protecting Your Discs . 274
...................... Auxiliary Input Jack . 277
................ Remote Audio Controls . 278
................. Radio Thef t Protection . 280
........................... Compass System . 281
................ Voice Control Basics . 304
...................... Setting the Clock . 313
............................ Security System . 315
............................... Cruise Control . 316.. Adaptive Cruise Control (ACC) . 319
HomeLink
Universal
................................ Transceiver . 334
.................................... AcuraLink
. 337
........
HandsFreeLink. 354
................ Backup Sensor System . 377
... Rearview Camera and Monitor . 380
BluetoothBluetooth
Features
Features
203
11/07/20 18:25:56 31SJA670_208
ProCarManuals.com

Turn the interf ace knob until the
unit you want to convert f rom is
highlighted (kilogram, f or
example), then press ENTER to
select it as it the example above.The set-up f unctions consist of three
dif f erent screens that allow you to
change and update inf ormation in
the system. To display the
, say ‘‘Set up’’ or press the
SET UP button, and then select an
item. To select more setup items, say
‘‘More,’’ or select at the top
right corner of the screen.
The f irst setup screen allows you to
change the system’s brightness,
contrast, black level, volume,
interf ace dial f eedback, and clock
adjustment. To select a setup item,
turn the interf ace knob until it is
highlighted, then press ENTER to
select it. 4.
CONT INUED
System Set-up
Set up
screen
MOREFirst Set up Screen
Compass Syst em (U.S. model wit hout navigat ion syst em)
Features
293
11/07/20 18:37:55 31SJA670_298
ProCarManuals.com

Interf ace Dial Feedback
On
Auto
(def ault)
NoThe system always
reads what you select.
The system reads your
selection only while
the vehicle is moving.
The system does not
read your selection.
Clock Adjustment
Changing this setting allows you to
controlwhen(andif)thesystemwill
read the current selection you
choose with the interf ace dial. This
feature can minimize the need to
look at the screen while operating
the dial. The three settings are
explained in the f ollowing table. The
f actory def ault setting is .You can adjust the clock of your
system. When the battery is
disconnected or the f use f or the
compass system is removed, you
need to reset the time. See page
f or more inf ormation on setting
the clock.
The second setup screen allows you
to change the system’s voice
recognition f eedback, auto volume
f or speed, and clock settings. To
select a setup item, turn the interf ace
knob until it is highlighted, then
press ENTER to select it. 313
CONT INUED
AUTO
Set t ing Feedback L evel
Second Set up Screen
Compass Syst em (U.S. model wit hout navigat ion syst em)
Features
295
11/07/20 18:38:17 31SJA670_300
ProCarManuals.com

To set the clock, the ignition switch
must be in the ACCESSORY (I) or
ON (II) position, and either or both
remotes must be linked.
Say ‘‘Set up’’ or press the SET UP
button on the center console to
display the . Then
move the interface dial to the right.
Select the , then
press ENTER. The display changes
to the screen for
HOUR. Select the by
turning the interface knob, then
press ENTER.
CONT INUED
Setting the Clock
Set up screen
T ime A djustment
T ime A djustment Clock A djustment
Compass Syst em (U.S. model wit hout navigat ion syst em)
Features
313
11/07/20 18:40:33 31SJA670_318
ProCarManuals.com

To adjust the hour, turn the interface
knob, then press ENTER.Turn the interface knob to adjust the
minute.
Press ENTER to set the time. The
screen will return to the
screen (see page ). To adjust the minute, push the
interf ace knob to the right to display
the adjustment screen f or MINUTE. 313
Compass Syst em (U.S. model wit hout navigat ion syst em)
Clock
adjustment
314
11/07/20 18:40:38 31SJA670_319
ProCarManuals.com

When the radiator and engine are
cool, relieve any pressure in the
cooling system by turning the
radiator cap counterclockwise,
without pressing down.
Remove the radiator cap by
pushing down and turning
counterclockwise. Lift up the lid on the front
bulkhead cover f rom the f ront.The coolant level should be up to
the base of the f iller neck. Add
coolant if it is low.
Pourthecoolantslowlyand
caref ully so you do not spill any.
Clean up any spill immediately; it
could damage components in the
engine compartment.
Put the radiator cap back on, and
tighten it fully.
3. 2. 1.4.
5.
Engine Coolant
462
LID
RADIATOR CAP
11/07/20 19:00:50 31SJA670_467
ProCarManuals.com
