windshield wipers ACURA RL 2012 Owners Manual

This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your vehicle. All the essential
controls are within easy reach.
........................... Control Locations . 60
............................ Instrument Panel . 61.......... Instrument Panel Indicators . 62
............................................. Gauges . 70
................... Temperature Gauge . 70
.................................. Fuel Gauge . 70
............. Multi-Inf ormation Display . 71
Controls Near the Steering
......................................... Wheel . 136
Windshield Wipers and
..................................... Washers . 137
....... Turn Signals and Headlights . 140
................................. Fog Lights . 142
......... Daytime Running Lights . 142
Automatic Lighting Off
................................... Feature . 143
Adaptive Front Lighting System
.......................................... (AFS) . 144
............... Hazard Warning Button . 146
...... Instrument Panel Brightness . 146
............... Rear Window Def ogger . 147
...... Steering Wheel Adjustments . 148
............................. Keys and Locks . 150
...................... Immobilizer System . 150
.............................. Ignition Switch . 152
.................................... Door Locks . 153
.............................................. Trunk . 154
...... Emergency Trunk Opener . 155................ Childproof Door Locks . 155
............................................... Seats . 156
........................................... Mirrors . 161
Driving Position Memory
........................................ System . 164
................ Keyless Access System . 167
....................... Front Seat Heaters . 182
Front Seat Heaters and Seat
................................. Ventilation . 183
Rear Seat Heaters
................... (Canadian models) . 185
............................ Power Windows . 186
....................................... Moonroof . 189
............................... Parking Brake . 191
......... Interior Convenience Items . 192
.................................. Glove Box . 193
..................... Beverage Holders . 194
............. Console Compartment . 195
.................................. Sun Visors . 196
............................ Vanity Mirror . 196
........ Accessory Power Sockets . 197
.................. Front Door Pockets . 198
.............. Power Rear Sunshade . 198
.............. Integrated Sunshades . 199
............................... Interior Lights . 200
Instruments and Controls
Inst rument s and Cont rols
59
11/07/20 18:07:19 31SJA670_064
ProCarManuals.com

µ
µ
µµ
µµ
µ
µ
MIST
OFF
INT Intermittent
LO Low speed
HI High speed
Windshield washersPush the right lever up or down to
select a position.
The wipers run at high
speed until you release the lever.
The wipers are not activated.The wipers run at low speed.
The wipers run at high speed.
The length of the wipe
interval is varied automatically
according to vehicle speed.
To change the ‘‘WIPER ACTION’’
setting, see page .
Vary the delay by turning the
adjustment ring. If you turn it to the
shortest delay ( position), the
wipers change to low speed
operation when the vehicle speed
exceeds 12 mph (20 km/h). 1.
2.
3.
4.
5.
6.134
CONT INUED
MIST
OFFLO
HI
INT
Windshield Wipers and Washers
Inst rument s and Cont rols
137
ADJUSTMENT RING
11/07/20 18:17:05 31SJA670_142
ProCarManuals.com

µPull back
and hold the wiper control lever.
The washers spray until you
release the lever. The wipers run
at low speed, then complete one
more sweep af ter you release the
lever.
The headlight washers can be
operated at any time by pressing the
headlight washer button located next
to the steering wheel column. The
headlights must be turned on to use
this button. In addition, the headlight
washer operates without pressing
the button at the first time you turn
on the windshield washers af ter you
turn the ignition switch to the ON
(II) position.The headlight washers use the same
f luid reservoir as the windshield
washers.
When you activate the windshield
washer with the headlights turned
on, the headlight washer will be
activated under certain conditions.
For more inf ormation, see
sectioninthenextcolumn.
On Canadian models
Windshield Wipers and Washers
Windshield Washer Headlight Washers
Headlight
WashersCanadian models only
138
HEADLIGHT WASHER BUTTON
11/07/20 18:17:12 31SJA670_143
ProCarManuals.com

The windshield wiper arms have two
parked positions: winter and summer.
In the winter position, the arms sit
slightly above the edge of the hood.
This reduces the possibility of
damage to the wiper arms or
windshield wiper motor by a build-up
of snow and ice.
A heavy build-up of snow or ice on
the wiper arms will cause them to
automatically park in the winter
position. Adjust the wiper arms to the winter
position by holding both arms as
shown in the illustration at the same
time. Pull on the arm, parallel to the
windshield, until it locks in the
higher position.To return to the summer position,
pushthesameareaof botharmsthe
other direction.
Windshield Wipers and Washers
Wiper A rm Posit ions
Inst rument s and Cont rols
139
WIPER ARMS
Winter positionWIPER ARMS
Summer position HOLDING LOCATIONSHOLDING LOCATIONS
11/07/20 18:17:19 31SJA670_144
ProCarManuals.com

Examine the new wiper blades. If
they have no plastic or metal
reinf orcement along the back
edge, remove the metal
reinf orcement strips f rom the old
wiper blade, and install them in
the slots along the edge of the new
blade.Slide the new wiper blade into the
holder until the tabs lock.
Reinstall the blade assembly to the
wiper arm and tighten the two
screws securely. Reinstall the
cover by pushing it in.
Set the wiper arms back on the
windshield. Adjust the windshield
wipers to their previously parked
position.
Remove the blade f rom its holder
by grabbing the tabbed end of the
blade. Pull up f irmly until the tabs
come out of the holder. 4. 5.6.
7.
8.
Wiper Blades
Maint enance
479
BLADE
BLADE
REINFORCEMENT
11/07/20 19:03:19 31SJA670_484
ProCarManuals.com
