uuBrakinguBrake System
386Driving
Your vehicle is equipped with disc brakes at all four wheels. A vacuum power assist
helps reduce the effort needed on the brake pedal. The brake assist system increases
the stopping force when you depress the brake pedal hard in an emergency
situation. The anti-lock brake system (ABS) helps you retain steering control when
braking very hard.2Brake Assist System P. 390
2Anti-lock Brake System (ABS) P. 389■
Foot Brake
1Foot Brake
Check the brakes after driving through deep water,
or if there is a buildup of road surface water. If
necessary, dry the brakes by lightly depressing the
pedal several times.
If you hear a continuous metallic friction sound when
applying the brakes, the brake pads need to be
replaced. Have the vehicle checked by a dealer.
Constantly using the brake pedal while going down a
long hill builds up heat, which reduces the brake
effectiveness. Apply engine braking by taking your
foot off the accelerator pedal and downshifting to a
lower gear.
Do not rest your foot on the brake pedal while
driving, as it will lightly apply the brakes and cause
them to lose effectiveness over time and reduce pad
life. It will also confuse drivers behind you.
Your vehicle is equipped with a hydraulic brake
booster that, under certain conditions, such as
braking at high altitudes, supplements the vacuum
power assist. When the hydraulic brake booster
activates, you may hear a motor sound and a slight
vibration in the pedal. This is normal.

390
uuBrakinguBrake Assist System
Driving
Brake Assist SystemDesigned to assist the driver by generating greater braking force when you depress
the brake pedal hard during emergency braking.■Brake assist system operation
Press the brake pedal firmly for more powerful braking.
When brake assist operates, the pedal may wiggle slightly and an operating noise
may be heard. This is normal. Keep holding the brake pedal firmly down.■
Brake Assist System

455
Continued
Handling the Unexpected
If a Tire Goes FlatTemporarily Repairing a Flat TireIf the tire has a large cut or is otherwise severely damaged, you will need to have the
vehicle towed. If the tire only has a small puncture, from a nail for instance, you can
use the temporary tire repair kit so that you can drive to the nearest service station
for a more permanent repair.
If a tire goes flat while driving, grasp the steering wheel firmly, and brake gradually
to reduce speed. Then stop in a safe place.
1.Park the vehicle on a firm, level, and non-slippery surface and apply the parking
brake.
2.Move the shift lever to
(P
.
3.Turn on the hazard warning lights and set the power mode to VEHICLE OFF
(LOCK).
■
Getting Ready to Temporarily Repair the Flat Tire
1Temporarily Repairing a Flat Tire
The kit should not be used in the following situations.
Instead, contact a dealer or a roadside assistant to
have the vehicle towed.•The tire sealant has expired.•More than two tires are punctured.•The puncture or cut is larger than 3/16 inch (4mm).•The tire side wall is damaged or the puncture is
outside the contact area.•Damage has been caused by driving with the tire
extremely under inflated.•The tire bead is no longer seated.•The rim is damaged.
Do not remove a nail or screw that punctured the
tire. If you remove it from the tire, you may not be
able to repair the puncture using the kit.NOTICEDo not use a puncture-repairing agent other than the
one provided in the kit that came with your vehicle. If
a different agent is used, you may permanently
damage the tire pressure sensor.
When the puncture is:
Kit Use
Smaller than 3/16 inch
(4 mm)
Yes
Larger than 3/16 inch
(4 mm)
No
Contact
Area
Instruction
Manual
Air Only Hose (Black)Speed Restriction Label Repair Notification Label Pressure Relief
ButtonInflator Switch
Selector Switch
SEALANT/AIR side Sealant/Air Hose (Clear)AIR ONLY side
Power Plug Pressure Gauge
Tire Sealant
Expiration Date
U.S. CanadaU.S. Canada

472Handling the Unexpected
Engine Does Not StartChecking the EngineIf the engine does not start, check the starter.
Starter condition
Checklist
Starter doesn’t turn or turns
over slowly.
The battery may be dead. Check
each of the items on the right and
respond accordingly.
Check for a message on the multi-information display.●If the To Start, Hold Remote Near Start Button message appears
2If the Keyless Access Remote Battery is Weak P. 473
uMake sure the keyless access remote is in its operating range.
2ENGINE START/STOP Button Operating Range P. 133
Check the brightness of the interior light.
Turn on the interior lights and check the brightness.●If the interior lights are dim or do not come on at all
2Battery P. 446
●If the interior lights come on normally
2 Fuses P. 485
The starter turns over normally
but the engine doesn’t start.
There may be a problem with the
fuse. Check each of the items on
the right and respond accordingly.Review the engine start procedure.
Follow its instructions, and try to start the engine again.
2 Starting the Engine P. 342
Check the immobilizer system indicator.
When the immobilizer system indicator is blinking, the engine cannot be started.
2Immobilizer System P. 128
Check the fuel level.
There should be enough fuel in the tank.
2 Fuel Gauge P. 94
Check the fuse.
Check all fuses, or have the vehicle checked by a dealer.
2Inspecting and Changing Fuses P. 489
If the problem continues:
2Emergency Towing P. 490
1Checking the Engine
If you must start the vehicle immediately, use an
assisting vehicle to jump start it.
2Jump Starting P. 475

476
uuJump Startingu
Handling the Unexpected
5.Connect the other end of the second
jumper cable to the engine hanger as
shown.
Do not connect this jumper cable to any
other part.
6.If your vehicle is connected to another
vehicle, start the assisting vehicle’s engine
and increase its rpm slightly.
7.Attempt to start your vehicle’s engine. If it
turns over slowly, check that the jumper
cables have good metal-to-metal contact.

Index
510Index
Index
AAAC.................................................... 225, 249
ABS (Anti-lock Brake System)................... 389
Accessories and Modifications................. 406
Accessory Power Sockets.......................... 167
AcuraLink.................................................. 327
Adaptive Cruise Control (ACC) with Low
Speed Follow (LSF)............................ 81, 355
Additives
Coolant ................................................... 424
Engine Oil ................................................ 419
Washer .................................................... 427
Additives, Engine Oil................................ 419
Adjusting
Armrest ................................................... 158
Front Seats .............................................. 152
Head Restraints........................................ 155
Mirrors .................................................... 149
Steering Wheel ........................................ 148
Temperature .............................................. 99
Agile Handling Assist System................... 377
Aha
TM Menu.............................................. 248
AhaTM Radio.............................................. 259
Air Conditioning System (Climate Control
System).................................................... 177
Changing the Mode ................................ 180
Defrosting the Windshield and
Windows ............................................... 183
Dust and Pollen Filter ............................... 448
Rear Temperature Control Dial................. 184
Sensors .................................................... 185Using Automatic Climate Control ............ 177
Air Pressure....................................... 438, 497
Airbags........................................................ 37
Advanced Airbags ..................................... 43
Airbag Care............................................... 51
Driver’s Knee Airbag.................................. 44
Event Data Recorder .................................. 22
Front Airbags (SRS) .................................... 40
Indicator.............................................. 49, 74
Passenger Airbag Off Indicator .................. 50
Sensors ..................................................... 37
Side Airbags .............................................. 46
Side Curtain Airbags.................................. 48
AM/FM Radio............................................ 217
Anti-lock Brake System (ABS).................. 389
Indicator.................................................... 74
Armrest..................................................... 158
Audio Remote Controls........................... 192
Audio System............................................ 188
Adjusting the Sound................................ 207
Auxiliary Input Jack.................................. 190
Error Messages ........................................ 254
General Information ................................ 260
HDD ........................................................ 228
Internet Radio ......................................... 246
iPod®....................................................... 238
MP3/WMA/AAC .............................. 225, 249
Reactivating ............................................ 191
Recommended CDs ................................. 261
Recommended Devices............................ 263
Remote Controls ..................................... 192Security Code ......................................... 191
Shortcuts ................................................ 195
Theft Protection ...................................... 191
USB Flash Drives...................................... 263
USB Port ................................................. 189
Authorized Manuals................................ 505
Auto Door Locking/Unlocking................ 124
Customize ...................................... 108, 277
Automatic Brake Hold............................. 387
Indicator ........................................... 70, 387
Automatic Brake Hold System
Indicator ........................................... 69, 387
Automatic Lighting.................................. 138
Automatic Transmission.......................... 346
Creeping................................................. 346
Fluid ....................................................... 426
Kickdown ............................................... 346
Operating the Shift Lever .................. 15, 348
Shift Lever Does Not Move ...................... 478
Shifting ................................................... 347
Auxiliary Input Jack................................. 190
Average Fuel Economy.............................. 99
Average Speed......................................... 100
BBattery...................................................... 446
Charging System Indicator ................ 71, 481
Jump Starting ......................................... 475
Maintenance (Checking the Battery) ....... 446
Maintenance (Replacing) ......................... 447

511Index
Belts (Seat).................................................. 30
Beverage Holders..................................... 166
Blind Spot Information (BSI) System....... 378
Bluetooth® Audio..................................... 252
Bluetooth® HandsFreeLink®.................... 287
Booster Seats (For Children)...................... 63
Brake System............................................ 384
Anti-lock Brake System (ABS) .................. 389
Automatic Brake Hold ............................. 387
Brake Assist System................................. 390
Fluid ....................................................... 427
Foot Brake .............................................. 386
Parking Brake.......................................... 384
Brake System (Amber)
Indicator ................................................... 70
Brake System (Red)
Indicator ........................................... 68, 482
Brake System Indicator (Amber)............... 70
Brightness Control (Instrument Panel)... 144
BSI (Blind Spot Information) System....... 378
Bulb Replacement.................................... 428
Back-Up Lights ........................................ 432
Brake/Taillights and Rear Side Marker
Lights .................................................... 431
Door Outer Handle Ambient Lights ......... 433
Front Side Marker Lights ......................... 430
Front Turn Signal/Parking Lights .............. 429
Headlights .............................................. 428
High-Mount Brake Light.......................... 433
Rear License Plate Lights ......................... 433
Rear Turn Signal Lights............................ 431Side Turn Signal/Emergency Indicator
Lights .................................................... 430
Taillights .................................................. 432
Bulb Specifications................................... 496
CCarbon Monoxide Gas................................ 64
Cargo Hooks............................................. 169
Carrying Cargo.................................. 337, 339
CD Player................................................... 225
Center Pocket........................................... 165
Certification Label.................................... 498
Changing Bulbs......................................... 428
Charging System Indicator................. 71, 481
Child Safety................................................. 52
Childproof Door Locks ............................. 123
Child Seat.................................................... 52
Booster Seats ............................................. 63
Child Seat for Infants ................................. 54
Child Seat for Small Children ..................... 55
Installing a Child Seat with a Lap/Shoulder Seat
Belt.......................................................... 59
Larger Children .......................................... 62
Rear-facing Child Seat ............................... 54
Selecting a Child Seat ................................ 56
Using a Tether ........................................... 61
Childproof Door Locks............................. 123
Cleaning the Exterior............................... 451
Cleaning the Interior................................ 449
Client Service Information....................... 506Climate Control System............................ 177
Changing the Mode ................................ 180
Defrosting the Windshield and
Windows ............................................... 183
Dust and Pollen Filter............................... 448
Rear Temperature Control Dial ................ 184
Sensors ................................................... 185
Using Automatic Climate Control ............ 177
Clock.......................................................... 114
CMBS
TM (Collision Mitigation Braking
SystemTM)................................................. 391
Coat Hooks............................................... 168
Collision Mitigation Braking System
TM
(CMBS
TM)................................................. 391
Compact Spare Tire (Optional)........ 466, 497
Console Compartment............................. 164
Controls..................................................... 113
Coolant (Engine)...................................... 424
Adding to the Radiator ............................ 425
Adding to the Reserve Tank..................... 424
Overheating ............................................ 479
Creeping (Automatic Transmission)........ 346
Cruise Control........................................... 352
Indicator.................................................... 78
Cup Holders.............................................. 166
Customized Features........................ 102, 264
DDaytime Running Lights.......................... 140
Dead Battery............................................. 475

513Index
Low Fuel Indicator..................................... 73
Range ..................................................... 100
Recommendation............................ 403, 496
Refueling ................................................ 403
Fuel Economy........................................... 405
Fuel Fill Door...................................... 16, 404
Fuses......................................................... 485
Inspecting and Changing ........................ 489
Locations ................................ 485, 487, 488GGasoline (Fuel)
Economy................................................. 405
Gauge ...................................................... 94
Information............................................. 403
Instant Fuel Economy .............................. 100
Low Fuel Indicator..................................... 73
Refueling ................................................ 403
Gauges........................................................ 94
Gear Shift Lever Positions
Automatic Transmission .......................... 347
Glass (care)............................................... 452
Glove Box................................................. 161HHandling the Unexpected....................... 453
HandsFreeLink® (HFL).............................. 287
Auto Answer .......................................... 302Automatic Import of Cellular Phonebook and
Call History ............................................ 304
Automatic Transferring ............................ 302
Displaying Messages ................................ 322
Editing User Name ................................... 301
HFL Buttons ............................................. 287
HFL Menus .............................................. 289
HFL Status Display ................................... 288
Limitations for Manual Operation ............ 288
Making a Call .......................................... 313
Options During a Call .............................. 319
Phone Setup ............................................ 293
Phonebook Phonetic Modification ........... 308
Receiving a Call ....................................... 318
Receiving a Text Message/E-mail .............. 320
Ring Tone ................................................ 303
Roadside Assistance ................................. 326
Selecting a Mail Account ......................... 321
Speed Dial ............................................... 305
To Create a Security PIN .......................... 300
To Set Up a Text Message/E-mail
Options ................................................. 298
Use Contact Photo .................................. 303
Hard Disc Drive (HDD) Audio................... 228
Hazard Warning Button............................... 2
Head Restraints......................................... 155
Headlight Washers................................... 143
Headlights................................................. 137
Aiming .................................................... 428
Automatic Operation ............................... 138
Dimming ......................................... 137, 140Operating................................................ 137
Heated Steering Wheel............................ 171
Heaters (Seat)........................... 172, 173, 174
HFL (HandsFreeLink®)............................... 287
High-Beam Indicator.................................. 77
Hill Start Assist System............................. 344
HomeLink® Universal Transceiver............ 285
IIdentification Numbers............................ 498
Engine and Transmission ......................... 498
Vehicle Identification ............................... 498
Illumination Control
Buttons ................................................... 144
Immobilizer System.................................. 128
Indicator.................................................... 77
Indicators.................................................... 68
Adaptive Cruise Control (ACC) with Low Speed
Follow (LSF) ..................................... 81, 355
Anti-lock Brake System (ABS)..................... 74
Automatic Brake Hold ....................... 70, 387
Automatic Brake Hold System ........... 69, 387
Blind Spot Information (BSI) ............... 83, 379
Brake System (Amber) ............................... 70
Brake System (Red) ............................ 68, 482
Charging System ............................... 71, 481
Collision Mitigation Brake System
TM
(CMBS
TM) ................................................. 83
CRUISE CONTROL ............................. 78, 353
CRUISE MAIN .................................... 78, 352

514Index
Door and Trunk Open .......................... 29, 75
Electric Parking Brake................................. 69
Electric Parking Brake System ............. 69, 483
Electric Power Steering (EPS) System .. 74, 483
Forward Collision Warning (FCW) .............. 79
High-Beam ................................................ 77
Immobilizer System .................................... 77
Keyless Access System ............................... 78
Lane Departure Warning (LDW) ................. 80
Lane Keeping Assist System (LKAS) .... 82, 371
Lights On ................................................... 77
Low Fuel .................................................... 73
Low Oil Pressure ................................ 68, 481
Low Tire Pressure/TPMS ............. 76, 380, 382
Malfunction Indicator Lamp ............... 71, 482
Precision All Wheel Steer System................ 81
Seat Belt Reminder .............................. 31, 73
Security System Alarm ............................... 77
Shift Lever Position .................................... 72
SPORT Mode ..................................... 81, 351
Supplemental Restraint System ............ 49, 74
System Message ........................................ 76
Transmission .............................................. 72
Turn Signal ................................................ 77
Vehicle Stability Assist (VSA®)
System ............................................. 75, 375
VSA® OFF .......................................... 75, 376
Information............................................... 495
Instant Fuel Economy............................... 100
Instrument Panel........................................ 67
Brightness Control ................................... 144Interface Dial............................................ 193
Interior Lights........................................... 159
Interior Rearview Mirror.......................... 149
JJack (Wheel Nut Wrench)........................ 469
Jump Starting........................................... 475KKey Number Tag....................................... 116
Keyless Access System.............................. 118
Keyless Lockout Prevention..................... 120
Keys........................................................... 115
Lockout Prevention.................................. 120
Number Tag ............................................ 116
Rear Door Won’t Open............................ 123
Remote Transmitter ................................. 117
Types and Functions ................................ 115
Kickdown (Automatic Transmission)....... 346LLane Departure Warning (LDW)............. 367
Lane Keeping Assist System (LKAS)......... 370
Language (HFL)........................................ 288
LATCH (Child Seats).................................... 57
Lights................................................. 137, 428
Automatic ............................................... 138
Bulb Replacement ................................... 428
Daytime Running Lights........................... 140High-Beam Indicator ................................. 77
Interior.................................................... 159
Light Switches......................................... 137
Lights On Indicator.................................... 77
Turn Signals ............................................ 136
Load Limits............................................... 339
Locking/Unlocking................................... 115
Auto Door Locking/Unlocking ................. 124
Childproof Door Locks ............................ 123
From Inside ............................................. 121
From Outside .......................................... 117
Keys........................................................ 115
Using a Key............................................. 120
Lockout Prevention System..................... 120
Low Battery Charge................................. 481
Low Fuel Indicator..................................... 73
Low Keyless Access Remote Signal
Strength.................................................. 116
Low Oil Pressure Indicator................. 68, 481
Lower Anchors........................................... 57
Luggage (Maximum Load Limit)............. 339
Lumbar Support....................................... 153
MMaintenance............................................ 407
Battery .................................................... 446
Brake Fluid .............................................. 427
Cleaning ................................................. 449
Climate Control System .......................... 448
Coolant .................................................. 424

517Index
Tools......................................................... 454
Towing a Trailer....................................... 341
Towing Your Vehicle............................... 341
Emergency .............................................. 490
TPMS (Tire Pressure Monitoring
System).................................................... 380
Transmission....................................... 15, 347
Automatic................................. 15, 346, 347
Fluid ....................................................... 426
Number .................................................. 498
Sequential Shift Mode............................. 349
Shift Lever Position Indicator ............. 72, 348
TRIP Button.......................................... 96, 98
Trip Meter.................................................. 99
Troubleshooting...................................... 453
Blown Fuse ............................. 485, 487, 488
Brake Pedal Vibrates ................................. 19
Buzzer Sounds When Opening Door ......... 20
Emergency Towing ................................. 490
Engine Won’t Start ................................. 472
Flat Tire/Puncture .................................... 455
Noise When Braking ................................. 20
Overheating ............................................ 479
Premium Gasoline ........................... 403, 496
Rear Door Won’t Open ..................... 19, 123
Select Lever Won’t Move ........................ 478
Warning Indicators.................................... 68
Trunk........................................................ 125
Lid .......................................................... 125
Light Bulbs .............................................. 496
Release Handle ....................................... 492Unable to Open ....................................... 492
Trunk Pass-through Cover........................ 170
Turn Signals.............................................. 136
Indicators (Instrument Panel) ...................... 77
Turn-by-Turn Directions........................... 100
UUnlocking the Doors................................ 117
Unlocking the Front Doors from
the Inside........................................... 10, 121
USB Flash Drives........................................ 263
USB Port.................................................... 189
Using the Keyless Access System.............. 118VValet Mode............................................... 162
Vanity Mirrors............................................... 5
Vehicle Identification Number................ 498
Vehicle Stability Assist (VSA®).................. 375
Off Button ............................................... 376
Off Indicator ...................................... 75, 376
System Indicator ................................ 75, 375
Viscosity (Oil).................................... 419, 497
VSA® (Vehicle Stability Assist).................. 375WWarning and Information Messages......... 84
Warning Indicator On/Blinking............... 481
Warning Labels........................................... 65Warranties (Warranty Manual provided
separately).............................................. 503
Watts......................................................... 496
Wear Indicators (Tire).............................. 442
Wheel Nut Wrench (Jack Handle)........... 469
Window Washers..................................... 141
Adding/Refilling Fluid .............................. 427
Switch ..................................................... 141
Windows (Opening and Closing)............ 130
Windshield
Cleaning ................................................. 452
Defrosting/Defogging .............................. 183
Washer Fluid ........................................... 427
Wiper Blades ........................................... 434
Wipers and Washers................................ 141
Winter Tires.............................................. 445
Snow Tires .............................................. 445
Tire Chains .............................................. 445
Wipers and Washers................................. 141
Checking and Replacing Wiper Blades ..... 434
WMA................................................. 225, 249
Worn Tires................................................ 437
XXM® Radio................................................ 222
