cruise control Acura RLX 2014 Owner's Guide

360
uuWhen DrivinguAdaptive Cruise Control (ACC) with Low Speed Follow (LSF)
*
Driving
Press the (distance) button to change the
ACC with LSF following distance.
Each time you press the button, the following
distance (the distance behind a vehicle
detected ahead of you) setting cycles through
short, middle, long, and extra long following
distances.
The higher your selected set speed is, the longer the short, middle, long or extra long
following distance becomes. See the following examples for your reference.
■
To Set or Change Following Distance
Distance Button
Following Distance
When the Set Speed is:
50 mph (80 km/h)
65 mph (104 km/h)
Short
83 feet
25 meters
100 feet
31 meters
Middle
110 feet
33 meters
137 feet
42 meters
Long
154 feet
47 meters
200 feet
61 meters
Extra
Long
204 feet
62 meters
265 feet
81 meters

Continued
361
uuWhen DrivinguAdaptive Cruise Control (ACC) with Low Speed Follow (LSF)
*
Driving
To cancel ACC with LSF, do any of the
following:
•Press the CANCEL button.
•Press the MAIN button.
uACC with LSF indicator goes off.
•Depress the brake pedal.
uWhen the LSF function has stopped the
vehicle, you cannot cancel ACC with LSF
by depressing the brake pedal.
■Automatic cancellation
The beeper sounds and a message appears on the multi-information display when
ACC with LSF is automatically canceled. Any of these conditions may cause the ACC
with LSF to automatically cancel:
•Your vehicle speed slows to 22 mph (35 km/h) or below when a detected vehicle
goes out of the ACC with LSF range.
•Bad weather (rain, fog, snow, etc.)
•When the radar sensor in the front grille gets dirty.
•The vehicle ahead of you cannot be detected.
•An abnormal tire condition is detected, or the tires are skidding.
•Driving on a mountainous road, or driving off road for extended periods.
•Abrupt steering wheel movement.
•When the ABS, VSA® or CMBS
TM is activated.
•When the VSA® system indicator comes on.
•When the vehicle is stopped on a very steep slope.
•When you manually apply the parking brake.
•When the detected vehicle within the ACC with LSF range is too close to your
vehicle.
■
To Cancel
1To Cancel
Resuming the prior set speed: After you have
canceled ACC with LSF, you can resume the prior set
speed while it is still displayed. Press the RES/+/SET/
– switch up when driving at a speed of at least 25
mph (40 km/h) or more.
Even if your vehicle speed has gone down to less than
25 mph (40 km/h), you can still resume the prior set
speed when ACC with LSF detects a vehicle ahead of
you.
You cannot set or resume in the following situations:•When the vehicle speed is less than 25 mph
(40km/h) and there is no vehicle detected in front
of your vehicle•When the MAIN button is turned off
CANCEL
ButtonMAIN
Button
1Automatic cancellation
Even though ACC with LSF has been automatically
canceled, you can still resume the prior set speed.
Wait until the condition that caused ACC with LSF to
cancel improves, then press the RES/+/SET/– switch
down.

362
uuWhen DrivinguAdaptive Cruise Control (ACC) with Low Speed Follow (LSF)
*
Driving
The ACC with LSF automatic cancellation can be also triggered by the following
causes. In these cases, the parking brake will be automatically applied.
•The driver’s seat belt is unfastened when the vehicle is stationary.
•The vehicle stops for more than 10 minutes.
•The engine is turned off.

363
uuWhen DrivinguAdaptive Cruise Control (ACC) with Low Speed Follow (LSF)
*
Driving
Press and hold the (distance) button for one second.
Cruise Mode Selected appears on the multi-information display for two seconds,
and then the mode switches to Cruise.
To switch back to ACC with LSF, press and hold the button again for one second.■
To Switch ACC with LSF to Cruise Control
1To Switch ACC with LSF to Cruise Control
Always be aware which mode you are in. When you
are driving in Cruise mode, be more cautious about
keeping a safe distance from a vehicle ahead of you.
The current mode is displayed on the multi-
information display.
2Switching the Display P. 95
ACC with
LSF ONCruise
Control ON
Distance Button

502
uuEmissions TestinguTesting of Readiness Codes
Information
7.Select a nearby, lightly traveled major highway where you can maintain a speed
of 50 to 60 mph (80 to 97 km/h) for at least 20 minutes. Drive on the highway in
(D
. Do not use cruise control. When traffic allows, drive for 90 seconds without
moving the accelerator pedal. (Vehicle speed may vary slightly; this is okay.) If you
cannot do this for a continuous 90 seconds because of traffic conditions, drive for
at least 30 seconds, then repeat it two more times (for a total of 90 seconds).
8.Drive in city/suburban traffic for at least 10 minutes. When traffic conditions
allow, let the vehicle coast for several seconds without using the accelerator pedal
or the brake pedal.
9.Park the vehicle and leave the engine off for 30 minutes.

Index
510Index
Index
AAAC.................................................... 225, 249
ABS (Anti-lock Brake System)................... 389
Accessories and Modifications................. 406
Accessory Power Sockets.......................... 167
AcuraLink.................................................. 327
Adaptive Cruise Control (ACC) with Low
Speed Follow (LSF)............................ 81, 355
Additives
Coolant ................................................... 424
Engine Oil ................................................ 419
Washer .................................................... 427
Additives, Engine Oil................................ 419
Adjusting
Armrest ................................................... 158
Front Seats .............................................. 152
Head Restraints........................................ 155
Mirrors .................................................... 149
Steering Wheel ........................................ 148
Temperature .............................................. 99
Agile Handling Assist System................... 377
Aha
TM Menu.............................................. 248
AhaTM Radio.............................................. 259
Air Conditioning System (Climate Control
System).................................................... 177
Changing the Mode ................................ 180
Defrosting the Windshield and
Windows ............................................... 183
Dust and Pollen Filter ............................... 448
Rear Temperature Control Dial................. 184
Sensors .................................................... 185Using Automatic Climate Control ............ 177
Air Pressure....................................... 438, 497
Airbags........................................................ 37
Advanced Airbags ..................................... 43
Airbag Care............................................... 51
Driver’s Knee Airbag.................................. 44
Event Data Recorder .................................. 22
Front Airbags (SRS) .................................... 40
Indicator.............................................. 49, 74
Passenger Airbag Off Indicator .................. 50
Sensors ..................................................... 37
Side Airbags .............................................. 46
Side Curtain Airbags.................................. 48
AM/FM Radio............................................ 217
Anti-lock Brake System (ABS).................. 389
Indicator.................................................... 74
Armrest..................................................... 158
Audio Remote Controls........................... 192
Audio System............................................ 188
Adjusting the Sound................................ 207
Auxiliary Input Jack.................................. 190
Error Messages ........................................ 254
General Information ................................ 260
HDD ........................................................ 228
Internet Radio ......................................... 246
iPod®....................................................... 238
MP3/WMA/AAC .............................. 225, 249
Reactivating ............................................ 191
Recommended CDs ................................. 261
Recommended Devices............................ 263
Remote Controls ..................................... 192Security Code ......................................... 191
Shortcuts ................................................ 195
Theft Protection ...................................... 191
USB Flash Drives...................................... 263
USB Port ................................................. 189
Authorized Manuals................................ 505
Auto Door Locking/Unlocking................ 124
Customize ...................................... 108, 277
Automatic Brake Hold............................. 387
Indicator ........................................... 70, 387
Automatic Brake Hold System
Indicator ........................................... 69, 387
Automatic Lighting.................................. 138
Automatic Transmission.......................... 346
Creeping................................................. 346
Fluid ....................................................... 426
Kickdown ............................................... 346
Operating the Shift Lever .................. 15, 348
Shift Lever Does Not Move ...................... 478
Shifting ................................................... 347
Auxiliary Input Jack................................. 190
Average Fuel Economy.............................. 99
Average Speed......................................... 100
BBattery...................................................... 446
Charging System Indicator ................ 71, 481
Jump Starting ......................................... 475
Maintenance (Checking the Battery) ....... 446
Maintenance (Replacing) ......................... 447

511Index
Belts (Seat).................................................. 30
Beverage Holders..................................... 166
Blind Spot Information (BSI) System....... 378
Bluetooth® Audio..................................... 252
Bluetooth® HandsFreeLink®.................... 287
Booster Seats (For Children)...................... 63
Brake System............................................ 384
Anti-lock Brake System (ABS) .................. 389
Automatic Brake Hold ............................. 387
Brake Assist System................................. 390
Fluid ....................................................... 427
Foot Brake .............................................. 386
Parking Brake.......................................... 384
Brake System (Amber)
Indicator ................................................... 70
Brake System (Red)
Indicator ........................................... 68, 482
Brake System Indicator (Amber)............... 70
Brightness Control (Instrument Panel)... 144
BSI (Blind Spot Information) System....... 378
Bulb Replacement.................................... 428
Back-Up Lights ........................................ 432
Brake/Taillights and Rear Side Marker
Lights .................................................... 431
Door Outer Handle Ambient Lights ......... 433
Front Side Marker Lights ......................... 430
Front Turn Signal/Parking Lights .............. 429
Headlights .............................................. 428
High-Mount Brake Light.......................... 433
Rear License Plate Lights ......................... 433
Rear Turn Signal Lights............................ 431Side Turn Signal/Emergency Indicator
Lights .................................................... 430
Taillights .................................................. 432
Bulb Specifications................................... 496
CCarbon Monoxide Gas................................ 64
Cargo Hooks............................................. 169
Carrying Cargo.................................. 337, 339
CD Player................................................... 225
Center Pocket........................................... 165
Certification Label.................................... 498
Changing Bulbs......................................... 428
Charging System Indicator................. 71, 481
Child Safety................................................. 52
Childproof Door Locks ............................. 123
Child Seat.................................................... 52
Booster Seats ............................................. 63
Child Seat for Infants ................................. 54
Child Seat for Small Children ..................... 55
Installing a Child Seat with a Lap/Shoulder Seat
Belt.......................................................... 59
Larger Children .......................................... 62
Rear-facing Child Seat ............................... 54
Selecting a Child Seat ................................ 56
Using a Tether ........................................... 61
Childproof Door Locks............................. 123
Cleaning the Exterior............................... 451
Cleaning the Interior................................ 449
Client Service Information....................... 506Climate Control System............................ 177
Changing the Mode ................................ 180
Defrosting the Windshield and
Windows ............................................... 183
Dust and Pollen Filter............................... 448
Rear Temperature Control Dial ................ 184
Sensors ................................................... 185
Using Automatic Climate Control ............ 177
Clock.......................................................... 114
CMBS
TM (Collision Mitigation Braking
SystemTM)................................................. 391
Coat Hooks............................................... 168
Collision Mitigation Braking System
TM
(CMBS
TM)................................................. 391
Compact Spare Tire (Optional)........ 466, 497
Console Compartment............................. 164
Controls..................................................... 113
Coolant (Engine)...................................... 424
Adding to the Radiator ............................ 425
Adding to the Reserve Tank..................... 424
Overheating ............................................ 479
Creeping (Automatic Transmission)........ 346
Cruise Control........................................... 352
Indicator.................................................... 78
Cup Holders.............................................. 166
Customized Features........................ 102, 264
DDaytime Running Lights.......................... 140
Dead Battery............................................. 475

512Index
Defrosting the Windshield and
Windows.................................................. 183
Devices that Emit Radio Waves................ 499
Dimming
Headlights ............................................... 137
Rearview Mirror ....................................... 149
Dipstick (Engine Oil)................................. 420
Directional Signals (Turn Signal).............. 136
Door Mirrors............................................. 150
Doors......................................................... 115
Auto Door Locking .................................. 124
Auto Door Unlocking ............................... 124
Door Open Indicator ............................ 29, 75
Keys ........................................................ 115
Locking/Unlocking the Doors from
the Inside ......................................... 10, 121
Locking/Unlocking the Doors from
the Outside ............................................ 117
Lockout Prevention System ...................... 120
DOT Tire Quality Grading........................ 440
Driver’s Knee Airbag.................................. 44
Driving....................................................... 335
Automatic Transmission ........................... 346
Braking .................................................... 384
Cruise Control ......................................... 352
Shifting Gear ........................................... 347
Starting the Engine .................................. 342
Driving Position Memory System............. 146
Dust and Pollen Filter............................... 448
EElapsed Time............................................. 100
Electric Parking Brake
Indicator.................................................... 69
Electric Parking Brake System
Indicator............................................ 69, 483
Electric Power Steering (EPS) System
Indicator............................................ 74, 483
Electronic Stability Control (ESC)............. 375
Emergency................................................ 490
Emissions Testing (Readiness Codes)....... 501
Engine....................................................... 498
Coolant ................................................... 424
Jump Starting .......................................... 475
Oil ........................................................... 419
Starting ................................................... 342
Switch Buzzer.......................................... 133
Engine Compartment Cover.................... 418
Engine Coolant......................................... 424
Adding to the Radiator ............................ 425
Adding to the Reserve Tank..................... 424
Overheating ............................................ 479
Temperature Gauge .................................. 94
Engine Oil................................................. 419
Adding .................................................... 421
Checking................................................. 420
Displaying Oil Life .................................... 412
Low Oil Pressure Indicator ................. 68, 481
Recommended Engine Oil ....................... 419
ENGINE START/STOP Button.................... 133
e-pretensioners........................................... 32EPS (Electric Power Steering) System........ 74
Exhaust Gas Hazard (Carbon Monoxide).. 64
Expanded Rear Door Sunshades............. 176
Expanded View Driver’s Mirror............... 151
Exterior Care (Cleaning).......................... 451
Exterior Mirrors........................................ 150
FFeatures.................................................... 187
Filters
Dust and Pollen....................................... 448
Oil .......................................................... 422
Flat Tire..................................................... 455
Floor Mats................................................ 450
Fluids
Automatic Transmission .......................... 426
Brake ...................................................... 427
Engine Coolant ....................................... 424
Windshield Washer ................................. 427
Foot Brake................................................ 386
Forward Collision Warning (FCW).......... 364
Front Airbags (SRS).................................... 40
Front Seat Heaters and Seat
Ventilation.............................................. 173
Front Seats................................................ 152
Adjusting ................................................ 152
Fuel..................................................... 16, 403
Economy................................................. 405
Gauge ...................................................... 94
Instant Fuel Economy .............................. 100

513Index
Low Fuel Indicator..................................... 73
Range ..................................................... 100
Recommendation............................ 403, 496
Refueling ................................................ 403
Fuel Economy........................................... 405
Fuel Fill Door...................................... 16, 404
Fuses......................................................... 485
Inspecting and Changing ........................ 489
Locations ................................ 485, 487, 488GGasoline (Fuel)
Economy................................................. 405
Gauge ...................................................... 94
Information............................................. 403
Instant Fuel Economy .............................. 100
Low Fuel Indicator..................................... 73
Refueling ................................................ 403
Gauges........................................................ 94
Gear Shift Lever Positions
Automatic Transmission .......................... 347
Glass (care)............................................... 452
Glove Box................................................. 161HHandling the Unexpected....................... 453
HandsFreeLink® (HFL).............................. 287
Auto Answer .......................................... 302Automatic Import of Cellular Phonebook and
Call History ............................................ 304
Automatic Transferring ............................ 302
Displaying Messages ................................ 322
Editing User Name ................................... 301
HFL Buttons ............................................. 287
HFL Menus .............................................. 289
HFL Status Display ................................... 288
Limitations for Manual Operation ............ 288
Making a Call .......................................... 313
Options During a Call .............................. 319
Phone Setup ............................................ 293
Phonebook Phonetic Modification ........... 308
Receiving a Call ....................................... 318
Receiving a Text Message/E-mail .............. 320
Ring Tone ................................................ 303
Roadside Assistance ................................. 326
Selecting a Mail Account ......................... 321
Speed Dial ............................................... 305
To Create a Security PIN .......................... 300
To Set Up a Text Message/E-mail
Options ................................................. 298
Use Contact Photo .................................. 303
Hard Disc Drive (HDD) Audio................... 228
Hazard Warning Button............................... 2
Head Restraints......................................... 155
Headlight Washers................................... 143
Headlights................................................. 137
Aiming .................................................... 428
Automatic Operation ............................... 138
Dimming ......................................... 137, 140Operating................................................ 137
Heated Steering Wheel............................ 171
Heaters (Seat)........................... 172, 173, 174
HFL (HandsFreeLink®)............................... 287
High-Beam Indicator.................................. 77
Hill Start Assist System............................. 344
HomeLink® Universal Transceiver............ 285
IIdentification Numbers............................ 498
Engine and Transmission ......................... 498
Vehicle Identification ............................... 498
Illumination Control
Buttons ................................................... 144
Immobilizer System.................................. 128
Indicator.................................................... 77
Indicators.................................................... 68
Adaptive Cruise Control (ACC) with Low Speed
Follow (LSF) ..................................... 81, 355
Anti-lock Brake System (ABS)..................... 74
Automatic Brake Hold ....................... 70, 387
Automatic Brake Hold System ........... 69, 387
Blind Spot Information (BSI) ............... 83, 379
Brake System (Amber) ............................... 70
Brake System (Red) ............................ 68, 482
Charging System ............................... 71, 481
Collision Mitigation Brake System
TM
(CMBS
TM) ................................................. 83
CRUISE CONTROL ............................. 78, 353
CRUISE MAIN .................................... 78, 352
