Acura RSX 2005 Owner's Manual

An auto-tensioner adjusts the tension
of the drive belt. The indicator on
the auto-tensioner should be in the
proper range. It should be checked
accordingtothetimeanddistance
recommendations in the
maintenance schedule.If the indicator is not within the
proper range, have the drive belt
replaced by your dealer as soon as
possible.
Drive Belts
Drive Belts
170
INDICATOR
Proper range

Check the level on the side of the
reservoir when the engine is cold.
The f luid should be between the
UPPER LEVEL and LOWER LEVEL.
If not add power steering f luid to the
UPPER LEVEL mark.
Pour the f luid slowly and caref ully so
you do not spill. Clean up any spill
immediately; it could damage
components in the engine
compartment.A low power steering f luid level can
indicate a leak in the system. Check
the f luid level f requently, and have
the system inspected as soon as
possible. Always use Honda Power Steering
Fluid. You may use another power
steering f luid as an emergency
replacement, but have the power
steering system f lushed and ref illed
with Honda PSF as soon as possible.
Power Steering Fluid
Power Steering Fluid
Maint enance
171
UPPER LEVEL
LOWER LEVEL
Do not spill the power steering f luid
over the body, auto-tensioner, drive
belt and pulleys.
If spilled accidentally, wipe of f any
f luid completely. T urning the steering wheel to f ull lef t
or right lock and holding it there can
damage the power steering pump.

Theheadlightswereproperlyaimed
when your vehicle was new. If you
regularly carry heavy items in the
cargo area or pull a trailer,
readjustment may be required.
Adjustment should be done by your
dealer or other qualif ied mechanic.Your vehicle uses halogen headlight
bulbs. When replacing a bulb, handle
it by its plastic case and protect the
glass from contact with your skin or
hard objects. If you touch the glass,
clean it with denatured alcohol and a
clean cloth.
If you need to change the low
beam headlight bulb on the driver’s
side, remove the neck of the
windshield washer reservoir f rom
the bracket by sliding it to the lef t.
1.
Lights
Headlight A iming
Replacing a Headlight BulbReplacing a Low Beam Headlight
Bulb
172
Driver’s side
Halogen headlight bulbs get very hot
when lit. Oil, perspiration, or a scratch
on the glass can cause the bulb to
overheat and shatter.

Insert the new bulb into the hole,
making sure the tabs are in their
slots. Pivot the hold-down wire
back in place, and clip the end into
the slot.
Install the rubber seal and make
sure it is right side up; it is marked
‘‘TOP.’’
Pull the battery back to its original
position, then install the bolt in the
hold-down, and tighten it securely. Push the electrical connector onto
the tabs of the new bulb. Make
sureitlocksinplace.Turnonthe
headlights to test the new bulb.
Install the neck of the windshield
washer reservoir on the bracket.
Then remove the bolt f rom the
battery hold-down, and caref ully
push the battery toward the
windshield to obtain enough
working space.
Unclip the end of the hold-down
wire f rom its slot. Pivot it out of
the way, and remove the bulb. Remove the rubber weather seal
by pulling on the tab. Remove the electrical connector
f rom the bulb by pulling the
connector straight back.
3.
4. 5.
6.
7.
8.
2.
Lights
Driver’s Side
Maint enance
173
HOLD DOWN
WIRE
BULB
WEATHER SEAL
CONNECTOR

To change a high beam headlight
bulb, remove the electrical
connector f rom the bulb by
pushing on the tab and pulling the
connector down.
Remove the bulb by turning it one-
quarter turn counterclockwise.Insert the new bulb into the hole
and turn it one-quarter turn clock-
wise to lock it in place.
Push the electrical connector back
onto the bulb. Make sure it is on
all the way.
Turn on the headlights to test the
new bulb.
Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise.
Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
3.
4.
5.
2. 1. 2. 1.
Lights
Replacing a Front T urn Signal
BulbReplacing a High Beam HeadlightBulb
174

Insert the socket into the
headlight assembly. Turn it
clockwise to lock it in place.
Testthelightstomakesurethe
new bulb is working.Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise.Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Turn on the parking lights and
check that the new bulb is
working.
The f ront parking light bulb is
above the high beam headlight
bulb.
3.
4.
1.2.
3.
4.
Lights
Replacing a Front Parking Light
Bulb
Maint enance
175

The f ront side marker light bulb is
above the low beam headlight bulb.
Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise.Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.
2.
3.
1. 4.
Lights
Replacing a Front Side Marker
Light Bulb
176

Pull the bulb straight out of its
socket.
Push the new bulb straight into
the socket until it bottoms.
Insert the socket back into the
light assembly. Turn it clockwise
to lock it in place.
Testthelightstomakesurethe
new bulb is working.
Reinstall the high-mount brake
light cover.
Open the hatch.
Remove the high-mount brake
light cover by pivoting it toward
the back of the vehicle.
Remove the socket by turning it
one-quarter turn counterclockwise. Open the hatch. Remove the light
assembly cover by pulling on the
tabontheoutsideedge.
2.
3. 1. 4.
5.
6.
7.
1.
CONT INUED
Replacing Rear Bulbs
Replacing a High-mount Brake
Light Bulb
Lights
Maint enance
177
COVER
COVER BULB

Reinstall the socket into the light
assembly by turning it clockwise
until it locks.
Testthelightstomakesurethe
new bulb is working.
Install the light assembly cover.
Make sure it locks in place.
Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms. Remove the socket by turning it
one-quarter turn counterclockwise. Determine which of the f our bulbs
is burned out: brake/taillight, turn
signal light, side marker light, or
back-up light.
2.
3.
4. 5.
6.
7.
Lights
178

If your seat belts get dirty, use a sof t
brush with a mixture of mild soap
and warm water to clean them. Do
not use bleach, dye, or cleaning
solvents. Let the belts air dry bef ore
you use the vehicle.
Dirt build-up in the loops of the seat
belt anchors can cause the belts to
retract slowly. Wipe the insides of
the loops with a clean cloth
dampened in mild soap and warm
water or isopropyl alcohol.The driver’s f loor mat that came
with your vehicle hooks over the
f loor mat anchor. This keeps the
f loor mat f rom sliding f orward and
possibly interf ering with the pedals.
If you remove the driver’s f loor mat,
make sure to re-anchor it when you
putitbackinyourvehicle.This f ilter removes the dust and
pollenthatisbroughtinfromthe
outside through the heating and
cooling system. If you use an aftermarket floor mat,
make sure it f its properly and that it
canbeusedwiththefloormat
anchor. Do not put additional f loor
mats on top of the anchored mat.
Have your dealer replace this filter
every 30,000 miles (48,000 km)
under normal conditions. It should
be replaced every 15,000 miles
(24,000 km) if you drive primarily in
urban areas that have high
concentrations of soot in the air, or if
the airflow from the heating and
cooling system is less than usual.
Floor Mats
Dust and Pollen Filter
Cleaning the Seat Belts
Cleaning the Seat Belts, Floor Mats, Dust and Pollen Filter
Maint enance
179
LOOP
