schedule of maintenance Acura TL 2001 3.2 User Guide

µ
Ì
Ì
Ì
Follow the Normal Conditions
Maintenance Schedule if the
severe driving conditions
specif ied in the Severe
Conditions Maintenance
Schedule do not apply.
NOTE: If you onlydrive under a
‘‘severe’’ condition, you should
f ollow the Normal Conditions
Maintenance Schedule.
Follow the Maintenance
Schedule f or Severe Conditions.
OCCASIONALLY
Maint enance
U.S. Owners
Canadian Owners
196
Visually inspect the following items:
Service at the indicated
distance or time whichever
comes first.
miles x 1,000
km x 1,000
months
Replace every 7,500 miles (12,000 km) or 12 months
Check oil and coolant at each fuel stop
Replace engine oil
Replace engine oil filter
Check engine oil and coolant
Replace air cleaner element
Inspect valve clearance
Replace spark plugs
Replace timing belt, and inspect water pump
Inspect and adjust drive belts
Inspect idle speed
Replace engine coolant
Replace transmission fluid
Inspect front and rear brakes
Replace brake fluid
Check parking brake adjustment
Replace air conditioning filter
Rotate tires (Check tire inflation and condition
at least once per month)
Tie rod ends, steering gear box, and boots
Suspension components
Driveshaft boots
Brake hoses and lines (including ABS)
All fluid levels and condition of fluids
Cooling system hoses and connections
Exhaust system
Fuel lines and connections Rotate tires every 7,500 miles (12,000 km)
15
24
12
30
48
24 60
96
48 120
192
96
75
120 60 105
168
84
45
72
36 90
144 72
Every 36 months (independent of mileage)
See information on maintenance and emissions warranty, last column, page .
120,000 miles (192,000 km) or 72 months, thereafter every
90,000 miles (144,000 km) or 60 months
120,000 miles (192,000 km) or 120 months, thereafter every
60,000 miles (96,000 km) or 60 months
: 195
Adjust only if noisy
Maintenance Schedule for Normal Conditions

µµ
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ì
Ì
Ì
Maint enance197
U.S. Owners
Canadian Owners
A, B, C, D
A
B
C
D
Refer to page to determine which schedule to use.
Use the Maintenance Schedule for Severe Conditions.
Replace engine oil.
Rotate tires (follow pattern on page235).
Replace engine oil filter.
Inspect front and rear brakes.
Check parking brake adjustment.
Inspect tie rod ends, steering gear box and boots.
Inspect suspension components.
Inspect driveshaft boots.
Inspect brake hoses and lines (including ABS).
Check all fluid levels, condition of fluids, and check
for leaks.
Inspect cooling system hoses and connections. Inspect exhaust system.
Inspect fuel lines and connections.
Replace air cleaner element.
Inspect and adjust drive belts.
Replace air conditioning filter.
Replace brake fluid every 3 years
(independent of mileage).
Service at the indicated distance or time, whichever comes first. Do the items in as required for each distance/time interval.
Do items in A.
Do items in A, B.
Do items in A.
DoitemsinA,B,C.
Do items in A.
DoitemsinA,B,D.
Do items in A.
DoitemsinA,B,C.
Do items in A.
Do items in A, B.
Do items in A.
DoitemsinA,B,C,D.
Do items in A.Replace timing belt, and inspect water pump.
Inspect valve clearance.
Check idle speed.
Replace spark plugs.
Do items in A, B.
Do items in A.
DoitemsinA,B,C. Replace engine coolant, thereafter replace
every 60,000 mi/96,000 km/5 yrs. Replace transmission fluid, thereafter replace
every 90,000 mi/144,000 km/5 yrs.
7,500 mi/12,000 km
15,000 mi/24,000 km/1 yr
22,500 mi/36,000 km
30,000 mi/48,000 km/2 yrs
37,500 mi/60,000 km
45,000 mi/72,000 km/3 yrs
52,500 mi/84,000 km
60,000 mi/96,000 km/4 yrs
67,500 mi/108,000 km
75,000 mi/120,000 km/5 yrs
82,500 mi/132,000 km
90,000 mi/144,000 km/6 yrs
97,500 mi/156,000 km
105,000 mi/168,000 km/7 yrs
112,500 mi/180,000 km
120,000 mi/192,000 km/8 yrs
120,000 mi/192,000 km/10 yrs
120,000 mi/192,000 km/6 yrs 196
See information on maintenance and emissions warranty, last
column, page .
Check engine oil and coolant at each fuel stop.
Check and adjust valve clearance, cold engine, only if noisy.
NOTE: :
195
Maintenance Schedule for Normal Conditions (listed by distance/time)

µ
Ì
Î
Î
Ì
Ì Î
Î
µ
ÌDriving less than 5 miles (8
km) per trip or, in f reezing
temperatures, driving less
than 10 miles (16 km) per trip.
Driving in extremely hot
[over 90°F (32°C)] conditions.
Extensive idling or long
periods of stop-and-go driving.
Trailer towing, driving with a
roof rack, or driving in
mountainous conditions.
Driving on muddy, dusty, or
de-iced roads.
Follow the Maintenance
Schedule f or Severe Conditions. Follow the Severe Conditions
Maintenance Schedule if you
drive your car under
one or more of the f ollowing
conditions:
MAINLY
Maint enance
U.S. Owners
Canadian Owners
198
Visually inspect the following items:
Service at the indicated
distance or time whichever
comes first.
miles x 1,000
km x 1,000
months
Replace every 3,750 miles (6,000 km) or 6 monthsCheck oil and coolant at each fuel stop
See Air Conditioning Filter on page for replacement information under special driving conditions. See information on maintenance and emissions warranty, last column, page .
Tie rod ends, steering gear box, and boots
Suspension components
Driveshaft boots
Brake hoses and lines (including ABS)
All fluid levels and conditions of fluids
Cooling system hoses and connections
Exhaust system
Fuel lines and connections
Lights and controls, Vehicle underbody Rotate tires every 7,500 miles (12,000 km)
Inspect every 7,500 miles (12,000 km) or 6 months
Every 7,500 miles (12,000 km) or 6 months
Every 36 months (independent of mileage)
See Timing Belt on page for replacement information under special driving conditions. 15
24
12
30
48
2445
72
3660
96
4875
120 60 90
144 72 105
168
84 120
192
96
Replace engine oil and oil filter
Check engine oil and coolant
Clean ( ) or replace ( ) air cleaner element
Inspect valve clearance
Replace spark plugs
Inspect and adjust drive belts
Inspect idle speed
Replace engine coolant
Replace transmission fluid
Inspect front and rear brakes
Replace brake fluid
Check parking brake adjustment
Replace air conditioning filter
Lubricate all hinges, locks and latches
Rotate tires (Check tire inflation and condition
at least once per month) 120,000 miles (192,000 km) or 120 months, thereafter every
60,000 miles (96,000 km) or 60 months
60,000 miles (96,000 km) or 36 months, thereafter every 30,000 miles (48,000 km) or 24 months
:
1:
2: 195
Adjust only if noisy
231 230
Use normal schedule except in dusty conditons
Replace timing belt , and inspect water pump
1
2
Maintenance Schedule for Severe Conditions

µµ
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ì
Ì
Î
ÌÎ
Ì
Î
Î
CONT INUED
Maint enance199
A, B, C, D, E
U.S. Owners
Canadian Owners
A
B
C
D
E
Service at the indicated distance or time, whichever comes first. Do the items in
as required for each distance/time.
Refer to page to determine which schedule to use. Use the Maintenance Schedule for Severe Conditions.
Replace engine oil and filter.
Inspect front and rear brakes.
Rotate tires (follow pattern on page235).
Inspect tie rod ends, steering gear box and boots.
Inspect suspension components.
Inspect driveshaft boots.
Check parking brake adjustment.
Lubricate all hinges, locks and latches with
multipurpose grease.
Inspect brake hoses and lines (including ABS).
Check all fluid levels, condition of fluids, and check
for leaks.
Inspect cooling system hoses and connections. Inspect exhaust system.
Inspect fuel lines and connections.
Check all lights.
Inspect the underbody.
Replace air cleaner element.
Inspect and adjust drive belts.
Replace air conditioning filter .
Replace brake fluid every 3 years
(independent of mileage).
3,750 mi/6,000 km
7,500 mi/12,000 km
11,250 mi/18,000 km
15,000 mi/24,000 km/1 yr
18,750 mi/30,000 km
22,500 mi/36,000 km
26,250 mi/42,000 km
30,000 mi/48,000 km/2 yrs
33,750 mi/54,000 km
37,500 mi/60,000 km
41,250 mi/66,000 km
45,000 mi/72,000 km/3 yrs
48,750 mi/78,000 km
52,500 mi/84,000 km
56,250 mi/90,000 km
60,000 mi/96,000 km/4 yrs
60,000 mi/96,000 km/3 yrs
63,750 mi/102,000 km
67,500 mi/108,000 km
71,250 mi/114,000 km
75,000 mi/120,000 km/5 yrs
78,750 mi/126,000 km Do items in A.
Do items in A, B.
Do items in A.
Clean air cleaner element.
DoitemsinA,B,C.
Do items in A.
Do items in A, B.
Do items in A.
DoitemsinA,B,C,D.
Do items in A.
Do items in A, B.
Do items in A. Clean air cleaner element.
DoitemsinA,B,C,E.
Do items in A.
Do items in A, B.
Do items in A. Replace timing belt , and inspect water pump.
DoitemsinA,B,C,D. Replace transmission fluid, thereafter replace
every 30,000 mi/48,000 km/2 yrs.
Do items in A.
Do items in A, B.
Do items in A. Clean air cleaner element.
DoitemsinA,B,C.
Do items in A.
198
Check engine oil and coolant at each fuel stop.
Check and adjust valve clearance, cold engine, only if noisy.
See information on maintenance and emissions warranty, last
column, page .
See Timing Belt on page for replacement information under
special driving conditions.
See Air Conditioning Filter on page for replacement
information under special driving conditions.
NOTE: :
1:
2: 195
231
230
2
1
Maintenance Schedule for Severe Conditions (listed by distance/time)

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Î
Î
Ì
Î
Î
Maint enance200
See information on maintenance and emissions warranty, last
column, page .
See Timing Belt on page for replacement information under
special driving conditions.
See Air Conditioning Filter on page for replacement
information under special driving conditions.
Check engine oil and coolant at each fuel stop.
Check and adjust valve clearance, cold engine, only if noisy.
NOTE: 195
:
1:
2: 231
230Do items in A, B.
Do items in A.
DoitemsinA,B,C,D,E.Replace transmission fluid.
Do items in A.
Do items in A, B.
Do items in A. Replace timing belt , and inspect water pump.
Check idle speed.
Clean air cleaner element.
Replace spark plugs.
Inspect valve clearance.
DoitemsinA,B,C.
Do items in A.
Do items in A, B.
Do items in A. Replace timing belt , and inspect water pump.
DoitemsinA,B,C,D. Replace engine coolant, thereafter replace
every 60,000 mi/96,000 km/5 yrs. Replace transmission fluid.
82,500 mi/132,000 km
86,250 mi/138,000 km
90,000 mi/144,000 km/6 yrs
90,000 mi/144,000 km/5 yrs
93,750 mi/150,000 km
97,500 mi/156,000 km
101,250 mi/162,000 km
105,000 mi/168,000 km/7 yrs
108,750 mi/174,000 km
112,500 mi/180,000 km
116,250 mi/186,000 km
120,000 mi/192,000 km/8 yrs
120,000 mi/192,000 km/10 yrs
120,000 mi/192,000 km/7 yrs
1
1
Maintenance Schedule for Severe Conditions (listed by distance/time)

CONT INUED
Maint enance
Required Maintenance Record (f or Normal and Severe Schedules)
201
3,750 mi
7,500 mi
11,250 mi
15,000 mi
18,750 mi
22,500 mi
26,250 mi
30,000 mi33,750 mi
37,500 mi
41,250 mi
45,000 mi
48,750 mi
52,500 mi
56,250 mi
60,000 mi
mi/km
Date
mi/km
Date
mi/km
Date
mi/km
Date
mi/km
Date
mi/km
Date
mi/km
Date
mi/km
Date
Signature or dealer stamp
Signature or dealer stamp mi/km
Date
mi/km
Date
mi/km
Date
mi/km
Date
mi/km
Date
mi/km
Date
mi/km
Date
mi/km
Date
You or the servicing dealer can record all completed maintenance here, whether you follow the schedule for normal conditions (page ) or severe
conditions (page ). Keep the receipts for all work done on your car.
6,000 km
12,000 km
18,000 km
24,000 km
(or 1 year)
30,000 km
36,000 km
42,000 km
48,000 km
(or 2 years) 54,000 km
60,000 km
66,000 km
72,000 km
(or 3 years)
78,000 km
84,000 km
90,000 km
96,000 km
(or 4 years)
198
196

Maint enance
Required Maintenance Record (f or Normal and Severe Schedules)
202
63,750 mi
67,500 mi
71,250 mi
75,000 mi
78,750 mi
82,500 mi
86,250 mi
90,000 mi93,750 mi
97,500 mi
101,250 mi
105,000 mi
108,750 mi
112,500 mi
116,250 mi
120,000 mi
Signature or dealer stamp mi/km
Date
mi/km
Date
mi/km
Date
mi/km
Date
mi/km
Date
mi/km
Date
mi/km
Date
mi/km
Date Signature or dealer stamp mi/km
Date
mi/km
Date
mi/km
Date
mi/km
Date
mi/km
Date
mi/km
Date
mi/km
Date
mi/km
Date
102,000 km
108,000 km
114,000 km
120,000 km
(or 5 years)
126,000 km
132,000 km
138,000 km
144,000 km
(or 6 years) 150,000 km
156,000 km
162,000 km
168,000 km
(or 7 years)
174,000 km
180,000 km
186,000 km
192,000 km
(or 8 years)

µ
The numbers on the container’s label
tell you the oil’s viscosity or weight.
Select the oil f or your car according
to this chart.
An oil with a viscosity of 5W-30 is
pref erred f or improved f uel economy
and year-round protection in your
Acura. You may use a 10W-30 oil if
the temperature in your area never
goes below 20°F ( 7°C).You may use a synthetic motor oil if
it meets the same requirements
given f or a conventional motor oil: it
displays the API Certif ication Seal,
and it is the proper weight as shown
on the chart. When using synthetic
oil, you must f ollow the oil and f ilter
change intervals given in the
maintenance schedule.
Engine Oil
Maint enance
Synthetic Oil
206
A A
m
m b
bi
ieen n t
t T
Te
emm p
pe
erraat tuu r
ree

CONT INUED
Always change the oil and f ilter
accordingtothetimeanddistance
(miles/kilometers) recommenda-
tions in the maintenance schedule.
The oil and f ilter collect contami-
nants that can damage your engine if
they are not removed regularly.
Changing the oil and f ilter requires
special tools and access f rom
underneath the car. The car should
be raised on a service station-type
hydraulic lif t f or this service. Unless
you have the knowledge and proper
equipment, you should have this
maintenance done by a skilled
mechanic.Run the engine until it reaches
normal operating temperature,
then shut it off.
Your Acura does not need any oil
additives. Purchasing additives f or
the engine or transmission will not
increase your car’s perf ormance or
longevity. It only increases the cost
of operating your car. 1.
Engine Oil
Maint enance
Additives
Changing the Oil and Filter
207

Pour coolant into the reserve tank.
Fill it to half way between the MAX
and MIN marks. Put the cap back
on the reserve tank.Do not add any rust inhibitors or
other additives to your car’s cooling
system. They may not be compatible
with the coolant or engine compo-
nents.
Draining the coolant requires access
to the underside of the car. Unless
you have the tools and knowledge,
you should have this maintenance
done by a skilled mechanic. Thecoolingsystemshouldbe
completely drained and ref illed with
new coolant according to the time
and distance recommendations in
the maintenance schedule. Only use
Honda All season Antif reeze/
Coolant Type 2.
6. Replacing Engine Coolant
Cooling Syst em
Maint enance212
R RE
ES
SE ER
RV V E
E T
TA
A N
NK K
