Acura TL 2004 Owners Manual

µ
See pages f or important saf ety
inf ormation and warnings about how toproperly position seats and seat-backs. 1211
The controls f or the power
adjustable front seats are on the
outside edge of each seat bottom.
You can adjust the seats with the
ignition switch in any position. Make
all seat adjustments bef ore you start
driving.
Moving the long horizontal switch on
the driver’s seat adjusts the seat
bottom in several directions. On the
passenger’s seat, the long horizontal
switch moves the seat only back and
f orth. The short vertical switch
adjusts the seat back angle.
The short horizontal switch on the
driver’s seat adjusts the degree of
lumbar support. Moves the seat forward
and backward.
Moves the seat up or
down and the rear of the
seat up or down.
(Driver’s seat only)
Raises or lowers the seat.
(Driver’s seat only)
Adjusts the seat-back
angle f orward or
backward.
Increases or decreases
the lumbar support.
(Driver’s seat only)
Seats
Inst rument s and Cont rols
Front Seat Power A djustments
88

See page f or important saf etyinf ormation and a warning about how toproperly position the head restraints. 13
The head restraints help protect you
and your passengers f rom whiplash
and other injuries. They are most
ef f ective when you adjust them so
the back of the occupant’s head rests
against the center of the restraint. A
taller person should adjust the
restraint as high as possible.
All head restraints adjust f or height.
The tilt of the f ront head restrains is
also adjustable. You need both hands
to adjust the restraint. Do not
attempt to adjust it while driving. To
raise it, pull upward. To lower the
restraint, push the release button
sideways, and push the restraint
down. To adjust the tilt, pivot the
f ront head restraint to the desired
position.The lid of the console compartment
canbeusedasanarmrestbymoving
it f orward and backward. Make sure
the armrest is securely latched.
Make sure the passenger’s hands or
fingersareawayfromthearmrest
bef ore moving it.
Seats
Inst rument s and Cont rols
Head Restraints
A rmrest
89
RELEASE BUTTON

Make sure all items in the trunk and
those extending through the pass-
through are secured.
For security, this cover can be
locked and unlocked only with the
master key. To lock the cover, insert
thekeyandturnitclockwise.
Never drive with this cover open and
the trunk lid open.
Seeon
page .
The trunk pass-through cover can be
opened f rom either side; it f olds
f orward onto the center armrest.
Open the cover by sliding the knob
downward and pushing or pulling on
the cover. To close the cover, swing
it up and push f irmly on the top.
Make sure it latches properly.
The rear seat armrest is in the
center of the rear seat. Pivot it down
to use it.
46
Carbon Monoxide Hazard
T runk Pass-through Cover
Seats, T runk Pass-through Cover
Inst rument s and Cont rols90
KNOB
COVER

Keeptheinsideandoutsidemirrors
clean and adjusted f or best visibility.
Be sure to adjust the mirrors bef ore
you start driving.The inside mirror can automatically
darken to reduce glare. To turn on
this feature, press the button on the
bottom of the mirror. The AUTO
indicator comes on as a reminder.
When it is on, the mirror darkens
when it senses the headlights of a
vehicle behind you, then returns to
normal visibility when the lights are
gone. Press the button again to turn
of f this sensing. Move the selector switch to L
(driver’s side) or R (passenger’s
side).
Push the appropriate edge of the
adjustment switch to move the
mirrorright,left,up,ordown.
1.
2.
Mirrors
Inst rument s and Cont rols
Adjusting the Power Mirrors
91
SELECTOR SWITCH
ADJUSTMENT
SWITCH

When you f inish, move the
selector switch to the center (off)
position. This turns of f the
adjustment switch so you can’t
move a mirror out of position by
accidentally bumping the switch.The outside mirrors are heated to
remove fog and frost. With the
ignition switch in the ON (II)
position, turn on the heaters by
pressing the button. The indicator in
the button comes on as a reminder.
Press the button again to turn the
heaters off.
Depending on the position of the
selector switch, the lef t or right side
mirror will pivot downward slightly
when you shif t the transmission into
reverse. In the Lef t position, the lef t
mirror pivots. In the Right position,
the right mirror pivots. This gives
you a better view of that side of the
vehicle while parallel parking. The
mirror returns to its original position
when you take the transmission out
of reverse. To turn this f eature of f ,
leave the switch in the center
position.
Outside mirror positions can be
stored in the driving position
memory system (see page ). 3.
93
Inst rument s and Cont rols
Mirrors
92
HEATED MIRROR BUTTON

Your Acura has a memory f eature
f or the driver’s seat and outside
mirror positions.
Two seat and outside mirror
positions, can be stored in separate
memories. You select a memorized
position by pushing the appropriate
button or using the appropriate
remote transmitter (Driver 1 or
Driver 2).Press and release the MEMO
buttononthecontrolpanel.You
will hear a beep. Immediately
press and hold one of the memory
buttons (1 or 2) until you hear two
beeps. The indicator in the
memory button will come on. The
current positions of the driver’s
seat and outside mirrors are now
stored.
Adjust the outside mirrors f or best
visibility (see page ). Adjust the seat to a comfortable
position (see page ). Turn the ignition switch to ON (II).
You cannot add a new driving
position in the memory unless the
ignition switch is in the ON (II)
position. You can recall a
memorized position with the
ignition switch in any position.
Store a driving position only when
the vehicle is parked.
3.
1.
2.
91
88
CONT INUED
Driving Posit ion Memory Syst em
Inst rument s and Cont rols
Storing a Driving Position in
Memory
93
MEMO BUTTON
MEMORY BUTTONS

Doing any of the f ollowing af ter
pressing the MEMO button will
cancel the storing procedure.Not pressing a memory button
within 5 seconds.
Readjusting the seat position.
Readjusting the outside mirror
position.
Each memory button stores only one
driving position. Storing a new
position erases the previous setting
stored in that button’s memory. If
you want to add a new position while
retaining the current one, use the
other memory button. To select a memorized position, do
this:
Make sure the parking brake is set
(M/T) or the shif t lever is in Park
(A/T).
Press the desired memory button
(1 or 2) until you hear a beep, then
release the button. The system will move the seat and
outside mirrors to the memorized
positions. The indicator in the
selected memory button will f lash
during movement. When the
adjustments are complete, you will
hear two beeps, and the indicator will
remain on.
You cannot select a memorized
position if the transmission is in
Reverse. Shif t to another gear,
then select.
If the parking brake is not set, you
must press and hold the memory
button until the adjustment is
complete.
1.
2.
Notes f or vehicles with M/T
Driving Posit ion Memory Syst em
Inst rument s and Cont rols
Selecting a Memorized Position
94
MEMORY BUTTONS

To stop the system’s automatic
adjustment, do any of these actions:Press any button on the control
panel: MEMO, 1, or 2. If desired, you can use the
adjustment switches to change the
positions of the seat or outside
mirrors af ter they are in their
memorized position. If you change
the memorized position, the
indicator in the memory button will
go out. To keep this driving position
f or later use, you must store it in the
driving position memory.
Adjust the outside mirrors. Shif t out of Park. Push any of the adjustment
switches f or the seat.
Driving Posit ion Memory Syst em
Inst rument s and Cont rols95

Both f ront seats are equipped with
seat heaters. The ignition switch
must be in the ON (II) position to
usethem.PushtheHIsideof the
switch to rapidly heat up the seat.
After the seat reaches a comfortable
temperature, push the LO side of the
switch. This will keep the seat warm.The HI or LO indicator stays on until
youturnitoff bypushingthe
opposite side of the switch lightly.
In HI, the heater turns of f when the
seat gets warm, and turns back on
after the seat’s temperature drops. It
continues to cycle as long as you
leave it set on HI. The HI indicator
stays on as a reminder that you have
the heater on.
In LO, the heater runs continuously.
It does not cycle with temperature
changes.
Follow these precautions whenever
you use the seat heaters:
Use the HI setting only to heat the
seats quickly. Select the LO
setting when the seats f eel warm.
The HI setting draws large
amounts of current f rom the
battery.
Do not use the seat heaters, even
on the LO setting, if the engine is
lef t idling f or an extended period.
Thiscanweakenthebattery,
causing hard starting.
Because of the sensors f or the side
airbag system, there is no heater in
the passenger’s seat-back.
Seat Heaters
Inst rument s and Cont rols96
SEAT HEATERS

Your vehicle’s windows are electri-
cally-powered. Turn the ignition
switch to ON (II) to raise or lower
any window.
Each door has a switch that controls
its window. To open the window,
push the switch down and hold it.
Release the switch when you want
the window to stop. Close the
window by pulling back on the
switch and holding it.The driver’s door armrest has a
master power window control panel.
To open any window, push down on
the appropriate switch and hold it
until the window reaches the desired
position. To close the window, pull
back on the window switch. Release
the switch when the window gets to
the position you want.
Power Windows
Inst rument s and Cont rols97
DRIVER’S WINDOW
SWITCHMAIN
SWITCH
Closing a power window on
someone’s hands or fingers can
cause serious injury.
Make sure your passengers are
away from the windows before
closing them.
