engine Acura TL 2008 User Guide

µ
To turn on automatic lighting, turn
the light switch to AUTO at any time.
The lights will come on automatically
when the outside light level becomes
low (at dusk, f or example). The
lights on indicator comes on as a
reminder. The lights and indicator
will turn of f automatically when the
system senses high ambient light.
The lights will remain on when you
turn of f the ignition switch. They will
turn of f automatically when you
remove the key and open the driver’s
door. To turn them on again, either
turn the ignition switch to the ON
(II) position or turn the light switch
to the position. Even with the automatic lighting
f eature turned on, we recommend
thatyouturnonthelightsmanually
when driving at night or in a dense
f og, or when you enter dark areas
such as long tunnels or parking
f acilities.
Do not leave the light switch in
AUTO if you will not be driving the
vehicle f or an extended period (a
weekormore).Youshouldalsoturn
of f the lights if you plan to leave the
engine idling or of f f or a long time. The automatic lighting f eature is
controlledbyasensorlocatedontop
of the dashboard. Do not cover this
sensor or spill liquids on it.
The automatic lighting
f eature turns on the headlights and
all other exterior lights when it
senses low ambient light.
CONT INUED
Turn Signals and Headlights
AUTO
Inst rument s and Cont rols
87
LIGHT SENSOR
\f—\f—
y
\f\fy
(%\fy\f\fy
2008 TL

The master key fits all the locks on
your vehicle.
The valet key works only in the
ignition and the driver’s door lock.
You can keep the trunk pass-through
cover and the glove box locked when
you leave your vehicle and the valet
key at a parking f acility.Youshouldhavereceivedakey
number tag with your key. You will
need this key number if you ever
have to get a lost key replaced. Use
only an Acura-approved key blank.
Donotdropthekeysorsetheavy
objects on them.
Protect the key f rom direct
sunlight, high temperature, and
high humidity.
Keep the keys away f rom liquids.
If they get wet, dry them
immediately with a sof t cloth.
These keys contain electronic
circuits that are activated by the
immobilizer system. They will not
work to start the engine if the
circuits are damaged.
The valet key does not contain a
battery. Do not try to take it apart.
Keys and Locks
92
KEY NUMBER
TAG
VALET
KEY
(GRAY)
MASTER
KEY
\f—\f—
y
\fy
(%\fy\f\fy
2008 TL

Always make sure the key is f ully
extended when you insert it to the
ignition switch. If the key is not f ully
extended the immobilizer system
may not operate properly and
prevent the engine f rom starting.Thekeymaycomeincontactwith
your f inger while being retracted or
extended. Make sure your f ingers do
not touch the pivot of the key when
retracting or extending it.
The master key can be retracted into
theremotetransmitter.Tousethe
key, push the release button. The
key should be f ully extended. To
retract the key, push the release
buttonandatthesametimepushthe
key into the remote transmitter until
it is securely latched.Retractable Master Key
Keys and Locks
Inst rument s and Cont rols
93
Push
RELEASE BUTTON
\f—\f—
y
\fy
(%\fy\f\fy
2008 TL

Do not attempt to alter this system
or add other devices to it. Electrical
problems could result that may make
your vehicle undrivable.
If you have lost your key and you
cannot start the engine, contact your
dealer.
If the system repeatedly does not
recognize the coding of your key,
contact your dealer.
When you turn the ignition switch to
the ON (II) position, the immobilizer
system indicator should come on
brief ly, then go of f . If the indicator
starts to blink, it means the system
does not recognize the coding of the
key. Turn the ignition switch to the
LOCK (0) position, remove the key,
reinsert it, and turn the ignition
switch to the ON (II) position again.
The system may not recognize your
key’s coding if another immobilizer
key or other metal object (i.e. key
f ob) is near the ignition switch when
you insert the key.
The immobilizer system protects
your vehicle f rom thef t. If an
improperly-coded key (or other
device) is used, the engine’s f uel
system is disabled.
As required by the FCC: This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.
Immobilizer System
94
Always take the ignition key with you
whenever you leave the vehicle alone.
\f—\f—
y
\f
y
(%\fy\f\fy
2008 TL

µµ
µ
µ
The ignition switch has f our
positions: LOCK (0), ACCESSORY
(I), ON (II), and START (III).
You can insert or
remove the key only in this position.
To turn the key, you must push the
key in slightly. If your vehicle has an
automatic transmission, the shif t
lever must also be in Park. If the f ront wheels are turned, the
anti-theft lock may make it difficult
to turn the key. Firmly turn the
steering wheel to the lef t or right as
you turn the key.
You can
operate the audio system and the
accessory power sockets in this
position.
This is the normal key
position when driving. Several of the
indicators on the instrument panel
come on as a test when you turn the
ignition switch f rom the
ACCESSORY (I) to the ON (II)
position. You will hear a reminder beeper if
you leave the key in the ignition
switch in the LOCK (0) or the
ACCESSORY (I) position and open
the driver’s door. Remove the key to
turn of f the beeper.
If your vehicle has an automatic
transmission, the shif t lever must be
in Park bef ore you can remove the
key f rom the ignition switch.
Use this position
only to start the engine. The switch
returns to the ON (II) position when
you let go of the key.
LOCK (0) A CCESSORY (I)
ON (II)
ST A RT (III)
Ignition Switch
Inst rument s and Cont rols
95
Removing the key from the
ignition switch while driving
locks the steering. This can
cause you to lose control of the
vehicle.
Remove the key from the
ignition switch only when
parked.
\f—\f—
y
\fy
(%\fy\f
\f\fy
2008 TL

Follow these precautions whenever
you use the seat heaters:Use the HI setting only to heat the
seats quickly, because it draws
large amounts of current f rom the
battery.
If the engine is lef t idling f or an
extended period, do not use the
seat heaters even on the LO
setting. It can weaken the battery,
causing hard starting.
Both f ront seats are equipped with
seat heaters. Because of the sensors
f or the side airbag cutof f system,
there is no heater in the passenger’s
seat-back. The ignition switch must
be in the ON (II) position to use the
heaters. Push the right side of the switch, HI,
to rapidly heat up the seat. Af ter the
seat reaches a comfortable
temperature, select LO by pushing
the lef t side of the switch. This will
keep the seat warm.
In the LO setting, the heater runs
continuously. It does not cycle with
temperature changes.
In the HI setting, the heater turns off
when the seat gets warm, and turns
back on after the seat’s temperature
drops.
Seat Heaters
Inst rument s and Cont rols
111
SEAT HEATER SWITCHES
\f—\f—
y
\fy
(%\fy\f

y
2008 TL

If your vehicle’s battery is
disconnected or goes dead, or a f ront
window f use is removed, the AUTO
f unction is disabled. The power
window system needs to be reset
af ter reconnecting the battery or
installing the f use.Start the engine. Push down and
hold the f ront window switch until
the window is f ully open.
Pullandholdthefrontwindow
switch to close the window
completely, then hold the switch
f or a second or two more.
If the power windows do not operate
properly af ter resetting, have your
vehicle checked by your dealer.
If either f ront window runs into any
obstacle while it is closing
automatically, it will reverse
direction, and then stop. To close the
window, remove the obstacle, then
use the window switch again.
Auto reverse stops sensing when the
window is almost closed. You should
always check that all passengers and
objects are away from the window
bef ore closing it.
To close either f ront window f ully,
pull back the window switch f irmly
to the second detent, then release it.
The window automatically goes all
the way up. To stop the window f rom
going all the way up, push down on
the window switch briefly.
When you push the MAIN switch in,
the switch is off, and the passengers’
windows cannot be raised or lowered.
To cancel this f eature, push on the
switch again to get it to pop out.
Keep the MAIN switch pushed in
whenyouhavechildreninthe
vehicle so they do not injure
themselves by operating the
windows unintentionally.
1.
2.
Auto Reverse
Power Windows
Inst rument s and Cont rols
113
\f—\f—
y
\f\fy
(%\fy\f

y
2008 TL

Use the mode control button to
select the vents the air flows from.
Some air will flow from the
dashboard vents in all modes.Air flows from the center
and corner vents in the dashboard.
Air f lows f rom the def roster
vents at the base of the windshield. Air f lows f rom the f loor
vents. When you select , the
system automatically switches to
f resh air mode. Airf low is divided between
the vents in the dashboard and the
f loor vents.
Airf low is divided between
the f loor vents and the def roster
vents at the base of the windshield. When you select or ,
the system automatically switches to
f resh air mode and turns on the A/C.
In this case, you cannot turn the A/C
off.
Select and fresh air mode.
Set the f an to the desired speed.
Adjust the warmth of the air with
the temperature control buttons.
The heater uses engine coolant to
warm the air. If the engine is cold, it
will be several minutes bef ore you
f eel warm air coming f rom the
system. Set the temperature to maximum.
Make sure the A/C is of f .
Select and fresh air mode.
Set the f an to the desired speed.
You can set the temperatures and
modes f or the driver’s side and the
passenger’s side separately when
this button is pressed (indicator on).
When the indicator in the DUAL
button is off, you can adjust both
sides to the same temperature and
mode with the driver’s side temperature control buttons and
mode control button.
When is selected, the
passenger’s temperature cannot be
set separately f rom the driver’s.
Thedriver’ssidemodeand
passenger’s side mode can be
selected separately when the dual
button is pressed. However, when is selected on the driver’s
side, mode selection on the
passenger’s side is not possible. The f low-through ventilation system
draws in outside air, circulates it
through the interior, then exhausts it
through vents near the rear window.
1.
2.
3.
4.
1.
2.
3.
Vents, Heating, and A/C
Mode Control Button
Using the Heater
Ventilation
Dual Button
Features
129
\f—\f—
y
\f
y
(%\fy\f
y
2008 TL

Air conditioning, as it cools, removes
moisture from the air. When used in
combination with the heater, it
makes the interior warm and dry.Switch the f an on.
Turn on the air conditioning.
Select and fresh air mode.
Adjust the temperature to your
pref erence.
This setting is suitable f or all driving
conditions whenever the outside
temperature is above 32°F (0°C).
Air conditioning places an extra load
on the engine. Watch the engine
coolant temperature gauge (see page
). If it moves near the red zone,
turn of f the A/C until the gauge
reading returns to normal.
To remove f og f rom inside the
windows:Set the f an to the desired speed, or
on high f or f aster def rosting.
Select . When you select , the system automatically
switches to f resh air mode and
turns on the A/C. The A/C ON indicator will not come on, if it was
previously of f .
Adjust the temperature so the
airflow feels warm.
Select to help clear the
rear window.
When you select or ,
the system automatically switches to
f resh air mode and turns on the A/C.
This helps to dehumidif y the air and
to def og the windshield. In either
mode, you cannot turn of f the A/C.
When you switch to another mode,
the A/C returns to its original setting,
either on or of f , as displayed by the
A/C ON or A/C OFF indicator.
Turn on the A/C by pressing the
button.
Set the temperature to the desired
level. For quick cooling set the
temperature to maximum cool.
Select .
If the outside air is humid, select
recirculation mode. If the outside
air is dry, select f resh air mode.
Set the f an to the desired speed.
you can
cool it down more rapidly by partially
opening the windows, turning on the
air conditioning, and setting the f an
to maximum speed in f resh air mode. 1.
2.
3.
4.
1.
2.3.
4.
1.
2.
3.
4.
5. 65
If the interior is very warm,
Vents, Heating, and A/C
Dehumidif y the Interior
Using the A/C
To Def og and Def rost
130
\f—\f—
y
\fy
(%\fy\f
y
2008 TL

You can make calls using any phone
number, or by using a name in the
HFL phonebook. You can also redial
the last number called. During a call,
theHFLallowsyoutotalkupto30
minutes af ter you remove the key
f rom the ignition switch. Continuing
a call without running the engine
may discharge and weaken the
vehicle’s battery.Press and release the Talk button.
Af ter the beep, say the number
you want to call. For example, say
‘‘123 456 7891.’’ The HFL response
is ‘‘123 456 7891. Say call, dial, or
continue to add numbers.’’
Press and release the Talk button.
Af ter the beep, say ‘‘Call’’ or ‘‘Dial.’’
The HFL response is ‘‘Calling’’ or
‘‘Dialing.’’ Once connected, you
will hear the person you called
through the audio speakers. To
change the volume, use the audio
system volume knob, or the
steering wheel volume controls.
To end the call, press the Back
button.
You can also make a call directly
f rom the list shown on the
navigation display.
For more inf ormation on how to
make a call, see page .
With your phone on and the
ignition in the ACCESSORY (I) or
ON (II) position, press and release
the Talk button. After the beep,
say ‘‘Call’’ or ‘‘Dial.’’ The HFL
response is, ‘‘What name or
number would you like to call/
dial?’’ 2.
4.
1. 3.
207
On vehicles with navigation system
To make a call using a phone number, do this:
Making a Call
BluetoothHandsFreeL ink
202
\f—\f—
y
\fy
(%\fy\f\fy
2008 TL
