To apply the parking brake, pull the
lever up f ully. To release it, pull up
slightly, push the button, and lower
the lever. The parking brake
indicator on the instrument panel
should go out when the parking
brake is f ully released (see page ).
You will also see a ‘‘RELEASE
PARKING BRAKE’’ message on the
multi-inf ormation display (see page). 59
68
Parking Brake
Inst rument s and Cont rols
117
Driving the vehicle with the parking
brake applied can damage the rear
brakes and axles. A beeper will sound
if the vehicle is driven with the parking
brake on.
\f—\f—
y
\fy
(%\fy\f
y
2008 TL

Vents, Heating, and A/C
126
AIR CONDITIONING BUTTON
RECIRCULATION BUTTON
PASSENGER’S SIDE MODE
CONTROL BUTTON
PASSENGER’S AUTO BUTTON
WINDSHIELD
DEFROST BUTTON
PASSENGER’S SIDE
TEMPERATURE
CONTROL BUTTONS
REAR WINDOW DEFOGGER BUTTON
DRIVER’S SIDE MODE
CONTROL BUTTON
OFF BUTTON
FAN CONTROL
BUTTONS DUAL BUTTON
DRIVER’S SIDE
TEMPERATURE
CONTROL BUTTONS TEMPERATURE DISPLAY
DRIVER’S AUTO BUTTON
Vehicles without navigation system
\f—\f—
y
\f\fy
(%\fy\f

y
2008 TL

Vents, Heating, and A/C
Features
127
REAR WINDOW DEFOGGER BUTTON
OFF BUTTON
WINDSHIELD
DEFROST BUTTON
FAN CONTROL
BUTTONS
DUAL BUTTON
RECIRCULATION BUTTON
AIR CONDITIONING
BUTTON
DRIVER’S SIDE MODE
CONTROL BUTTON DRIVER’S AUTO BUTTON TEMPERATURE DISPLAY PASSENGER’S AUTO BUTTON
Vehicles with navigation system
PASSENGER’S SIDE
MODE CONTROL BUTTON
PASSENGER’S SIDE
TEMPERATURE
CONTROL BUTTONS
DRIVER’S SIDE
TEMPERATURE
CONTROL BUTTONS
\f—\f—
y
\fy
(%\fy\f
y
2008 TL

Û
Ý When the indicator in the button is
on, air f rom the vehicle’s interior is
recirculated throughout the system.
When the indicator is off, air is
brought in f rom the outside of the
vehicle (fresh air mode).
The outside air intakes f or the
heating and cooling system are at
the base of the windshield. Keep this
area clear of leaves and other debris.
Thesystemshouldbeleftinfresh
air mode under almost all conditions.
Keeping the system in recirculation
mode, particularly with the A/C of f ,
can cause the windows to fog up.
Switch to recirculation mode when
driving through dusty or smoky
conditions, then return to fresh air
mode.
This button turns the rear window
def ogger of f and on (see page ).
The driver’s side temperature and
passenger’s side temperature can be
set separately. Press either side’s
button to increase the temperature
of airf low. Press either side’s
button to decrease it. When you set
the temperature to its lower limit or
its upper limit, it will be displayed as
‘‘Lo’’ or ‘‘Hi’’.
This button turns the air
conditioning on and of f . The A/C
ON indicator comes on in the display
when the A/C is on.
The climate control system in your
vehicle can also be operated using
the voice control system. See the
navigation section in your quick start
guide f or an overview of this system
and the navigation system manual
f or complete details.
Press the button to increase the
fanspeedandairflow.Pressthe
button to decrease it.
90
Only on models with navigation system
Voice Control System Recirculation Button
Rear Window Def ogger Button
Temperature Control Buttons
Air Conditioning (A/C) Button
Fan Control Buttons
Vents, Heating, and A/C
128
\f—\f—
y
\fy
(%\fy\f
y
2008 TL

Air conditioning, as it cools, removes
moisture from the air. When used in
combination with the heater, it
makes the interior warm and dry.Switch the f an on.
Turn on the air conditioning.
Select and fresh air mode.
Adjust the temperature to your
pref erence.
This setting is suitable f or all driving
conditions whenever the outside
temperature is above 32°F (0°C).
Air conditioning places an extra load
on the engine. Watch the engine
coolant temperature gauge (see page
). If it moves near the red zone,
turn of f the A/C until the gauge
reading returns to normal.
To remove f og f rom inside the
windows:Set the f an to the desired speed, or
on high f or f aster def rosting.
Select . When you select , the system automatically
switches to f resh air mode and
turns on the A/C. The A/C ON indicator will not come on, if it was
previously of f .
Adjust the temperature so the
airflow feels warm.
Select to help clear the
rear window.
When you select or ,
the system automatically switches to
f resh air mode and turns on the A/C.
This helps to dehumidif y the air and
to def og the windshield. In either
mode, you cannot turn of f the A/C.
When you switch to another mode,
the A/C returns to its original setting,
either on or of f , as displayed by the
A/C ON or A/C OFF indicator.
Turn on the A/C by pressing the
button.
Set the temperature to the desired
level. For quick cooling set the
temperature to maximum cool.
Select .
If the outside air is humid, select
recirculation mode. If the outside
air is dry, select f resh air mode.
Set the f an to the desired speed.
you can
cool it down more rapidly by partially
opening the windows, turning on the
air conditioning, and setting the f an
to maximum speed in f resh air mode. 1.
2.
3.
4.
1.
2.3.
4.
1.
2.
3.
4.
5. 65
If the interior is very warm,
Vents, Heating, and A/C
Dehumidif y the Interior
Using the A/C
To Def og and Def rost
130
\f—\f—
y
\fy
(%\fy\f
y
2008 TL

When the AUTO button on the
driver’s side is pressed, the
temperature control buttons on the
passenger’s side are disabled, and
the interior temperature is regulated
to the temperature set on the driver’s
side.WhentheAUTObuttononthe
passenger’s side is pressed,
temperature can be set on the driver’s
side and passenger’s side separately.
The system automatically selects the
proper mix of conditioned and/or
heated air that will, as quickly as
possible, raise or lower the interior
temperature to your pref erence.
When you set the temperature to its
lower or its upper limit, the system
runs at f ull cooling or heating only. It
does not regulate the interior
temperature.
The automatic climate control
system adjusts the f an speed and
airflow levels to maintain the interior
temperature you select.
In AUTO mode, the vehicle’s interior
temperature is independently
regulated f or the driver and
passenger. If the driver’s side of the
vehicle is getting too much sun, the
system will adjust to a lower
temperature.
Press the AUTO button.
Set the desired temperature with
the temperature control buttons.
You will see AUTO in the system’s
display.
Select . The system
automatically switches to f resh air
mode and turns on the A/C. The
A/C indicator does not come on if
it was previously off.
Select .
Set the f an and temperature
controls to maximum level.
To clear the windshield f aster, you
can close the dashboard corner vents
by rotating the wheel below each
vent. This sends more warm air to
the windshield def roster vents. Once
the windshield is clear, select f resh
air mode to avoid fogging the
windows.
For your saf ety, make sure you have
a clear view through all the windows
bef ore driving. 1.
2.
1.
2.
3.
On models with navigation system
CONT INUED
Climat e Cont rol
T o Cool or Heat A utomatically
Using A utomatic Climate Control
T o Remove Exterior Frost or Ice
From the Windows
Features
131
\f—\f—
y
\fy
(%\fy\f
y
2008 TL

You can manually select various
f unctions of the climate control
system when it is in f ully automatic
mode. All other f eatures remain
automatically controlled. Making any
manual selection causes the word
AUTO in the display to go out.
Press the OFF button. However, a
lack of airf low can cause the
windowstofogup.Youshouldkeep
the fan on at all times so stale air and
moisture do not build up in the
interior and cause f ogging.Theclimatecontrolsystemhasa
temperature sensor next to the
steering column. Do not cover the
sensor or spill any liquid on it.
When you press a f an control button,
the fan is taken out of AUTO mode
and starts to run at its lowest speed.
Press the button to make the
fan run faster.
Climat e Cont rol
Semi-automatic Operation
To Turn Everything Off
T emperature Sensor
132
TEMPERATURE SENSOR
\f—\f—
y
\fy
(%\fy\f
y
2008 TL

µ
µ ´µ µ
The ignition switch must be in the
ACCESSORY (I) or ON (II) position.
Turn the system on by pushing the
power/volume knob or the AM/FM
button. Adjust the volume by turning
the power/volume knob. You can use any of f ive methods to
f ind radio stations on the selected
band: tune, seek, scan, the preset
buttons, and auto select.
Use the TUNE knob to
tune the radio to a desired f requency.
Turn the knob to the right to tune to
a higher f requency, and turn it to the
lef t to tune to a lower f requency.
The band and f requency that the
radio was last tuned to are displayed.
To change bands, press the AM/FM
button. On the FM band, ST will be
displayed if the station is
broadcasting in stereo. Stereo
reproduction in AM is not available. The seek f unction
searches up and down from the
current f requency to f ind a station
with a strong signal. To activate it,
press the or SEEK button, then
release it. The scan f unction samples
all stations with strong signals on the
selected band. To activate it, press
the SCAN button, then release it.
You will see SCAN in the display.
The system will scan f or a station
with a strong signal. When it f inds
one, it will stop and play that station
f or about 10 seconds.
If you do nothing, the system will
scan f or the next strong station and
play it f or 10 seconds. When it plays
a station that you want to listen to,
press the SCAN button again.
CONT INUED
TUNE
SEEK SCAN
Playing the A M/FM Radio Selecting a Station
Audio System (Models without Navigation System)
Features
135
\f—\f—
y

\f\f\fy
(%\fy\f
\fy
2008 TL

µµEach preset button can
store one f requency on AM and two
f requencies on FM.
Select the desired band, AM or
FM. FM1 and FM2 let you store
two f requencies with each preset
button.
Usethetune,seek,orscan
function to tune the radio to a
desired station.
Repeat steps 1 through 3 to store a
total of six stations on AM and
twelve stations on FM.
Pick a preset button, and hold it
until you hear a beep. If you are
traveling far from home and can no
longer receive your preset stations,
you can use the auto select feature to
find stations in the local area.
Press the A. SEL button. You will see
A. SEL f lashing in the display, and
the system goes into scan mode f or
several seconds. It stores the
f requencies of six AM, and twelve
FM stations in the preset buttons.
You will see a ‘‘0’’ displayed af ter
pressing a preset button if auto
select cannot f ind a strong station f or
every preset button. If you do not like the stations auto
select has stored, you can store
other f requencies on the preset
buttons as previously described.
press the
A. SEL button. This restores the
presets you originally set.
For inf ormation on AM/FM radio
f requencies and reception, see page
.
1.
2.
3.
4.
180
To turn of f auto select,
Preset A UT O SEL ECT
Audio System (Models without Navigation System)
136
\f—\f—
y

\f\fy
(%\fy\f

y
2008 TL

µ
µ
µ
Bass, treble, balance, and fader are
each adjustable. In addition, you can
adjust the strength of the sound
coming from the center and the
subwoof er speakers. These two
modes adjust the strength of the
sound coming f rom the center
speaker and the subwoof er speaker.
If you turn the TUNE/SOUND knob
all the way to the lef t, you will see
‘‘OFF’’inthedisplay,andthecenter
speaker and/or subwoof er speaker
will be of f .
Press the TUNE/SOUND knob
repeatedly to display the bass, treble,
balance, f ader, center and subwoof er
setting.
Eachmodeisshowninthedisplayas
it changes. Turn the TUNE/SOUND
knob to adjust the setting to your
liking. When the level reaches the
center, you will see ‘‘C’’ in the display.
The system will automatically return
the display to the selected audio
mode about 5 seconds af ter you stop
adjusting a mode. Use the TREB/
BASS modes to adjust the tone to
your liking.
These two
modes adjust the strength of the
sound coming f rom each speaker.
BAL adjusts the side-to-side strength,
and FADE adjusts the f ront-to-back
strength.
CONT INUED
A djusting the Sound Center/Subwoof er Treble/Bass
Balance/Fader
Audio System (Models without Navigation System)
Features
137
\f—\f—
y

\f
y
(%\fy\f
y
2008 TL
