Pressing either INFO button ( / )
switches the display f rom the
message to another display. Once
you switch the display, this message
will go of f .
Press the SEL/RESET button on the
steering wheel repeatedly to select
the engine oil lif e. The message
‘‘SERVICE,’’ along with ‘‘5%,’’ and the
maintenance item code are displayed
on the multi-information display
when the calculated engine oil lif e is
1to5percent(seepage ).If the indicated maintenance service
is not done and the remaining engine
oil lif e reaches 0%, the multi-
inf ormation display will show the
message ‘‘SERVICE PAST DUE’’
and the maintenance item code(s).
This message is displayed when the
total distance traveled is less than 10
miles (f or U.S. models) or 10 km (f or
Canadian models) af ter the engine
oillifebecame0%.
498
Maintenance Minder
500
09/07/29 18:26:50 31TK4610_505
2010 TL

Î
ÛÝ
Î
CONT INUED
Press the SEL/RESET button on the
steering wheel repeatedly to select
the engine oil lif e. The message
‘‘SERVICE,’’ along with ‘‘0%,’’ and the
maintenance item code are displayed
on the multi-information display
when the calculated engine oil lif e is
0to1percent.
These messages will come on every
time you turn the ignition switch to
the ON (II) position.
If the indicated required service is
not done and the remaining engine
oil lif e becomes 0%, the multi-
inf ormation display will show a
‘‘SERVICE PAST DUE’’ message,
the total distance traveled after the
remaining oil lif e became 0%, and the
maintenance item code(s).
Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pages
and .
Pressing either INFO button ( / )
switches the display f rom the
message to another display. To see
the message again, press either
INFO button repeatedly. Immediately have the service
perf ormed, and make sure to reset
the display as described on page . :
178 181 503
Maintenance Minder
Maint enance
501
U.S.
CANADA TOTAL PAST DUE DISTANCE
TRAVELED
MAINTENANCE CODES
09/07/29 18:27:00 31TK4610_506
2010 TL

ÛÝ
This message is displayed again
when you drive over 10 miles (f or
U.S. models) or 10 km (f or Canadian
models) af ter seeing the 0% message.
Immediately have the service
perf ormed, and make sure to reset
the display as described on page .
Pressing either INFO button ( / )
switches the display f rom the
message to another display. To see
the message again, press either
INFO button repeatedly.
All maintenance items shown on the
multi-inf ormation display are in code.
For an explanation of these
maintenance codes, see page .
When you press the SEL/RESET
button to select the engine oil lif e,
the message ‘‘SERVICE,’’ along with
the maintenance item code(s) and
the total negative distance traveled
af ter the oil lif e became 0%, will be
displayed on the multi-inf ormation
display.
501
506
Maintenance Minder
Maintenance Main Items and Sub
Items
502
U.S.
CANADAMAINTENANCE
MAIN ITEM
MAINTENANCE
SUB ITEMS
MAINTENANCE
MAIN ITEM MAINTENANCE
SUB ITEMS
TOTAL PAST DUE DISTANCE
TRAVELED
09/07/29 18:27:10 31TK4610_507
2010 TL

ÛÝ
Î
Î Î
Select ‘‘RESET’’ by pressing the
INFO ( / ) button, then press
the SEL/RESET button to reset
the engine oil lif e display. The
maintenance item code(s) will
disappear, and the engine oil lif e
will reset to ‘‘100.’’ If you want to
cancel the oil lif e reset mode,
select ‘‘CANCEL.’’
Your dealer will reset the display
af ter completing the required
maintenance service. You will see
‘‘OIL LIFE 100%’’ on the display the
next time you turn the ignition
switch to the ON (II) position.
Turn the ignition switch to the
ON (II) position.
Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pages and .
If maintenance service is done by
someone other than your dealer,
reset the maintenance minder as
f ollows: If the engine oil lif e is not
displayed, press the SEL/RESET
buttononthesteeringwheel
repeatedly.
Press and hold the SEL/RESET
button on the steering wheel f or
more than 10 seconds. The
remaining engine oil lif e reset
mode will be shown on the multi-
inf ormation display.
3. 1.
2.
4.
:
178 181
Maintenance Minder
Resetting the Engine Oil Lif e
Display
Maint enance
503
09/07/29 18:27:20 31TK4610_508
2010 TL

Ì
U.S. Vehicles:
According to state and federal
regulations, f ailure to perf orm
maintenance on the items marked
with will not void your emissions
warranties. However, all
maintenance services should be
perf ormed in accordance with the
intervals indicated by the multi-
inf ormation display.
Your authorized dealer knows your
vehicle best and can provide
competent, ef f icient service.
However, service at a dealer is not
mandatory to keep your warranties
in effect. Maintenance may be done
by any qualif ied service f acility or
person who is skilled in this type of
automotive service. Keep all receipts
as proof of completion, and have the
person who does the work f ill out
your Maintenance Journal or
Canadian Maintenance Log. Check
your warranty booklet f or more
inf ormation.
If you have the required service
done but do not reset the display, or
reset the display without doing the
service, the system will not show the
correct maintenance intervals. This
canleadtoseriousmechanical
problems because you will no longer
have an accurate record of when
maintenance is needed.
We recommend using Acura parts
and fluids whenever you have
maintenance done. These are
manuf actured to the same high-
quality standards as the original
components, so you can be conf ident
of their perf ormance and durability.
Maintenance Minder
Maintenance, replacement, or
repair of emissions control
devices and systems may be done
by any automotive repair
establishment or individual using
parts that are ‘‘certif ied’’ to EPA
standards.
Important Maintenance
Precautions
504
09/07/29 18:27:28 31TK4610_509
2010 TL

Î
Î
Î
Î
Ì Ì
µµ
Ì
Î
Î
Maintenance Minder
506
:
If the message ‘‘SERVICE DUE NOW’’ does not appear more than 12 months
after the display is reset, change the engine oil every year.
See information on maintenance and emissions warranty on page .
Independent of the maintenance messages on the multi-information
display, replace the brake fluid every 3 years.
Inspect idle speed every 160,000 miles (256,000 km).
Adjust the valves during service 3 if they are noisy.
NOTE:
2:
1:
SH-AWD only
504
Maintenance Sub Items
Rotate tires
Replace air cleaner element If you drive in dusty conditions, replace every
15,000 miles (24,000 km).
Replace dust and pollen filter If you drive primarily in urban areas that have high
concentrations of soot in the air from industry and
from diesel-powered vehicles, replace every 15,000
miles (24,000 km).
Inspect drive belt
Replace transmission fluid
Replace transmission and transfer fluid
Replace spark plugs
Replace timing belt and inspect water pump If you drive regularly in very high temperatures (over
110°F, 43°C), or in very low temperatures (under20°F, 29°C), replace every 60,000 miles (U.S.)/
100,000 km (Canada).
Inspect valve clearance
Replace engine coolant
Replace rear differential fluid Driving in mountainous areas at very low vehicle
speeds results in higher level of mechanical (shear)
stress to fluid. This requires differential fluid changes
more frequently than recommended by the
maintenance minder. If you regularly drive your
vehicle under these conditions, have the differential
fluid changed at 7,500 miles (12,000 km), then every
15,000 miles (24,000 km).
Maintenance Main Items
Replace engine oil
Replace engine oil and oil filter
Inspect front and rear brakes
Check parking brake adjustment
Inspect these items: Tie rod ends, steering gear box, and boots
Suspension components
Driveshaft boots
Brake hoses and line (including ABS/VSA)
All fluid levels and condition of fluids
Exhaust system
Fuel lines and connections
A
B
Symbol
Symbol
3
4
5 1
2
6
2
2
1
1
Maintenance Minder
09/07/29 18:27:48 31TK4610_511
2010 TL

Oil is a major contributor to your
engine’s perf ormance and longevity.
Always use a premium-grade 5W-20
detergent oil displaying the API
Certif ication Seal. This seal indicates
the oil is energy conserving, and that
it meets the American Petroleum
Institute’s latest requirements.
Unscrew and remove the engine oil
fill cap on top of the valve cover.
Pour in the oil slowly and caref ully so
you do not spill. Clean up any spills
immediately. Spilled oil could
damage components in the engine
compartment. Install the engine oil
f ill cap, and tighten it securely. Wait
a f ew minutes, and recheck the oil
level (see page ). Do not f ill
above the upper mark; you could
damage the engine. Acura Motor Oil is the pref erred
5W-20 lubricant f or your vehicle. It is
highly recommended that you use
Acura Motor Oil in your vehicle f or
optimum engine protection. Make
sure the API Certif ication Seal says
‘‘For Gasoline Engines.’’
448
CONT INUED
Recommended Engine Oil
A dding Engine Oil
Maint enance
509
API CERTIFICATION SEAL
ENGINE OIL FILL CAP
09/07/29 18:28:13 31TK4610_514
2010 TL

You may use a synthetic motor oil if
it meets the same requirements
given f or a conventional motor oil: it
displays the API Certif ication Seal
and it is the proper weight. You must
f ollow the oil and f ilter change
intervals shown on the multi-
inf ormation display.
Your vehicle does not require any oil
additives. Additives may adversely
af f ect the engine or transmission
perf ormance and durability.
The oil viscosity or weight is
provided on the container’s label.
5W-20 oil is f ormulated f or year-
round protection of your vehicle to
improve cold weather starting and
f uel economy.
Always change the oil and f ilter
according to the maintenance
messages shown on the multi-
inf ormation display. The oil and f ilter
collect contaminants that can
damage your engine if they are not
removed regularly.
Changing the oil and f ilter requires
special tools and access f rom
underneath the vehicle. The vehicle
should be raised on a service station-
type hydraulic lif t f or this service.
Unless you have the knowledge and
proper equipment, you should have
this maintenance done by a skilled
technician.
Synthetic Oil
Engine Oil A dditives
Changing the Engine Oil and
Filter
A dding Engine Oil, Changing the Engine Oil and Filter
510
Ambient Temperature
09/07/29 18:28:24 31TK4610_515
2010 TL

Check the f luid level in the
windshield washer reservoir at least
monthly during normal use.If the washer f luid is low, a ‘‘LOW
WASHER FLUID’’ message appears
on the multi-information display.
Fill the reservoir with a good-quality
windshield washer f luid. This
increases the cleaning capability and
prevents f reezing in cold weather.
When you ref ill the reservoir, clean
the edges of the windshield wiper
blades with windshield washer f luid
on a clean cloth. This will help to
condition the blade edges.
To check washer f luid level, cover
the reservoir cap center hole with
your f inger while lif ting the cap and
the attached measuring tube. The
washer f luid level in the tube will
indicate the washer f luid level in the
reservoir.
On U.S. models On Canadian models
Windshield Washers
514
TUBE
Do not use engine antif reeze or a
vinegar/water solution in the
windshield washer reservoir. Antif reeze
can damage your vehicle’s paint, while
a vinegar/water solution can damage
the windshield washer pump. Use only
commercially-available windshield
washer f luid.
09/07/29 18:29:13 31TK4610_519
2010 TL

Insert the dipstick all the way back
into the transmission securely as
shown in the illustration.
The transmission should be drained
and ref illed with new f luid when this
service is indicated by a maintenance
message on the multi-inf ormation
display.
If you are not sure how to check and
add f luid, contact your dealer.
If the level is below the lower
mark, add f luid into the f iller hole
to bring it to the level between the
upperandlowermarks.
Pour the f luid slowly and caref ully
so you do not spill any. Clean up
any spill immediately; it could
damage components in the engine
compartment.
Always use Acura ATF-Z1
(automatic transmission f luid).
5.
6.
T ransmission Fluid
516
Using transmission f luid other than
Acura ATF-Z1 may cause deterioration
in transmission operation and
durability, and could result in damage
to the transmission.
Damage resulting f rom the use of
transmission f luid other than Acura
AT F-Z1 is not covered by the Acura
new vehicle warranty. Use only Acura ATF-Z1 (automatic
transmission f luid). Do not mix with
other transmission f luids.
09/07/29 18:29:34 31TK4610_521
2010 TL
