Acura TL 2011 Owner's Manual

The f ollowing keys come with your
vehicle. Refer to page for how to
separate the keys.
This key is used to lock/unlock the
doors, glove box, and trunk pass-
through cover.This remote is used to lock/unlock
the doors and unlock the trunk.
When you carry the remote, you can
lock/unlock the doors, unlock the
trunk, and start the engine.
Anyone can lock/unlock a door or
open the trunk if the remote is
within the operating range of the
door or the trunk. You can lock/unlock the doors
within about a 32 inch (about 80 cm)
radius f rom the outside door handle.
You can open the trunk within about
a 32 inch (about 80 cm) radius f rom
thetrunkreleaseswitch.
195
Keys
K eyless A ccess System
Built -in K ey
K eyless A ccess Remot e
168
BUILT-IN KEYS
OPERATING
RANGE
KEYLESS ACCESS
REMOTES
KEY NUMBER TAG
10/07/29 12:01:36 31TK4620_173
2011 TL

Theremotemaynotworkif:It is too close to the vehicle.
It is above or below the vehicle,
even when it is within its operating
range.
The handle of each f ront door has a
sensor. That sensor works with the
remote so you can automatically
unlock the door(s).
By def ault, only the driver’s door
unlocks when you grab its handle.
Each f ront door has a LOCK/
UNLOCK f eature.
To change the ‘‘KEYLESS ACCESS
BEEP’’ setting, see page . To unlock the remaining doors and
the trunk, press the UNLOCK
button on the remote or the rear of
the master door lock switch on the
driver’s door.
To change the ‘‘DOOR UNLOCK
MODE’’ setting, see page .
All the doors unlock when you
grab the handle of the front
passenger’s door.
When you unlock the door(s), some
exterior lights blink twice and the
system beeps twice.
To change the ‘‘KEYLESS ACCESS
LIGHT FLASH’’ setting, see. 112
114
CONT INUED
K eyless A ccess System
Unlocking the Door(s)
Inst rument s and Cont rols
169
10/07/29 12:01:45 31TK4620_174
page 113
2011 TL

Bef ore locking the doors, make sure
theremoteisnotinsidethevehicle. When you press the door lock button
on the f ront door, all the doors and
the trunk will lock.
Theremoteisnotwithinthe
operating range.
The remote is too close to the
vehicle.
When the doors are unlocked.
The vehicle battery is dead. Theremotebatteryisdead.
Each unlock sensor does not operate
when:
If you wear a glove while grabbing a
f ront door handle, the door sensor
maybeslowtorespondormaynot
respond by unlocking the doors.
If you do not open any of the doors
within 30 seconds, they will
automatically relock.
If a remote is within operating range
while you wash your vehicle or when
it is raining heavily, the door sensors
may respond by unlocking the doors.
K eyless A ccess System
L ocking the Doors
170
DOOR LOCK BUTTON
10/07/29 12:01:54 31TK4620_175
2011 TL

When you lock the doors, some
exterior lights blink and the system
beeps once. If no exterior lights blink
and/or no beeper sounds, check to
see if the trunk or hood is open.
To change the ‘‘KEYLESS ACCESS
LIGHT FLASH’’ setting, see.
To change the ‘‘KEYLESS ACCESS
BEEP’’ setting, see page .
Within 2 seconds of pressing the
door lock button or locking the doors
with the remote, pull the handle to
make sure the doors are actually
locked. The door unlock sensors will
not operate f or about 2 seconds af ter
the doors are locked. The door lock button does not work if:
Theremoteisnotwithinthe
operating range. If you open the driver’s door, pull its
locktabrearwardonthedoor,and
shutitwhentheremoteisinsidethe
vehicle, the driver’s door will unlock.
Make sure you carry the remote
with you when you lock the doors.
Any door is open.
The power mode is not set to
VEHICLE OFF (LOCK).
The remote is in the keyless
access slot.
The remote is too close to the
vehicle.
Theremotebatteryisdead.
The vehicle battery is dead. This function is also activated on the
f ront passenger’s door. If you open
the f ront passenger’s door, and shut
it af ter pulling its lock tab rearward
whentheremoteisinsidethevehicle,
all doors will unlock.
The door lock prevention will also
activate if you try to lock the doors
with the master door lock switch
whentheremoteisinsidethevehicle.
114
K eyless A ccess System
Door L ock Prevent ion
Inst rument s and Cont rols
171
10/07/29 12:02:05 31TK4620_176
page 113
2011 TL

When you close the trunk with all
doors locked, the trunk will lock.
When you unlock all the doors with
the remote, built-in key or power
door lock master switch, the trunk
will unlock.The remote is too close to the
trunk lid.
The trunk cannot be locked if :
Theremoteisontheinteriorrear
panel.
The remote is too close to the
seat-back of the rear seat or the
seat cushion. Youcanopenthetrunkinanyof
these ways: Pushthetrunkreleaseswitch
when carrying the remote (if the
doors are locked).
Press the trunk release button
inside the vehicle.
Press the trunk button on the
remote. To close the trunk, use the inner
handle to lower the lid, then press
down on the back edge.
Pushthetrunkreleaseswitch
when the doors are unlocked.
L ocking and Unlocking the T runk Opening and Closing the T runk
K eyless A ccess System
172
TRUNK RELEASE SWITCH
INNER HANDLE
10/07/29 12:02:16 31TK4620_177
2011 TL

µ
CONT INUED
Bef ore closing the trunk, make sure
theremoteisnotinthetrunk.
If you close the trunk when the
remote is in it, the system beeps, and
the trunk reopens.
Keep the trunk lid closed at all times
while driving to avoid damaging the
lid, and to prevent exhaust gas f rom
getting into the interior. Seeon page .
Press this button once to
lock all doors. Some exterior lights
will f lash. When you push the LOCK
button twice within 5 seconds, you
will hear a beep to verify that the
doors are locked and the security
system is set. You cannot lock the doors if any
door is not f ully closed, if the remote
is in the keyless access remote slot,
or if the power mode is in any
position except VEHICLE OFF
(LOCK).
When you cannot set the security
system because the trunk or hood is
open, no exterior light blinks and/or
no beeper sounds.
57
K eyless A ccess System
Carbon
Monoxide Hazard K eyless A ccess Remote
LOCK
Inst rument s and Cont rols
173
LED
PANIC
BUTTON
TRUNK
RELEASE
BUTTON
LOCK
BUTTON
UNLOCK
BUTTON
10/07/29 12:02:24 31TK4620_178
2011 TL

µµ
µ
Press this button once
to unlock the driver’s door. Press it
twice to unlock the other doors.
Some exterior lights will f lash twice
each time you press the button. The
door activated map lights (if the door
activated light switch is set) will
come on when you press the
UNLOCK button. If you do not open
any door within 30 seconds, the map
lights f ade out. If you relock the
doors with the remote bef ore 30
seconds have elapsed, the lights will
go of f immediately. Pressthisbuttonfor
about 1 second to open the trunk.
You cannot open the trunk with the
exterior trunk release switch if the
remote is in the keyless access
remote slot, or the power mode is in
any position except VEHICLE OFF
(LOCK). You cannot open the trunk
with the remote if the trunk main
switch in the glove box is turned of f .
Pressthisbuttonfor
about 2 seconds to attract attention:
thehornwillsoundandtheexterior
lights will f lash f or about 30 seconds.
To cancel panic mode, press any
other button on the remote.
To change the ‘‘KEY AND REMOTE
UNLOCK MODE’’ setting, see
.
To change the ‘‘KEYLESS LOCK
ACKNOWLEDGMENT’’ setting, see
page . To change the ‘‘SECURITY
RELOCK TIMER’’ setting, see page .
If you unlock the doors with the
remote, but do not open any door
within 30 seconds, the doors
automatically relock and the security
system sets. To change the ‘‘INTERIOR LIGHT
DIMMING TIME,’’ see page .
126 117
UNL OCK
T RUNK
PA NIC
K eyless A ccess System
174
10/07/29 12:02:31 31TK4620_179
page 127
page 125
2011 TL

´
As required by the FCC:This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.
An improperly disposed of battery
can hurt the environment.
Always conf irm local regulations f or
battery disposal.
Battery type: CR2032 Replace the battery if necessary.
To replace the battery:
Replace the old battery with a new
battery. Place the battery so the
side is f acing up. Snap the two
halvesof theremotecaseback
together.
Remove the built-in key (see
page ).
Place a cloth on the edge to
prevent scratches, then remove
the upper half by caref ully prying
on the edge with a coin.
1.
2. 3.
195
Replacing the Remote Battery
K eyless A ccess System
Inst rument s and Cont rols
175
10/07/29 12:02:40 31TK4620_180
2011 TL

Here are the settings activated with
the remote:Driving position memory
(see page ).
Audio system settings
(see page ).
Climate control settings
(see page ).
When you unlock the door with your
remote, each remote activates the
keyless memory settings related to
that remote. The driver’s ID (Driver
1orDriver2)isshownontheback
of each remote. Navigation system pref erences
(see the navigation system
manual).Avoid dropping or throwing the
transmitter.
Protect the transmitter from
extreme temperature.
Do not immerse the transmitter in
any liquid.
If you lose a transmitter, the
replacement needs to be
reprogrammed by your dealer.
Keyless memory settings
(see page ).
164
97
273
217
K eyless Memory Settings
K eyless A ccess System
Remot e Care
176
DRIVER’S ID
TM
10/07/29 12:02:51 31TK4620_181
2011 TL

The engine may not run, and some
malf unctions may occur, if the
remote is outside the vehicle.The engine may not start if the
remote is subjected to strong radio
waves.
Also, the engine may not start if the
remote is too close to the windows.
K eyless A ccess System
Engine Start/Stop Button
Operating Range
Inst rument s and Cont rols
177
Make sure you know where the remote
is when you are inside the vehicle.
Remember that you can start the engine
when the remote is inside the vehicle.
Make sure you always carry the remote
with you.
10/07/29 12:02:57 31TK4620_182
2011 TL
