The power mode must be in
ACCESSORY or ON. Press the
AUDIO button to view the audio
control display. Turn the system on
by pressing the VOL/ knob or
the AM/FM button. Adjust the
volume by turning the
VOL/ knob.Your vehicle has the engine start/
stop button instead of an ignition
switch. For more inf ormation on how
to select the power mode, see
. You can use any of f ive methods to
f ind radio stations on the selected
band: tune, skip (seek), scan, the
preset buttons, and auto select.
On the FM band, you can also use
the f eatures provided by the radio
data system (RDS). For more
information on the RDS, see
.
On the AM band, AM noise
reduction turns on automatically. The band and f requency that the
radio was last tuned to are shown on
the display. To change bands, press
the AM/FM button. You can also
change bands by pushing the
interf ace selector up. Each time you
push it up, the band will change to
FM1, FM2 or AM. On the FM bands,
STEREO will be shown on the
navigation screen and ST on the
center display, if the station is
broadcasting in stereo. Stereo
reproduction on AM is not available.
CONT INUED
T o Play the A M/FM Radio T o Select a Station
Playing the A M/FM Radio (Models with navigation system)
Features
287
BAND
STEREO INDICATOR
11/01/14 18:43:42 31TK4630_292
page
184
page 290
2012 TL

µµ
µ
Use the TUNE bar to tune
the radio to a desired f requency.
Press the side of the bar to tune
to a higher f requency, or the side to tune to a lower
f requency. To tune with the
interf ace dial, push the interf ace
selector down, and turn the interf ace
dial to select Tune. Then press
ENTER on the interf ace selector,
andturntheinterfacedialtothe
desired f requency. To exit the
TUNE mode, press ENTER on the interface selector, then push the
interfaceselectoruptogoback.
The skip (seek)
f unction searches up and down f rom
the current f requency to f ind a
station with a strong signal. To
) of the SKIP bar,
then release it.
The SCAN function
samples all stations with strong
signals on the selected band. To
activate it, press the SCAN side of
the SCAN A.SEL bar, then release it.
To scan with the interface dial,
push the interface selector down,
and turn the interface dial to select
Scan, then press ENTER on the
interface selector.
Playing the A M/FM Radio (Models with navigation system)
TUNE SK IP (SEEK )
SCAN
288
TUNE SCAN
11/01/14 18:43:50 31TK4630_293
FeaturesTo activate it, press either side
( or
2012 TL

µ
µ
When the system finds a strong
signal, it will stop and play that
station f or about 10 seconds. If you
do nothing, the system will then scan
f or the next strong station and play it
f or 10 seconds. When it plays a
station that you want to listen to,
press the SCAN side of the bar again.
Press the preset button, and hold
it until you hear a beep. You can
also store f requencies with the
interf ace dial. Select the preset
icon you want to store the
f requency on, then press ENTER
on the interf ace selector, and hold
it until you hear a beep.
Repeat steps 1 through 3 to store a
total of six stations on AM and
twelve stations on FM.
If you are
traveling and can no longer receive
your preset stations, you can use the
auto select feature to find stations in
the local area.
Each preset button or
preset icon can store one f requency
on AM and two f requencies on FM.
Select the desired band, AM or
FM. FM1 and FM2 let you store
six stations each.
Usethetune,skip(seek),scan,or
RDS function to tune the radio to a
desired station.
1.
2. 3.
4.
CONT INUED
To store a preset memory location:
Playing the A M/FM Radio (Models with navigation system)
AUTO SELECT
Preset
Features
289
A.SEL INDICATOR
A.SEL
11/01/14 18:44:01 31TK4630_294
2012 TL

Push the interf ace selector down to
display the AUDIO MENU. Turn the
interf ace dial to select A.SEL, then
press ENTER on the interf ace
selector. Turn the interf ace dial to
select ON, then press ENTER on the
interf ace selector. You will see
A.SEL on the center display and the
audio control display (if selected),
and the system goes into auto select
mode f or several seconds.
You can also press the A.SEL side of
the SCAN/A.SEL bar. You will see
A.SEL on the center display or the
screen, and the system goes into
auto select mode f or several seconds.
You will see ‘‘0’’ displayed if auto
select cannot f ind a strong station f or
every preset button (icon). The system stores the f requencies of
six AM and twelve FM stations in
the preset buttons (icons).If you do not like the stations auto
select has stored, you can store
other f requencies on the preset
buttons (icons) as previously
described.
select A.Sel on
the audio menu again and turn the
interf ace dial to select A.SEL OFF,
or press the A.SEL side of the bar
again. This restores the presets you
originally set.
For inf ormation on AM/FM radio
frequencies and reception, see . On the FM band, you can select a
favorite station and display the
program service name provided by
the radio data system (RDS).
The RDS INFO display f unction
shows the name of the station you
are listening to. With the audio
system on and the FM band selected,
you can turn this f unction on or of f .
To cancel auto select,
Playing the A M/FM Radio (Models with navigation system)
Radio Data System (RDS)
RDS INFO Display
290
11/01/14 18:44:12 31TK4630_295
page 385
Features
2012 TL

If the station you are listening to is
not an RDS station, the audio screen
and the center display continue to
show the f requency.
To switch the RDS INFO display
f unction on and of f , press and
release the TITLE button. With the
system on, you will see the ‘‘RDS
INFO ON’’ message on the center
display. If the station you are
listening to is an RDS station, the
displayed f requency switches to the
station name. When you turn of f this f unction by
pressing the TITLE button, the
center display shows ‘‘RDS INFO
OFF.’’
On the FM band selected, you can
select the program type provided by
the RDS. Press the AUDIO button
to display the radio information
on the screen. Push down the
interface selector, then turn the
interface dial to select RDS search.
Press ENTER to set your selection.
The principal RDS categories are
shown as follows:
If the station you are
listening to is an RDS station, the
audio screen will always display the
RDS inf ormation.
CONT INUED
Radio Data System (RDS) Category
Playing the A M/FM Radio (Models with navigation system)
Features
291
NOTE:RDS INFO MESSAGE
RDS SEARCH
11/01/14 18:44:23 31TK4630_296
2012 TL

´µ
ALL: All RDS category stations
TOP 40: Top 40 hits
ROCK: Rock, classic rock and sof t
rock music
OLDIES: Nostalgia music and oldies
JAZZ: Jazz
SOFT: Adult hits and sof t music
R & B: Rhythm and blues, and sof t
rhythm and blues
CLASSIC: Classical music
RELIGION: Programs concerned
with religion
INFO: News, inf ormation, sports,
talk shows, f oreign language,
personality, public, college, and
weather
Turn the interface dial to select an
RDS category. You can use the
search or scan function to find radio
stations on the selected RDS
category by pressing the interface
selector to the left or the right.
Press ENTER to set your selection.
If you do nothing while the
RDS category is selected, the
selected category is canceled.You can also select an RDS category
with the CATEGORY bar. Press
either side ( or ) of the
CATEGORY bar to display an RDS
category in the center display. Select
a category by pressing either side of
the bar.
TRAFFIC: Traffic information COUNTRY: Country music
Playing the A M/FM Radio (Models with navigation system)
292
RDS CATEGORY
RDS CATEGORY
11/01/14 18:44:38 31TK4630_297
Features
2012 TL

This f unction searches up and down
f or strong signal f requencies that
carry the selected RDS category
inf ormation. This can help you to
find a station in your favorite
category. To activate it, press and
release either side ( or ) of
the SKIP bar. You will also see the
selected RDS category name
blinking in the center display while
searching it.To activate RDS category search
with the interf ace dial, push the
AUDIO button to display the FM
radio inf ormation on the screen.
Push the interf ace selector down,
and turn the interf ace dial to select
RDS search. Press ENTER on the
interf ace selector. The screen shows
youtheRDScategorylist.While the RDS category is selected,
move the interface selector to the
lef t or right to select SEEK up,
SEEK down, or SCAN in the upper
right corner of the screen. Press
ENTER to activate the RDS category
search (SEEK up/down). Turn the interface dial to the desired
RDS category.
If the system does not find a station,
‘‘NOTHING’’ will blink f or about 5
seconds, then the system goes back
to the last selected station.
CONT INUED
Playing the A M/FM Radio (Models with navigation system)
RDS Cat egory Search
Features
293
SEEK is selected. SEEK/SCAN ICON (RDS Search mode)
RDS CATEGORY LIST
11/01/14 18:44:47 31TK4630_298
2012 TL

To activate RDS category scan with
the interf ace dial, push the AUDIO
button to display the FM radio
inf ormation on the screen. Push the
interf ace selector down, and turn the
interf ace dial to select RDS search
on the audio menu. Press ENTER on
the interf ace selector. The screen
shows you the RDS category list.
If you do nothing, the system will
scan f or the next strong station and
play it f or 10 seconds. When it plays
a station that you want to listen to,
press the SCAN side of the SCAN/
A.SEL bar again.
The scan f unction samples all
stations with strong signals on the
selected RDS category one by one.
To activate it, press and release the
SCAN side of the SCAN/A.SEL bar.
YouwillseeSCANinthecenter
display. The system will scan f or a
station with a strong signal in the
selected RDS category. You will also
see the selected RDS category name
blinking in the center display while
scanning it. When the system f inds
one, it will stop and play that station
f or about 10 seconds. If the system does not find a station,
‘‘NOTHING’’ will blink f or about 5
seconds, then the system goes back
to the last selected station.
Playing the A M/FM Radio (Models with navigation system)
RDS Category SCAN
294
RDS CATEGORY LIST
SEEK/SCAN ICON (RDS Search mode)
SCAN is selected.
11/01/14 18:44:55 31TK4630_299
Features
2012 TL

While the RDS category is selected,
move the interface selector to the
lef t or the right to select SCAN.
Then press ENTER to activate the
RDS SCAN.To activate radio text display, use
the interf ace dial. Push the interf ace
selector down, and turn the interf ace
dial to select Read Radio Text. Press
ENTER on the interf ace selector to
enter the setting.
This f unction displays the radio text
inf ormation of the selected RDS
station.
If the selected RDS station has the
radio text inf ormation, you will see
the text indicator on the screen.
Turn the interface dial to the desired
RDS category.
CONT INUED
Radio T ext Display
Playing the A M/FM Radio (Models with navigation system)
Features
295
TEXT INDICATOR
READ RADIO TEXT
11/01/14 18:45:04 31TK4630_300
2012 TL

To adjust the sound, press the
AUDIO button, push the interf ace
selector down, and turn the interf ace
dial to Sound Setup. Then press
ENTER on the interf ace selector.
BASS, TREBLE, FADER, and
BALANCE are each adjustable. You
can also adjust the strength of the
sound coming f rom the center and
subwoof er speakers. In addition, you
can set the Dolby PL (ProLogic) II
and Speed-sensitive volume
compensation (SVC).
Theseadjustmentscanbemadewith
the (Sound) button or the
interf ace dial.
The display shows up to 64
characters on the selected RDS
station. Adjusting the Sound
Playing the A M/FM Radio (Models with navigation system)
296
SOUND SETUP
11/01/14 18:45:13 31TK4630_301
Features
2012 TL
