Your vehicle uses halogen light
bulbs. When replacing a bulb, handle
it by its plastic case, and protect the
glass from contact with your skin or
hard objects. If you touch the glass,
clean it with denatured alcohol and a
clean cloth.Start the engine. If you are
replacing a driver’s side bulb, turn
the steering wheel all the way to
theright.If youarereplacinga
passenger’s side bulb, turn the
steering wheel to the lef t. Turn of f
the engine.
Thefoglightswereproperlyaimed
when your vehicle was new. If you
regularly carry heavy items in the
trunk, readjustment may be required.
Adjustment should be done by your
dealer or another qualif ied
technician.
Install the new bulb in the socket
by pushing it straight in the socket
until it bottoms.
Push the under cover in place and
set the inner f ender cover in the
original position. Install the bolts
and tighten them securely. Insert
each holding clip, and lock it by
pushingonitscenter. Turn on the lights to make sure
the new bulb is working. Insert the socket into the light
assembly. Turn it clockwise to
lock it in place.
6.
7.
8.
9. 1.
Replacing a Front Fog L ight Bulb
Lights
560
Halogen bulbs get very hot when lit. Oil,
perspiration, or a scratch on the glass
can cause the bulb to overheat and
shatter.
12/07/20 11:42:16 31TK4640_565
Maint enance
2013 TL

µ
If you need to connect the battery to
a charger, disconnect both cables to
prevent damaging your vehicle’s
electrical system. Always disconnect
the negative ( ) cable first, and
reconnect it last.
Check the terminals f or corrosion (a
white or yellowish powder) af ter
removing all engine compartment
covers (see page ). To remove
corrosion, cover the terminals with a
solution of baking soda and water. It
will bubble up and turn brown. When
this stops, wash it of f with plain
water. Dry off the battery with a
cloth or paper towel. Coat the
terminals with grease to help prevent
f urther corrosion.
If additional battery maintenance is
needed, see your Acura dealer or a
qualif ied technician.
Battery posts,
terminals, and related accessories
contain lead and lead compounds.
The sensor on the negative
terminal monitors your
vehicle’s battery condition.
If there is a problem with the sensor,
you will see a ‘‘CHECK BATTERY
SENSOR’’ message on the multi-
inf ormation display. Have the vehicle
checked by your dealer.
To see the battery label, remove the
lef t side engine compartment cover
(see page ).
542 542
CONT INUED
Checking the Battery
WARNING:
Wash your hands af ter handling.
Maint enance
577
The battery gives off explosive
hydrogen gas during normal
operation.
A spark or flame can cause the
battery to explode with enough
force to kill or seriously hurt you.
Wear protective clothing and a
face shield, or have a skilled
technician do the battery
maintenance.
12/07/20 11:44:39 31TK4640_582
2013 TL

Cover the vehicle with a
‘‘breathable’’ cover, one made
f rom a porous material such as
cotton. Non-porous materials, such
as plastic sheeting, trap moisture,
which can damage the paint.
If possible, periodically run the
engine until it reaches f ull
operating temperature (the
cooling f ans cycle on and of f
twice). Pref erably, do this once a
month.Vacuum dirt and dust f rom the
leather f requently. Pay close
attention to the pleats and seams.
Clean the leather with a sof t cloth
dampened with a 90% water and 10%
neutral wool detergent solution.
Then buf f it with a clean, dry cloth.
Remove any dust or dirt on leather
surf aces immediately. Leather
Vehicle Storage, Interior Care
Maint enance
579
12/07/20 11:44:54 31TK4640_584
2013 TL

This section covers the more
common problems that motorists
experience with their vehicles. It
gives you inf ormation about how to
safely evaluate the problem and what
to do to correct it. If the problem has
stranded you on the side of the road,
you may be able to get going again.
If not, you will also f ind instructions
on getting your vehicle towed.......................
Compact Spare Tire .582
....................
Changing a Flat Tire .583
.............
If the Engine Won’t Start . 588
................................
Jump Starting .591
..............
If the Engine Overheats . 593
.........
Low Oil Pressure Indicator . 595
..........
Charging System Indicator . 596
.......
Malf unction Indicator Lamp . 597
...............
Brake System Indicator . 598
Opening the Fuel Fill Door ....................................
Manually .599
..............................................
Fuses .600
..............................
Fuse Locations .604
......................
Emergency Towing .607
..........
If Your Vehicle Gets Stuck . 609
Taking Care of the Unexpected
T aking Care of t he Unexpect ed
581
12/07/20 11:44:59 31TK4640_586
2013 TL

Î
CONT INUED
If you have a f lat tire while driving,
pull over saf ely. Drive slowly along
the shoulder until you get to an area
far away from traffic lanes.Park the vehicle on f irm, level, and
non-slippery ground. Put the
transmission in Park (automatic)
or reverse (manual). Apply the
parking brake.
Turn on the hazard warning lights,
and turn the ignition switch to
the LOCK (0) position. Have all
passengers get out of the vehicle
while you change the tire.
Open the trunk. Raise the trunk
f loor lid by lif ting up on the back
edge.
3.
2. 1.
Changing a Flat Tire
T aking Care of t he Unexpect ed
583
The vehicle can easily roll off
the jack, seriously injuring
anyone underneath.
Follow the directions for
changing a tire exactly, and
never get under the vehicle
when it is supported only by the
jack.
12/07/20 11:45:15 31TK4640_588
Î
Models equipped with the
keyless access system have an engine
start/stop button instead of
an ignition switch. VEHICLE OFF
(LOCK) Mode is the equivalent of
LOCK (0).
For more information
,
see pages
and .
:
184 187
2013 TL

When you turn the ignition switch to
the START (III) position or on
models with keyless access system,
press the engine start/stop button to
set START Mode (see page ),
you do not hear the normal noise of
the engine trying to start. You may
hear a clicking sound, a series of
clicks, or nothing at all.
Diagnosing why the engine won’t
start f alls into two areas, depending
on what you hear when you turn the
ignition switch to the START (III)
position or on models with keyless
access system, press the engine
start/stop button to set START
Mode (see page ):
You can hear the starter motor
operating normally, or the starter
motor sounds like it is spinning
f aster than normal, but the engine
does not start up and run. You hear nothing, or almost
nothing. The engine’s starter
motor does not operate at all, or
operates very slowly. Check these things:
Check the transmission interlock.
If you have a manual transmission,
the clutch pedal must be pushed
all the way to the f loor or the
starter will not operate. With an
automatic transmission, it must be
in Park or neutral. Turn the ignition switch to the ON
(II) position or on models with
keyless access system, press the
engine start/stop button to set ON
Mode (see page ). Turn on the
headlights, and check their
brightness. If the headlights are
very dim or do not come on at all,
the battery is discharged. See
on page .
184
184
591
184
If theEngineWon’tStart
Nothing Happens or the Starter
Motor Operates Very Slowly
Jump Starting
588
12/07/20 11:45:54 31TK4640_593
T aking Care of t he Unexpect ed
2013 TL

In this case, the starter motor’s
speed sounds normal, or even f aster
than normal, when you turn the
ignition switch to the START (III)
position or on models with keyless
access system, press the engine
start/stop button to set START
Mode (see page ), but the engine
does not run.
Turn the ignition switch to the
START (III) position or on models
with keyless access system, press
the engine start/stop button to set
STARTMode(seepage ).If
the headlights do not dim, check
the condition of the fuses. If the
f uses are OK, there is probably
something wrong with the
electrical circuit for the ignition
switch or starter motor. You will
need a qualif ied technician to
determine the problem. See
on page .If the headlights dim noticeably or
go out when you try to start the
engine, either the battery is
discharged or the connections are
corroded. Check the condition of
the battery and terminal connec-
tions (see page ). You can
then try jump starting the vehicle
f rom a booster battery (see page
).
Are you using a properly coded
key or keyless access remote (on
models with keyless access
system)? An improperly coded key
or keyless access remote will
cause the immobilizer system
indicator in the instrument panel
to blink rapidly (see page ).65
184
184
607 591
577
CONT INUED
T he Starter Operates Normally
Emergency T owing
If theEngineWon’tStart
T aking Care of t he Unexpect ed
589
12/07/20 11:45:59 31TK4640_594
2013 TL

Do you have your keyless access
system remote with you? The
vehicle will not start without the
remote within operating range and
with the keyless access main
switch in the glove box turned on.
Are you using the proper starting
procedure? Ref er to
on pages and .
If you are unable to stop the
engine normally while in the Park
position, see on page .
You may need to hold the start/
stop button down or hold the key
in the START (III) position until
the engine starts. It can be held
forupto15seconds.
There may be an electrical
problem, such as no power to the
f uel pump. Check all the f uses
(see page ). Do you have f uel? Check the f uel
gauge; the warning indicator may
not be working. If youfindnothingwrong,youwill
need a qualif ied technician to f ind
the problem. See
on page .
487 489
600 192 607
On models with keyless access system
If theEngineWon’tStart
Starting the
Engine
Emergency Engine
Stop Emergency
Towing
590
NOTE:
12/07/20 11:46:07 31TK4640_595
T aking Care of t he Unexpect ed
2013 TL

Although this seems like a simple
procedure, you should take several
precautions.
You cannot start a vehicle with an
automatic transmission by pushing
or pulling it.Open the hood, and check the
physical condition of the battery.
In very cold weather, check the
condition of the electrolyte. If it
seems slushy or like ice, do not try
jump starting until it thaws.
To jump start your vehicle:
Turn of f all the electrical
accessories: climate control, audio
system, lights, etc. Put the
transmission in neutral (manual)
or Park (automatic), and set the
parking brake. Pull up the battery terminal cover
to remove. The battery terminal
cover can be removed without
removing the lef t side engine
compartment cover.
1.
2.
3.
CONT INUED
Jump Starting
T aking Care of t he Unexpect ed
591
BATTERY TERMINAL COVER
A battery can explode if you do
not follow the correct procedure,
seriously injuring anyone
nearby.
Keep all sparks, open flames,
and smoking materials away
from the battery.
If a battery sits in extreme cold, the
electrolyte inside can f reeze.
Attempting to jump start with a f rozen
battery can cause it to rupture.
12/07/20 11:46:15 31TK4640_596
2013 TL

´´ µStart the vehicle. If the starter
motor still operates slowly, check
that the jumper cables have good
metal-to-metal contact.
If the booster battery is in another
vehicle, have an assistant start
that vehicle and run it at a fast idle.
The numbers in the illustration
show you the order to connect the
jumper cables.
Connect one jumper cable to the
positive ( ) terminal on your
battery. Connect the other end to
the positive ( ) terminal on the
booster battery. Once the vehicle is running,
disconnect the negative cable f rom
your vehicle, then f rom the
booster battery. Disconnect the
positive cable f rom your vehicle,
and then from the booster battery.
Install the battery terminal cover.
Keep the ends of the jumper cables
away from each other and any metal
on the vehicle until everything is
disconnected. Otherwise, you may
cause an electrical short.
Connect the second jumper cable
to the negative ( ) terminal on
the booster battery. Connect the
other end to the engine hanger as
shown. Do not connect this jumper
cable to any other part of the engine.
4. 5.
6.7.
8.
9.
Jump Starting
592
BOOSTER
BATTERY
12/07/20 11:46:24 31TK4640_597
T aking Care of t he Unexpect ed
2013 TL
