display Acura TL 2013 Owner's Manual

µµ µ
µ´µ
Each time you press and release the
TITLE button, the center display
changes in the f ollowing sequence:
NAME (artist name), TITLE (music
title), and CHANNEL NAME
(channel name).
Onthescreen,youwillseethe
selected CHANNEL (number),
CATEGORY, NAME (artist name),
and TITLE (music title).
You may experience periods when
XM Radio does not transmit the
artist’s name and song title
inf ormation. If this happens, there is
nothing wrong with your system.
To switch between the
category mode and channel mode,
push the interface selector down to
display AUDIO MENU, then turn
the interface dial to select Mode, and
press ENTER on the interface
selector.
Turn the interf ace dial to select CH
or CAT, then press ENTER on the
interface selector. Move the
interfaceselectoruptogoback.
You can also switch the mode by
pressing the TITLE button for
In the category mode, such as Jazz,
Rock, Classical, etc., you can
navigate through all of the channels
within that category. In the channel
mode, you can select all of the
available channels. Press either side of the
TUNE bar to change channel
selections. Press the side of the
bar f or higher numbered channels
and the side for lower
numbered channels. You can also
change channels with the interf ace
selector. Push down the interf ace selector to select AUDIO MENU,
then turn the interface dial to choose
TuneandpressENTERonthe
interf ace selector. Turn the interf ace
dial to the appropriate direction. In
the category mode, you can only
select channels within that category.
Push down the
interf ace selector to select AUDIO
MENU,thenturntheinterfacedial
to select Channel List and press
ENTERontheselector.Turnthe
interf ace dial to select a channel,
then press ENTER to set your
selection.
Press
either side of the bar to select
another category.
CONT INUED
MODE
TUNECHA NNEL L IST
CATEGORY ( or )
Playing the XMRadio (Models with navigation system)
Features
301
12/07/20 11:08:11 31TK4640_306
3 seconds.
2013 TL

µµ µ
µ
The scan f unction gives
you a sampling of all channels while
in the channel mode. In the category
mode, only the channels within that
category are scanned. To activate
SCAN,presstheSCANsideof the
SCAN/A.SEL bar. You will see
SCAN on the screen and center
display.
The system plays each channel in
numerical order f or a f ew seconds,
then selects the next channel. When
you hear a channel you want to
continue listening to, press the
SCAN side of the bar to cancel.
This f unction
samples all channels. Push down the
interf ace selector to select AUDIO
MENU,thenturntheinterfacedial
to select Channel Scan and press
ENTER on the interf ace selector. Press the button. Either
XM1 or XM2 will be shown on the
display.
To store a channel: Youcanstoreupto12
preset channels using the six preset
buttons. Each button stores one
channel f rom the XM1 band and one
channel f rom the XM2 band.
This
f unction samples the stations in the
selected category. Push down the
interf ace selector to select AUDIO
MENU,thenturntheinterfacedial
to select Category Scan and press
ENTER on the interf ace selector. 1.
SCAN
CHA NNEL SCA N
Preset
CAT EGORY SCAN
Playing the XMRadio (Models with navigation system)
302
XM BAND
12/07/20 11:08:19 31TK4640_307
Features
2013 TL

µ
µ
µ
µ µ
µ
µ
The encryption
code is being updated. Wait until the
encryption code is f ully updated.
Channels 0 and 1 should still work
normally. XM is loading the
audio or program inf ormation. The channel
currently selected is no longer
broadcasting. Once a channel is stored, press
and release the proper preset
button to tune to it.
Press the button or scroll
up again. The other XM band will
be shown. Store the next six
channels using steps 2 and 3. Repeat steps 2 and 3 to store the
f irst six channels. Pick the preset button you want
f or that channel. Press and hold
the preset button until you hear a
beep. You can also pick the
number with the interf ace dial.
Select your desired number and
press and hold ENTER on the
interf ace selector. In category mode, only channels
within that category can be
selected. In channel mode, all
channels can be selected. Use the tune, list, or scan f unction
to tune to a desired channel. The signal is
currently too weak. Move the vehicle
to an area away from tall buildings,
and with an unobstructed view of the
southern horizon. The selected channel
number does not exist, or is not part
of your subscription, or this channel
has no artist or title inf ormation at
this time.
There is
a problem with the XM antenna.
Please consult your dealer. The selected
channel has no artist or title
inf ormation at this time.
5. 3.
4. 2.
CONT INUED
‘‘UPDA T ING’’ ‘‘L OA DING’’ ‘‘OFF A IR’’ XM Radio Display Messages
‘‘NO SIGNA L ’’ ‘‘----’’
‘‘CHECK A NT ENNA ’’ ‘‘NO INFO’’
Playing the XMRadio (Models with navigation system)
Features
303
12/07/20 11:08:30 31TK4640_308
2013 TL

CONT INUED
To replay and see the stored file,
press the AUDIO button to select
the audio display on the
navigation screen.
Push down the interf ace selector
to display the audio menu. Turn
the interface dial to select Note,
then press ENTER.
This f unction stores the sound
content played on the selected XM
Radio station with the channel,
category, name, and title inf ormation.
To activate this function, press and
hold the button for about 2
seconds while a song or passage
which you want to store is playing.
You can record f or up to 10 seconds.
To stop recording, press the AM/
FM button or button.
Once you store the recorded sound
f ile, you can replay it and conf irm the
inf ormation. The system can store
up to 30 sound f iles. If you continue
tostoremorefiles,theoldestone
will be deleted each time you add a
new f ile.
There may be other geographic
situations that could affect
XM Radio reception.
This device complies with the
appropriate requirements or the
required standards. See page f or
more inf ormation.
628
U.S. models only
Playing the XMRadio (Models with navigation system)
Note Function
Features
305
NOTE ICON
12/07/20 11:08:48 31TK4640_310
2013 TL

´
Turn the selector dial to select a
sound file, then press ENTER. The
display shows the category, name
and title information of the
selected file.
To delete all f iles, push the interf ace
selector to the lef t to select
‘‘DELETE ALL,’’ then press ENTER.
To delete one f ile, select the f ile you
want to delete and push the interf ace
selector to the right, then press
ENTER. If your XM Radio service has expired
or you purchased your vehicle f rom
a previous owner, you can listen to a
sampling of the broadcasts available
on XM Radio. With the power mode
in ACCESSORY or ON, press the
button. A variety of music
types and styles will play.
Your vehicle has the engine start/
stop button instead of an ignition
switch. For more information on how
to select the power mode, see
page . After you have registered with XM
Radio, keep your audio system in the
XM Radio mode while you wait for
activation. This should take about
While waiting for activation, make
sure your vehicle remains in an open
area with good reception. Once your
audio system is activated, CAT
(category) or CH (channel) will
appear in the center display, and
you’ll be able to listen to XM Radio
broadcasts. XM Radio will continue
to send an activation signal to your
vehicle for at least 12 hours from the
activation request. If the service has
not been activated after 36 hours,
contact XM
Radio. In Canada,
contact XM CANADA
.
If you decide to purchase XM radio
service, contact XM Radio at
,orat
1-800-852-9696. In Canada, contact
XM CANADA
at , or
at 1-877-209-0079. You will need to
give them your radio I.D. number
and your credit card number. To get
your radio I.D. number, press the
side of the CATEGORY bar until ‘‘0’’ appears in the display. Your I.D. will
appear in the displays.
184
www.siriusxm.com www.xmradio.ca
Playing the XMRadio (Models with navigation system)
Receiving XM Radio Service
306
SOUND FILE RECORDED DATE
12/07/20 11:08:57 31TK4640_311
Features30 min ute s.
2013 TL

CONT INUED
Playing a Disc (Models with navigation system)
Features
307
INTERFACE DIALSCAN/A.SEL
(SCAN/AUTO SELECT) BAR SKIP BAR NAVIGATION SCREEN
DISC SLOT
EJECT BUTTON
TITLE BUTTON
PRESET BUTTONS
CATEGORY BAR
AUDIO BUTTON VOL/
(VOLUME/POWER)KNOB
DISC BUTTON
CENTER DISPLAY
12/07/20 11:09:03 31TK4640_312
2013 TL

You cannot load and play 3-inch
(8-cm)discsinthissystem.
It is possible to select up to 999 f iles
f or inclusion in CD-Rs and CD-RWs,
and up to 3,500 f iles f or inclusion in
DVD-Rs and DVD-RWs.Insert a disc about half way into the
disc slot. The drive will pull the disc
intherestof thewaytoplayit.You
operate the disc player with the
same controls used f or the radio.
The number of the current track is
showninthedisplay.Whenplayinga
disc in MP3, WMA or AAC, the
numbers of the current f older and
f ile are shown. The system will
continuously play a disc until you
change modes.
For information on how to handle
and protect compact discs, see
page
.
Manuf actured under license under
U.S. Patent’s: 5,451,942; 5,956,674;
5,974,380; 5,978,762; 6,487,535 &
other U.S. and worldwide patents
issued & pending. DTS and DTS
Digital Surround are registered
trademarks and the DTS logos and
Symbol are trademarks of DTS, Inc.
All Rights Reserved. Reverse
engineering or disassembly is
prohibited.
Depending on the sof tware the f iles
were made with, it may not be
possible to play some f iles, or display
some text data.
381
To Load a Disc
Playing a Disc (Models with navigation system)
Features
309
Do not use discs with adhesive labels.
The label can curl up and cause the
disc to jam in the unit.
12/07/20 11:09:20 31TK4640_314
2013 TL

Select the disc player by pressing the
DISC button. The system will begin
playing the last selected track in the
disc. You will see the current track
position highlighted.
Title inf ormation will be displayed in
a list when the inf ormation is f ound
in the Gracenote
Album Inf o
(Gracenote
Media Database) on the
built-inharddiskdrive.Whenyou
play a CD recorded with text data,
you will see the genre, artist name,
album and track name on the screen.
When you play MP3/WMA/AAC
discs, you will see the genre, artist
name, album name and track name
on the screen. If the disc was not
recorded with this inf ormation, it will
not be displayed. Each time you press the TITLE
button, the center display changes
f rom artist name to album name, to
track name and then to normal
display that shows the track number
and the elapsed time. When playing
a disc in MP3/WMA/AAC, the
display mode changes f rom f older
name,tofilename,toartisttag,to
album tag, to track tag, and then to
normal display.
Each time you press and release the
side of the skip bar, the player
skips forward to the beginning of the
next track. Press and release the side of the skip bar to skip
backward to the beginning of the
current track. Press the side
againtoskiptotheprevioustrack.
To move rapidly within a track, press
andholdeithersideof theskipbar.
When you insert a CD f or the f irst
time, the system automatically starts
recording to the hard disc. For
inf ormation on recording f rom music
CDs, see page .
When you insert a CD f or the f irst
time, a Gracenote notif ication
appears. For more inf ormation, see
page . 322
351
To Play a Disc
To Change Tracks
Playing a Disc (Models with navigation system)
310
12/07/20 11:09:27 31TK4640_315
Features
2013 TL

You can also choose a track directly
from a track list. If there are no track
names, you will see ‘‘No Title’’
displayed. Turn the interf ace dial to
select the desired track, then press
ENTER on the interf ace selector.To replay the current track
continuously, push the interf ace
selector down while playing a disc.
Turn the interf ace dial to select
Repeat on the AUDIO MENU, and
press ENTER on the interf ace
selector. Turn the interf ace dial to
select Repeat icon, and press
ENTER on the interf ace selector.To turn this feature off, turn the
interface dial to select the OFF
icon, and press ENTER on the
interface selector.
To Choose a Track
Track Repeat
Playing a Disc (Models with navigation system)
Features
311
REPEAT OFF ICON
TRACK REPEAT ICON
TRACK LIST TRACK REPEAT INDICATOR
12/07/20 11:09:35 31TK4640_316
2013 TL

Combining a low sampling f requency
with a low bitrate may result in
extremely degraded sound quality.
To play an MP3/WMA/AAC disc,
use the disc controls previously
described, along with the f ollowing
inf ormation.While playing an MP3/WMA/AAC
disc, you can select a f older within
the disc by pressing either side of
the category bar. Each time you
press either side of the bar, the
f older title and its f irst f ile’s
inf ormation appear on the center
display and on the navigation screen
in hierarchical order of the f olders
which contain f iles within the disc.
If the root f older has some additional
f olders in the lower layer, they will
belistedonthescreen. Using the interf ace selector, you can
see the list of all the f olders within a
disc. While playing an MP3/WMA/
AAC disc, push the interf ace selector
up. The f older list in the currently
playing disc will appear on the screen.
Changing and Selectingthe Folders/Files
Playing a Disc (Models with navigation system)
Changing the Folders
314
NOTE:
FOLDER LIST
12/07/20 11:10:00 31TK4640_319
Features
2013 TL
