Pressing either INFO button ( / )
switches the display f rom the
message to another display. Once
you switch the display, this message
will go of f .
Along with the message, the system
message indicator comes on (see
page ).
When the remaining engine oil lif e is
15 to 6 percent, the multi-inf ormation
display shows a ‘‘SERVICE DUE
SOON’’ message along with the
maintenance item code(s) indicating
themainandsubitemsrequiredat
thetimeof theoilchange.Referto
page f or a complete list of the
maintenance main items and sub
items.
The remaining engine oil lif e is
shown on the multi-inf ormation
display according to this table:
The message appears on the multi-
inf ormation display each time you
turn the ignition switch to the ON
(II) position.72
540
Calculated Engine Oil Lif e (%)
100% 91% 90% 81%
80% 71%
70% 61%
60% 51%
50% 41%
40% 31%
30% 21%
20% 16%
15% 11%10% 6% 5% 1% 0% Displayed
Engine Oil Lif e (%) 100%90%
80%
70%
60%
50%
40%
30%
20%
15%
10%5%
0%
Maintenance Minder
532
MAINTENANCE MAIN ITEM CODE
MAINTENANCE SUB ITEM CODE(S)
TM
12/07/20 11:38:45 31TK4640_537
Maint enance
Î
Mod els eq uip ped wit h th e keyless
a cce ss sy ste m have an en gin e sta rt/
s to p butto n in ste ad of an ignition
s w it c h .O N Mod e is th e eq uiv ale n t of
O N (II) . F or m ore in fo rm atio n ,se e
p ag es
and .
:
184 187
2013 TL

Your tires have wear indicators
molded into the tread. When the
tread wears down, you will see a 1/2
inch (12.7 mm) wide band across the
tread. This shows there is less than
1/16 inch (1.6 mm) of tread lef t on
the tire.
A tire this worn gives very little
traction on wet roads. You should
replace the tire if you can see three
or more tread wear indicators.The service lif e of your tires is
dependent on many f actors,
including, but not limited to, driving
habits, road conditions, vehicle
loading, inf lation pressure,
maintenance history, speed, and
environmental conditions (even
when the tires are not in use).
In addition to your regular
inspections and inf lation pressure
maintenance, it is recommended that
you have annual inspections
perf ormed once the tires reach f ive
years old. It is also recommended
that all tires, including the spare, be
removed from service after 10 years
from the date of manufacture,
regardless of their condition or state
of wear.
The last f our digits of the TIN (tire
identif ication number) are f ound on
the sidewall of the tire and indicate
the date of manufacture (See
on page ).619
Tires
Tire
Labeling
Tire Service Lif e
572
INDICATOR LOCATION MARKS
TREAD WEAR INDICATOR
12/07/20 11:43:59 31TK4640_577
Maint enance
2013 TL

Immediately turn of f all electrical
accessories. Try not to use other
electrically operated controls such as
the power windows. Keep the engine
running; starting the engine will
discharge the battery rapidly.
Go to a service station or garage
where you can get technical
assistance.
If the charging system
indicator comes on brightly
when the engine is running, the
battery is not being charged.
You will also see a ‘‘CHECK
CHARGING SYSTEM’’ message on
the multi-information display.
Charging System Indicator
596
12/08/03 21:01:37 31TK4640_601
T aking Care of t he Unexpect ed
2013 TL

ÎIf the f luid level is low, take your
vehicle to a dealer, and have the
brake system inspected f or leaks or
worn brake pads.
However, if the brake pedal does not
f eel normal, you should take
immediate action. A problem in one
part of the system’s dual circuit
design will still give you braking at
two wheels. You will f eel the brake
pedal go down much f arther bef ore
the vehicle begins to slow down, and
you will have to press harder on the
pedal. You will also see a ‘‘LOW BRAKE
FLUID’’ message on the multi-
inf ormation display.
You will also see a ‘‘CHECK BRAKE
SYSTEM’’ message on the multi-
inf ormation display when this
indicator comes on.
To check if they are set, turn the
ignition switch to the ON (II)
position (set the power mode to ON,
on models with keyless access
system), without starting the engine.
The malf unction indicator lamp will
come on f or 20 seconds. If it then
goes of f , the readiness codes are set.
If it blinks f ive times, the readiness
codes are not set. If possible, do not
take your vehicle f or an emissions
test until the readiness codes are set.
Refer to
for
more information (see page ). If the brake system indicator comes
on while driving, the brake f luid level
is probably low. Press lightly on the
brake pedal to see if it f eels normal.
If it does, check the brake f luid level
thenexttimeyoustopataservice
station (see page ). The brake system indicator normally
comes on when you turn the ignition
switch to the ON (II) position, and
as a reminder to check the parking
brake. It will stay on if you do not
f ully release the parking brake.
626 553
Brake System
Indicator
Emissions T esting
Malf unction Indicator L amp, Brake System Indicator
598
Canada
U.S.
12/07/20 11:47:08 31TK4640_603
T aking Care of t he Unexpect ed
Î
Mod els eq uip ped wit h th e keyless
a cce ss sy ste m have an en gin e sta rt/
s to p butto n in ste ad of an ignition
s w it c h .O N Mod e is th e eq uiv ale n t of
O N (II) . F or m ore in fo rm atio n ,se e
p ag es
and .
:
184 187
2013 TL

............................
Capacities Chart .614
.............
Carbon Monoxide Hazard . 57
............................
Carrying, Cargo .481
.............
CAUTION, Explanation of . iv
.........................................
CD Care . 381
...................................
CD Changer .253
.......................................
CD Player .307
........................
Certif ication Label .612
............................................
Chains .575
....................
Changing a Flat Tire .583
Changing Oil ........................................
How to .544
......................................
When to . 531
...
Charging System Indicator . 65,596
............
Checklist, Bef ore Driving . 486
.....................................
Child Saf ety .37
..............................
Booster Seats .54
...................................
Child Seats .45
..........................................
Inf ants .42
............................
Large Children .53
.........................................
LATCH .47
......................
Risks with Airbags .38
.............................
Small Children .43
.........................................
Tethers .51 .....................
Warning Labels .39, 59
.........
Where Should a Child Sit? . 38
.......................................
Child Seats .45
.........................................
LATCH .47
..........
Tether Anchorage Points . 51
................
Childproof Door Locks . 153
................
Cleaning the Seat Belts . 564
..........
Client Service Inf ormation . 630
.......
Climate Control System . 226,227
..........................
On/Off Button .229
..............................................
Clock .391
...................................
Clutch Fluid .554
..................
CO in the Exhaust . 57,623
....
Cold Weather, Starting in . 487,489
......................
Compact Spare Tire .582
.........................................
Compass .397
.................
Console Compartment . 216
.................
Consumer Inf ormation . 630
.............
Controls, Instruments and . 61
Coolant ........................................
Adding .546
....................................
Checking .475
.........................
Proper Solution .546
...................
Temperature Gauge . 77
........
Water Temp Hot Message . 77Crankcase Emissions Control
........................................
System .623
................
Cruise Control Indicator . 72
............
Cruise Control Operation . 401
...................................
Cup Holders .214
.............
Customer Service Of f ice . 630
........................
Customized Settings .94
...............
DANGER, Explanation of . iv
...................................
Dashboard .3, 62
..............
Daytime Running Lights . 142
.................................
Dead Battery .591
............
Def ects, Reporting Saf ety . 632
..............
Def ogger, Rear Window . 145
..............
Def rosting the Windows . 231
..
Devices that Emit Radio Waves . 628
....................................
Dimensions .614
.............
Dimming the Headlights . 139
Dipstick ..........
Automatic Transmission . 549
..................................
Engine Oil .474
........................
Directional Signals .139
........
Disc Brake Wear Indicators . 507
.................................
Disc Changer .253
D
C
II
12/08/03 21:01:56 31TK4640_641
IndexA B C D E F G H I J K L \℮M N O P Q R S T U V W X \℮Y Z
2013 TL

Î
Reserve Tank, Engine...............................
Coolant .475, 546
......................
Reverse Tilt Mirror .168
...............................
Restraint, Child .37
..................
Reverse Gear Position . 496
................................
Rotation, Tire .573
..................................
Saf ety Belts .8, 20
............
Safety Defects, Reporting . 632
.................................
Saf ety Features .7
...........................................
Airbags .9
.......................................
Seat Belts .8
.............
Saf ety Labels, Location of . 58
..............................
Saf ety Messages .iii
.....................................
Seat Belts .8, 20
...............
Additional Information . 20
Automatic Seat Belt ...............................
Tensioners .22
.....................................
Cleaning . 564
......................
Lap/Shoulder Belt .21
................................
Maintenance .23
Reminder Indicator and ................................
Beeper .20, 64
...................
System Components . 20...............
Use During Pregnancy . 18
..........................
Seat Heaters .202, 204
......................
Seats, Adjusting the . 161
.............................
Seat Ventilation .204
............................
Security System . 395
.....................
Selecting a Child Seat .45
...
Selector Knob (Disc Changer) . 236
..................
Sequential Shif t Mode . 501
...............................
Serial Number .612
..............................
Service Minder . 531
...........................
Service Manual .633
.........
Service Station Procedures . 470
..........................
Setting the Clock .391
........................
SH-AWD
Indicator . 73
...
Shif t Lever Position Indicators . 494
........................
Shif t Lock Release . 497
................................
Side Airbags .9 ,30
........
Side Airbag Of f Indicator . 33, 67
......................
Side Curtain Airbags .32
.............................
Signaling Turns .139
.....................................
Snow Tires .575
................................
Sound System .235
Spare Tire ......................................
Inf lating .582
....................
Specif ications .582, 616
....................................
Spark Plugs .615 ................................
Specif ications .614
................................
Speed Control .401
...................................
Speedometer .76
..........
SRS, Additional Inf ormation . 24
...
Additional Safety Precautions . 36
.............................
Airbag Service .35
......
Airbag System Components . 24
How the Passenger Airbag Of f ......................
Indicator Works .34
How the Side Airbag Of f ......................
Indicator Works .33
How the SRS Indicator .......................................
Works .32
How Your Front Airbags .........................................
Work .26
...
How Your Side Airbags Work . 30
How Your Side Curtain Airbags .........................................
Work .32
.............................
SRS Indicator .32, 67
..
START (Ignition Key Position) . 151
START Mode ...................
(Power Mode) . 184, 185
...
Start/Stop Button, Engine . 183,188
VIII
12/08/03 21:02:26 31TK4640_647
IndexA B C D E F G H I J K L \℮M N O P Q R S T U V W X \℮Y Z
S
ÎU.S.
:
2013 TL

Î
CONT INUED
..............
Starting the Engine . 487,489
....
Check Starting System . 488,490
In Cold Weather at High ..........................
Altitude .487, 489
................
With a Dead Battery . 591
........
Steam Coming f rom Engine . 593
Steering Wheel ..............................
Adjustments .146
...
Anti-thef t Column Lock . 151,189
Steering Wheel ..............
Buttons . 387,401,407,425
...................
Stereo Sound System . 235
....................
Storing Your Vehicle .578
......................................
Sun Visors .217
........................
Sunglasses Holder . 218
Super Handling All-Wheel ...
Drive (TM) (SH-AWD
) . 73,504
....
Supplemental Restraint System . 24
......................................
Servicing .35
...............................
SRS Indicator .32
...................
System Components . 24
..................................
Synthetic Oil .544
.....................................
Tachometer .76 .
Taking Care of the Unexpected . 581
Technical Descriptions ....
DOT Tire Quality Grading . 617
.....
Emissions Control Systems . 623
Three Way Catalytic .......................
Converter .624, 625
.......................
Temperature Gauge . 77
....................
Temperature, Outside . 86
........
Temperature, Inside Sensor . 234
..............
Tether Anchorage Points . 51
................
Thef t Protection, Radio . 390
..
Three Way Catalytic Converter . 625
.........
Tighten Fuel Cap Message . 471
................
Tilt the Steering Wheel . 146
..........................
Time, Setting the .391
....................................
Tire Chains .575
.........
Tire, How to Change a Flat . 583
...........................
Tire Inf ormation .617
.................................
Tire Labeling .619
Tire Pressure Monitoring ....................
System (TPMS) .514
Low Tire Pressure/TPMS ...........................
Indicator .69, 514
......................
Pressure Monitor . 515
Required Federal ............................
Explanation .621 ..............
TPMS System Failure . 517
...............................................
Tires .568
......................
Air Pressure .568, 570
........................................
Chains .575
.........................
Checking Wear .571
..........................
Compact Spare .582
......
DOT Tire Quality Grading . 617
.
Glossary of Tire Terminology . 620
......................................
Inf lation .568
..................................
Inspection .571
...................................
Replacing .573
......................................
Rotating .573
................................
Service Lif e .572
...........................................
Snow .575
....................
Specif ications .574, 616
.......................
Traction Devices .575
..........................
Winter Driving .575
...................
Tools, Tire Changing . 584
Torque Distribution Monitor ...............................
(SH-AWD
) .504
Towing .....................................
A Trailer .528
................
Emergency Wrecker . 607
...........................................
Hook .609
IX
12/08/03 21:02:31 31TK4640_648
IndexA B C D E F G H I J K L \℮M N O P Q R S T U V W X \℮Y Z
T
Î U.S.
:
2013 TL
