Always use Honda Long-lif e Anti-
f reeze/Coolant Type 2. This coolant
is pre-mixed with 50 percent
antif reeze and 50 percent distilled
water. Never add straight antif reeze
or plain water.
If Honda antifreeze/coolant is not
available, you may use another
major-brand non-silicate coolant as a
temporary replacement. Make sure
it is a high-quality coolant
recommended for aluminum
engines. Continued use of any
non-Honda coolant can result
in corrosion, causing the
cooling system to malfunction or fail.
Have the cooling system flushed
and refilled with Honda antifreeze/
coolant as soon as possible.
Reinstall the engine oil f ill cap.
Start the engine. The oil pressure
indicator should go out within 5
seconds. If it does not, turn of f the
engine and check your work.
Let the engine run f or several
minutes, then check the drain bolt
and oil f ilter f or leaks.
Turn of f the engine, let it sit f or
several minutes, then check the oil
level on the dipstick. If necessary,
add more oil.
If the coolant level in the reserve
tank is at or below the MIN line, add
coolant to bring it up to the MAX line.
Inspect the cooling system f or leaks.
To access the radiator reserve tank,
remove the right-side engine
compartment cover (see page ).
7.
8.
9.
542
A dding Engine Coolant
Changing the Engine Oil and Filter, Engine Coolant
546
RESERVE TANK
MIN
MAX
Improper disposal of engine oil can be
harmf ul to the environment. If you
change your own oil, please dispose of
the used oil properly. Put it in a sealed
container, and take it to a recycling
center. Do not discard it in a trash bin
or dump it on the ground.
12/07/20 11:40:27 31TK4640_551
Maint enance
2013 TL

The coolant level should be up to
the base of the f iller neck. Add
coolant if it is low.
Remove all engine compartment
covers (see page ).
When the radiator and engine are
cool, relieve any pressure in the
cooling system by turning the
radiator cap counterclockwise,
without pressing down.
Remove the radiator cap by
pushing down and turning
counterclockwise.
If the reserve tank is completely
empty, you should also check the
coolant level in the radiator.
Pour the coolant slowly and
caref ully so you do not spill any.
Clean up any spill immediately; it
could damage components in the
engine compartment.
Put the radiator cap back on and
tighten it.
Pour coolant into the reserve tank.
Fill it to half way between the MAX
and MIN marks. Put the cap back
on the reserve tank.
Reinstall the engine compartment
covers.
Do not add any rust inhibitors or
other additives to your vehicle’s
cooling system. They may not be
compatible with the coolant or
engine components.
1.
2. 4.
5.
3. 6.
7.
542
Engine Coolant
Maint enance
547
RADIATOR CAP
Removing the radiator cap
while the engine is hot can
cause the coolant to spray out,
seriously scalding you.
Always let the engine and
radiator cool down before
removing the radiator cap.
12/07/20 11:40:37 31TK4640_552
2013 TL

Check the f luid level in the
windshield washer reservoir at least
monthly during normal use.If the washer f luid is low, a ‘‘LOW
WASHER FLUID’’ message appears
on the multi-information display.
Fill the reservoir with a good-quality
windshield washer f luid. This
increases the cleaning capability and
prevents f reezing in cold weather.
When you ref ill the reservoir, clean
the edges of the windshield wiper
blades with windshield washer f luid
on a clean cloth. This will help to
condition the blade edges.
Check the reservoir’s f luid level by
removing the cap and looking inside.
On U.S. models On Canadian models
Windshield Washers
548
Do not use engine antif reeze or a
vinegar/water solution in the
windshield washer reservoir. Antif reeze
can damage your vehicle’s paint, while
a vinegar/water solution can damage
the windshield washer pump. Use only
commercially-available windshield
washer f luid.
12/08/10 10:34:45 31TK4640_553
Maint enance
2013 TL

CONT INUED
Insert the dipstick all the way into
the transmission securely as
shown in the illustration.
Remove the dipstick and check
the f luid level. It should be
between the upper and lower
marks.
Remove the dipstick (yellow loop)
f rom the transmission, and wipe it
with a clean cloth.
Check the f luid level with the engine
at normal operating temperature.
Park the vehicle on level ground.
Start the engine, let it run until the
radiator f an comes on, then shut
of f the engine. For accurate
results, wait about 60 seconds (but
no longer than 90 seconds) bef ore
doing step 2.
1.
2.3.
4.
Automatic Transmission
T ransmission Fluid
Maint enance
549
DIPSTICK
UPPER
MARK
LOWER
MARK GUIDE
12/07/20 11:40:52 31TK4640_554
2013 TL

Insert the dipstick all the way back
into the transmission securely as
shown in the illustration.
If the level is below the lower
mark, add f luid into the dipstick
hole to bring it to the level
between the upper and lower
marks.
Always use Acura ATF DW-1
(automatic transmission f luid). Pour the f luid slowly and caref ully
so you do not spill any. Clean up
any spill immediately; it could
damage components in the engine
compartment.
The transmission should be drained
and ref illed with new f luid according
to the Maintenance Minder (see
page ).
If you are not sure how to check and
add f luid, contact your dealer.Make sure the rubber cap on the
dipstick f its in the dipstick guide
and that you push the dipstick in
all the way.
5.
6.
531
T ransmission Fluid
550
TM
Use only Acura ATF DW-1 (automatic
transmission f luid). Do not mix with
other transmission f luids.
Using transmission f luid other than
Acura ATF DW-1 may cause
deterioration in transmission operation
and durability, and could result in
damage to the transmission.
Damage resulting f rom the use of
transmission f luid other than Acura
AT F DW-1 is not covered by the Acura
new vehicle warranty.
12/07/20 11:40:59 31TK4640_555
Maint enance
2013 TL

The transmission should be drained
and ref illed with new f luid according
to the Maintenance Minder (see
page ).
If you are not sure how to check and
add f luid, contact your dealer.
Reinstall the under cover, tighten the
mounting bolts securely, then put
the holding clips back in place. Make
sure the under cover is installed
under the edge of the f ront bumper.
Pour the fluid into the filler hole slowly
and carefully so you do not spill any.
Clean up any spills immediately; it
could damage components in the
engine compartment.
Let the f luid run out until it stops,
then reinstall the check bolt and the
f iller bolt.
Make sure to put a new washer on
each bolt when reinstalling it. If Acura MTF is not available, you
may use an SAE 0W-20 or 5W-20
viscosity motor oil with the API
Certif ication Seal that says ‘‘FOR
GASOLINE ENGINES’’ as a
temporary replacement. However,
motor oil does not contain the proper
additives, and continued use can
cause stiffer shifting. Replace as
soon as it is convenient. 531
T ransmission Fluid
552
TM
12/07/20 11:41:12 31TK4640_557
Maint enance
2013 TL

The f luid level should be between
theMINandMAXmarksontheside
of the reservoir. If the level is at or
below the MIN mark, your brake
system needs attention. Have the
brake system inspected f or leaks or
worn brake pads.
You need to remove the lef t engine
compartment cover to check the
f luid level (see page ).
Check the f luid level in the
reservoirs monthly. There are up to
two reservoirs, depending on the
model. They are:
Brake f luid reservoir (all models)
Clutch f luid reservoir
(manual transmission models
only)
To access the reservoirs, remove the
lef t engine compartment cover (see
page ).
You will also see a ‘‘LOW BRAKE
FLUID’’ message on the multi-
inf ormation display. Always use Honda Heavy Duty
Brake Fluid DOT 3. If it is not
available, you should use only DOT 3
or DOT 4 f luid, f rom a sealed
container, as a temporary
replacement.
Brake f luid marked DOT 5 is not
compatible with your vehicle’s
braking system and can cause
extensive damage. Using any non-Honda brake f luid can
cause corrosion and decrease the lif e
of the system. Have the brake
system f lushed and ref illed with
Honda Heavy Duty Brake Fluid
DOT 3 as soon as possible.
Independent of the Maintenance
Minder inf ormation, replace the
brake f luid every 3 years. 542
542
Brake and Clutch Fluid
Brake Fluid
Maint enance
553
MAX
MIN
12/07/20 11:41:20 31TK4640_558
2013 TL

µ
If you need to connect the battery to
a charger, disconnect both cables to
prevent damaging your vehicle’s
electrical system. Always disconnect
the negative ( ) cable first, and
reconnect it last.
Check the terminals f or corrosion (a
white or yellowish powder) af ter
removing all engine compartment
covers (see page ). To remove
corrosion, cover the terminals with a
solution of baking soda and water. It
will bubble up and turn brown. When
this stops, wash it of f with plain
water. Dry off the battery with a
cloth or paper towel. Coat the
terminals with grease to help prevent
f urther corrosion.
If additional battery maintenance is
needed, see your Acura dealer or a
qualif ied technician.
Battery posts,
terminals, and related accessories
contain lead and lead compounds.
The sensor on the negative
terminal monitors your
vehicle’s battery condition.
If there is a problem with the sensor,
you will see a ‘‘CHECK BATTERY
SENSOR’’ message on the multi-
inf ormation display. Have the vehicle
checked by your dealer.
To see the battery label, remove the
lef t side engine compartment cover
(see page ).
542 542
CONT INUED
Checking the Battery
WARNING:
Wash your hands af ter handling.
Maint enance
577
The battery gives off explosive
hydrogen gas during normal
operation.
A spark or flame can cause the
battery to explode with enough
force to kill or seriously hurt you.
Wear protective clothing and a
face shield, or have a skilled
technician do the battery
maintenance.
12/07/20 11:44:39 31TK4640_582
2013 TL

When you turn the ignition switch to
the START (III) position or on
models with keyless access system,
press the engine start/stop button to
set START Mode (see page ),
you do not hear the normal noise of
the engine trying to start. You may
hear a clicking sound, a series of
clicks, or nothing at all.
Diagnosing why the engine won’t
start f alls into two areas, depending
on what you hear when you turn the
ignition switch to the START (III)
position or on models with keyless
access system, press the engine
start/stop button to set START
Mode (see page ):
You can hear the starter motor
operating normally, or the starter
motor sounds like it is spinning
f aster than normal, but the engine
does not start up and run. You hear nothing, or almost
nothing. The engine’s starter
motor does not operate at all, or
operates very slowly. Check these things:
Check the transmission interlock.
If you have a manual transmission,
the clutch pedal must be pushed
all the way to the f loor or the
starter will not operate. With an
automatic transmission, it must be
in Park or neutral. Turn the ignition switch to the ON
(II) position or on models with
keyless access system, press the
engine start/stop button to set ON
Mode (see page ). Turn on the
headlights, and check their
brightness. If the headlights are
very dim or do not come on at all,
the battery is discharged. See
on page .
184
184
591
184
If theEngineWon’tStart
Nothing Happens or the Starter
Motor Operates Very Slowly
Jump Starting
588
12/07/20 11:45:54 31TK4640_593
T aking Care of t he Unexpect ed
2013 TL

In this case, the starter motor’s
speed sounds normal, or even f aster
than normal, when you turn the
ignition switch to the START (III)
position or on models with keyless
access system, press the engine
start/stop button to set START
Mode (see page ), but the engine
does not run.
Turn the ignition switch to the
START (III) position or on models
with keyless access system, press
the engine start/stop button to set
STARTMode(seepage ).If
the headlights do not dim, check
the condition of the fuses. If the
f uses are OK, there is probably
something wrong with the
electrical circuit for the ignition
switch or starter motor. You will
need a qualif ied technician to
determine the problem. See
on page .If the headlights dim noticeably or
go out when you try to start the
engine, either the battery is
discharged or the connections are
corroded. Check the condition of
the battery and terminal connec-
tions (see page ). You can
then try jump starting the vehicle
f rom a booster battery (see page
).
Are you using a properly coded
key or keyless access remote (on
models with keyless access
system)? An improperly coded key
or keyless access remote will
cause the immobilizer system
indicator in the instrument panel
to blink rapidly (see page ).65
184
184
607 591
577
CONT INUED
T he Starter Operates Normally
Emergency T owing
If theEngineWon’tStart
T aking Care of t he Unexpect ed
589
12/07/20 11:45:59 31TK4640_594
2013 TL
