coolant temperature Acura TL 2013 Owner's Manual

This shows the temperature of the
engine’s coolant. During normal
operation, the pointer should rise
from the bottom mark to about the
middle of the gauge. In severe
driving conditions, such as very hot
weather or a long period of uphill
driving, the pointer may rise to the
upper zone. If it reaches the red
(hot) mark, pull saf ely to the side of
the road. Turn to page for
instructions and precautions on
checking the engine cooling system. If the pointer of the temperaturegauge reaches to or above the red
mark, you will also see the ‘‘WATER
TEMP HOT’’ message on the multi-
information display. This will alert
you that the engine should be
593
Temperature Gauge
Gauges
Inst rument s and Cont rols
77
12/07/20 10:39:34 31TK4640_082
cooled down.
2013 TL

µ
Your vehicle’s starting system has an
auto control mode. When you turn
the ignition switch to the START
(III) position, this f eature keeps the
engine’s starter motor running until
the engine starts. Follow these
instructions to start the engine:
Make sure the shif t lever is in
Park. Press on the brake pedal. In cold weather, turn of f all
electrical accessories to reduce
the drain on the battery. Apply the parking brake. Without touching the accelerator
pedal, turn the ignition switch to
the START (III) position, then
release the ignition switch. You do
not need to hold the ignition
switch in the START (III) position
to start the engine. The starter
motor runs until the engine starts
or a maximum of 10 25 seconds
depending on engine coolant
temperature.
If the engine does not start, wait at
least 10 seconds bef ore trying
again.
1.
2.
3. 4.
Starting the Engine (Models without Keyless Access System)
Driving
487
The engine is harder to start in cold
weather. Also, the thinner air f ound at
altitudes above 8,000 f eet (2,400
meters) adds to this problem.
T he immobilizer system protects your
vehicle f rom thef t. If an improperly
coded key (or other device) is used, the
engine’s f uel system is disabled. For
more inf ormation, see page . 149
12/07/20 11:33:26 31TK4640_492
2013 TL

µ
The keyless access remote battery
becomes weak or dead. The keyless access remote system
main switch is of f .
In either of the f ollowing cases, you
should insert the keyless access
remote into the keyless remote slot.
For more inf ormation, see pages
and .
Your vehicle’s starting system has an
auto control mode. When you have
your keyless access remote and push
the engine start/stop button while
depressing the brake pedal (A/T) or
clutch pedal (M/T), this f eature
keeps the engine’s starter motor
running until the engine starts.
Follow these instructions to start the
engine:
Make sure the shif t lever is in
Park. Press on the brake pedal. Press the clutch pedal down all the
way. The power mode f rom ON to
START does not f unction unless
the clutch pedal is pressed. In cold weather, turn of f all
electrical accessories to reduce
the drain on the battery. Apply the parking brake. Without touching the accelerator
pedal, push and release the engine
start/stop button. You do not need
to hold the engine start/stop
button to start the engine. The
starter motor runs until the engine
starts or a maximum of 10 25
seconds depending on engine
coolant temperature.If the engine does not start, wait at
least 10 seconds bef ore trying
again.
1.
2.
3. 4.194 195
Automatic transmission:
Manual transmission:
Starting the Engine (Models with Keyless Access System)
Driving
489
T he immobilizer system protects your
vehicle f rom thef t. If an improperly
coded keyless access remote (or other
device) is used, the engine’s f uel system
is disabled. For more inf ormation, see
page .
The engine is harder to start in cold
weather. Also, the thinner air f ound at
altitudes above 8,000 f eet (2,400
meters) adds to this problem. 149
12/07/20 11:33:41 31TK4640_494
2013 TL

Î
Î
Ì Ì Î
Î
µµÌ
Î
Î
Maintenance Minder
540
:
TM
If the message ‘‘SERVICE DUE NOW’’ does not appear more than 12 months
after the display is reset, change the engine oil every year.
See information on maintenance and emissions warranty on page .
Inspect idle speed every 160,000 miles (256,000 km). Independent of the Maintenance Minder information, replace the brake
fluid every 3 years.
Adjust the valves during services A, B, 1, 2, or 3 if they are noisy.
NOTE:
2:
1:
SH-AWD only
538
Maintenance Main Items
Replace engine oil
Replace engine oil and oil filter
Inspect front and rear brakes
Check parking brake adjustment
Inspect these items: Tie rod ends, steering gear box, and boots
Suspension components
Driveshaft boots
Brake hoses and line (including ABS/VSA)
All fluid levels and condition of fluids
Exhaust system
Fuel lines and connections Maintenance Sub Items
Rotate tires
Replace air cleaner element If you drive in dusty conditions, replace every
15,000 miles (24,000 km).
Replace dust and pollen filter If you drive primarily in urban areas that have high
concentrations of soot in the air from industry and
from diesel-powered vehicles, replace every 15,000
miles (24,000 km).
Inspect drive belt
Replace transmission fluid
Replace transmission and transfer fluid
Replace spark plugs
Replace timing belt and inspect water pump If you drive regularly in very high temperatures (over
110°F, 43°C), or in very low temperatures (under20°F, 29°C), replace every 60,000 miles (U.S.)/
100,000 km (Canada).
Inspect valve clearance
Replace engine coolant
Replace rear differential fluid Driving in mountainous areas at very low vehicle
speeds results in higher level of mechanical (shear)
stress to fluid. This requires differential fluid changes
more frequently than recommended by the
Maintenance Minder. If you regularly drive your
vehicle under these conditions, have the differential
fluid changed at 7,500 miles (12,000 km), then every
15,000 miles (24,000 km).
A
B
Symbol
Symbol
3
4
5 1
2
61
1
2
2
12/07/20 11:39:42 31TK4640_545
Maint enance
2013 TL

If you do not see steam or spray,
leave the engine running and
watch the temperature gauge. If
the high heat is due to overloading,
the engine should start to cool
down almost immediately. If it
does, wait until the temperature
gauge comes down to the midpoint,
then continue driving.
The pointer of the vehicle’s
temperature gauge should stay in
the midrange. If it climbs to the red
mark, you should determine the
reason (hot day, driving up a steep
hill, etc.).
If the temperature gauge stays at
the red mark, turn off the engine.
Look f or any obvious coolant leaks,
such as a split radiator hose.
Everything is still extremely hot,
so use caution. If you f ind a leak, it
must be repaired bef ore you
continue driving (seeon page ).
Saf ely pull to the side of the road.
Put the transmission in neutral
(manual) or Park (automatic), and
set the parking brake. Turn of f all
accessories, and turn on the
hazard warning lights.
If you see steam and/or spray
coming f rom under the hood, turn
of f the engine. Wait until you see
no more signs of steam or spray,
then open the hood.
If the vehicle overheats, you should
take immediate action. The only
indication may be the temperature
gauge climbing to or above the red
mark. Or you may see steam or
spray coming f rom under the hood. You will also see a ‘‘WATER TEMP
HOT’’ message on the multi-
inf ormation display (see page ).
1.
2.3.
4.
5.
607
77
CONT INUED
Emergency
Towing
If theEngineOverheats
T aking Care of t he Unexpect ed
593
Steam and spray from an
overheated engine can
seriously scald you.
Do not open the hood if steam
is coming out.
Driving with the temperature gauge
pointer at the red mark can cause
serious damage to the engine.
12/07/20 11:46:33 31TK4640_598
2013 TL

If you don’t f ind an obvious leak,
check the coolant level in the
radiator reserve tank. Add coolant
if the level is below the MIN mark
(seeon
page ).
If there was no coolant in the
reserve tank, you may need to add
coolant to the radiator. Let the
engine cool down until the pointer
reaches the middle of the tempera-
ture gauge, or lower, bef ore check-
ing the radiator. If the temperature stays normal,
check the coolant level in the
radiator reserve tank. If it has
gone down, add coolant to the
MAX mark. Put the cap back Put the radiator cap back on
tightly. Run the engine, and check
the temperature gauge. If it goes
back to the red mark, the engine
needs repair (seeon page ).
Start the engine, and set the
interior temperature to maximum
heat (each temperature control
sets to ‘‘ ’’). Add coolant to
the radiator up to the base of the
f iller neck. If you do not have the proper coolant mixture available,
you can add plain water.
Remember to have the cooling
system drained and refilled with
the proper mixture as soon
as you can.
Using gloves or a large heavy
cloth, turn the radiator cap
counterclockwise, without
pushing down, to the first stop.
After the pressure releases,
push down on the cap, and turn it
until it comes off.
8.
9.
7. 6.
10.
11.
546
607
A dding Engine Coolant
Emergency
Towing
If theEngineOverheats
594
Removing the radiator cap
while the engine is hot can
cause the coolant to spray out,
seriously scalding you.
Always let the engine and
radiator cool down before
removing the radiator cap.
12/07/20 11:46:40 31TK4640_599
T aking Care of t he Unexpect ed
on t ig h tly.
2013 TL

............................
Capacities Chart .614
.............
Carbon Monoxide Hazard . 57
............................
Carrying, Cargo .481
.............
CAUTION, Explanation of . iv
.........................................
CD Care . 381
...................................
CD Changer .253
.......................................
CD Player .307
........................
Certif ication Label .612
............................................
Chains .575
....................
Changing a Flat Tire .583
Changing Oil ........................................
How to .544
......................................
When to . 531
...
Charging System Indicator . 65,596
............
Checklist, Bef ore Driving . 486
.....................................
Child Saf ety .37
..............................
Booster Seats .54
...................................
Child Seats .45
..........................................
Inf ants .42
............................
Large Children .53
.........................................
LATCH .47
......................
Risks with Airbags .38
.............................
Small Children .43
.........................................
Tethers .51 .....................
Warning Labels .39, 59
.........
Where Should a Child Sit? . 38
.......................................
Child Seats .45
.........................................
LATCH .47
..........
Tether Anchorage Points . 51
................
Childproof Door Locks . 153
................
Cleaning the Seat Belts . 564
..........
Client Service Inf ormation . 630
.......
Climate Control System . 226,227
..........................
On/Off Button .229
..............................................
Clock .391
...................................
Clutch Fluid .554
..................
CO in the Exhaust . 57,623
....
Cold Weather, Starting in . 487,489
......................
Compact Spare Tire .582
.........................................
Compass .397
.................
Console Compartment . 216
.................
Consumer Inf ormation . 630
.............
Controls, Instruments and . 61
Coolant ........................................
Adding .546
....................................
Checking .475
.........................
Proper Solution .546
...................
Temperature Gauge . 77
........
Water Temp Hot Message . 77Crankcase Emissions Control
........................................
System .623
................
Cruise Control Indicator . 72
............
Cruise Control Operation . 401
...................................
Cup Holders .214
.............
Customer Service Of f ice . 630
........................
Customized Settings .94
...............
DANGER, Explanation of . iv
...................................
Dashboard .3, 62
..............
Daytime Running Lights . 142
.................................
Dead Battery .591
............
Def ects, Reporting Saf ety . 632
..............
Def ogger, Rear Window . 145
..............
Def rosting the Windows . 231
..
Devices that Emit Radio Waves . 628
....................................
Dimensions .614
.............
Dimming the Headlights . 139
Dipstick ..........
Automatic Transmission . 549
..................................
Engine Oil .474
........................
Directional Signals .139
........
Disc Brake Wear Indicators . 507
.................................
Disc Changer .253
D
C
II
12/08/03 21:01:56 31TK4640_641
IndexA B C D E F G H I J K L \℮M N O P Q R S T U V W X \℮Y Z
2013 TL

Î
CONT INUED
...
Disc Changer Error Messages . 263
.....................
Disposal of Used Oil .546
Doors .....
Lock Button, Outer Handle . 176
..........
Lockout Prevention . 153,177
.................
Monitor Indicator . 12,71
....................
Power Door Locks . 152
.
Unlock Sensor, Outer Handle . 175
........
DOT Tire Quality Grading . 617
Downshif ting, ..............
Manual Transmission . 491
....................
D-Paddle Shif t Mode .499
...........
Driver and Passenger Safety . 5
...........................................
Driving .485
....................................
Economy .476
Driving Position Memory ........................................
System .170
Dual Temperature and Mode .......................................
Control .232
..................
Dust and Pollen Filter . 566
..............................
Economy, Fuel .476
Electronic Stability Control ............................
(ESC) System .510 ..................................
Emergencies .581
.............
Battery, Jump Starting . 591
...........
Brake System Indicator . 598
................
Changing a Flat Tire . 583
.....
Charging System Indicator . 596
..................
Checking the Fuses . 600
.......
Hazard Warning Flashers . 145
.........
If the Engine Won’t Start . 588
......
If Your Vehicle Gets Stuck . 609
............................
Jump Starting .591
.....
Low Oil Pressure Indicator . 595
...
Malf unction Indicator Lamp . 597
Manually Opening Fuel Fill .......................................
Door .599
..................
Overheated Engine . 593
.......................................
Towing .607
.........................
Emergency Brake .212
..............
Emergency Engine Start . 490
....................
Emergency Flashers .145
......................
Emergency Towing .607
..........
Emergency Trunk Opener . 156
.......................
Emissions Controls .623
........................
Emissions Testing .626
Engine ............
Adding Engine Coolant . 546
....
Coolant Temperature Gauge . 77.........................
If It Won’t Start .588
Malf unction Indicator ................................
Lamp .64, 597
.................................
Oil Lif e .86, 531
........
Oil Pressure Indicator . 64,595
..............
Oil, What Kind to Use . 543
...............................
Overheating .593
............................
Specif ications .615
....................
Speed Limiter . 492,497
.............
Start/Stop Button . 183,188
..............................
Starting .487, 489
Starting System .........................
Message .488, 490
......
Engine Compartment Covers . 542
..............................
Engine Coolant .546
....
Engine Start/Stop Button . 183,188
......................
Ethanol in Gasoline .469
.
Evaporative Emissions Controls . 623
...............................
Exhaust Fumes .57
Expectant Mothers, Use of Seat ........................................
Belts by .18
E
III
12/08/03 21:02:01 31TK4640_642
IndexA B C D E F G H I J K L \℮M N O P Q R S T U V W X \℮Y Z
Î U.S.
:
2013 TL

...................................
Fan, Interior .230
.........................................
Features .225
....................
Filling the Fuel Tank . 470
Filters .........................
Dust and Pollen .566
...............................................
Oil .544
...........
Flashers, Hazard Warning . 145
...................
Flat Tire, Changing a . 583
.....................................
Floor Mats .565
Fluids ..........
Automatic Transmission . 549
..........................................
Brake .553
.........................................
Clutch .554
..............
Manual Transmission . 551
................
Windshield Washers . 548
FM Stereo Radio ...................................
Reception .385
.....................................
Fog Lights .143
........................
Four-way Flashers .145
..............................
Front Airbags .9, 26
....................................
Front Seats .161
....................................
Adjusting .161
.....................................
Airbags .9, 26
..............................
Heaters .202, 204 .................................
Ventilation .204
.................................................
Fuel .468
......................
Fill Door and Cap .470
...........................................
Gauge .76
.....................
Low Fuel Indicator .73
................
Octane Requirement . 468
...............................
Oxygenated .469
........................
Tank, Filling the .470
...............................
Fuel Economy .476
.....................
Fuses, Checking the .601
...............
Gas Mileage, Improving . 476
.........................................
Gasoline .468
...........................................
Gauge .76
.....................
Low Fuel Indicator .73
................
Octane Requirement . 468
........................
Tank, Ref ueling .470
................
Gas Station Procedures . 470
Gauges ...
Engine Coolant Temperature . 77
...............................................
Fuel .76
Gearshif t Lever Positions ..........
Automatic Transmission . 494
..............
Manual Transmission . 491......................................
Glove Box .216
Gross Vehicle Weight Rating .............................
(GVWR) .483, 614
.......................
Halogen Bulbs .555, 560
......
HandsFreeLink
(HFL) . 407,424
............
Hazard Warning Flashers . 145
Hard Disc Drive (HDD), ........................................
Playing .320
.....................................
Headlights .139
........................................
Aiming .555
............
Automatic Lighting Off . 141
............
Automatic Lighting On . 140
.........
Daytime Running Lights . 142
..................
High Beam Indicator . 71
.......................
Reminder Beeps .139
........................
Replacing Bulbs .555
.................................
Turning on .139
.....................................
Washers .138
............................
Head Restraints .162
.............................
Heated Mirrors .169
...........................
Heater, Seat .202, 204
...............
High-Low Beam Switch . 140
.............................
Hill Start Assist .512
H
G
F
IV
12/08/03 21:02:05 31TK4640_643
IndexA B C D E F G H I J K L \℮M N O P Q R S T U V W X \℮Y Z
2013 TL
