front sensor camera ACURA TLX 2022 Owner's Manual

483
uuAcuraWatchTMuFront Sensor Camera
Driving
1Front Sensor Camera
If the Some Driver Assist Systems Cannot
Operate: Camera Temperature Too High message
appears:
•Use the climate control system to cool down the
interior and, if necessary, also use defroster mode
with the airflow directed towards the camera.
•Start driving the vehicle to lower the windshield
temperature, which cool s down the area around
the camera.
If the Some Driver Assist Systems Cannot
Operate: Clean Front Windshield message
appears:
•Park your vehicle in a sa fe place, and clean the
windshield. If the message does not disappear after
you have cleaned the windshield and driven for a
while, have your vehicle checked by a dealer.
22 ACURA TLX-31TGV6100.book 483 \b

498
uuParking Your Vehicle uParking Sensor System*
Driving
■When the distance betwe en your vehicle and obstacles becomes shorter
*1:At this stage, only the center sensors detect obstacles.
Interval between beepsDistance between the Bumper and ObstacleIndicatorAudio/Information ScreenCorner SensorsCenter Sensors
Moderate—
Front: About 39-24 in
(100-60 cm)
Rear: About 43-24 in
(110-60 cm)
Blinks in Yellow*1
ShortAbout 24-18 in (60-45 cm) About 24-18 in (60-45 cm)
Blinks in Amber
Very shortAbout 18-14 in (45-35 cm) About 18-14 in (45-35 cm)
ContinuousAbout 14 in
(35 cm) or lessAbout 14 in
(35 cm) or lessBlinks in Red
Models with multi-view rear
camera system
Indicators light up where the
sensor detects an obstacle.
Models with surround view
camera system
Indicators light up where the
sensor detects an obstacle.
22 ACURA TLX-31TGV6100.book 498 \b

uuCleaning uInterior Care
572
Maintenance
Wipe using a glass cleaner.
The front floor mats hook over floor anchors,
which keep them from sliding forward. To
remove a mat for cleaning, turn the anchor
knob(s) to the unlock position. When
reinstalling the mat after cleaning, turn the
knob(s) to the lock position.
Do not put additional floor mats on top of
the anchored mats.
To properly clean leather:
1. Use a vacuum or soft dry cloth first to remove any dirt or dust.
2. Clean the leather with a soft cloth dampen ed with a solution comprised of 90%
water and 10% neutral soap.
3. Wipe away any soap residu e with a clean damp cloth.
4. Wipe away residual water and allow leather to air dry in the shade.
■Cleaning the Window
■Floor Mats
1Cleaning the Window
Wires are mounted to the in side of the rear window.
Wipe along the same direct ion as the wires with a
soft cloth so as not to damage them.
Be careful not to spill fluids, such as water or glass
cleaner, on or around the co ver of both the front
sensor camera and the rainfall/light sensor
*.
2 Automatic Operation (automatic lighting
control) P. 151
2 Automatic Intermittent Wipers
* P. 158
2 Front Sensor Camera P. 482
1Floor Mats
If you use any floor mats that were not originally
provided with your vehicle, make sure they are
designed for your specific ve hicle, fit correctly, and
are securely anchored by the floor anchors.
Position the rear seat fl oor mat properly. If not
properly positioned, the fl oor mat can interfere with
the front seat functions.Unlock
Lock
■Maintaining Genuine Leather1 Maintaining Genuine Leather
It is important to clean or wipe away dirt or dust as
soon as possible. Spills can soak into leather resulting
in stains. Dirt or dust ca n cause abrasions in the
leather. In addition, pl ease note that some dark
colored clothing can rub onto the leather seats
resulting in discol oration or stains.
* Not available on all models
22 ACURA TLX-31TGV6100.book 572 \b

646
Index
B
BatteryCharging (Battery) ................................... 567
Charging System Indicator ................. 83, 613
If the Battery Is Dead ............................... 606
Maintenance (Checking the Battery) ........ 564
Belts (Seat) .................................................. 36
Beverage Holders ...................................... 184
Blind spot information System ................ 413
Bluetooth ® Audio ..................................... 261
Bluetooth ® HandsFreeLink ®................... 329
Booster Seats (For Children) ....................... 74
Brake System ............................................. 485
Anti-lock Brake System (ABS) ................... 492
Automatic Brake Hold.............................. 490
Brake Assist System ................................. 493
Fluid ........................................................ 549
Foot Brake ............................................... 489
Indicator ................................ 80, 81, 82, 615
Indicator (Red) ......................................... 617
Parking Brake .......................................... 485
Brightness Control (Instrument Panel) .... 159
Built-in Key ................................................ 121
Bulb Replacement ..................................... 550
Brake, Rear Turn Si gnal and Taillight/Rear
Side Marker Lights ................................. 551
Fog Lights ................................................ 550
Front Turn Signal, Parking/Daytime
Running and Front Side Marker Lights.... 550
Headlights ............................................... 550
High-Mount Brake Light .......................... 551 Puddle Lights........................................... 551
Rear License Plate Light ........................... 551
Side Turn Signal/Emergency Indicator
Lights .................................................... 550
Taillights and Back-Up Lights ................... 551
Bulb Specifications ................................... 632
C
CAMERA Button....................................... 508
Carbon Monoxide Gas ............................... 75
Carrying Cargo ................................. 369, 371
Certification Label .................................... 634
Changing Bulbs ........................................ 550
Charging System Indicator ................. 83, 613
Child Safety ................................................. 61
Childproof Door Locks............................. 134
Child Seat .................................................... 61
Booster Seats ............................................ 74
Child Seat for Infants................................. 63
Child Seat for Small Children ..................... 64
Installing a Child Seat with a Lap/Shoulder Seat Belt .................................................. 69
Larger Children ......................................... 73
Rear-facing Child Seat ............................... 63
Selecting a Child Seat ................................ 65
Using a Tether ........................................... 71
Childproof Door Locks ............................. 134
Cleaning the Exterior ............................... 573
Cleaning the Interior ................................ 571
Client Service Information ....................... 644Climate Control System
........................... 197
Defrosting the Windshield and
Windows .............................................. 199
Dust and Pollen Filter .............................. 570
Sensors ................................................... 201
Synchronized Mode ................................ 200
Clock ......................................................... 118
CMBS
TM (Collision Mitigation Braking
SystemTM) ................................................ 420
Coat Hooks ............................................... 186
Collision Mitigation Braking System
TM
(CMBSTM) ................................................. 420
Compact Spare Tire (Optional) ....... 596, 633
Console Compartment ............................. 183
Controls .................................................... 117
Coolant (Engine) .............................. 544, 546
Adding the Coolant ................................ 547
Adding to the Radiator ........................... 545
Adding to the Reserve Tank .................... 544
Overheating ............................................ 609
Creeping (Automatic Transmission) ........ 381
Cross Traffic Monitor ............................... 500
Cup Holders .............................................. 184
Customized Features ............................... 302
D
Daytime Running Lights .......................... 153
Dead Battery ............................................ 606
Defaulting All the Settings ...................... 325
22 ACURA TLX-31TGV6100.book 646 \b

647
Index
Defrosting the Windshield and Windows ................................................. 199
Devices that Emit Radio Waves ............... 635
Dimming Headlights .............................................. 150
Rearview Mirror ...................................... 165
Dipstick (Engine Oil) ................................ 537
Directional Signals (Turn Signal) ............. 149
Door Mirrors ............................................. 166
Doors ........................................................ 120
Auto Door Locking.................................. 135
Auto Door Unlocking .............................. 135
Door Open Indicator ................................. 35
Keys........................................................ 120
Locking/Unlocking the Doors from the Inside .............................................. 15, 132
Locking/Unlocking the Doors from the
Outside ................................................. 123
Lockout Prevention System ..................... 130
DOT Tire Quality Grading ........................ 558
Driver Attention Monitor ........................ 108
Driving ...................................................... 367
Automatic Transmission .......................... 381
Braking ................................................... 485
Shifting Gear .......................................... 382
Starting the Engine ................................. 374
Driving Position Memory System ............ 162
Dust and Pollen Filter .............................. 570
Dynamic Mode Switch ............................. 392E
Electric Power Steering (EPS) System
Indicator ............................................ 88, 616
Electronic Stability Control (ESC) ............. 405
Emergency ................................................ 627
Emissions Testing (Readiness Codes) ....... 637
Engine ....................................................... 634
Coolant ........................................... 544, 546
If the Battery Is Dead ............................... 606
Oil ........................................................... 536
Remote Engine Start ................................ 376
Starting ................................................... 374
Engine Coolant ................................. 544, 546
Adding the Coolant ................................. 547
Adding to the Radiator ............................ 545
Adding to the Reserve Tank ..................... 544
Overheating ............................................ 609
Temperature Gauge .................................. 97
Engine Oil ................................................. 536
Adding .................................................... 539
Checking ................................................. 537
Displaying Oil Life .................................... 525
Engine Oil Pressure Low Warning ............ 612
Recommended Engine Oil ........................ 536
Engine Oil Pressure Low Warning ........... 612
ENGINE START/STOP Button .................... 146
Exhaust Gas Hazard (Carbon Monoxide) .. 75
Exterior Care (Cleaning) ........................... 573
Exterior Mirrors ........................................ 166
F
Features.................................................... 203
Filters Dust and Pollen ....................................... 570
Oil ........................................................... 540
Flat Tire ..................................................... 581
Floor Mats ................................................. 572
Fluids
Automatic Transmission .......................... 548
Brake ...................................................... 549
Engine Coolant ............................... 544, 546
Windshield Washer ................................. 549
FM/AM Radio ............................................ 238
Fog Lights ................................................. 153
Indicator.................................................... 90
Foot Brake ................................................ 489
Front Airbags (SRS) ..................................... 46
Front Seats ................................................ 168
Adjusting ................................................ 168
Front Sensor Camera ................................ 482
Fuel ...................................................... 22, 515
Economy ................................................. 518
Gauge ....................................................... 97
Instant Fuel Economy .............................. 103
Low Fuel Indicator ..................................... 87
Range ..................................................... 103
Recommendation ............................ 515, 632
Refueling................................................. 515
Fuel Economy ........................................... 518
Fuel Fill Door ...................................... 22, 516
22 ACURA TLX-31TGV6100.book 647 \b
