Contents
This owner’s manual should be considered a permanent part of the
vehicle and should remain with the vehicle when it is sold.
The Navigation Manual is available online at owners.acura.com
(U.S.) or acura.ca (Canada). If you are the firs t registered owner
of your vehicle, you may request a complimentary printed
copy of the Navigation Manual within the first six months of
vehicle purchase. To request a copy, visit owners.acura.com. In
Canada, please request a copy from your Acura dealer.
This owner’s manual covers all models of your vehicle. You may find
descriptions of equipment and features that are not on your
particular model.
Images throughout this owner’s ma nual (including the front cover)
represent features and equipment that are available on some, but
not all, models. Your particular mo del may not have some of these
features.
This owner’s manual is for vehicles sold in the United States and
Canada.
The information and specifications in cluded in this publication were
in effect at the time of approval for printing. Honda Motor Co., Ltd.
reserves the right, however, to discontinue or change specifications
or design at any time without notice and without incurring any
obligation.2 Safe Driving P. 31
For Safe Driving P. 32 Seat Belts P. 36 Airbags P. 43
2Instrument Panel P. 77
Indicators P. 78 Gauges and Multi-Information Display P. 97
2Controls P. 117
Clock P. 118 Locking and Unlocking the Doors P. 120
Windows P. 142 Moonroof P. 145
Seats P. 168 Interior Convenience Items P. 180
2Features P. 203
Audio System P. 204 Audio System Basic Operation P. 210
Customized Features P. 302 HomeLink® Universal Transceiver P. 326
2 Driving P. 367
Before Driving P. 368 Towing a Trailer P. 373
Parking Your Vehicle P. 494 Multi-View Rear Camera* P. 505
Turbo Engine Vehicle P. 519
2 Maintenance P. 521
Before Performing Maintenance P. 522 Maintenance MinderTM P. 525
Checking and Maintaining Wiper Blades P. 552
Climate Control System Maintenance P. 570
2Handling the Unexpected P. 579
Tools P. 580 If a Tire Goes Flat P. 581
Indicator, Coming On/Blinking P. 612 Fuses P. 620
If You Cannot Open the Trunk P. 629
2Information P. 631
Specifications P. 632 Identification Numbers P. 634
Emissions Testing P. 637 Warranty Coverages P. 640
22 ACURA TLX-31TGV6100.book 4 \b

367
Driving
This chapter discusses driving and refueling.
Before Driving................................... 368
Towing a Trailer ................................ 373
When Driving
Starting the Engine .......................... 374
Precautions While Driving................. 380
Automatic Transmission ................... 381
Shifting ............................................ 382
Integrated Dynamics System............. 391
Auto Idle Stop .................................. 398
Vehicle Stability AssistTM (VSA® ), aka
Electronic Stability Control (ESC),
System ........................................ 405
Agile Handling Assist ....................... 407 Super Handling-All Wheel Drive
TM (SH-
AWD® )*......................................... 408
Tire Pressure Monitoring System (TPMS)
with Tire Fill Assist .......................... 409
Tire Pressure Monitoring System (TPMS) - Required Federal Explanation ........... 411
Blind spot information System
*........ 413
AcuraWatchTM................................... 416
Collision Mitigati on Braking SystemTM
(CMBSTM) ....................................... 420
Adaptive Cruise Control (ACC) with Low Speed Follow ................................. 431
Lane Keeping Assist System (LKAS) .. 450 Traffic Jam Assist ............................. 459
Road Departure Mi
tigation (RDM)
System ........................................ 471
Traffic Sign Recognition System ....... 476
Front Sensor Camera ....................... 482
Radar Sensor ................................... 484
Braking .............................................. 485
Parking Your Vehicle ........................ 494
Multi-View Rear Camera
*................ 505
Surround View Camera System*..... 507
Refueling ........................................... 515
Fuel Economy and CO
2 Emissions .... 518
Turbo Engine Vehicle ....................... 519
* Not available on all models
22 ACURA TLX-31TGV6100.book 367 \b

371
uuBefore Driving uMaximum Load Limit
Continued
Driving
Maximum Load Limit
The maximum load for your ve hicle is 838 lbs (380 kg).
See the Tire and Loading Information label attached to the driver’s
doorjamb.
This figure includes the total weig ht of all occupants, cargo, and
accessories, and the tongue load if you are towing a trailer.
Steps for Determining Correct Load Limit -
(1) Locate the statement “The combined weight of occupants and
cargo should never exceed XXX kg or XXX lbs.” on your
vehicle’s placard.
(2) Determine the combined weight of the driver and passengers
that will be riding in your vehicle.
(3) Subtract the combined weight of the driver and passengers
from XXX kg or XXX lbs.
(4) The resulting figure equals the available amount of cargo and
luggage load capacity. For exampl e, if the “XXX” amount equals
1,400 lbs. and there will be five 150 lb. passengers in your vehicle,
the amount of available cargo and luggage load capacity is 650 lbs.
(1,400 - 750 (5 x 150) = 650 lbs.)1 Maximum Load Limit
Gross Vehicle Weight Rating (GVWR):
The maximum allowable weight of the vehicle, all
occupants, all accesso ries and all cargo.
2 Specifications P. 632
Gross Axle Weight Rating (GAWR):
The maximum allowable weight of the vehicle axle. 2 Specifications P. 632
3WARNING
Overloading or improper loading
can affect handling and stability
and cause a crash in which you
can be hurt or killed.
Follow all load limits and other
loading guidelines in this manual.
Label Example
22 ACURA TLX-31TGV6100.book 371 \b

uuBefore Driving uMaximum Load Limit
372
Driving
(5) Determine the combined weight of luggage and cargo being
loaded on the vehicle. That we ight may not safely exceed the
available cargo and luggage load capacity calculated in step 4.
(6) If your vehicle will be towing a trailer, load from your trailer will
be transferred to your vehicl e. Consult this manual to
determine how this reduces the available cargo and luggage
load capacity of your vehicle.
In addition, the total weight of the vehicle, all occupants,
accessories, cargo, and trailer tongue load must not exceed the
Gross Vehicle Weight Rating (GVW R) or the Gross Axle Weight
Rating (GAWR). Both are on a label on the driver’s doorjamb.1 Maximum Load Limit
Towing a Trailer:
See Towing a Trailer to determine whether your
vehicle is designed to tow a trailer.
2 Towing a Trailer P. 373
Load Limits Example
Example1 Max Load838 lbs
(380 kg) Passenger Weight
150 lbs x 2 = 300 lbs (68 kg x 2 = 136 kg) Cargo Weight
538 lbs
(244 kg)
Example2 Max Load838 lbs
(380 kg) Passenger Weight
150 lbs x 5 = 750 lbs (68 kg x 5 = 340 kg) Cargo Weight
88 lbs
(40 kg)
22 ACURA TLX-31TGV6100.book 372 \b

373
Driving
Towing a Trailer
Your vehicle is not designed to tow a trailer. Attempting to do so can void your
warranties.
Towing Behind a Motorhome
Your vehicle is not designed to be towed behind a motor home. If your vehicle needs
to be towed in an emergency, refer to the emergency towing information.
2Emergency Towing P. 627
22 ACURA TLX-31TGV6100.book 373 \b

652
Index
Storage Items............................................ 182
Summer Tires ............................................ 563
Super Handling-All Wheel Drive
TM
(SH-AWD® )............................................... 408
Supplemental Restraint System (SRS) ........ 46
Surround View Camera System ................ 507
Switches (Around the Steering Wheel) ............................................. 6, 7, 146
Synchronized Mode .................................. 200
System Message Indicator .......................... 92
System Updates ......................................... 227
T
Tachometer............................................... 104
Temperature
Gauge ....................................................... 97
Outside Temperature Display ..................... 99
Temperature Sensor ........................... 99, 201
Temporary Tire Repair Kit ........................ 582
Time (Setting) ........................................... 118
Tire Fill Assist ............................................. 409
Tire Pressure Monitoring System (TPMS) Indicator .................................................... 89
Tire Pressure Monitoring System (TPMS) with Tire Fill Assist .................................. 409
Indicator .................................................. 618
Tire Fill Assist ........................................... 409
Tire Repair Kit ........................................... 581
Tires ........................................................... 555
Air Pressure ..................................... 556, 633 Chains..................................................... 563
Checking and Maintaining ...................... 555
Flat Tire (Puncture) .......................... 581, 596
Inspection ............................................... 555
Labeling .................................................. 556
Puncture (Flat Tire) .......................... 581, 596
Regulations ............................................. 558
Rotation .................................................. 562
Spare (Optional) .............................. 596, 633
Summer .................................................. 563
Temporary Tire Re
pair Kit ........................ 582
Wear Indicators ....................................... 560
Winter..................................................... 563
Tools .......................................................... 580
Towing a Trailer ....................................... 373
Towing Behind a Motorhome ................. 373
Emergency .............................................. 627
TPMS (Tire Pressure Monitoring System) Indicator.................................................... 89
TPMS (Tire Pressure Monitoring System) with Tire Fill Assist .................................. 409
Indicator.................................................. 618
Tire Fill Assist ........................................... 409
Traffic Jam Assist ...................................... 459
Traffic Sign Recognition System .............. 476
Transmission ....................................... 20, 382
Automatic ......................................... 20, 382
Gear Position Indicator ...................... 83, 384
Number................................................... 634
Sequential Mode ..................................... 389 Transmission System
Indicator ................................................... 84
Trip Computer .......................................... 102
Trip Meter ................................................ 102
Troubleshooting ...................................... 579
Blown Fuse ............................. 620, 622, 623
Brake Pedal Vibrates ................................. 27
Buzzer Sounds When Opening Door ......... 27
Emergency Towing ................................. 627
Engine Won’t Start ................................. 603
Flat Tire/Puncture .................................... 581
Noise When Braking ................................. 29
Overheating ............................................ 609
Premium Gasoline ........................... 515, 632
Puncture/Flat Tire ............................ 581, 596
Rear Door Won’t Open ..................... 27, 134
Warning Indicators.................................... 78
True Touchpad Interface ......................... 211
Trunk ........................................................ 136
Lid .......................................................... 136
Light Bulbs .............................................. 632
Main Switch............................................ 138
Unable to Open ...................................... 629
Turbo Engine Vehicle .............................. 519
Turn Signals .............................................. 149
Indicators (Instru ment Panel) ..................... 90
Turn-by-Turn Directions .......................... 115
Two-way Keyless Remote ................ 131, 376
22 ACURA TLX-31TGV6100.book 652 \b
