If the charging system indicator
comes on brightly when the engine
is running, or if you see a ‘‘CHECK
CHARGING SYSTEM’’ message on
the multi-information display, the
battery is not being charged.
Immediately turn of f all electrical
accessories. Try not to use other
electrically operated controls such as
the power windows. Keep the engine
running; starting the engine will
discharge the battery rapidly.
Go to a service station or garage
where you can get technical
assistance.If this indicator comes on while
driving, or if you see a ‘‘CHECK
EMISSION SYSTEM’’ message on
the multi-information display, it
means one of the engine’s emissions
control systems may have a problem.
Even though you may f eel no
dif f erence in your vehicle’s
perf ormance, it can reduce your f uel
economy and cause increased
emissions. Continued operation may
cause serious damage.
If you have recently ref ueled your
vehicle, the indicator could come on
due to a loose or missing f uel f ill cap.
You will also see a ‘‘TIGHTEN FUEL
CAP’’ message on the inf ormation
display. Tighten the cap until it clicks
at least once. Tightening the cap will
not turn the indicator of f
immediately; it can take several days
of normal driving.
If the indicator comes on repeatedly,
even though it may turn of f as you
continue driving, have your vehicle
checked by your dealer as soon as
possible.
Charging System Indicator, Malf unction Indicator L amp
Charging System
Indicator
Malf unction Indicator
Lamp
332

However, if the brake pedal does not
feel normal, you should take
immediate action. A problem in one
part of the system’s dual circuit
design will still give you braking at
two wheels. You will feel the brake
pedal go down much farther before
the vehicle begins to slow down, and
you will have to press harder on the
pedal. If you must drive the vehicle a short
distance in this condition, drive
slowly and carefully.
Slow
down by shifting to a lower
gear, and pull to the side of the road
when it is safe. Because of the long
distance needed to stop, it is
hazardous to drive the vehicle. You
should have it to wed and repaired as
soon as possible (see
on page ).
If the brake system indicator comes
on while driving, the brake fluid level
is probably low. You will see a
‘‘BRAKE FLUID LOW’’ message on
the multi-information display. Press
lightly on the brake pedal to see if it
feels normal. If it does, check the
brake fluid level the next time you
stop at a service station (see page
).
The brake system indicator normally
comes on when you turn the ignition
switch to the ON (II) position, and as
a reminder to check the parking
brake. It will stay on if you do not
f ully release the parking brake.
If the f luid level is low, take your
vehicle to a dealer, and have the
brake system inspected f or leaks or
worn brake pads.
You will also see a ‘‘CHECK BRAKE
SYSTEM’’ message on the multi-
inf ormation display when this
indicator comes on.
If the ABS indicator and the VSA
system indicator come on with the
brake system indicator, have your
vehicle inspected by your dealer
immediately.
288 341
Emergency
Towing
Brake System Indicator
334
U.S. Canada

µµ
If your vehicle needs to be towed,
call a prof essional towing service or
organization. Never tow your vehicle
with just a rope or chain. It is very
dangerous.
The operator
loads your vehicle on the back of a
truck. Therearetwowaystotowyour
vehicle: If , due to damage, your vehicle must
be towed with the f ront wheels on
the ground, do this:
Release the parking brake.
Shif t the transmission to neutral.
With the f ront wheels on the ground,
it is best to tow the vehicle no farther
than 50 miles (80 km), and keep the
speedbelow35mph(55km/h).
The tow
truck uses two pivoting arms that go
under the tires (f ront) and lif t them
of f the ground. The other two tires
remain on the ground. Turn of f the engine. ShifttoD,thentoN.
Start the engine.
Release the parking brake. Leave the ignition switch in the
ACCESSORY (I) position so the
steering wheel does not lock.
Leave the ignition switch in the
ACCESSORY (I) position so the
steering wheel does not lock.
Manual transmission:
Automatic transmission:
CONT INUED
Flat -bed EquipmentWheel-lif t Equipment
T his is the best way to
transport your vehicle.
T his is an
acceptable way to tow your
vehicle.
Emergency Towing
T aking Care of t he Unexpect ed
341
Improper towing preparation will
damage the transmission. Follow the
above procedure exactly. If you cannot
shif t the transmission or start the
engine (automatic transmission), your
vehicle must be transported with the
f ront wheels of f the ground.

µ
Quality grades can be f ound where
applicable on the tire sidewall
between the tread shoulder and the
maximum section width. For
example: The treadwear grade is a compara-
tive rating based on the wear rate of
the tire when tested under controlled
conditions on a specif ied government
test course. For example, a tire
graded 150 would wear one and one-
half (1 1/2) times as well on the
government course as a tire graded
100. The relative perf ormance of
tires depends upon the actual condi-
tions of their use, however, and may
depart signif icantly f rom the norm
due to variations in driving habits,
service practices, and dif f erences in
road characteristics and climate.The traction grades, f rom highest to
lowest, are AA, A, B, and C. Those
grades represent the tire’s ability to
stop on wet pavement as measured
under controlled conditions on
specif ied government test surf aces
of asphalt and concrete. A tire
marked C may have poor traction
perf ormance.
Warning: The traction grade
assignedtothistireisbasedon
straight-ahead braking traction tests,
and does not include acceleration,
cornering, hydroplaning, or peak
traction characteristics.
The tires on your vehicle meet all
U.S. Federal Saf ety Requirements.
All tires are also graded f or
treadwear, traction, and temperature
perf ormance according to
Department of Transportation
(DOT) standards. The f ollowing
explains these gradings.
All passenger car tires must conf orm
to Federal Saf ety Requirements in
addition to these grades. Unif orm T ire Quality Grading
T readwear 200
Traction AA
Temperature A Treadwear
Traction AA, A, B, C
DOT Tire Quality Grading (U.S. Vehicles)
Technical Inf ormation
349

....
Customer Service Inf ormation . 360
....................
Warranty Coverages .361
Reporting Saf ety Def ects ............................
(U.S. Vehicle) .362
.....................
Authorized Manuals .363
Warranty and Customer Relations
Warrant y and Cust omer Relat ions
359

Acura dealership personnel are
trained professionals. They should
be able to answer all your questions.
If you encounter a problem that your
deal ership does not solve to your
satisfaction, please discuss it with
the dealership’s management. The
service manager or general manager
can help. Almost all problems are
solved in this way.
U.S. Owners:
If
you are dissatisfied with the
decision made by the dealership’s
management, contact the Acura
Client Services Office. Canadian
Owners:
In Puerto Rico and the U.S. Virgin
Islands: When
you call or write, please give
us this inf ormation:
Vehicle Identif ication Number
(see page )
Name and address of the dealer
who services your vehicle
Date of purchase
Mileage on your vehicle
Your name, address, and tele-
phone number
A detailed description of the
problem
Name of the dealer who sold the
vehicle to you 344
Customer Service Inf ormation
360
CUSTOMER RELATIONS
RELATIONS AVEC LA CLIENTÉLE
American Honda Motor Co., Inc.
Acura Client Services
Mail Stop 500-2N-7E
1919 Torrance Blvd.
Torrance, CA 90501-2746
Tel: (800) 382-2238 Honda Canada Inc.
715 Milner Avenue
Toronto, ON
M1B 2K8
Tel: 1-888-9-ACURA-9
Fax: Toll-free 1-877-939-0909
Toronto (416) 287-4776
Vortex Motor Corp.
Bella International
P.O. Box 190816
San Juan, PR 00919-0816
Tel: (787) 620-7546

µ
Î
Î Î
Î





*
T he publications shown below can be purchased f rom Helm
Incorporated. You can order in any of three ways:
Detach and mail the order f orm on the right half of this page
Call Helm Inc. at 1-800-782-4356
Go online at
If you are interested in other years or models, contact Helm Inc.
at 1-800-782-4356.
CONT INUED
(credit card orders only)
Valid only f or sales within the United States. Canadian owners should contact their authorized Acura dealer.
Authorized Manuals
Purchasing Factory Authorized Manuals (U.S. only)
Authorized Manuals
363
ORDER TOLL FREE: 1-800-782-4356
OR
(NOTE: For Credit Card Holder Orders Only)
MINIMUM CREDIT CARD PURCHASE $10.00
Price
Each
$75.00
$50.00
$44.00
$37.00
$29.00
$12.00
$12.00 FREE
Form Description
2004-2007 Acura TSX Service Manual 2004-2007 Acura TSX
Electrical Troubleshooting Manual
2004-2007 Acura TSX Body Repair Manual 2007 Acura TSX Owner’s Manual2007 Acura TSX NavigationSystem Owner’s Manual
2007 Acura TSX Maintenance Journal 2007 Acura TSX Quick Start GuideOrder Form for Previous Years-
Indicate Year and Model Desired
Publication
Form Number 61SEA03
61SEA03EL
61SEA30
31SEA630
31SEA800
31SEAM00 31SEAQ30 ACU-R
PUBLICATION NUMBER VEHICLE MODEL
Name Year Qty
Price
Each Total
Price
GRAND TOTAL HANDLING CHARGE Mich. Purchases
Add 6% Sales Tax TOTAL MATERIAL
$6.95
Monday-Friday 8:00 A.M. 6:00 P.M. EST
By completing this form you can order the materials desired. You can
pay by check or money order, or charge to your credit card. Mail to
Helm Incorporated at the address shown on the back of the order form.
Prices are subject to change without
notice and without incurring obligation.
Orders are mailed within 10 days. Please
allow adequate time for delivery.
Prices are subject to change without notice and without incurring obligation.
www. helminc. com

µµ
µ
(


%
)
$
%

.
"

#
)
This manual covers maintenance and recommended
procedures f or repair to engine and chassis components.
It is written f or the journeyman mechanic, but is simple
enough f or most mechanically-inclined owners to under-
stand.
This manual complements the service manual by
providing in-depth troubleshooting inf ormation f or each
electrical circuit in your vehicle.
This manual describes the procedures involved in the
replacement of damaged body parts.
Authorized Manuals
Service Manual:
Electrical T roubleshooting Manual:
Body Repair Manual:
364
NOTE: Dealers and Companies please provide dealer or company name,
and also the name of the person to whose attention the shipment should
be sent. For purchases outside U.S.A. please write to the address shown
below for a quotation.
P.O. BOX 07280·DETROIT, MICHIGAN 48207·1-800-782-4356
Customer Name Attention
Apartment Number
State & Zip Code
City
Daytime Telephone Number
Check or money order enclosed payable to Helm Inc U.S. funds only.
Do not send cash
Master
Card VISA
Check here if your billing address is different
from the shipping address shown above.
Account Number Expiration: Mo. Yr.
CUSTOMER SIGNATURE DATE
Street Address No P.O. Box Number
()
These Publications cannot be returned for credit without receiving advance authorization within 14
days of delivery. On returns, a restocking fee may be applied against the original order.

CONT INUED
....................................
Accessories .236
ACCESSORY (Ignition Key .....................................
Position) .128
............
Accessory Power Sockets . 156
....................
Additives, Engine Oil . 288
.....................
Adjusting the Sound .175
Adjust Outside Temp. ...................................
Display . 73, 96
........
Advice For Pregnant Women . 17
.....................................
Airbag (SRS) .9
.....
Airbag, Additional Information . 23
...
Additional Safety Precautions . 35
.............................
Airbag Service .34
Check Airbag System ...................................
Message .83
How the Passenger Airbag Of f ......................
Indicator Works .33
How the Side Airbag Of f ......................
Indicator Works .32
..
How the SRS Indicator Works . 32
How Your Front Airbags .........................................
Work .26
...
How Your Side Airbags Work . 30How Your Side Curtain
..........................
Airbags Work .31
........................
SRS Components .23
............................
Air Conditioning .160
.........................................
Usage .162
.......................
Air Pressure, Tires .311
......................................
Alignment .312
.......................
Alcohol in Gasoline .230
Anti-lock Brakes (ABS) ...............................
Indicator . 65, 255
.......................................
Message .83
...................................
Operation .255
..............
Anti-thef t, Audio System . 201
Anti-thef t Steering Column ............................................
Lock .128
................................
Audio System .170
................
Automatic Lighting Off . 122
.
Automatic Seat Belt Tensionners . 21
..............
Automatic Transmission . 246
..........................
Capacity,Fluid .346
...............
Checking Fluid Level . 293
....
Sequential SportShif t Mode . 248
.......................................
Shif ting .246
.
Shif t Lever Position Indicator . 246
................
Shif t Lever Positions . 246
....................
Shif t Lock Release . 251......................
Auxiliary Input Jack .184
Battery Charging System ...........................
Indicator . 62, 332
.......................................
Message .84
............................
Jump Starting .327
..............................
Maintenance .316
............................
Specif ications .347
..............................
Bef ore Driving .229
..........................................
Belts, Seat .8
.........................
Beverage Holders .156
..................................
Booster Seats .52
Index
A
B
INDEX
I

CONT INUED
.......................................
Child Seats .36
......
LATCH Anchorage System . 46
...........
Lower Anchorage Points . 46
..........
Tether Anchorage Points . 49
..............
Climate Control Sensors . 169
.........................
Clock, Setting the .202
...................................
Clutch Fluid .297
............
Cold Weather, Starting in . 243
......................
Compact Spare Tire .320
.................
Console Compartment . 157
.................
Consumer Inf ormation . 360
.............
Controls, Instruments and . 59
Coolant ........................................
Adding .291
....................................
Checking .234
.........................
Proper Solution .291
...................
Temperature Gauge . 68
Crankcase Emissions Control ........................................
System .354
........
Cruise Control Message . 85, 204
............
Cruise Control Operation . 204
....................
Cruise Main Indicator .66
...................................
Cup Holders .156
.............
Customer Service Of f ice . 360
.......................
Customized Settings .86
....................................
Def ault All .90 ...............
Door · Window Setup . 110
...........................
Lighting Setup .106
.................................
Meter Setup .93
...........................
Position Setup .104
........................
Setting to Def ault .90
...............................
Wiper Setup .117
...............
DANGER, Explanation of . iii
...................................
Dashboard . 3, 60
..............
Daytime Running Lights . 122
........................................
Def ault All .90
............
Defects, Reporting Safety . 362
..............
Def ogger, Rear Window . 124
....................................
Dimensions .346
.............
Dimming the Headlights . 121
Dipstick .
Automatic Transmission . 293, 294
..................................
Engine Oil .234
........................
Directional Signals .121
........
Disc Brake Wear Indicators . 254
.............
Display, Multi-inf ormation . 69
.....................
Disposal of Used Oil .290
Doors ............
Locking and Unlocking . 129..................
Lockout Prevention . 130
...................
And Trunk Open . 11, 78
......................
Power Door Lock .129
.......................
Door Lock Mode .111
..........
DOT Tire Quality Grading . 349
Downshif ting, 6-speed Manual .............................
Transmission .244
...........
Driver and Passenger Safety . 5
.......................................
Driver’s ID .86
...........................................
Driving .241
....................................
Economy .235
Driving Position ........................
Memory System .142
......
DRL, Check System Message . 85
..........
Dual Temperature Control . 167
..................
DustandPollenFilter . 307
..............................
Economy, Fuel .235
.........
Elap. Time Reset Condition . 100
Index
INDEX
DD
E
III
