turn signal Acura TSX 2008 Owner's Manual

ÃŽ
ÃŽ
ÃŽ
ÃŽ Only on vehicles equipped with navigation system. Ref er to the navigation system manual.
To use the horn, press the pad around the ‘‘Acura’’ logo.
1:
2:
Your Vehicle at a Glance
4
WINDSHIELD
WIPERS/WASHERS
MOONROOF
SWITCH
REMOTE AUDIO
CONTROL BUTTONS
MULTI-INFORMATION
BUTTONSCRUISE CONTROL
BUTTONS
REAR WINDOW
DEFOGGER BUTTON
HAZARD WARNING
BUTTON
HORN
INSTRUMENT PANEL BRIGHTNESS
STEERING WHEEL ADJUSTMENT PASSENGER AIRBAG
OFF INDICATOR
HEADLIGHTS/TURN SIGNALS/FOG LIGHTS
VEHICLE STABILITY
ASSIST (VSA) SYSTEM
OFF SWITCH
Vehicle without navigation system is shown. SEAT HEATER SWITCHES
(P.269)
(P.121-122)
(P.202)
(P.150)
(P.125) (P.123)
(P.120)
(P.33)(P.124)
(P.124)
(P.206)
(P.137)
(P.71,72)
BLUETOOTH
HANDSFREELINKBUTTONS/
VOICE CONTROL BUTTONS
(P.214)1
2
\f—\f—
y
y
(\fy\f\f\fy
2008 TSX

Your airbag system includes:Two side airbags, one f or the
driver and one f or a f ront
passenger. The airbags are stored
in the outer edges of the seat-
backs. Both are marked ‘‘SIDE
AIRBAG’’ (see page ).
Two SRS (supplemental restraint
system) f ront airbags. The driver’s
airbag is stored in the center of
the steering wheel; the f ront
passenger’sairbagisstoredinthe
dashboard. Both are marked ‘‘SRS
AIRBAG’’ (see page ). Two side curtain airbags, one f or
each side of the vehicle. The
airbags are stored in the ceiling,
above the side windows. The f ront
and rear pillars are marked ‘‘SIDE
CURTAIN AIRBAG’’ (see page
).
Automatic front seat belt
tensioners (see page ). Sensors that can detect whether
a child is in the passenger’s side
airbag path and signal the
control unit to turn the airbag
of f (see page ).
Sensors that can detect whether
the driver’s seat belt and the
frontpassenger’sseatbeltare
latched or unlatched (see page
).
A driver’s seat position sensor
that monitors the distance of
theseatfromthefrontairbag.If
the seat is too f ar f orward, the
airbag will inf late with less f orce
(see page ).
Sensors that can detect a
moderate to severe frontal or side
impact.
26
30 31
30
19
28
21
Additional Inf ormation About Your Airbags
24
\f—\f—
y


y
(\fy\f\fy
2008 TSX

If the impact is on the passenger’s
side, the passenger’s side curtain
airbag will inflate even if there are no
occupants on that side of the vehicle.
To get the best protection f rom the
side curtain airbags, occupants
should wear their seat belts and sit
upright and well back in their seats.
A f ront seat passenger should not
use a cushion or other object as a
backrest. It may prevent the cutof f
system f rom working properly.
There will be some delay between
the moment the passenger moves
into or out of the airbag deployment
pathandwhentheindicatorcomes
on or goes of f .
If the side airbag of f indicator comes
on (see page ), have the
passenger sit upright. Once the
passenger is out of the airbag’s
deployment path, the system will
turn the airbag back on, and the
indicator will go out.
In a moderate to severe side impact,
sensors will detect rapid acceleration
and signal the control unit to
instantly inflate the side curtain
airbag and activate the seat belt
tensioner on the driver’s or the
passenger’s side of the vehicle.
32
Additional Inf ormation About Your Airbags
How Your Side Curtain A irbags
Work
Driver and Passenger Saf ety
31
SIDE CURTAIN AIRBAG
\f—\f—
y
y
(\fy\f\fy
2008 TSX

This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your vehicle. All the essential
controls are within easy reach............................
Control Locations .60
............................
Instrument Panel .61
..........
Instrument Panel Indicators .62
.............................................
Gauges .68
.............
Multi-Inf ormation Display .69
Controls Near the Steering
.........................................
Wheel .119
Windshield Wipers and .....................................
Washers .120
.......
Turn Signals and Headlights .121
.................................
Fog Lights .122
Automatic Lighting Off .......................................
Feature .122
..............
Daytime Running Lights .122
......
Instrument Panel Brightness .123
...............
Hazard Warning Button .124
...............
Rear Window Def ogger .124
........
Steering Wheel Adjustment .125
.............................
Keys and Locks .126
......................
Immobilizer System .127
..............................
Ignition Switch .128
....................................
Door Locks .129
................
Childproof Door Locks .130
.....................
Remote Transmitter .131
..............................................
Trunk .135
......
Emergency Trunk Opener .136 ...................
Trunk Main Switch .136
..................................
Seat Heaters .137
...............................................
Seats .138
...........
Power Seat Adjustment .138
.........
Driver’s Lumbar Support .139
........................
Head Restraints .139
.....................
Folding Rear Seat .141
Driving Position Memory ........................................
System .143
...........................................
Mirrors .145
..
Adjusting the Power Mirrors .146
..............
Power Mirror Heaters .146
............................
Power Windows .147
.......................................
Moonroof .150
...............................
Parking Brake .151
........................................
Sun Visor .152
................................
Vanity Mirror .152
...............................
Interior Lights .153
.........
Interior Convenience Items .155
.....................
Beverage Holders .156
........
Accessory Power Sockets .156
.............
Console Compartment .157
....................
Sunglasses Holder .158
..................................
Glove Box .158
Instruments and Controls
Inst rument s and Cont rols
59
\f—\f—
y
y
(\fy\f\fy
2008 TSX

This indicator has three f unctions:Itcomesonasareminderthatyou
have turned off the vehicle
stability assist (VSA) system.
It flashes when VSA is active (see
page ).
It comes on along with the VSA
system indicator if there is a
problem with the VSA system.
You will also see a ‘‘CHECK VSA
SYSTEM’’ message on the multi-
inf ormation display (see page ).
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. For more inf ormation, see
page . When you press the hazard warning
button, both turn signals blink. All
turn signals on the outside of the
vehicle should f lash.This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. If this indicator comes on at
any other time, there is a problem in
theABS.If thishappens,takethe
vehicle to your dealer to have it
checked. With this indicator on, your
vehicle still has normal braking
ability but no anti-lock f unction. You
will also see a ‘‘CHECK ABS
SYSTEM’’ message on the multi-
inf ormation display (see page ).
For more inf ormation, see page .
The lef t or right turn signal indicator
blinks when you signal a lane change
or turn. If an indicator does not blink
or blinks rapidly, it usually means
one of the turn signal bulbs is
burned out (see pages and ).
Replace the bulb as soon as possible,
since other drivers cannot see that
you are signaling.
1.
2.
3.
83
82
268
268 304 306
261
Instrument Panel Indicators
Turn Signal and
Hazard Warning
Indicators
VSA A ctivation Indicator
A nti-lock Brake System
(A BS) Indicator
Inst rument s and Cont rols
65
——
y
y
(yy
2008 TSX

ÃŽ
ÃŽ
ÃŽ
ÃŽ
Only on vehicles equipped with navigation system. Ref er to the navigation system manual.
To use the horn, press the pad around the ‘‘Acura’’ logo.
1:
2:
Controls Near the Steering Wheel
Inst rument s and Cont rols
119
HEADLIGHTS/TURN SIGNAL/
FOG LIGHTS
REMOTE AUDIO
CONTROL BUTTONS
REAR WINDOW
DEFOGGER BUTTON
CRUISE CONTROL
BUTTONS
WINDSHIELD WIPERS/
WASHERS
HAZARD WARNING
BUTTON
MULTI-INFORMATION
BUTTONS
MOONROOF
SWITCH
(P.150) PASSENGER AIRBAG
OFF INDICATOR
(P.33)
(P.121-122)
(P.120)
(P.124)
(P.124)
(P.71,72) (P.123)
INSTRUMENT PANEL BRIGHTNESS
(P.206)
VEHICLE STABILITY
ASSIST (VSA) SYSTEM
OFF SWITCH
(P.202)
Vehicle without navigation system is shown. SEAT HEATER SWITCHES
(P.137)
HORN
(P.269) (P.125)
STEERING WHEEL
ADJUSTMENT
BLUETOOTH
HANDSFREELINKBUTTONS/
VOICE CONTROL BUTTONS
(P.214)
1
2
\f—\f—
y
\fy
(\fy\f
y
2008 TSX

µµPush down on the
lef t lever to signal a lef t turn and up
to signal a right turn. To signal a lane
change, push lightly on the lever in
the proper direction and hold it. The
lever will return to center when you
release it or complete a turn. Turning the switch
on the lef t lever to the
‘‘ ’’position turns on the parking
lights, taillights, instrument panel
lights, side-marker lights, and rear
license plate lights.
Turning the switch to the ‘‘ ’’
position turns on the headlights.
When the light switch is in the
‘‘ ’’ or the ‘‘ ’’ position, the
Lights On indicator comes on as a
reminder. This indicator stays on if
you leave the light switch on and
turn the ignition switch to the
ACCESSORY (I) or LOCK (0)
position.
If you leave the lights on with the
key removed f rom the ignition
switch, you will hear a reminder
chime when you open the driver’s
door.
Turn signal
Of f
Parking and indicator lights
Headlights
High beams
Flashhighbeams
Fog lights of f
Fog lights on
1.
2.
3.
4.
5.
6.
7.
8.
CONT INUED
Turn Signal
Headlights
Turn Signals and Headlights
Inst rument s and Cont rols
121
\f—\f—
y
\fy
(\fy\f
y
2008 TSX

Make sure the rear window is clear
and you have good visibility bef ore
starting to drive.
The rear window def ogger will clear
fog, frost, and thin ice from the
window. Push the def ogger button to
turn it on and of f . The indicator
above the button comes on to show
the def ogger is on. If you do not turn
it of f , the def ogger will shut itself of f
af ter about 35 minutes. It also shuts
of f when you turn of f the ignition
switch. You have to turn the
def ogger on again when you restart
the vehicle.
Push the button between the center
vents to turn on the hazard warning
lights (f our-way f lashers). This
causes all f our outside turn signal
lights and both turn signal indicators
in the instrument panel to flash. Use
the hazard warning lights if you need
to park in a dangerous area near
heavy traffic, or if your vehicle is
disabled.
The def ogger and antenna wires on
the inside of the rear window can be
accidentally damaged. When
cleaning the glass, always wipe side-
to-side.
Rear Window Def ogger
Hazard Warning Button
Hazard Warning Button, Rear Window Def ogger
124
Without navigation system With navigation system
\f—\f—
y
\fy
(\fy\f
y
2008 TSX

µ
µ
You can use any of f ive methods to
f ind radio stations on the selected
band: TUNE, SEEK, SCAN, the
preset buttons or icons, and AUTO
SELECT.
The band and f requency that the
radio was last tuned to is displayed.
To change bands, press the FM/AM
button. On the FM band, ST will be
displayed if the station is broadcast-
ing in stereo. Stereo reproduction on
AM is not available.
XM satellite radio inf ormation is
available on page .
The audio system f or your vehicle
can also be operated using the voice
control system. See the Navi section
in your Quick Start Guide f or an
overview of this system, and the
Navigation System manual f or
complete details.
Use the TUNE/SOUND
knob to tune the radio to a desired
f requency. Turn the knob right to
tune to a higher f requency, and turn
theknoblefttotunetoalower
f requency.
The ignition switch must be in the
ACCESSORY (I) or the ON (II)
position. Turn the system on by
pushingtheVOL/PWRknoborthe
AM/FM button. Adjust the volume
by turning the same knob.
The SEEK f unction
searches up and down from the
current f requency to f ind a station
with a strong signal. To activate it,
press the or side of the
SEEK/SKIP bar, then release it.
Pushing the AUDIO button will also
turn on the system.
179
On vehicles with navigation system On vehicles with navigation system
On U.S. models
Playing the AM/FM Radio
To Select a Station
To Play the AM/FM Radio
Voice Control System
TUNE
SEEK
172
——
y


y
(y
y
2008 TSX

Depending on where you drive, you
may experience reception problems.
Interf erence can be caused by any of
these conditions:If you decide to purchase XM
satellite radio service, contact XM
Radio at , or at
1-800-852-9696. You will need to give
them your radio I.D. number and
your credit card number.Turn the TUNE knob until ‘‘0’’
appears in the display. Your I.D. will
appear in the display.
Af ter you have registered with XM
Radio, keep your audio system in the
SAT Radio mode while you await
activation. This should take about 30
minutes.
While awaiting activation, make sure
your vehicle remains in an open area
with good reception. Once your
audio system is activated, ‘‘category’’
or ‘‘CH’’ will appear on the display
and you will be able to listen to XM
Radio broadcasts. XM Radio will
continue to send an activation signal
to your vehicle for at least 12 hours
from activation request. If the
service has not been activated after
36 hours, contact XM Radio.
If your XM Radio service has expired
or you purchased your vehicle f rom
a previous owner, you can listen to a
sampling of the broadcasts available
on XM Satellite Radio. With the
ignition switch in the ACCESSORY
(I) or ON (II) position, push the
VOL/PWR knob to turn on the audio
system and press the CD/AUX XM
button. A variety of music types and
styles will play.
Driving on the north side of an
east/west mountain road.
Driving on the north side of a
large commercial truck on an
east/west road.
Driving in tunnels.
Driving on a road beside a vertical
wall, steep clif f , or hill to the south
of you.
Driving on the lower level of a
multi-tiered road.
Driving on a single lane road
alongside dense trees taller than
50 ft. (15 m) to the south of you.
There may be other geographic
situations that could af f ect satellite
radio reception.As required by the FCC: Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
www.xmradio.com
Playing the XMSatellite Radio (U.S. Models)
Receiving Satellite Radio Service To get your XM Satellite radio ID
number:Features
183
\f—\f—
y

y
(\fy\f
y
2008 TSX
