There may be other geographic
situations that could af f ect XM Radio
reception.After you’ve registered with XM
Radio, keep your audio system in the
XM Radio mode while you wait f or
activation. This should take about 30
minutes.
If your XM Radio service has expired
or you purchased your vehicle f rom
a previous owner, you can listen to a
sampling of the broadcasts available
on XM Radio. With the ignition
switch in the ACCESSORY (I) or the
ON (II) position, press the
button. A variety of music
types and styles will play.
If you decide to purchase XM radio
service, contact XM Radio at ,orat
1-800-852-9696. In Canada, contact
XM CANADA
at , or
at 1-877-209-0079. You will need to
give them your radio I.D. number
and your credit card number. To get
your radio I.D. number, press the button, then turn the
selector knob until ‘‘CH 000’’ appears
in the display. Your I.D. will appear
in the display. While waiting for activation, make
sure your vehicle remains in an open
area with good reception. Once your
audio system is activated,
‘‘CATEGORY’’ or ‘‘CHANNEL’’ will
appear in the display, and you’ll be
able to listen to XM radio broadcasts.
XM Radio will continue to send an
activation signal to your vehicle f or
at least 12 hours from the activation
request. If the service has not been
activated after 36 hours, contact
XM
Radio. In Canada, contact XM
CANADA
.
As required by the FCC:
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
www.xmradio.comwww.xmradio.ca
Playing the XMRadio (Models without navigation system)
Receiving XM Radio Service
188
2010 TSX

Playing a Disc (Models without navigation system)
Features
Canadian T SX wit h 4-cylinder engineWithout XMRadio A ll models except Canadian T SX wit h 4-cylinder engine
With XMRadio
189
MENU BUTTON
RETURN BUTTON
SCAN BUTTON
SELECTOR
KNOB
MP3/WMA INDICATOR
MENU BUTTON
RETURN BUTTON
SCAN BUTTON
SELECTOR
KNOB CD
BUTTON
PRESET
BUTTONS
SKIP BAR
TITLE
BUTTON
DISC SLOT MP3/WMA INDICATOR
VOL/
(VOLUME/POWER) KNOB
DISC EJECT
BUTTONDISC SLOT
TITLE
BUTTON
CATEGORY
BAR VOL/
(VOLUME/POWER) KNOB
CD
BUTTON
DISC EJECT
BUTTONPRESET
BUTTONS
SKIP BAR
FOLDER
BAR
2010 TSX

µ
µ
µ
µ
µ
µ
This audio system can also play
CD-Rs and CD-RWs compressed in
MP3 or WMA f ormat. When playing
a disc in MP3, you will see ‘‘MP3’’ in
the display. In WMA f ormat, ‘‘WMA’’
will appear in the display. The disc,
f older and track numbers are
displayed. You can select up to 255
folders or tracks.
To load or play a disc, the ignition
switch must be in the ACCESSORY
(I) or ON (II) position.
You operate the disc player with the
same controls used f or the radio. To
select the disc player, press the CD
button. You will see ‘‘CD’’ in the
display. The disc and track numbers,
andtheelapsedtimeareshownin
the display. You can also select the
displayed inf ormation with the
TITLE button (see page ). The
system will continuously play a disc
until you change modes. The specif ications f or compatible
MP3 f iles are:
A disc compressed in AAC f ormat
cannot be played in this audio
system.
Video CDs and DVDs do not work in
this unit. Sampling f requency:
32/44.1/48 kHz (MPEG1)
16/22.05/24 kHz (MPEG2)
Maximum layers
(including ROOT): 8 layers Bitrate:
32/40/48/56/64/80/96/112/128/
160/192/224/256/320 kbps
(MPEG1)
8/16/24/32/40/48/56/64/80/96/
112/128/160 kbps (MPEG2)
Compatible with variable bitrate
and multi-session
Compatible with variable bitrate
and multi-session Maximum layers
(including ROOT): 8 layers
The specif ications f or compatible
WMA f iles are: Sampling f requency:
22.05/32/44.1/48 kHz
Bitrate:
48/64/80/96/128/160/192 kbps
191
To Play a Disc
Playing a Disc (Models without navigation system)
190
Do not use discs with adhesive labels.
The label can curl up and cause the
disc to jam in the unit.
2010 TSX

Insert a disc about half way into the
disc slot. The drive will pull the disc
intherestof thewaytoplayit.You
operate the disc player with the
same controls used f or the radio.
The number of the current track is
showninthedisplay.Whenplayinga
disc in MP3 or WMA, the numbers
of the current f older and f ile are
shown. The system will continuously
play a disc until you change modes.
You cannot load and play 3-inch
(8-cm) discs in this unit.
For inf ormation on how to handle
and protect compact discs, see page. Each time you press the TITLE
button, the display shows you the
text, if the disc was recorded with
text data.
You can see the album, artist, and
track name in the display. If a disc is
recorded in MP3 or WMA, you can
see the f older and f ile name, and the
artist, album, and track tag.
When you press and release the
TITLE button while a disc without
text data is playing, you will see ‘‘NO
INFO’’ on the display. With the f older name, you will see
the FOLDER indicator in the display.
The TRACK indicator is shown with
the file or track name.
If a f ile on a WMA disc is protected
by digital rights management
(DRM), the audio unit displays
UNSUPPORTED, and then skips to
the next f ile.
256
CONT INUED
To Load a Disc Text Data Display Function
Playing a Disc (Models without navigation system)
Features
191
NOTE:
2010 TSX

The display shows up to 16
characters of selected text data (the
f older name, f ile name, etc.).You will also see some text data
under these conditions:
When a new f older, f ile, or track is
selected.
When you change the audio mode
to play a disc with text data or in
MP3 or WMA.
When you insert a disc, and the
system begins to play.
When playing a CD-DA with text
data, the album and track name are
showninthedisplay.Withadiscin
MP3 or WMA, the display shows the
f older and f ile name.
When you turn on the audio system
next time, the system keeps your
selection with the TITLE button. Use the SKIP bar while a disc is
playing to select passages and
change tracks (f iles in MP3 or WMA
mode).
If the text data has more than 16
characters, you will see the first 15
characters and the indicator on
the display. Press and hold the
TITLE button until the next 16
characters are shown. You can see
up to 31 characters of text data. In MP3 or WMA mode, use the
FOLDER bar (CATEGORY bar on
models with XM Radio) to select
f olders in the disc and use either
side of the skip bar to change files.
If youpressandholdtheTITLE
button again, the display shows the
f irst 15 characters again.
If any letter is not available, it is
replaced with ‘‘ . ’’ (dot) in the display.
When the disc has no text data, you
will see ‘‘NO INFO’’ on the display.T o Change or Select T racks/Files
Playing a Disc (Models without navigation system)
192
2010 TSX

µµ
ÛÝ
Û
Ý
Each time you press and
releasethe sideof theSKIPbar,
the player skips forward to the
beginning of the next track (f ile in
MP3 or WMA mode). Press and
releasethe sideof thebarto
skip backward to the beginning of
the current track. Press it again to
skip to the beginning of the previous
track.
To move rapidly within a track or f ile,
press and hold either side ( or )of theSKIPbar. To
select a dif f erent f older, press either
side ( or ) of the FOLDER bar
(CATEGORY bar on models with
XM Radio) to move to the beginning
of the next f older. Press the side
to skip to the next folder, and press
the side to skip to the beginning
of the previous f older.
In MP3 or WMA mode, you can also
select a f older or track/f ile f rom the
list by using the selector knob. Push
the selector knob (ENTER) to
switch the display to the list
displayed with three segments, then
turn the knob to select a f older.
Press the selector knob (ENTER) to
change the display to the track/file
list, then turn the same knob to
select a track/f ile. Press the selector
knob (ENTER) to set your selection.In MP3 or WMA mode
CONT INUED
SK IP FOLDER SELECTION
Playing a Disc (Models without navigation system)
Features
193
Press ENTER
Folder Selection
Track Selection
2010 TSX

You can select any type of repeat,
random and scan modes by using the
MENU button and the selector knob.
Push the MENU button to display
themenuitems,thenturnthe
selector knob to select ‘‘PLAY
MODE.’’ Press the selector knob
(ENTER) to set the selection.Turn the selector knob to select an
appropriate repeat, random or scan
mode, then press the selector knob
(ENTER) to set your selection.
To cancel the selected repeat,
random, or scan mode, press the
MENU button to show ‘‘PLAY
MODE,’’ then press the selector
knob (ENTER). When you see
‘‘NORMAL PLAY,’’ press ENTER
again.
Playing a Disc (Models without navigation system)
T o Select Repeat , Random or ScanMode:
194
MENU ITEMS
PLAY MODE ITEMS
2010 TSX

µµ
µ µ
Pressing either side of the SKIP bar
also turns of f the repeat f eature. To
continuously replay a track (f ile in
MP3 or WMA mode), select
REPEAT ONE TRK f rom the menu
items. You will see REPEAT in the
display. Select normal play to turn it
off. This feature
plays the tracks within a disc (the
f iles in MP3 or WMA mode) in
random order. To activate random
play, select RANDOM IN DISC f rom
the menu items. You will see
RANDOM in the display. Select
normal play to return to normal play.
This feature,
when activated, replays all the f iles
on the selected f older in the order
they are compressed in MP3 or
WMA. To activate folder repeat
mode, select REPEAT ONE FLD
from the menu items. You will see
F-REPEAT in the display. The
system continuously replays the
current f older. Select normal play to
turn it of f . Selecting a dif f erent
folder with the FOLDER bar
(CATEGORY bar on models with
XM Radio) also turns of f the repeat
feature. This feature,
when activated, plays the f iles within
the current f older in random order,
rather than in the order they are
compressedinMP3orWMA.To
activate folder random play, select
RANDOM IN FLD f rom the menu
items. You will see F-RANDOM in
the display. The system will then
select and play f iles randomly. This
continues until you deactivate f older
random play by selecting normal play,
or you select a dif f erent f older with
the FOLDER bar (CATEGORY bar
on models with XM Radio).
CONT INUED
In MP3 or WMA mode In MP3 or WMA mode
Playing a Disc (Models without navigation system)
REPEAT ONE TRK
RANDOM IN DISC
REPEAT ONE FLD RANDOM IN FLD
Features
195
2010 TSX

µµ
You can also select the scan feature
from the menu items with the
selector knob (see page ). The SCAN f unction
samples all the tracks on the disc in
the order they are recorded on the
disc (all f iles in the selected f older in
MP3 or WMA mode). To activate the
scan feature, press and release the
SCAN button. You will see SCAN in
the display. You will get a 10 second
sampling of each track/f ile in the
disc/f older. Press and hold the
SCAN button to get out of scan
mode and play the last track sampled. This f unction
samples the f irst f ile in each f older in
the order they are stored. To
activate the folder scan feature,
press and release the SCAN button
repeatedly. You will see F-SCAN in
the display. You will get a 10 second
sampling of the f irst f ile in each
folder.PressandholdtheSCAN
button to get out of the f older scan
mode and play the last f ile sampled.
You can also select the folder scan
f eature f rom the menu items with
the selector knob (see page ). Pressing either side of the
CATEGORY or SKIP bar also turns
of f the f eature.
Each time you press and release the
SCAN button, the mode changes
f rom f ile scan to f older scan, then to
normal play. Each time you press and release the
SCAN button, the mode changes
between scan and normal play.
194 194In MP3 or WMA mode
In MP3 or WMA mode
Playing a Disc (Models without navigation system)
SCAN T RKSCAN FL D
196
2010 TSX

Press the eject button ( ) to
remove the disc. If you eject the disc,
but do not remove it f rom the slot,
the system will automatically reload
the disc af ter 10 seconds and begin
playing.
You can also eject the disc when the
ignition switch is of f .
To play the radio when a disc is
playing,presstheAM,FMorXM(if
equipped) button. Press the AUX
button to switch to an appropriate
audio unit (if it is connected to the
auxiliary input jack or the USB
adapter cable). Press the CD button
again to switch back to the disc
player.For inf ormation on how to handle
and protect compact discs, see page
.
If you turn the system of f while a
disc is playing, either with the VOL/
knob or by turning of f the
ignition switch, the disc will stay in
the drive. When you turn the system
back on, the disc will begin playing
where it lef t of f . 256
To Stop Playing a Disc
Protecting Discs
Playing a Disc (Models without navigation system)
Features
197
2010 TSX
