These include:
❒Painting products and systems which
give the car particular resistance to
corrosion and abrasion;
❒Use of galvanised (or pretreated)
steel sheets, with high resistance to
corrosion;
❒Spraying of plastic parts, with a pro-
tective function, in the more exposed
points: underdoor, inner fender parts,
edges, etc.;
❒Use of “open” boxed sections to pre-
vent condensation and pockets of
moisture from triggering rust inside;
❒use of special anti-abrasion protective
tapes in the most exposed areas
(e.g.: rear mudguard, rear door,
etc.).
BODY AND UNDERBODY
WARRANTY
Your car is covered by warranty against
perforation due to rust of any original el-
ement of the structure or body. For the
general terms of this warranty, refer to
the Alfa Romeo Warranty booklet.
ADVICE FOR PRESERVING
THE BODYWORK
Paint
Paintwork does not only serve an
aestethic purpose, but also protects the
underlying sheet metal.
In the case of deep scrapes or scores,
you are advised to have the necessary
touching up carried out immediately to
avoid the formation of rust. Use only
original paint products for touching up
(see “Bodywork paint identification
plate” in section “Technical specifica-
tion”).
Normal paint maintenance consists in
washing at intervals depending on the
conditions and environment of use. For
example, in highly polluted areas, or if
the roads are sprayed with salt, it is wise
to wash the car more frequently.
BODYWORK
PROTECTION FROM
ATMOSPHERIC AGENTS
The main causes of corrosion are the fol-
lowing:
❒atmospheric pollution;
❒salty air and humidity (coastal areas,
or hot humid climates);
❒ seasonal environment conditions.
Not to be underestimated is also the
abrasive action of wind-borne atmos-
pheric dust and sand and mud and grav-
el raised by other cars.
On your car, Alfa Romeo implemented
the best manufacturing technologies to
effectively protect the bodywork against
corrosion.

Exterior plastic parts must be cleaned in
the same way as the rest of the car.
Where possible, do not park under trees;
the resinous substance many species re-
lease give the paint a dull appearance
and increase the possibility of triggering
rust processes.
IMPORTANTBird droppings must be
washed off immediately and thorough-
ly as the acid they contain is particular-
ly aggressive.
246
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
CAR
MAINTENANCE
Windows
Use specific window cleaner products. Use
also clean cloths to avoid scratching the
glass or damaging the transparency.
IMPORTANTThe inside of the
rearscreen should be wiped gently with
a cloth in the direction of the filaments
to avoid damaging the heating device.
Front headlights
Front headlights shall be washed with
soft cloth moistened with water and car
detergent.
IMPORTANT Cleaning headlight lens-
es with a dry cloth will damage the
headlights with lack of performance as
a consequence. Solvents mat the lens-
es with lack of performance as a con-
sequence.
IMPORTANT When washing the front
headlights with a water monitor noz-
zle keep at least 2 cm away from the
lenses. To wash the car correctly proceed as fol-
lows:
❒remove the aerial from the roof to
prevent damage to it if the car is
washed in an automatic system;
❒wash the body using a low pressure
jet of water;
❒wipe a sponge with a slightly soapy
solution over the bodywork, fre-
quently rinsing with the sponge;
❒rinse well with water and dry with a
jet of air or a chamois leather.
When drying, take particular care with
the less visible parts like door surrounds,
bonnet and around the headlights where
water may stagnate. The car should not
be taken to a closed area immediately,
but left in the open so that residual wa-
ter can evaporate.
Do not wash the car after it has been left
in the sun or with the bonnet hot: this
may alter the shine of the paintwork.
Detergents cause water
pollution. Therefore the
car should be washed
in areas equipped for collecting
and purifying the liquid used in
the washing process.

LEANING LEATHER SEATS
Remove dried on dirt with lightly moist-
ened chamois leather or cloth without
pressing too hard.
Remove liquid or grease stains with a dry
absorbent cloth without rubbing. Then
wipe with a soft cloth or chamois leather
with water and neutral soap.
If the stain persists, use specific prod-
ucts, carefully following the instructions
for use.
IMPORTANTNever use spirit or al-
cohol-based products.
247
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
CAR
MAINTENANCE
Engine compartment
At the end of the winter the engine com-
partment should be carefully washed,
without directing the jet against electronic
control units. Contact a specialised work-
shop to have this done.
IMPORTANT The car should be
washed with the engine cold and the key
removed from the ignition device. After
washing make sure that the various pro-
tections (e.g. rubber caps and various cov-
ers) have not been damaged or removed.INTERIORS
Periodically check that water is not
trapped under the mats (due to water
dripping off shoes, umbrellas, etc.)
which could cause oxidisation of the
sheet metal.
CLEANING SEATS AND
FABRIC AND VELVET PARTS
Use a soft brush or vacuum cleaner to
remove dust. Velvet is cleaned better if
the brush is moistened.
Rub the seats with a sponge moistened
with a solution of water and neutral de-
tergent.

Upholstery of your car
has been designed to
withstand wear deriv-
ing from common use of the car.
You are however recommended
to avoid strong and/or contin-
uous scratching with clothing
accessories such as metallic
buckles, studs, Velcro fasten-
ings and the like, since these
items cause circumscribed stress
of the cover fabric that could
lead to yarn breaking, and dam-
age the cover as a consequence.
248
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
CAR
MAINTENANCE
INTERIOR PLASTIC PARTS
Clean plastic parts with a cloth moist-
ened with water and non-abrasive neu-
tral detergent. To remove grease or hard
stains, use appropriate products de-
signed to preserve the appearance of
components.
IMPORTANTNever use spirit or pe-
troleum to clean the instrument panel
or other plastic parts.
Never use flammable
products like oil ether
or rectified petrol for cleaning
car interiors. Electrostatic dis-
charges generated by rubbing
during cleaning operations
could cause fire.
WARNING
Do not keep aerosol
cans in the car: they
might explode. Aerosol cans
must never be exposed to a
temperature above 50°C. The
temperature inside the car ex-
posed to the sun may go well
beyond that figure.
WARNING
STEERING WHEEL/
GEAR LEVER KNOB WITH
GENUINE LEATHER
COVERING
These components shall only be cleaned
with water and neutral soap. Never use
spirit or alcohol-based products.
Before using special products for clean-
ing interiors, read carefully label in-
structions and indications to make sure
they are free from spirit and/or alcohol-
based substances.
If when cleaning the windscreen with
special glass products, some drops fall
on the leather covering of the steering
wheel/gear lever knob remove them
immediately and then clean with wa-
ter and neutral soap.
IMPORTANTTake the utmost care
when engaging the steering lock to pre-
vent scratching the leather covering.

249
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
TECHNICALSPECIFICATIONS
T T
E E
C C
H H
N N
I I
C C
A A
L L
S S
P P
E E
C C
I I
F F
I I
C C
A A
T T
I I
O O
N N
S S
IDENTIFICATION DATA ......................................... 250
ENGINE CODES - BODYWORK VERSIONS ............... 252
ENGINE ............................................................ 253
FUEL FEED/IGNITION ........................................ 255
TRANSMISSION ................................................ 255
BRAKES ............................................................ 256
STEERING.......................................................... 256
SUSPENSIONS................................................... 256
WHEELS ........................................................... 257
DIMENSIONS..................................................... 261
PERFORMANCE .................................................. 263
WEIGHTS .......................................................... 264
CAPACITIES........................................................ 266
FLUIDS AND LUBRICANTS .................................... 267
FUEL CONSUMPTION .......................................... 269
CO
2EMISSIONS ............................................... 270

250
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
TECHNICALSPECIFICATIONS
IDENTIFICATION LABEL
This is to be found in the engine com-
partment, aside the upper right shock-
absorber connection and it bears the fol-
lowing identification data:
A.Space for details of national ho-
mologation
B.Space for punching the consecutive
chassis number
IDENTIFICATION
DATA
You are advised to note the identifica-
tion codes. The identification data
stamped and given on the plates and
their position are the following fig. 1:
1- Identification label
2- Body label
3- Bodywork paint identification label
4- Engine label.C.Space available for maximum
weights authorised by various national
regulations
D.Space for version and any supple-
mentary indications to those specified
E.Space for smoke coefficient (diesel
versions only)
F.Space for punching the Manufactur-
er’s name.
A0A0045mfig. 1A0E0013mfig. 2

BODYWORK PAINT
IDENTIFICATION LABEL
This is located in the inner side of the
tailgatefig. 4and it includes:
A.Paint manufacturer
B.Name of colour
C.Colour code.
D.Colour code for touching up and re-
spraying.
ENGINE MARKING
Engine marking is stamped on the gear-
box side, on the rear left side.
BODYWORK LABEL
This is located on the passenger com-
partment floor near the front passen-
ger’s seat.
It can be reached by raising cover A-
fig. 3and it includes:
❒type of vehicle (ZAR 939000);
❒Manufacturer’s serial number (chas-
sis number).
251
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
TECHNICALSPECIFICATIONS
A0A0222mfig. 4A0A0175mfig. 3

252
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
TECHNICALSPECIFICATIONS
ENGINE CODES - BODYWORK VERSIONS
Versions Engine code Body version
1.9 JTS939A6000 939AXA1B 00
939BXA1B ()
2.2 JTS939A5000 939AXB1B 03
939BXB1B ()
3.2 JTS 939A000 939AXG2B 09
939BXG2B ()
1.9 JTD
M8v939A1000 939AXE1B 04
939A7000 (*) 939AXH1B 06 (*)
939BXE1B (
)
939BXH1B ()(*)
1.9 JTD
M16v939A2000 939AXC1B 01
939A8000 (*) 939AXF1B 05 (*)
939BXC1B (
)
939BXF1B () (*)
2.4 JTD
M939A3000 939AXD1B 02
939BXD1B (
)
(*) For specific markets
(
) Sportwagon versions

253
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
TECHNICALSPECIFICATIONS
1.9 JTS
939A6000
Otto
4 in line
4
86 x 80
1859
118
160
6500
190
19.4
4500
NGKFR5CP
Unleaded petrol
95 RON
(Specification EN228)2.2 JTS
939A5000
Otto
4 in line
4
86 X 94.6
2198
136
185
6500
230
23.4
4500
NGKFR5CP
Unleaded petrol
95 RON
(Specification EN228)3.2 JTS
939A000
Otto
6 in 60° V
4
85.6 X 89
3195
191
260
6200
322
32.8
4500
BOSCH
HR7MPP152
Unleaded petrol
95 RON
(Specification EN228)
ENGINE
GENERAL
Engine code
Cycle
Number and layout of cylinders
Valves per cylinder
Piston bore and stroke mm
Total displacement cm3
Maximum power (EEC) kW
HP
corresponding ratio rpm
Maximum torque (EEC) Nm
kgm
corresponding ratio rpm
Spark plugs
Fuel

254
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
TECHNICALSPECIFICATIONS
1.9
JTD
M8v
939A1000
Diesel
4 in line
2
82 x 90.4
1910
88
120
4000
280
28.6
2000
–
Diesel fuel
for motor
vehicles
(Specification
EN590)1.9
JTDM16v
939A2000
Diesel
4 in line
4
82 x 90.4
1910
110
150
4000
320
32.6
2000
–
Diesel fuel
for motor
vehicles
(Specification
EN590)2.4 JTD
M
939A3000
Diesel
5 in line
4
82
X90.4
2387
147
200
4000
400
40.8
2000
–
Diesel fuel
for motor
vehicles
(Specification
EN590)
(*) For specific markets1.9
JTD
M8v (*)
939A7000
Diesel
4 in line
2
82 x 90,4
1910
85
115
4000
275
28
2000
–
Diesel fuel
for motor
vehicles
(Specification
EN590)1.9
JTDM16v (*)
939A8000
Diesel
4 in line
4
82 x 90,4
1910
100
136
4000
305
31
2000
–
Diesel fuel
for motor
vehicles
(Specification
EN590)
GENERAL
Engine code
Cycle
Number and layout of cylinders
Valves per cylinder
Piston bore and stroke mm
Total displacement cm3
Maximum power (EEC) kW
HP
corresponding ratio rpm
Maximum torque (EEC) Nm
kgm
corresponding ratio rpm
Spark plugs
Fuel
