USERS FUSE AMPERE FIGURE
Front cigar lighter on central console F44 10 56
Sunroof control unit (curtain) F45 20 56
Sunroof F46 20 56
Left front power window F47 20 56
Right front power window/
passenger’s door control unit F48 30 56
Radionavigation system F49 7.5 56
Rain sensor control unit F49 7.5 56
Steering wheel branch point F49 7.5 56
Sunroof F49 7.5 56
Control buttons panel F49 7.5 56
Volumetric alarm control unit F49 7.5 56
Parking sensor branch point F49 7.5 56
Central console button panel F49 7.5 56
Front seat controls light F49 7.5 56
Windscreen services F49 7.5 56
Mobile phone presetting F39 10 56
START/STOP button F49 7.5 56
Air Bag system F50 7.5 56
Tyer pressure monitoring system control unit F51 7.5 56

218
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
IN AN
EMERGENCY
USERS FUSE AMPERE FIGURE
Sound system presetting F51 7.5 56
Rear window washer/wiper F52 15 56
Rear cigar lighter F52 15 56
Instrument panel branch point F53 10 56
Sound system amplifier with DSP F54 30 62
Front left seat movement control F56 25 62
Driver’s seat warming left F57 7.5 62
Front right seat movement control F60 25 62
Amplifier on rear parcel shelf F61 15 62
Front passenger’ seat warming right F67 7.5 62
Free F58 --- 62
Free F58 --- 62
Free F58 --- 62
Free F58 --- 62
Free F58 --- 62
Free F58 --- 62
Free F58 --- 62
Free F58 --- 62
Free F58 --- 62
Free F58 --- 62
Free F58 --- 62
Free F80 --- 62

228
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
CAR
MAINTENANCE
CHECKING
FLUID LEVELS
For refilling amounts refer to Technical
Specifications section.
1.Engine oil - 2.Battery
3.Brake fluid - 4.Windscreen washer
fluid - 5.Engine coolant -
6.Power steering fluid
fig. 1 - 1.9 JTS - 2.2 JTS versionsA0E0161m
fig. 2 - 3.2 JTS versionA0E0038m
Never smoke while
working in the engine
compartment; gas and inflam-
mable vapours may be pre-
sent, with the risk of fire.
WARNING
When topping up take
care not to confuse the
various types of fluids:
they are all incompatible with
one another and could serious-
ly damage the car.

A A
L L
F F
A A
1 1
5 5
9 9
S S
P P
O O
R R
T T
W W
A A
G G
O O
N N
REARSCREEN WIPER .......................................... 272
