Page 169 of 280
Roof rack/ski rack
Remove the roof rack or the ski rack
from the roof after use. These
accessories lower aerodynamic
penetration and adversely affect
consumption levels. When transporting
particularly large objects, use a trailer
if possible.
Electrical devices
Use the electrical devices only for the
necessary amount of time. The heated
rear window, additional headlights,
screen wipers and heater fan require a
considerable amount of energy;
increasing the current uptake increases
fuel consumption (by up to +25% in
an urban cycle).
Climate control system
Using the climate control system will
increase consumption: use the air vents
when the temperature outside permits.
Devices for
aerodynamic control
The use of non-certified devices for
aerodynamic control may adversely
affect air drag and fuel consumption.DRIVING STYLE
Starting
Do not warm up the engine at low or
high revs when the car is stationary;
this causes the engine to warm up
more slowly, thereby increasing fuel
consumption and emissions. It is
therefore advisable to move off
immediately, slowly, avoiding high
speeds: in this way the engine will
warm up more quickly.
Unnecessary actions
Avoid accelerating when stopped at
traffic lights or before switching off the
engine. The latter action, as well as
double-declutching, is unnecessary and
causes increased fuel consumption
and pollution.
Gear selection
Use a high gear when traffic and road
conditions allow it. Using a low gear for
faster acceleration will increase fuel
consumption. In the same way
improper use of a high gear increases
consumption, emissions and engine
wear.Maximum speed
Fuel consumption considerably
increases as speed increases. Maintain
a constant speed, avoiding
unnecessary braking and acceleration,
which cost in terms of both fuel
consumption and emissions.
Acceleration
Accelerating violently severely affects
consumption and emissions:
acceleration should be gradual and
should not exceed the maximum
torque.
165
Page 206 of 280
Thousands of miles 18 36 54 72 90 108
Thousands of kilometres 30 60 90 120 150 180
Months24 48 72 96 120 144Visually inspect conditions of the accessory drive belt(s)●●
Check exhaust emissions.●●●●●●
Check battery charge status and possibly recharge●●●●●●
Check engine management system operation (through the diagnosis socket)●●●●●●
Check and, if necessary, top up the electro-hydraulic actuator oil level
(versions with Alfa TCT)●
Replace accessory drive belt(s)●
Replacement of toothed timing belt (*)●
Replace spark plugs (**)●●●●●●
Replace air cleaner cartridge●●●
Change engine oil and oil filter (or every 24 months) (***)●●●●●●
Change brake fluid(****)●●●
Replace pollen filter(*****)●●●●●●(*) Regardless of the distance covered, the timing belt must be changed every 4 years for particularly demanding use (cold climates, town driving, long periods of
idling) or at least every 5 years.
(**) For 1.4 Turbo Petrol and 1.4 Turbo MultiAir versions, in order to guarantee correct operation and prevent serious damage to the engine, it is essential to observe
the following: only use spark plugs specifically certified for these engines; all spark plugs should be of the same type and brand (see the “Engine” paragraph in
the "Technical Specifications" section); strictly comply with the replacement intervals in the Scheduled Servicing Plan; you are advised to contact an Alfa Romeo
Dealership to have plugs replaced.
(***) If the vehicle has an annual mileage of less than 10,000 km, the engine oil and engine oil filter should be changed every 12 months.
(****) The brake fluid must be changed every 24 months.
(*****) The pollen filter must be replaced every 12 months.
202
SERVICING AND MAINTENANCE
Page 208 of 280
Thousands of miles 21 42 63 84 105
Thousands of kilometres 35 70 105 140 175
Months24 48 72 96 120Check exhaust emissions.●●●●●
Check battery charge status and possibly recharge●●●●●
Check engine management system operation (through the diagnosis socket)●●●●●
Replace accessory drive belt(s)●
Replacement of toothed timing belt (*)●
Replace spark plugs●●
Replace air cleaner cartridge●●
Change engine oil and replace oil filter (**)
Change brake fluid(***)●●
Replace pollen filter(****)●●●●●(*) Regardless of the distance covered, the timing belt must be changed every 4 years for particularly demanding use (cold climates, town driving, long periods of
idling) or at least every 5 years.
(**) The actual interval for changing the oil and replacing the engine oil filter depends on the car usage conditions, it is signalled by the warning light or message (for
versions/markets, where provided) in the instrument panel and must never exceed 12 months.
(***) The brake fluid must be changed every 24 months.
(****) The pollen filter must be replaced every 12 months.
204
SERVICING AND MAINTENANCE
Page 210 of 280
Thousands of miles 21 42 63 84 105
Thousands of kilometres 35 70 105 140 175
Months24 48 72 96 120Check engine management system operation (through the diagnosis socket)●●●●●
Check battery charge status and possibly recharge●●●●●
Check and, if necessary, top up the electro-hydraulic actuator oil level for Alfa TCT
(for versions/markets, where provided)●
Replace accessory drive belts●
Replacement of toothed timing belt (*)●
Replace fuel filter●●
Replace air cleaner cartridge●●
Replace engine oil and oil filter (or every 24 months) (**) (***)
Change brake fluid(****)●●
Replace pollen filter(*****)●●●●●(*) Regardless of the distance covered, the timing belt must be changed every 4 years for particularly demanding use (cold climates, town driving, long periods of
idling) or at least every 5 years.
(**) The actual interval for changing the oil and replacing the engine oil filter depends on the car usage conditions, it is signalled by the warning light or message (if
present) in the instrument panel and must never exceed 24 months.
(***) If the car is mainly used in towns and cities, change the engine oil and filter every 12 months.
(****) The brake fluid must be changed every 24 months.
(*****) The pollen filter must be replaced every 12 months.
206
SERVICING AND MAINTENANCE
Page 248 of 280
REFUELLING
1.4 Turbo Petrol 1.4 Turbo MultiAir
Recommended fuels
and original lubricants
litres kg litres kg
Fuel tank 60 – 60 –Unleaded petrol not less
than 95 RON (EN 228
specification) including a reserve of 8 - 10 – 8 - 10 –
Engine cooling system (with
climate control)5,7 5,0 5,7 5,050-50 mixture of
demineralised water and
PARAFLU
UP
(*)
Engine sump 2,75 2,3 3,1 2,6SELENIA K P.E. (1.4 Turbo
Petrol versions)
SELENIA DIGITECH P.E.
(1.4 Turbo MultiAir
versions) Engine sump and filter 3,1 2,6 3,5 2,9
Gearbox casing/differential 1,87 1,6 1,87 1,6TUTELA TRANSMISSION
GEARFORCE
Hydraulic brake circuit with
ABS antilock brakes0,83 0,78 0,83 0,78 TUTELA TOP 4
Windscreen/rear window/
headlight washer fluid
reservoir (**)2,8 (4,6) 2,5 (4,1) 2,8 (4,6) 2,5 (4,1)Mixture of water and
TUTELA PROFESSIONAL
SC 35
(*) For particularly harsh climate conditions, a mixture of 60%
UPand 40% demineralised water is recommended.
(**) Values in brackets refer to versions with headlight washers
244
TECHNICAL SPECIFICATIONS
Page 249 of 280
1750 Turbo Petrol
Prescribed fuels and original
lubricants
litres kg
Fuel tank 60 –
Unleaded petrol not less than 95
RON (EN 228 specification)
including a reserve of 8 - 10 –
Engine cooling system (with climate
control)6,4 5,7Mixture of 50% demineralised water
and 50% PARAFLU
UP
(*)
Engine sump 5,0 4,25
SELENIA SPORT POWER
Engine sump and filter 5,1 4,35
Automatic transmission housing 1,87 1,6TUTELA TRANSMISSION
GEARFORCE
Hydraulic brake circuit with ABS (Anti-
lock braking system)0,83 0,78 TUTELA TOP 4
Windscreen/rear window/headlight
washer fluid reservoir (**)2,8 (4,6) 2,5 (4,1)Mixture of water and TUTELA
PROFESSIONAL SC 35
(*) For particularly harsh climate conditions, a mixture of 60%
UPand 40% demineralised water is recommended.
(**) Values in brackets refer to versions with headlight washers
245
Page 250 of 280
1.6 JTD
M
2.0 JTD
M
Recommended fuels
and original lubricants
litres kg litres kg
Fuel tank 60 – 60 –Diesel for automotive
engines (EN 590
Specification) including a reserve of 8 - 10 – 8 - 10 –
Engine cooling system (with
climate control)6,8 6,0 6,7 5,950-50 mixture of
demineralised water and
PARAFLU
UP
(**)
Engine sump 4,0 3,4 4,0 3,4
SELENIA WR FORWARD
Engine sump and filter 4,2 3,5 4,2 3,5
Gearbox casing/differential 1,87 1,6 1,87 1,6TUTELA TRANSMISSION
GEARFORCE
Hydraulic brake circuit with
ABS antilock brakes0,83 0,78 0,83 0,78 TUTELA TOP 4
Windscreen/rear window/
headlight washer fluid
reservoir (*)2,8 (4,6) 2,5 (4,1) 2,8 (4,6) 2,5 (4,1)Mixture of water and
TUTELA PROFESSIONAL
SC 35
(**) For particularly harsh climate conditions, a mixture of 60%
UPand 40% demineralised water is recommended.
(*) Values in brackets refer to versions with headlight washers
246
TECHNICAL SPECIFICATIONS
Page 255 of 280
FUEL CONSUMPTIONThe fuel consumption figures given in the tables below are determined on the basis of the type-approval tests laid down by
specific European Directives.
The procedures below are followed for measuring consumption:
❒urban cycle: cold starting followed by driving that simulates urban use of the car;
❒extra-urban cycle: frequent accelerating in all gears, simulating extra-urban use of the car: speed varies between 0 and 120
km/h;
❒combined fuel consumption: calculated with a weighting of approximately 37% of the urban cycle and 63% of the extra-
urban cycle.
IMPORTANT The type of route, traffic conditions, weather conditions, driving style, general condition of the car, trim level/
equipment/accessories, use of the climate control, car load, presence of roof racks and other situations that adversely affect
the aerodynamics or wind resistance lead to different fuel consumption figures than those measured.
FUEL CONSUMPTION ACCORDING TO THE CURRENT EUROPEAN DIRECTIVE (litres/100 km)Versions Urban Extra-urban Combined1.4 Turbo Petrol8,3 5,3 6,4
1.4 Turbo MultiAir7,6 4,6 5,7
1750 Turbo Petrol10,8 5,8 7,6
1.6 JTD
M105 HP5,0 3,4 4,0
2.0 JTDM136/150 HP5,0 3,7 4,2
251
Page 259 of 280
DASHBOARDThe presence and position of controls, instruments and gauges may vary according to different versions.
1. Adjustable air vent 2. Passenger front air bag 3. Control buttons 4. Windscreen wiper/rearscreen wiper/trip computer control lever 5. Instrument
panel 6. Exterior lighting control lever 7. Driver front air bag 8. Cruise Control (for versions/markets, where provided) 9. Uconnect Radio/Uconnect
Radio Nav (for versions/markets, where provided) 10. Heating/ventilation/climate control system controls 11. Glove compartment
1
A0K0730
255
RIGHT HAND DRIVE VERSIONS
Page 274 of 280
INDEX
ABS .............................................. 65
Additional heater ............................ 35
AFS adaptive lights (Adaptive
Frontlight System) ........................ 38
Air cleaner ...................................... 213
Alarm ............................................. 14“Alfa DNA” system ........................ 69
– Driving modes ........................... 70
– Engagement/disengagement
of "All Weather" mode ............... 72
– Engagement/disengagement
of "Dynamic" mode ................... 71
– "Natural" Mode.......................... 70Alfa Romeo Code system ............. 10
ALFA TCT ...................................... 157
Ashtray .......................................... 50
ASR system (Anti-Slip
Regulation) ................................... 66
Automatic dual zone climate
control ......................................... 28Battery .......................................... 214
– advice for extending lifetime ...... 214
– replacement .............................. 214
Battery (recharging) ........................ 196
Bodywork
– maintenance ............................. 218
– protection against
atmospheric agents................... 218
– warranty .................................... 218Bonnet ........................................... 62
– Closing ...................................... 62
– Opening .................................... 62
Brakes ........................................... 233
– brake fluid level.......................... 212
bulb replacement ........................... 184
Bulb replacement
– exterior lights ............................. 183
– interior lights .............................. 186
Bulbs
– types of bulbs ........................... 181
Carrying children safely ................. 139
CBC (Cornering Brake Control)
system ......................................... 66
Central locking ............................... 46
Changing a bulb............................. 179
– General instructions................... 179
Changing a wheel .......................... 171
Checking levels .............................. 208
Cigar lighter.................................... 50
Cleaning and maintenance
– bodywork .................................. 218
– car interior ................................. 220
– front headlights ......................... 219
– leather parts .............................. 221
– leather seats.............................. 220
– plastic and coated parts ............ 221
– seats and fabric parts ................ 220
Climate control ............................... 22– Central air diffusers.................... 22
– Rear air diffuser ......................... 22
– Side air diffusers ........................ 22
– Upper air diffusers ..................... 22
Climatic comfort ............................. 23
– Diffusers .................................... 23
Clutch ............................................ 232
CO2 emissions............................... 252
CODE Card .................................... 11
Control buttons .............................. 91
Control panel and instruments ....... 100
– Multifunction display .................. 100
– Reconfigurable multifunction
display....................................... 101
Controls ......................................... 45
Courtesy light
– bulb replacement ...................... 187
Cruise Control ................................ 41
Daytime running lights (DRL) ......... 36
Diesel filter ..................................... 213
Dimensions .................................... 240
Dipped beam headlights
– bulb replacement ...................... 183
Direction indicators ................... 37-184
– bulb replacement ...................... 184
– “Lane change” function ............. 37
Display ........................................... 90
Doors ............................................. 54
– Child safety device .................... 55
