Page 69 of 280
ESC SYSTEM
IN BRIEF
The ESC system improves the
directional control and stability of the
car in various driving conditions.
The ESC system corrects the car’s
understeer and oversteer, distributing
the brake force on the appropriate
wheels. The torque supplied by
the engine can also be reduced in
order to maintain control of the car.
30) 31) 32) 33) 34)
The ESC system uses sensors installed
on the car to determine the trajectory
that the driver intends to follow and
compares it with the car’s effective
trajectory. When the real trajectory
deviates from the desired trajectory, the
ESC system intervenes to counter the
car’s understeer or oversteer.
❒Oversteer: occurs when the car is
turning more than it should according
to the angle of the steering wheel.
❒Understeer: occurs when the car is
turning less than it should according
to the angle of the steering wheel.The ESC system also includes the
following systems:
❒EBD
❒ABS
❒CBC
❒ASR
❒HILL HOLDER
❒HBA
❒MSR
❒DST
❒“ELECTRONIC Q2” (“E-Q2”)
❒"PRE-FILL" (RAB - Ready Alert
Brake)
SYSTEM ACTIVATION
The ESC system switches on
automatically when the engine is
started and cannot be switched off.
SYSTEM INTERVENTION
This is indicated by the flashing of the
warning light on the instrument
panel, to inform the driver that the car is
in critical stability and grip conditions.EBD SYSTEM
The EBD system is an integral part of
the ESC system and intervenes during
braking, distributing the brake force
optimally between front and rear
wheels.
This guarantees greater braking stability
for the car, preventing sudden locking
of the rear wheels and the consequent
instability of the car.
ABS
This system, which is an integral part of
the braking system, prevents one or
more wheels from locking and slipping
in all road surface conditions,
irrespective of the intensity of the
braking action, ensuring that the car
can be controlled even during
emergency braking and optimising
stopping distances.
The system intervenes when braking
and the wheels are about to lock,
typically in emergency braking or
low-grip conditions, when locking may
be more frequent.
The system also improves control and
stability of the car when braking on a
surface where the grip of the left and
right wheels varies, or on corners.
65
Page 88 of 280
IMPORTANT The volume of the
acoustic signal can be adjusted through
the option "Warning volume" of the
Setup menu (see paragraph “Menu
Items” in the “Knowing the instrument
panel” section).
OPERATION WITH
TRAILER
Parking sensor operation is deactivated
automatically when the trailer electric
cable plug is fitted into the car tow
hook socket.
11)
The sensors are automatically
reactivated when the trailer's cable plug
is removed.
59) 60)
GENERAL WARNINGS
During parking manoeuvres, pay the
utmost attention to any obstacles that
could be located above or below the
sensors.
Objects located near the rear of the car
are not detected under certain
circumstances and could therefore
cause damage to the car or be
damaged.
The following conditions may influence
the performance of the parking sensor
system:❒reduced sensor sensitivity and a
reduction in the parking assistance
system performance could be due to
the presence on the surface of the
sensor of: ice, snow, mud, thick paint
❒the sensors may detect a non-
existent obstacle (echo interference)
due to mechanical interference, for
example when washing the car,
in rain (strong wind), hail;
❒The signals sent by the sensors can
also be altered by the presence of
ultrasonic systems (e.g. pneumatic
brake systems or pneumatic drills)
near the vehicle.
❒sensor performance can also be
influenced by the position of the
sensors. For example by a change in
the ride setting (caused by the wear
of the shock absorbers, suspension),
overloading the vehicle and carrying
out specific tuning operations that
require the vehicle to be lowered;
❒The detection of obstacles at the top
part of the car may not be
guaranteed because the system
detects obstacles that could cause
an impact with the car in the bottom
part.
IMPORTANT
11) The sensors must be clean of
mud, dirt, snow and ice in order
for the system to work. Be careful
not to scratch or damage the
sensors while cleaning them.
Avoid using dry, rough or hard
cloths. The sensors must be
washed using clean water, with
the addition of car shampoo if
necessary. When using special
washing equipment such as high
pressure jets or steam cleaning,
clean the sensors very quickly
keeping the jet more than 10 cm
away.
WARNING
59) Only have the bumpers repainted
or any retouches to the paintwork
in the area of the sensors carried
out by an Alfa Romeo Dealership.
Incorrect paint application could
affect the operation of the parking
sensors.
84
GETTING TO KNOW YOUR CAR
Page 93 of 280
KNOWING THE INSTRUMENT PANEL
This section of the booklet gives you all
the information you need to
understand, interpret and use the
instrument panel correctly.DISPLAY ......................................... 90
MENU ITEMS .................................. 93
CONTROL PANEL AND
INSTRUMENTS ...............................100
TRIP COMPUTER ...........................102
WARNING LIGHTS AND
MESSAGES ...................................10
- LOW BRAKE FLUID/HANDBRAKE
ENGAGED .......................................... 106
- EBD FAILURE .................................. 107
- AIRBAG FAILURE ............................. 107
- SEAT BELTS NOT FASTENED .......... 107
- ALTERNATOR FAILURE ................... 108
- LOW ENGINE OIL PRESSURE ......... 1
-ENGINE OIL DETERIORATED ........... 110
- ENGINE COOLANT TEMPERATURE
TOO HIGH .......................................... 112
- ALFA TCT FAILURE .......................... 113
-INCOMPLETE DOOR LOCKING ........ 113
-SPEED LIMIT EXCEEDED ................. 113
- DUAL PINION ACTIVE STEERING
FAILURE ............................................. 114
- ALFA ROMEO CODE SYSTEM
FAILURE/ALARM FAILURE ................. 114
- FUEL RESERVE/LIMITED RANGE .... 115
- GENERAL FAILURE ......................... 116
- GENERAL FAILURE ......................... 117
-REAR FOG LIGHTS ........................... 11
- ABS FAILURE ................................... 119
-BRAKE PAD WEAR ........................... 119
- PASSENGER SIDE AIRBAG
DEACTIVATED .................................... 119
- INJECTION/EOBD SYSTEM
FAILURE ............................................. 120
- GLOW PLUG HEATING/GLOW
PLUG HEATING FAILURE (diesel
versions) ............................................. 121-WATER IN DIESEL FILTER (diesel
versions) ............................................. 121
- DPF CLEANING (particulate trap) in
progress (diesel versions with DPF
only) ................................................... 123
- iTPMS SYSTEM ............................... 125
- ELECTRONIC STABILITY CONTROL
(ESC) SYSTEM ................................... 126
- CRUISE CONTROL .......................... 127
- SIDE LIGHTS ................................... 127
- FOLLOW ME HOME ........................ 12
- DIPPED BEAM HEADLIGHTS .......... 127
- FOG LIGHTS .................................... 128
- LEFT-HAND DIRECTION
......................................... 128
- RIGHT-HAND DIRECTION
INDICATOR ........................................ 128
- MAIN BEAM HEADLIGHTS .............. 128
- FUEL CUT-OFF ................................ 12
- POSSIBLE ICE ON ROAD ................ 129
- BRAKE LIGHT FAILURE ................... 129
- DUSK SENSOR FAILURE ................. 129
- RAIN SENSOR FAILURE .................. 130
- PARKING SENSOR FAILURE ........... 130
-START&STOP SYSTEM
ACTIVATION/DEACTIVATION .............. 131
-START&STOP FAILURE .................... 131
- DISPLAY OF SELECTED DRIVING
MODE (“Alfa DNA” system) ................. 13
89
INDICATOR
687
2 9 09
Page 133 of 280
SYMBOLS AND MESSAGES ON THE DISPLAY
Symbol on the
displayWhat it means What to do
FUEL CUT-OFF
On some versions the display will show a
message + symbol if the fuel cut-off intervenes.For the fuel cut-off system reactivation procedure,
refer to the "Fuel Cut-Off System" section of the
"Controls" paragraph, in the "Knowing your car"
chapter. If it is still not possible to restore the fuel
supply, contact an Alfa Romeo Dealership.POSSIBLE ICE ON ROAD
On versions equipped with "Reconfigurable
multifunction display", a message and a symbol
will appear when the outdoor temperature falls to
or below 3°C.
On versions with “Multifunction display” only the
dedicated message is shown.
IMPORTANT In the event of outside temperature
sensor failure, the digits that indicate the value are
replaced by dashes.BRAKE LIGHT FAILURE
On some versions the display will show a
message + symbol if there is a fault in the brake
lights.The fault may be caused by a blown bulb, a
blown protection fuse or an interruption of the
electrical connection.DUSK SENSOR FAILURE
(for versions/markets, where provided)
On some versions the display will show a
message + symbol if there is a fault in the dusk
sensor.Go to an Alfa Romeo Dealership to have the fault
fixed as soon as possible.
129
Page 275 of 280
– Door central
locking/unlocking ...................... 54
DPF (particulate filter) ..................... 87
DST system (Dynamic Steering
Torque)......................................... 67
Dual Pinion active steering ............. 79
Dusk sensor ................................... 36EBD system .................................. 65
Electric sun roof ............................. 52
Electric windows ............................ 56
– Controls .................................... 57"Electronic Q2" system ("E-Q2") .... 68Engine codes - bodywork
versions ....................................... 225
Engine compartment
– washing .................................... 219
Engine coolant temperature
indicator ....................................... 102
Engine............................................ 227
– engine cooling system fluid
level........................................... 212
– marking ..................................... 224
Engine oil
– consumption ............................. 211
– level check ................................ 211
EOBD system ................................ 79
ESC (Electronic Stability Control)
system ......................................... 65
External courtesy lights .................. 38
External lights................................. 35Extinguisher ................................... 51
Filling the tank ............................... 86
Fitting "Universal" child seat ........... 140
Fix&Go Automatic kit...................... 176
Flashing ......................................... 37
Fluids and lubricants ...................... 247
Fog lights ................................. 45-184"Follow Me Home" device ............. 38Front airbags................................. 146
Front armrest ................................. 48
Front driver side airbag................... 146
Front passenger airbag .................. 146
Front roof light
– bulb replacement ...................... 186
Fuel consumption .......................... 251
Fuel cut-off system......................... 46
Fuel level gauge ............................. 102
Fuel supply..................................... 231
Fuel tank cap ................................. 86
Fuses (if a fuse blows) .................... 187Gear Shift Indicator ....................... 91
Glove compartment courtesy
light
– bulb replacement ...................... 187Handbrake.................................... 156
Hazard warning lights..................... 45
HBA system ................................... 67
Headlights...................................... 64– Adjusting headlights abroad ...... 64
– bulb replacement ...................... 183
– Headlight alignment corrector.... 64
– Light beam direction.................. 64
Headlight washers ......................... 217
Head restraints............................... 18
– "Anti-Whiplash" device .............. 19
– Front headrests ......................... 18
– Rear head restraints .................. 19
Hill Holder system .......................... 66
Identification data
– bodywork paint plate ................. 224
– Chassis marking........................ 224
– engine marking.......................... 224
– identification data plate.............. 224
Ignition device ................................ 15
– Steering lock ............................. 16
Installing a Universal Isofix child
seat.............................................. 143
Installing electrical/electronic
devices ........................................ 81
Interior fittings ................................ 47
Interiors (cleaning) .......................... 220
iTPMS system ................................ 77Jack.............................................. 171Light clusters
– front light clusters (changing a
bulb).......................................... 183
INDEX
Page 276 of 280
– rear light clusters (changing a
bulb).......................................... 184
Luggage compartment courtesy
light
– bulb replacement ...................... 186
Luggage compartment................... 59
– Bag hooks................................. 62
– Closing the luggage
compartment ............................ 60
– Emergency luggage
compartment opening ............... 59
– Extending the luggage
compartment ............................ 60
– Luggage compartment
initialisation ................................ 60
– Luggage retaining net ................ 62
– Opening the luggage
compartment ............................ 59
– Securing your load .................... 61M
ain beam headlights .................. 37
– bulb replacement ...................... 183
Maintenance and care
– heavy-duty use of the car .......... 207
– periodic checks ......................... 207
– scheduled servicing ................... 200
– scheduled servicing plan ........... 201
Manual climate control ................... 24
Menu options ................................. 93
Money holder ................................. 50
MSR system .................................. 67
Multifunction display....................... 90
Number plate lights
– bulb replacement ...................... 185Parking ......................................... 155
– Handbrake ................................ 156
Parking lights ................................. 36
Parking sensors ............................. 82
Performance .................................. 241
Pollen filter ..................................... 213
Power sockets ............................... 49
Pre-Fill system (RAB - Ready
Alert Brake) .................................. 68
Preparation for "Isofix" child seat .... 143
Pretensioners ................................. 137
– Load limiters.............................. 137
Protecting the environment ............ 87Radio transmitters and mobile
phones ........................................ 81
Rain sensor .................................... 39
Raising the car ............................... 197
Rear armrest .................................. 48
Rear fog lights ................................ 45
Rear fog lights/reversing lights........ 184
Rear roof light
– bulb replacement ...................... 186
Rear view mirrors ........................... 20
– Door mirrors .............................. 21
– Internal mirror ............................ 20
Rear window washer jets ............... 217
Rear window washer– rear window washer fluid level ... 212
Rear window washer/wiper ............ 40
Rear window wiper
– blade replacement..................... 217
Reconfigurable multifunction
display ......................................... 90
Refuelling ....................................... 244
Refuelling the car ........................ 85-86
Rev counter ................................... 102
Rim Protector (tyres)....................... 237
Roof lights...................................... 42
– Courtesy lights .......................... 44
– Front roof light ........................... 42
– Glove compartment light ........... 44
– Luggage compartment roof
light ........................................... 44
– Rear roof light............................ 43
Roof rack/ski rack .......................... 63
Saving fuel .................................... 164
SBR system (Seat Belt
Reminder) .................................... 135
Scheduled Servicing Plan ............... 201
Seat belts....................................... 134
– Use ........................................... 134
Seats ............................................. 16
– Front seats ................................ 16
Setup menu ................................... 92
Side airbags (Side Bags -
Window Bags).............................. 150
Side bags (front side airbags) ......... 150
