NAME (directory) 102
– Search and select the entry that is to be changed
page 101, fig.105 and make your changes.Selecting a text field automatically activates a speller which allows
letters and numerals to be entered.Viewing entriesFig. 106 Directory: Show list– Press the function button page 16 if another
menu is currently being displayed.
– Select Show list page 101, fig.104. All entries for the
directory are listed.
You can select individual entries from this list to recall or to change
the stored data (e.g. navigation destination)
page 101.
Deleting individual directory entriesFig. 107 Directory: deleting an individual entry– Press the function button page 16 if another
menu is currently being displayed.
– Select Find entry or Show list page 99, fig.101.
– Select the entry to be deleted from the directory
page 101, fig.105.
– Select Delete this entry.
NAME
NAME
Page 108 of 194
NAME (directory)103
General operation
RADIO, CD
NAME, TEL
NAV, INFO
CAR, SETUP
–Confirm Are you sure you want to delete this entry? w ith
Ye s. The selected directory entry is deleted.Deleting all directory entriesFig. 108 Directory: Delete directory– Press the function button page 16 if another
menu is currently being displayed.
–Select Delete directory fig.108.
–Confirm Are you sure you want to delete all entries from
the directory? with Ye s. All directories entries are
deleted.
Setting directory navigation destinationFig. 109 Directory: Select category
Fig. 110 Directory: Enter navigation destination for an entry
NAME
Page 109 of 194
NAME (directory) 104
– Press the function button page 16.
– Select an existing entry page 101 o r c r e a t e a n e w e n t r y
page 100.
– Select as required Category private or business
page 103, fig.109.
– Select Navigation destination page 103, fig.110.
– Enter the data for the navigation destination, or
– Select Copy from current position or Get from previous
dest. to import the destination data from one of the
previous navigation destinations.
– Select as required Display as top destination to display
the navigation destination in a destination entry menu
page 133.You can store two navigation destinations for one directory entry,
one destination for the business category and one destination for
the personal category.
If the Display as top destination function shows a check mark
after it, this function is active. These navigation destinations are
shown in the main navigation menu
page 133 under the menu
item Start route guidance.
When you have entered the navigation destination and you press
t h e b u t t o n , y o u a r e r e t u r n e d t o t h e d i r e c t o r y c a r d a n d c a n
enter additional data if you wish.
Through the directory (Name), you can call up all entries, without
and with stored navigation destination. You can open the directory
entries with navigation destination in the navigation menu via the control button with the Memory function and by selecting the Load
from directory
page 136 function.
Tips
If you have not inserted a navigation DVD into the Navigation DVD
drive
page 35, you cannot use the Navigation and Directory
functions.
NAME
RETURN
Page 113 of 194
Navigation (NAV) 108Navigation (NAV)General safety precautionsThe driver is completely responsible for traffic safety
even when driving with the Navigation System active.Fig. 111 Display: WarningWhen you set your vehicle in motion and you press the
button, a warning message is shown in the display.
Lesen Sie die Warnmeldung aufmerksam und beachten Sie
die wichtigen Hinweise.
– Select Accept by pressing the control knob when you
have finished reading the warning message.
Be sure that you always have complete control of your vehicle in all
traffic situations when using navigation.
WARNING
Always obey traffic laws, signs and signals, they take prece-
dence over navigation system recommendations.
Always concentrate on driving and pay attention to the road,
listen to the voice prompts and never let yourself be distracted by
the map display on the screen
page 9.
Always remember that data on the Navigation DVD can differ
from the actual situation because of insufficient data or because
the road or traffic routing has changed since the area was
mapped. Do a “reality check” and ignore the navigation system
recommendation if necessary.
Always remember that even if one-way streets, pedestrian
zones, etc. are stored on the Navigation DVD, traffic routing is
subject to constant change. Traffic signals, turning lanes or prohi-
bitions, stop and yield signs, no parking and similar zones as well
as narrow lanes are not covered by the navigation system.
Always adjust your speed to road, traffic and weather condi-
tions and visibility. Never let information about the road ahead
cause you to drive too fast for conditions, for example in fog.
The volume setting should be selected to ensure that outside
signals, such as police and fire truck sirens, are always audible -
danger of accident!
NAV
Page 114 of 194
Navigation (NAV)109
General operation
RADIO, CD
NAME, TEL
NAV, INFO
CAR, SETUP
Tips
The Navigation System is designed to provide you with
suggested routes in locating addresses, destinations and other
points of interest.
Changes in street names, construction zones, traffic flow, points
of interest or other road system changes are beyond the control of
Audi of America, Inc.
Complete, detailed mapping of lanes, roads, streets, toll roads,
highways, etc., is not possible, therefore you may encounter
discrepancies between the mapping and your actual location.
IntroductionGeneralFig. 112 Display: Example of navigation mapThe Audi Navigation System can help you to reach your destination
without spending a lot of time studying maps.
During the trip you will receive information on vehicle location,
in structions for turning (directio n and dis tance to turn-off), p resen t
distance to destination and estimated time of arrival at destination
in the Navigation System display
fig.112 and in the instrument
cluster display
page 111, fig.114. In addition you will receive
navigation prompts in the form of a spoken announcement
page 112.
There are two possibilities for guide destination:
Route without stopover (Single destination mode)
Page 115 of 194
Navigation (NAV) 110
Route with stopover (Route plan)
Route without stopover (Single destination mode)
In single destination mode you can drive directly to a destination
page 119.
If you enter a direct destination and start guidance, you are given
the option of up to three different routes
page 130.
Route with stopover (Route plan)
In this mode, you can choose up to three stopovers and one final
destination
page 139.
For example, while on your way to your final destination, you could
have three stopovers, such as: the nearest gasoline station, then a
restaurant and after that a point of interest to visit
page 121.
WARNING
Follow the traffic laws for the area in which you are driving. If
driving instructions run contrary to traffic laws, the traffic laws
always take precedent.
Tips
However, the system will not provide you with any information
about the meaning of traffic signs and signals!
How does the Navigation System work?
The Navigation System works with the help of satel-
lites (GPS).To determine current vehicle position, distance sensors, gyroscopes
and satellite signals are analyzed. The signals are transmitted by
GPS satellites. The acronym GPS stands for “Global Positioning
System”.
The recorded information is transferred to the navigation system
a n d t h e n c o m p a re d w i t h t h e m a p m a t e r i a l s to re d o n t h e N a v i g a t io n
DVD. In this way, guidance to your destination can be calculated
precisely.
To c a l c u l a t e g u i d a n c e t o y o u r d e s t i n a t i o n , t h e n a v i g a t i o n D V D h a s t o
be inserted into the navigation drive. The drive for the Navigation
System is located behind the system display
page 35.
When the navigation DVD is inserted, the system starts automati-
cally and navigation destinations can be entered page 117.
Five differe nt languages (German, E nglish, French, Spanish, Italian)
are availabe on the navigation DVD for the audible navigation
prompts. You can change the language for the audible navigation
voice messages using the Menu language function in Setup
page 170.Tips
Snow and other objects on the GPS antenna or screening by
trees and large buildings can interfere with satellite reception and
m a ke i t m o re d i ffe re n t to d e t e rm i n e v e h i c l e l o c a t i o n . I f s e v e ra l s a t e l -
lites are turned off or disabled, this may result in interference with
GPS reception and make it more difficult to determine vehicle loca-
tion.
Page 116 of 194
Navigation (NAV)111
General operation
RADIO, CD
NAME, TEL
NAV, INFO
CAR, SETUP
Your map data DVD includes the continental United States
(excluding Alaska), Hawaii and parts of Canada on a single media
allowing for seamless routing across coverage areas.
Street and city names can be changed. For this reason, there may
be exceptions where the names stored on the DVD do not match the
names that have been changed.
Navigation DVDs can be purchased from an Audi dealer. The
dealer can also provide you with information about navigation DVD
updates.
GPS positioning works in only one direction, i.e. the navigation
system receives data to determine vehicle location, but does not
broadcast data.
Navigation route guidanceFig. 113 Navigation: Example of screen in the Navigation System display
Guidance for your route navigation is provided both visually and
acoustically:
with voice messages
page 112
through a screen in the Navigation System display
fig.113
(
page 112)
through a display in the instrument cluster
fig.114
(
page 113)Tips
If the recommended route is not followed, the system will calcu-
late a new route from the current location.
It is also possible to start the navigation in demo mode
page 161 for simulation purposes.
Fig. 114 Navigation:
Example of display in
the instrument cluster
Page 117 of 194
Navigation (NAV) 112Navigation voice guidanceRoute calculation is announced with the voice message “The route
is being calculated”. During this time, “The route is being calcu-
lated” is shown in the Navigation System display and “CALC” is
shown in the instrument cluster display.
When route calculation is complete, guidance is given by spoken
driving instructions and symbols. Driving recommendations are
a l w a y s m a d e w i t h e n o u g h t i m e t o m a k e a t u r n . A n a n n o u n c e m e n t i s
made in different stages in preparation for a change of direction.
Yo u c a n u s e t h e f o l l o w i n g o p t i o n s t o r e p e a t t h e l a s t n a v i g a t i o n v o i c e
message:
Press the Nav-Info control button in the navigation menu
page 150, if you are not in the Nav-Info submenu.
Press the right thumbwheel on the “multi-function steering
wheel with audio operation - version B*”
page 23.
You can choose which language you want for the voice messages
page 170.
WARNING
If driving instructions run contrary to traffic laws, the traffic laws
always take precedence.
Tips
During the announcement of a navigation prompt, you can
adjust the volume of the navigation prompt using the on/off knob
page 19 on the Navigation System or the volume buttons or the
right thumb wheel on the multi-function steering wheel*
page 21
.
If the v ehicle is in a loca tion which c annot be read b y the Naviga-
tion System (parking lot, garage, parking structure), a voice
message will inform you.
Presentation of maps in the Navigation System display
A comprehensive route will be shown graphically on a
map in the display.Fig. 115 Navigation: Example of a map in the Navigation System displayPress the SETUP function button page 16 in the naviga-
tion menu. The route is visible on a map fig.115.In addition to route guidance, you can display detailed information
a b o u t y o u r r o u t e o n t h e m a p . S e t t i n g s c a n b e e n t e r e d d i r e c t l y o n t h e
Page 118 of 194
Navigation (NAV)113
General operation
RADIO, CD
NAME, TEL
NAV, INFO
CAR, SETUP map
page 143 and in Setup Navigation
page 151 to d i s p l a y th e
map.
If you are navigating without stopovers, you have the option of
selecting from up to three routes, in addition to detailed route infor-
mation
page 130.
If you are n avigatin g with stopovers, you are shown the entire route
with all stopovers and detailed information in an overview
page 132.
You can also use the map as presented in the Navigation System
display to enter a destination
page 128.
Applies to vehicles: with display of the instrument clusterVisual presentation in the instrument cluster display
A s s o o n a s y o u h a v e e n t e r e d a r o u t e i n t o t h e N a v i g a t i o n S y s t e m a n d
begun navigating, guidance to your destination will also be
displayed in the instrument cluster display.
Fig. 116 Instrument
cluster display:
Example of route guid-
ance presentation
Display
Shor t descriptionEstimated time of arrival at destination or current
stopoverDistance remaining to next turn pointDirectional arrowLocation-dependent display of freeway, highway
and street names
An arrow before the display identifies the name of
the street onto which you should turn.Total kilometers to destination or current stopover
Fig. 117 Instrument
cluster display:
Example of route guid-
ance presentation
(turn off)
A1A2A3A4A5
Page 119 of 194
Navigation (NAV) 114When the turn-off is immediately ahead, the arrow points in the
direction in which you should turn. In addition, the name of the
street is shown under the arrow. A bar graph
page 113, f i g .1 1 7 o n
the right in the display takes you precisely to the turn-off point.
If it is necessary to make a lane change before the turn off, you are
warned in plenty of time about this lane change before the turn-off
arrow by a second arrow
page 111, fig.114.
Tips
With active guidance, you can switch to the trip computer display*
by pressing the trip computer reset button*. Pushing the trip
c o mp ut e r re s e t b ut to n * a g a in r e t ur n s y o u to g u i d a n c e . Yo u c a n fin d
detailed information about the trip computer* in the Owner's
Manual.
Applies to vehicles: with color instrument cluster display:Visual presentation in the instrument cluster display
Change of direction arrowBar graph (countdown): bars decreasing in size indi-
cate how the distance to the immediate turn-off
point is decreasing; the bar graph is not shown until
a change of direction arrow is displayed.If there is another side street before the turn-off
point which is n ot pa r t of current guidan ce , this side
street is represented by a side-street symbol in the
instrument cluster display.
Display
Short description
A6A7A8
Fig. 118 Instrument
cluster display:
Example of route guid-
ance presentationFig. 119 Instrument
cluster display:
Example of route guid-
ance presentation
(turn off)
