Instruments and warning/indicator lamps
16
NoteIf the warning lamp lights up while the vehicle is moving, this indi-
cates a fault in the engine management system. The engine should
be serviced by a qualified workshop without delay.Applies to vehicles: with diesel engineGlow plug system

The indicator lamp lights up to show that the glow plugs
are preheating.Your vehicle is equipped with an automatic glow plug system.
The indicator lamp
 lights up while the gl ow plugs are preheating.
If the engine fails to start imme diately, the glow plugs have not
finished preheating. In this case, keep the clutch pedal depressed
(or keep your foot on the brake if your vehicle has an automatic
gearbox) until the engine starts.
Note
•
If the glow plug indicator lamp should start flashing while the
vehicle is moving, this indicates a fault in the engine management
system. The engine should be serviced without delay.
•
If the indicator lamp fails to light up when the ignition is
switched on, this can mean that the glow plug system is defective.
The engine should be serviced.
Electronic stabilisation program (ESP)

This warning lamp monitors the electronic stabilisation
program.The warning lamp
 has the following functions:
•
It flashes when the ESP or trac tion control system (ASR) inter-
venes while the vehicle is in motion.
•
The warning lamp will light up continuously if the ESP or the
traction control system (ASR) has been switched off using the ESP
OFF button ⇒page 196 .
•
It lights up when the ignition is switched on and should go out
again after about 2 seconds. This signals that the lamp is working
properly.
•
It will light up continuously if there is a malfunction in the ESP.
•
It will also come on if a fault sh ould occur in the ABS because the
ESP operates in conjunction with the ABS.
If the battery has been disconnected, if the battery voltage is very
low, or if the engine has been started from an outside power source,
the ESP system will perform an init ialisation of the various on-board
sensors while you drive the first few metres. The warning lamp will
light up during this period. It will go out when the initialisation has
been completed.
If the warning lamp lights up and stays on after the engine is
started, this may mean that the control system has temporarily
switched off the ESP. In this case the ESP can be reactivated by
switching the ignition off and then on again. If the warning lamp
goes out, this means the system is fully functional.
For further information on the ESP ⇒page 196 .
Airbag system

This warning lamp monitors the airbag and seat belt
tensioner system.The warning lamp
 should light up for a few seconds when the
ignition is switched on.
If the warning lamp does not go out, or if it lights up, flashes or
flickers when the vehicle is moving, this indicates a malfunction in
the system. This is also the case if the warning lamp does not light
up when the ignition is switched on.
document_0900452a8179700c.book Seite 16 Donnerstag, 22. März 2007 10:19 10
--4 -
-T
•
-+
rn
+-
•
•

Driver information system
20Driver information systemIntroductionGeneral notes
The driver information system in the instrument cluster
shows you the status of various on-board systems at a
glance.The display for the driver information system is in the centre of the
instrument cluster.
The system runs a check on certain components and functions
when the ignition is switched on and while the vehicle is moving. It
gives an audible warning if a fault should occur or if servicing is
required, and a red or yellow warn ing symbol (in some cases with a
corresponding driver message) ap pears in the dashboard display.
The system will also display information for the radio and CD player
and (if fitted) the route guidance directions from the navigation
system* . For further information on these systems, please refer to
the MMI operating manual.
On some models the display of information shown in the instru-
ment cluster differs from the illustrations used here.
The driver information system includes the following functions:
Note
If a fault should occur, the display will show a red or yellow warning
symbol. A red warning symbol indicates a serious malfunction
⇒ page 30 . A yellow warning symbol indicates a less serious
malfunction , or other item requiring attention ⇒page 34 .
Fig. 8 Dashboard:
Display in instrument
cluster (automatic
gearbox)
CD and radio display
⇒page 21
Outside temperature
⇒page 21
Gear-change indicator
⇒page 21
Digital speedometer*
⇒page 22
Door catches/boot lid warning
⇒page 23
Service interval display
⇒page 23
Auto-check control*
⇒page 29
Driver messages
⇒page 30
Speed warning
⇒page 28
On-board computer*
⇒page 25
Selector lever positions for automatic gearbox*
⇒page 131
document_0900452a8179700c.book Seite 20 Donnerstag, 22. März 2007 10:19 10
--4 -
-T
-+
[]]
+-
•

Driver information system
24
– The remaining time and distance to the next service are indicated every time the ignition is switched on, until the
service becomes due.
Service due
–When a service is due, Service! will appear in the display as soon as you switch on the ignition. The display reverts
back to the standard display after about 5 seconds.
Displaying the service interval
– Select: Function selector button > Service interval
display ⇒ page 23, fig. 15.
Resetting the oil change interval display
– Select: Function selector button > Service interval
display > Reset oil change interval .Displaying distance to next service
You can have the distance to the next service displayed on the MMI
screen ⇒page 23, fig. 15. The remaining distance to the next
service is updated every time the ignition is switched on (starting at
500 km after a service has been performed).
On a new vehicle, the display wi ll always show the following
message for the first 500 km.
SERVICE IN ----- KM --- DAYS
Caution
The system cannot calculate the figures for the service indicator if
the battery is disconnected from the vehicle, so no service reminder
can be displayed during this time. Please remember that keeping to
the correct service intervals is most important for the service life
and residual value of the vehicle (and especially for the life of the
engine). The period between two services must never be longer than the time specified in the Service Schedule, even if you only
cover a low mileage during this time.
Note
•
Do not reset the display between oil changes - otherwise the
display will be incorrect.
•
The information in the service interval display remains intact if
the battery is disconnected.
•
The distance to the next service cannot be called up if the system
has detected a Priority 1 fault (red symbol).
•
If the service was not performed by a qualified workshop, the oil
change interval display can only be set to “fixed service intervals” of
15,000 km. If you wish to continue with the “LongLife” service, you
will need to have the oil change interval display reset by a qualified
workshop.
CARCAR
document_0900452a8179700c.book Seite 24 Donnerstag, 22. März 2007 10:19 10
--4 -
-T
-+
•
+-
0

Index
304Convenience open function . . . . . . . . . . . 50
Cooling system
Anti-freeze additive . . . . . . . . . . . . . . . 235
Checking coolant level . . . . . . . . . . . . 236
Coolant . . . . . . . . . . . . . . . . . . . . . . . . . 235
Coolant temperature gauge . . . . . . . . . 11
Malfunction . . . . . . . . . . . . . . . . . . . . . . 32
Radiator fan . . . . . . . . . . . . . . . . . . . . . 237
Topping up coolant . . . . . . . . . . . . . . 236
Cruise control system Adjusting speed . . . . . . . . . . . . . . . . . 127
Control lever on steering wheel . . . . 125
Cruise mode . . . . . . . . . . . . . . . . . . . . 126
Indicator lamp . . . . . . . . . . . . . . . . . . . . 17
Introduction . . . . . . . . . . . . . . . . . . . . . 125
Pre-selecting a speed . . . . . . . . . . . . . 128
Resuming cruise control . . . . . . . . . . 128
Safety notes . . . . . . . . . . . . . . . . . . . . . 125
Switching off . . . . . . . . . . . . . . . . . . . . 129
Switching off temporarily . . . . . . . . . 128
Cup holders . . . . . . . . . . . . . . . . . . . . . . . . . 85
Current fuel consumption . . . . . . . . . . . . . 25DDate display . . . . . . . . . . . . . . . . . . . . . . . . 13
Daytime running lights . . . . . . . . . . . . . . . 56
DCP See Dynamic gear control program . 133
Deactivating front passenger's airbag . . 183
Deadlock mechanism . . . . . . . . . . . . . . 43, 46
Defrosting windows . . . . . . . . . . . . . . 98, 107 Deluxe automatic air conditioner . . . . . . . 93
Air distribution . . . . . . . . . . . . . . . . . . . 97
Air outlets . . . . . . . . . . . . . . . . . . . . . . . . 99
Air outlets for rear passengers . . . . . . 99
Air recirculation mode . . . . . . . . . . . . . 97
Automatic mode . . . . . . . . . . . . . . . . . . 95
Basic settings . . . . . . . . . . . . . . . . . . . 100
Blower . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Controls . . . . . . . . . . . . . . . . . . . . . . . . . 94
Defrosting . . . . . . . . . . . . . . . . . . . . . . . 98
Description . . . . . . . . . . . . . . . . . . . . . . . 93
Economical operation . . . . . . . . . . . . . 100
Heated rear window . . . . . . . . . . . . . . . 98
Seat heating, front . . . . . . . . . . . . . . . 115
Supplementary heater . . . . . . . . . . . . 101
Switching on and off . . . . . . . . . . . . . . 95
Temperature . . . . . . . . . . . . . . . . . . . . . 96
Deluxe automatic air conditioner plus . . 101 AC mode . . . . . . . . . . . . . . . . . . . . . . . . 107
Air distribution . . . . . . . . . . . . . . . . . . 106
Air outlets . . . . . . . . . . . . . . . . . . . . . . . 108
Air outlets for rear passengers . . . . . 108
Air recirculation mode . . . . . . . . . . . . 106
Automatic mode . . . . . . . . . . . . . . . . . 104
Automatic recirculation . . . . . . . . . . . 110
Auxiliary heating . . . . . . . . . . . . . . . . . 111
Auxiliary heating - remote control . . 114
Auxiliary heating - running time . . . . 113
Basic settings . . . . . . . . . . . . . . . . . . . 109
Blower . . . . . . . . . . . . . . . . . . . . . . . . . 105
Controls . . . . . . . . . . . . . . . . . . . . . . . . 103
Defrosting . . . . . . . . . . . . . . . . . . . . . . 107
Description . . . . . . . . . . . . . . . . . . . . . . 101
Economical operation . . . . . . . . . . . . . 109 Heated rear window . . . . . . . . . . . . . . 107
Supplementary heater . . . . . . . . . . . . 110
Switching on and off . . . . . . . . . . . . . . 104
Synchronisation . . . . . . . . . . . . . . . . . 110
Temperature . . . . . . . . . . . . . . . . . . . . 104
Diesel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227
Diesel particulate filter . . . . . . . . . . . . 37, 205 Engine oil . . . . . . . . . . . . . . . . . . . . . . . 233
Digital clock . . . . . . . . . . . . . . . . . . . . . . . . . 13
Digital compass . . . . . . . . . . . . . . . . . . . . . 68
Digital speedometer . . . . . . . . . . . . . . . . . . 22
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . 292
Dipped headlights . . . . . . . . . . . . . . . . . . . 54 Defective . . . . . . . . . . . . . . . . . . . . . . . . . 36
DIS See Driver information system . . . . . . 20
Door catches/boot lid warning . . . . . . . . . 23
Doors Manual locking . . . . . . . . . . . . . . . . . . . 48
Driver See Sitting position . . . . . . . . . . . . . . . 164
Driver information system . . . . . . . . . . . . . 20 Auto-check control . . . . . . . . . . . . . . . . 29
Bulb monitor . . . . . . . . . . . . . . . . . . . . . 36
CD and radio display . . . . . . . . . . . . . . . 21
Digital speedometer . . . . . . . . . . . . . . . 22
Door catches/boot lid warning . . . . . . 23
Driver messages . . . . . . . . . . . . . . . . . . 30
On-board computer . . . . . . . . . . . . . . . . 25
Outside temperature display . . . . . . . . 21
Red symbols . . . . . . . . . . . . . . . . . . . . . 30
Service interval display . . . . . . . . . . . . . 23
document_0900452a8179700c.book Seite 304 Donnerstag, 22. März 2007 10:19 10
--4 -
-T
-+ +-

Index307
Controls
Safety
Driving tips
General maintenance
Self-help
Technical data
Interior mirrors
See Mirrors . . . . . . . . . . . . . . . . . . . . 65, 66
Interior monitor . . . . . . . . . . . . . . . . . . . . . . 47
Intermittent wipe . . . . . . . . . . . . . . . . . . . . 62 Rain sensor . . . . . . . . . . . . . . . . . . . . . . . 62
ISOFIX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191
JJack . . . . . . . . . . . . . . . . . . . . . . . . . . . 255, 262
Jacking points . . . . . . . . . . . . . . . . . . . . . . 262
Jump-starting . . . . . . . . . . . . . . . . . . . . . . 265KKey-operated switch for front passenger's airbag . . . . . . . . . . . . . . . . . . . . . . . . . 183
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 Emergency key . . . . . . . . . . . . . . . . . . . . 41
Replacement keys . . . . . . . . . . . . . . . . . 39
Replacing the battery . . . . . . . . . . . . . . 40
Kick-down multitronic® . . . . . . . . . . . . . . . . . . . . . 133LLeather careAlcantara . . . . . . . . . . . . . . . . . . . . . . . 226
Natural leather . . . . . . . . . . . . . . . . . . . 225
Light sensor . . . . . . . . . . . . . . . . . . . . . . . . . 54
Light sensor defective . . . . . . . . . . . . . . . . 35
Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 Coming home . . . . . . . . . . . . . . . . . . . . . 56
Daytime running lights . . . . . . . . . . . . . 56 Exterior lighting . . . . . . . . . . . . . . . . . . . 56
Front fog lights . . . . . . . . . . . . . . . . . . . 55
Headlight control . . . . . . . . . . . . . . . . . . 54
Leaving home . . . . . . . . . . . . . . . . . . . . . 56
Rear fog lights . . . . . . . . . . . . . . . . . . . . 55
Switching on and off . . . . . . . . . . . . . . . 54
Loading luggage compartment . . . . . . . . 168
Load-through hatch . . . . . . . . . . . . . . . . . . 83
Locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 Central locking system . . . . . . . . . . . . . 46
Locking and unlocking the vehicle from in- side
Central locking system . . . . . . . . . . . . . 47
Locking doors manually . . . . . . . . . . . . . . . 48
LongLife Service . . . . . . . . . . . . . . . . . . . . 233
Luggage compartment . . . . . . . . . . . . . . . . 77 Extending . . . . . . . . . . . . . . . . . . 80, 81, 82
Fastening rings . . . . . . . . . . . . . . . . . . . 78
Loading . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Load-through hatch . . . . . . . . . . . . . . . . 83
Side storage compartment . . . . . . . . . . 79
Stretch net . . . . . . . . . . . . . . . . . . . . . . . 79
See also Loading luggage compartment
168
Luggage rack See Roof carrier . . . . . . . . . . . . . . . . . . . 84
MMain beam headlights . . . . . . . . . . . . . . . . 59
Indicator lamp . . . . . . . . . . . . . . . . . . . . 17
Make-up mirrors . . . . . . . . . . . . . . . . . . . . . 61 Manual operation
Boot lid . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Fuel tank flap . . . . . . . . . . . . . . . . . . . . 229
Tilting panorama roof . . . . . . . . . . . 52, 53
Manual release Selector lever (multitronic®) . . . . . . . 136
Maximum speed See Performance, weights and
dimensions . . . . . . . . . . . . . . . . . . . . 295
Memory for driver's seat . . . . . . . . . . . . . . . 74 Activating remote control key . . . . . . . 75
Recalling settings . . . . . . . . . . . . . . . . . 74
Storing settings . . . . . . . . . . . . . . . . . . . 74
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Mileage recorder . . . . . . . . . . . . . . . . . . . . . 14
Minimising pollution . . . . . . . . . . . . . . . . . 206
Mirrors Anti-dazzle setting . . . . . . . . . . . . . . . . . 66
Automatic anti-dazzle exterior mirrors 68
Automatic anti-dazzle interior mirror . 66
Exterior mirrors . . . . . . . . . . . . . . . . . . . 67
Interior mirror . . . . . . . . . . . . . . . . . . . . . 65
Make-up mirrors . . . . . . . . . . . . . . . . . . . 61
MMI control console, cleaning . . . . . . . . 223
MMI display, cleaning . . . . . . . . . . . . . . . . 223
Mobile phones . . . . . . . . . . . . . . . . . . . . . . 251
Modifications . . . . . . . . . . . . . . . . . . . . . . . 250
multitronic® . . . . . . . . . . . . . . . . . . . . . . . . 130 Driving with multitronic® . . . . . . . . . . 130
Dynamic gear control program . . . . . 133
Kick-down feature . . . . . . . . . . . . . . . . 133
Selector lever lock . . . . . . . . . . . . . . . . 132
Selector lever positions . . . . . . . . . . . . 131
document_0900452a8179700c.book Seite 307 Donnerstag, 22. März 2007 10:19 10
--4 -
-T
-+ +-

Index309
Controls
Safety
Driving tips
General maintenance
Self-help
Technical data
Rear fog lights . . . . . . . . . . . . . . . . . . . . . . . 55
Rear lights
Defective . . . . . . . . . . . . . . . . . . . . . . . . . 36
Rear View camera See Reversing camera . . . . . . . . . . . . . 140
Rear view mirrors See Mirrors . . . . . . . . . . . . . . . . . . . . 65, 66
Rear window, sun blind . . . . . . . . . . . . . . . 61
Remote control keys . . . . . . . . . . . . . . . . . . 39 Indicator lamp . . . . . . . . . . . . . . . . . . . . 40
Replacing the battery . . . . . . . . . . . . . . 40
Unlocking and locking . . . . . . . . . . . . . 44
Replacement keys . . . . . . . . . . . . . . . . . . . . 39
Replacement parts . . . . . . . . . . . . . . . . . . 250
Reset button . . . . . . . . . . . . . . . . . . . . . . . . 14
Retaining net . . . . . . . . . . . . . . . . . . . . . . . . 79
Rev counter . . . . . . . . . . . . . . . . . . . . . . . . . 12
Reverse gear multitronic® . . . . . . . . . . . . . . . . . . . . . 131
Reversing camera . . . . . . . . . . . . . . . 140, 143 Parking mode 1 . . . . . . . . . . . . . . . . . . 145
Parking mode 2 . . . . . . . . . . . . . . . . . . 146
RME fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . 227
Roof carrier . . . . . . . . . . . . . . . . . . . . . . . . . 84 Attachment points . . . . . . . . . . . . . . . . . 84
Roof load . . . . . . . . . . . . . . . . . . . . . . . . 85
Running in . . . . . . . . . . . . . . . . . . . . . . . . . 205 New engine . . . . . . . . . . . . . . . . . . . . . 205
SSAFE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Safe driving . . . . . . . . . . . . . . . . . . . . . . . . 162 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Safety features . . . . . . . . . . . . . . . . . . . . . 162
Seat adjustment
Backrest angle (manual) . . . . . . . . . . . . 70
Easy-entry function . . . . . . . . . . . . . 71, 73
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . 72
Forwards and backwards (manual) . . . 70
Manual . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Seat height (manual) . . . . . . . . . . . . . . . 70
Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . 170 Adjusting seat belts . . . . . . . . . . . . . . . 173
Belt tensioners . . . . . . . . . . . . . . . . . . . 175
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . 226
During pregnancy . . . . . . . . . . . . . . . . 174
Putting on . . . . . . . . . . . . . . . . . . . . . . . 173
Safety notes . . . . . . . . . . . . . . . . . . . . . 171
Taking off . . . . . . . . . . . . . . . . . . . . . . . 174
Warning lamp . . . . . . . . . . . . . . . . . . . . . 17
Seat heating Front (deluxe automati c air conditioner)
115
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Seat memory . . . . . . . . . . . . . . . . . . . . . . . . 74
Selector lever Manual release (multitronic®) . . . . . . 136
Selector lever positions multitronic® . . . . . . . . . . . . . . . . . . . . . 131
Service interval display . . . . . . . . . . . . . . . . 23
Service position for windscreen wipers . . 64
servotronic . . . . . . . . . . . . . . . . . . . . . . . . . 201
Side lights . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Single journey memory . . . . . . . . . . . . . . . 26 Sitting position
Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . 164
Front passenger . . . . . . . . . . . . . . . . . . 165
Incorrect sitting position . . . . . . . . . . . 167
Rear passengers . . . . . . . . . . . . . . . . . . 165
Snow chains . . . . . . . . . . . . . . . . . . . . . . . . 248
Sockets 230 Volt . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Spare key . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 Starting the engine . . . . . . . . . . . . . . . . 42
Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . 250
Spare wheel . . . . . . . . . . . . . . . . . . . . . . . . 256
Speed warning . . . . . . . . . . . . . . . . . . . . . . . 28
Speedometer . . . . . . . . . . . . . . . . . . . . . 14, 22
Starting the engine After fuel tank has been run dry . . . . 228
Jump-starting . . . . . . . . . . . . . . . . . . . . 265
Spare key . . . . . . . . . . . . . . . . . . . . . . . . 42
Tow-starting . . . . . . . . . . . . . . . . . . . . . 267
Starting with jump leads . . . . . . . . . . . . . 265
Steering Locking the steering . . . . . . . . . . . . . . 116
Malfunction . . . . . . . . . . . . . . . . . . . . . . 33
Steering wheel height adjustment (manual) . . . . . . . . . . . . . . . . . . . . . . . 116
Storage compartments . . . . . . . . . . . . . . . . 91 Front seats . . . . . . . . . . . . . . . . . . . . . . . 92
Stretch net . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Sun blind . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Sun roof (tilting panorama roof) . . . . . . . . 52 Manual operation . . . . . . . . . . . . . . . 52, 53
Tilting open and closed . . . . . . . . . . . . . 52
Sun visors . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
document_0900452a8179700c.book Seite 309 Donnerstag, 22. März 2007 10:19 10
--4 -
-T
-+ +-

Index
310Sunroof (tilting panorama roof)
Convenience open/close function . . . . 50
Supplementary heater Deluxe automatic air conditioner . . . 101
Deluxe automatic air conditioner plus . . .110
Switches on driver's door Central locking system . . . . . . . . . . . . . 47
Switching off the engine . . . . . . . . . 118, 120
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15TTailgate See Boot lid . . . . . . . . . . . . . . . . . . . . . . 48
Tank capacity . . . . . . . . . . . . . . . . . . . . . . 293
Technical data . . . . . . . . . . . . . . . . . . . . . 292
Text messages . . . . . . . . . . . . . . . . . . . . . . 30
Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255
Total journey memory . . . . . . . . . . . . . . . . 26
Tow-away protection . . . . . . . . . . . . . . . . . 47
Towing Automatic braking . . . . . . . . . . . . . . . 209
Trailer stabilisation . . . . . . . . . . . . . . . 209
Towing away . . . . . . . . . . . . . . . . . . . . . . . 267
Towing bracket Parking system . . . . . . . . . . . . . . . . . . 147
Towing bracket, removable . . . . . . . . . . . 211
Towing bracket, retrofitting . . . . . . . . . . 216
Towline anchorage Front . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . 269
Tow-starting . . . . . . . . . . . . . . . . . . . . . . . 269 Traction control system
How the system works . . . . . . . . . . . . 198
Trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208 Accessories . . . . . . . . . . . . . . . . . . . . . 211
Notes on towing . . . . . . . . . . . . . . . . . 210
Points to check before towing . . . . . . 208
Technical requirements . . . . . . . . . . . 208
Trailer stabilisation . . . . . . . . . . . . . . . . . . 209
Trailer turn signals Indicator lamp . . . . . . . . . . . . . . . . . . . . 17
Trailer weights See Performance, weights and
dimensions . . . . . . . . . . . . . . . . . . . . 295
Transport bag See Load-through hatch . . . . . . . . . . . . 83
Tread depth . . . . . . . . . . . . . . . . . . . . . . . . 245
Trip recorder . . . . . . . . . . . . . . . . . . . . . . . . 14
Trips, checklist . . . . . . . . . . . . . . . . . . . . . 162
Turn signals . . . . . . . . . . . . . . . . . . . . . . . . . 59 Indicator lamp . . . . . . . . . . . . . . . . . . . . 17
Type plate . . . . . . . . . . . . . . . . . . . . . . . . . 293
Tyre Mobility System . . . . . . . . . . . . . . . . 257
Tyre pressure . . . . . . . . . . . . . . . . . . . . . . 243
Tyre repair kit . . . . . . . . . . . . . . . . . . . . . . 255 Tyre Mobility System . . . . . . . . . . . . . 257
Tyres Inflation pressures . . . . . . . . . . . . . . . 243
Tread wear indicators . . . . . . . . . . . . . 245
Tyre service life . . . . . . . . . . . . . . . . . . 243
UUniversal transmitter . . . . . . . . . . . . . . . . 154 Unleaded fuel . . . . . . . . . . . . . . . . . . . . . . 227
Unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Central locking system . . . . . . . . . . . . . 46
VVehicle data sticker . . . . . . . . . . . . . . . . . . 293
Vehicle identification data . . . . . . . . . . . . 293
Vehicle identification number . . . . . . . . . 293
VentilationDeluxe automatic air conditioner . . . . 93
Deluxe automatic air co nditioner plus . . .
101
Ventilation slots . . . . . . . . . . . . . . . . . . . . 168WWarning lamps . . . . . . . . . . . . . . . . . . . . . . 15 Airbag system . . . . . . . . . . . . . . . . . . . . 16
Anti-lock brake system . . . . . . . . . . . . . 18
Brake system . . . . . . . . . . . . . . . . . . . . . 19
Electro-mechanical parking brake . 18, 19
Electronic stabilisation program . . . . . 16
Emission control system . . . . . . . . . . . 17
Engine management . . . . . . . . . . . . . . . 15
Seat belt . . . . . . . . . . . . . . . . . . . . . . . . . 17
Warning triangle . . . . . . . . . . . . . . . . . . . . 254
Washer fluid level low . . . . . . . . . . . . . . . . 36
Washing the vehicle By hand . . . . . . . . . . . . . . . . . . . . . . . . . 220
Car wash . . . . . . . . . . . . . . . . . . . . . . . . 220
With high-pressure cleaner . . . . . . . . 220
Waxing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221
document_0900452a8179700c.book Seite 310 Donnerstag, 22. März 2007 10:19 10
--4 -
-T
-+ +-
