7000.0 COMPONENT LOCATION CHART









COMP. DESCRIPTION LOCATION7100.0 8500.0
A2w . . INSTRUMENT CLUSTER . . . . . . . . . . . . LH side of dash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0

A8 . . . .

CRUISE CONTROL MODULE
(TEMPOMAT) . . . . . . . . . . . . . . . . . . . . .

behind glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

0





A12 . .



SUPPLEMENTAL RESTRAINT
SYSTEM CONTROL MODULE . . . . .


below rear seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .


0



A18 . . HIFI AMPLIFIER . . . . . . . . . . . . . . . . . . . . in LH side of luggage compartment behind trim panel . . . . . . . . . . . . . . . . . . 0

A35y . BOARD COMPUTER (BC – LOW) . . . . center of dash center console

A36 . .
REAR WIPER/WASHER INTERVAL
CONTROL MODULE . . . . . . . . . . . . . .
in lift gate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .


0



A51 . .
WIPER/WASHER MODULE . . . . . . . . . .
behind glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

0

A52 . .

SLIP CONTROL MODULE (ABS/ASC) .

behind glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

0




A56 . .

TILT/SLIDE SUNROOF CONTROL
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . .
in roof panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

0


A64 . . WIPER/WASHER MODULE (LOW II) . . behind glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
0

A104 .
BODY ELECTRONICS CONTROL
MODULE (ZKE IV) . . . . . . . . . . . . . . . .
behind glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

0



A107 .
INTEGRATED HEATING– AND
CLIMATE CONTROL MODULE . . . . .
center of dash center console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .


0



A110 .
DIGITAL CLOCK . . . . . . . . . . . . . . . . . . . .
center of dash center console



A113 . SEAT OCCUPANCY DETECTOR . . . . . under RH front seat


A837 .

ELECTRONIC IMMOBILIZER
CONTROL MODULE (EWS III) . . . . .
below LH side of dash




A6000 ENGINE CONTROL MODULE (DME) . . rear RH side of engine compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0




COMPONENT LOCATION CHART








COMP.8500.0 7100.0LOCATION DESCRIPTION
K6300 ENGINE CONTROL MODULE RELAY . rear LH side of engine compartment in Power Distribution Box . . . . . . . . . .
0

K6301w

FUEL PUMP RELAY . . . . . . . . . . . . . . . .

rear LH side of engine compartment in Power Distribution Box . . . . . . . . . .


0


K6304 SECONDARY AIR PUMP RELAY . . . . . rear LH side of engine compartment in Power Distribution Box . . . . . . . . . .
0
K6326 UNLOADER RELAY, TERMINAL 15 . . . rear RH side of engine compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
0

L1 . . . .
EWS TOROIDAL COIL . . . . . . . . . . . . . .
at ignition switch



M2 . . .

FUEL PUMP . . . . . . . . . . . . . . . . . . . . . . . .

below RH side of rear seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

0


M3 . . . WIPER MOTOR . . . . . . . . . . . . . . . . . . . . rear of engine compartment below center of cowl . . . . . . . . . . . . . . . . . . . . . 0
M4 . . . WASHER PUMP . . . . . . . . . . . . . . . . . . . . front RH side of engine compartment on washer fluid reservoir . . . . . . . . . . 0

M7 . . .
HEADLIGHT/FOG LIGHT WASHER
PUMP . . . . . . . . . . . . . . . . . . . . . . . . . . .
front RH side of engine compartment on washer fluid reservoir . . . . . . . . . .

0



M9 . . .

AUXILIARY FAN MOTOR . . . . . . . . . . . .

behind front grille behind trim panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

0


M12 . . DRIVER’S DOOR LOCK MOTOR . . . . . in lower LH front door behind trim panel
M13 . . PASSENGER’S DOOR LOCK MOTOR in lower RH side of front door behind trim panel

M16 . .
GAS FILLER LOCK MOTOR . . . . . . . . .
in RH rear side of luggage compartment behind trim panel . . . . . . . . . . . . .

0



M17 . .

LUGGAGE COMPARTMENT LOCK
MOTOR . . . . . . . . . . . . . . . . . . . . . . . . . .
rear side of luggage compartment behind trim panel . . . . . . . . . . . . . . . . . . .

0

M21 . . DRIVER’S WINDOW MOTOR . . . . . . . . LH front door behind door panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

0
M23 . . PASSENGER’S WINDOW MOTOR . . . . RH front door behind door panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
0

M24z . FOLDING SUNROOF MOTOR . . . . . . . . in roof panel



M25 . .



CRUISE CONTROL ACTUATOR
(TEMPOMAT) . . . . . . . . . . . . . . . . . . . . .


front LH side of engine compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .


0



M30 . . BLOWER MOTOR . . . . . . . . . . . . . . . . . . rear of engine compartment behind RH fresh air cowl




COMPONENT LOCATION CHART









COMP.8500.0 7100.0LOCATION DESCRIPTION
P90 . . FRONT POWER DISTRIBUTION BOX rear LH side of engine compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0


P95 . .

AUXILIARY FUSE BOX . . . . . . . . . . . . . .

below LH side of dash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .


0


P97 . . AUXILIARY FUSE BOX . . . . . . . . . . . . . . below LH side of dash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0
R11 . . BLOWER RESISTORS . . . . . . . . . . . . . . behind center of dashboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0


R6252
THROTTLE POSITION SENSOR . . . . .
LH side of engine compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
0


R6255z

THROTTLE POSITION SENSOR (ASC)

LH side of engine compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .


0


S2 . . . . IGNITION SWITCH . . . . . . . . . . . . . . . . . . LH side of dash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0


S3 . . . .

AUTOMATIC TRANSMISSION RANGE
SWITCH . . . . . . . . . . . . . . . . . . . . . . . . .
center console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

0


S4 . . . . HORN SWITCH . . . . . . . . . . . . . . . . . . . . . on steering wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0

S5 . . . .

WIPER/WASHER SWITCH . . . . . . . . . . .

LH side of dash RH side of steering column above




S6 . . . . ASC SWITCH . . . . . . . . . . . . . . . . . . . . . . center console
S7 . . . . COMBINATION SWITCH . . . . . . . . . . . . . LH side of dash LH side of steering column above . . . . . . . . . . . . . . . . . . . . 0

S8 . . . .
LIGHT SWITCH . . . . . . . . . . . . . . . . . . . . .
LH side of dash



S13 . . PASSENGER’S DOOR JAMB SWITCH RH front door jamb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
0
S14 . . DRIVER’S DOOR JAMB SWITCH . . . . . front LH door pillar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
0
S17 . . MIRROR CONTROL SWITCH . . . . . . . . in upper LH front door

S18 . .

HAZARD SWITCH . . . . . . . . . . . . . . . . . .

below front of console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

0


S21w . ENGINE HOOD SWITCH . . . . . . . . . . . . front RH side of engine compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0
S28 . . CRUISE CONTROL SWITCH . . . . . . . . . LH side of dash RH side of steering column above . . . . . . . . . . . . . . . . . . . . 0

S29 . .
BRAKE LIGHT SWITCH . . . . . . . . . . . . .
LH footwell on brake pedal support bracket behind LH footwell trim . . . . . .
0

X13252X13253X13254
A8
CRUISE CONTROL
MODULE
(TEMPOMAT)
X22
X1170
A52
SLIP CONTROL
MODULE
(ABS/ASC)X74
A12
SUPPLEMENTAL
RESTRAINT
SYSTEM CONTROL
MODULE
X1441
A104
BODY
ELECTRONICS
CONTROL MODULE
(ZKE IV)




COMPONENT LOCATION VIEWS
ELECTRICAL CONTROL MODULE LOCATIONS
















M3
WIPER MOTOR
X333
B18
BRAKE FLUID
LEVEL SWITCH
X20X70X6205




COMPONENT LOCATION VIEWS













D100
DATA LINK
CONNECTOR
X69
X111X6002
X6217
B6205
INTAKE AIR
TEMPERATURE
SENSOR
B6217
HOT FILM AIR
MASS METER
M25
CRUISE CONTROL
ACTUATOR
(TEMPOMAT)

S2
IGNITION SWITCH
S7
COMBINATION
SWITCH
S28
CRUISE CONTROL
SWITCHX13
X14
C101
CONTACT RING
G5
DRIVER’S AIR BAG
GAS GENERATOR
S4
HORN SWITCHX9997




COMPONENT LOCATION VIEWS
