BMW NA
ELECTRICAL TROUBLESHOOTING
MANUAL
SERIES 3 – E36/5 (318ti)
SCHEMATICS MODEL YEAR 1999
0100.0 INDEX
0110.0 INTRODUCTION
0140.0 SYMBOLS
0670.0POWER DISTRIBUTION CHART 0670.1 FUSE CHART 0670.2 POWER DISTRIBUTION 0670.3 FUSE DETAILS 0670.4 GROUND DISTRIBUTION
0670.5 DATA LINK


1210.20

ENGINE CONTROL SYSTEM
(DME M5.2, 4–CYLINDER M44)
1230.0 CHARGING SYSTEM
1240.0 START


2460.2

ELECTRONIC TRANSMISSION
CONTROL (EGS A4S 270R)
3234.0 SUPPLEMENTAL RESTRAINT
SYSTEM (AIR BAG)
3450.1 SLIP CONTROL (ABS/ASC) 5116.0 POWER MIRRORS 5126.0 ZKE CENTRAL LOCKING (ZV)
5133.0 ZKE POWER WINDOWS (FH)
5200.0 POWER SEATS
5203.0 HEATED SEATS


5410.1

POWER TILT/SLIDE SUNROOF
(SHD)
5410.4 ELECTRIC FOLDING SUNROOF
6100.0 CENTRAL BODY
ELECTRONICS (ZKE IV)
6133.0 HORN
6135.1
DRIVE–AWAY PROTECTION
(EWS III)


6160.1

WIPER/WASHER MODULE
(WWM)


6169.0

WINDSHIELD WASHER JET
HEATERS
6211.0 INSTRUMENT CLUSTER
6213.0 DIGITAL CLOCK
6300.0 LIGHT SWITCH DETAILS
6312.0HEADLIGHTS/FOG LIGHTS 6313.0 TURN/HAZARD LIGHTS
6314.0
PARK/TAIL/UNDERHOOD
LIGHTS


6320.0

LICENSE PLATE/LUGGAGE
COMPARTMENT LIGHTS
6322.0 BACK UP LIGHTS
6325.0 BRAKE LIGHTS
6330.3 INTERIOR LIGHTS
6332.0 INTERIOR ACCESSORIES
6350.0 CRASH CONTROL MODULE
6410.7 HEATING CONTROL (HS)
6424.0REAR WINDOW DEFOGGER
6450.6
INTEGRATED HEATING– AND
CLIMATE CONTROL
6510.0 RADIO/STEREO 6510.1 RADIO/HIFI


6561.0

CELLULAR TELEPHONE
(PROVISIONS)


6571.0

CRUISE CONTROL
(TEMPOMAT)
6575.2 ANTI–THEFT SYSTEM (ALPINE)


6581.3

BOARD COMPUTER
(BC – LOW)
7000.0 COMPONENT LOCATION
CHART

7100.0
COMPONENT LOCATION
VIEWS
8000.0 SPLICE LOCATION VIEWS 8500.0 CONNECTOR VIEWS




0100.0 INDEX











ABS HYDRAULIC UNIT, Y1 3450.1-01. . . . . . . . . . . . . . . . . . . . . . . . .
ABS PUMP MOTOR RELAY, TIMED, K125 3450.1-00. . . . . . . . . . . .
AIR BAG GAS GENERATOR, DRIVER’S, G5 3234.0-00. . . . . . . . . .
AIR BAG GAS GENERATOR, LEFT SIDE, G14 3234.0-01. . . . . . . .
AIR BAG GAS GENERATOR, PASSENGER’S, G6 3234.0-00. . . . .
AIR BAG GAS GENERATOR, RIGHT SIDE, G15 3234.0-01. . . . . .
AIR CONDITIONING COMPRESSOR, Y2 6450.6-02. . . . . . . . . . . . .
AIR PUMP, Y6133 1210.20-08. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ANTENNA AMPLIFIER AM/FM, N8 6424.0-01. . . . . . . . . . . . . . . . . . .
ANTI–THEFT CONTROL MODULE (ALPINE), N12w 6575.2. . . . . .
ANTI–THEFT HORN (ALPINE), H1w 6575.2-01. . . . . . . . . . . . . . . . .
ANTI–THEFT SYSTEM (ALPINE) 6575.2. . . . . . . . . . . . . . . . . . . . . . .
ASC SWITCH, S6 3450.1-02. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
AUTOMATIC TRANSMISSION RANGE SWITCH, S3 2460.2-01. . .
AUXILIARY FAN MOTOR, M9 6450.6-03. . . . . . . . . . . . . . . . . . . . . . .
AUXILIARY FUSE BOX, P95 0670.2-02. . . . . . . . . . . . . . . . . . . . . . . .
AUXILIARY FUSE BOX, P97 0670.2-01. . . . . . . . . . . . . . . . . . . . . . . .
AUXILIARY THROTTLE POSITION MOTOR (ADS), M93 3450.1-02
AUXILIARY TURN LIGHT, LEFT FRONT, H9 6313.0-02. . . . . . . . . .
AUXILIARY TURN LIGHT, RIGHT FRONT, H8 6313.0-02. . . . . . . . .
BACK UP LIGHT, LEFT, H27 6322.0-00. . . . . . . . . . . . . . . . . . . . . . . .
BACK UP LIGHT, RIGHT, H28 6322.0-00. . . . . . . . . . . . . . . . . . . . . . .
BACK UP LIGHTS 6322.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BATTERY, G1 0670.2-00. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BLOWER MOTOR, M30 6410.7-01. . . . . . . . . . . . . . . . . . . . . . . . . . . .
BLOWER MOTOR, M30 6450.6-00. . . . . . . . . . . . . . . . . . . . . . . . . . . .
BLOWER RELAY, K4 6410.7-00. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BLOWER RELAY, K4 6450.6-00. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BLOWER RESISTORS, R11 6410.7-01. . . . . . . . . . . . . . . . . . . . . . . .
BLOWER RESISTORS, R11 6450.6-00. . . . . . . . . . . . . . . . . . . . . . . .
BLOWER SWITCH, S75 6410.7-01. . . . . . . . . . . . . . . . . . . . . . . . . . . .
BLOWER SWITCH, S75 6450.6-00. . . . . . . . . . . . . . . . . . . . . . . . . . . . BOARD COMPUTER (BC – LOW) 6581.3. . . . . . . . . . . . . . . . . . . . . .
BOARD COMPUTER (BC – LOW), A35y 6581.3-00. . . . . . . . . . . . . .
BODY ELECTRONICS CONTROL MODULE (ZKE IV),
A104 6100.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BRAKE FLUID LEVEL SWITCH, B18 6211.0-00. . . . . . . . . . . . . . . . .
BRAKE LIGHT SWITCH, S29 6325.0-00. . . . . . . . . . . . . . . . . . . . . . . .
BRAKE LIGHT SWITCH, S30 2460.2-04. . . . . . . . . . . . . . . . . . . . . . . .
BRAKE LIGHT SWITCH, S30 6325.0-00. . . . . . . . . . . . . . . . . . . . . . . .
BRAKE LIGHT, LEFT, H24 6325.0-00. . . . . . . . . . . . . . . . . . . . . . . . . .
BRAKE LIGHT, RIGHT, H31 6325.0-00. . . . . . . . . . . . . . . . . . . . . . . . .
BRAKE LIGHTS 6325.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BRAKE PAD SENSOR, LEFT FRONT, B16 6211.0-01. . . . . . . . . . . .
BRAKE PAD SENSOR, RIGHT REAR, B17 6211.0-01. . . . . . . . . . .
CARBON CANISTER VALVE, Y199 1210.20-08. . . . . . . . . . . . . . . . .
CD CHANGER, N22 6510.0-00. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CD CHANGER, N22 6510.1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CELLULAR TELEPHONE (PROVISIONS) 6561.0. . . . . . . . . . . . . . .
CENTER INTERIOR LIGHT, REAR, E32z 6330.3-00. . . . . . . . . . . . .
CENTRAL BODY ELECTRONICS (ZKE IV) 6100.0. . . . . . . . . . . . . .
CENTRAL LOCKING SWITCH, S302 5126.0-00. . . . . . . . . . . . . . . . .
CHARGING SYSTEM 1230.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CHIME MODULE, H10 6211.0-05. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CIGAR LIGHTER LIGHT, FRONT, E29 6332.0-00. . . . . . . . . . . . . . . .
CIGAR LIGHTER, FRONT, E28 6332.0-00. . . . . . . . . . . . . . . . . . . . . .
CLIMATE CONTROL SWITCH ILLUMINATION, E103 6424.0-00. .
CLIMATE CONTROL SWITCH ILLUMINATION, E103 6450.6-00. .
CLOCK 6213.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CLUTCH SWITCH, S32 6571.0-01. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
COMBINATION SWITCH, S7 6312.0. . . . . . . . . . . . . . . . . . . . . . . . . . .
COMBINATION SWITCH, S7 6313.0-00. . . . . . . . . . . . . . . . . . . . . . . .
COMBINATION SWITCH, S7 6581.3-00. . . . . . . . . . . . . . . . . . . . . . . .
COMPONENT LOCATION CHART 7000.0. . . . . . . . . . . . . . . . . . . . . .




INDEX










FUEL PUMP, M2 1210.20-03. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
FUEL TANK PRESSURE SENSOR, B72 1210.20-04. . . . . . . . . . . . .
FUEL TANK SENSOR II, B25y 6211.0-04. . . . . . . . . . . . . . . . . . . . . . .
FUEL TANK SENSOR II, B25y 6581.3-00. . . . . . . . . . . . . . . . . . . . . . .
FUSE CHART 0670.1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
FUSE DETAILS 0670.3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
FUSIBLE LINK, F97 0670.2-00. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GAS FILLER LOCK MOTOR, M16 5126.0-03. . . . . . . . . . . . . . . . . . .
GENERATOR, G6509 1230.0-00. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GLOVE BOX LIGHT SWITCH, S37 6332.0-00. . . . . . . . . . . . . . . . . . .
GLOVE BOX LIGHT, E42 6332.0-00. . . . . . . . . . . . . . . . . . . . . . . . . . .
GROUND DISTRIBUTION 0670.4. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HALL EFFECT CAMSHAFT SENSOR, B6209 1210.20-03. . . . . . . .
HAZARD FLASHER RELAY, K16 6313.0-00. . . . . . . . . . . . . . . . . . . .
HAZARD SWITCH, S18 6313.0-01. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HEADLIGHT, LEFT, E7 6312.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HEADLIGHT, RIGHT, E8 6312.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HEADLIGHT/FOG LIGHT WASHER PUMP, M7 6160.1-03. . . . . . . .
HEADLIGHTS/FOG LIGHTS 6312.0. . . . . . . . . . . . . . . . . . . . . . . . . . .
HEATED SEATS 5203.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HEATING CONTROL (HS) 6410.7. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HIFI AMPLIFIER, A18 6510.1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HIGH BEAM LIGHT RELAY, K46 6312.0-02. . . . . . . . . . . . . . . . . . . . .
HIGH BEAM LIGHT, LEFT, E11 6312.0. . . . . . . . . . . . . . . . . . . . . . . . .
HIGH BEAM LIGHT, RIGHT, E12 6312.0. . . . . . . . . . . . . . . . . . . . . . . .
HIGH LEVEL STOP LIGHT, H34 6325.0-00. . . . . . . . . . . . . . . . . . . . .
HIGH RANGE SPEAKER, LEFT FRONT, H59 6510.0-00. . . . . . . . .
HIGH RANGE SPEAKER, LEFT FRONT, H59 6510.1-03. . . . . . . . .
HIGH RANGE SPEAKER, LEFT REAR, H56 6510.1-01. . . . . . . . . .
HIGH RANGE SPEAKER, RIGHT FRONT, H50 6510.0-00. . . . . . . .
HIGH RANGE SPEAKER, RIGHT FRONT, H50 6510.1-03. . . . . . . .
HIGH RANGE SPEAKER, RIGHT REAR, H53 6510.1-02. . . . . . . . . HIGH SPEED RELAY, K22 6450.6-03. . . . . . . . . . . . . . . . . . . . . . . . . .
HORN 6133.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HORN RELAY, K2 6133.0-00. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HORN SWITCH, S4 6133.0-00. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HORN, LEFT, H2 6133.0-00. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HORN, RIGHT, H3 6133.0-00. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HOT FILM AIR MASS METER, B6217 1210.20-05. . . . . . . . . . . . . . .
IDLE SPEED CONTROL VALVE, Y6130 1210.20-01. . . . . . . . . . . . .
IGNITION COIL, CYL. 1, T6151 1210.20-02. . . . . . . . . . . . . . . . . . . . .
IGNITION COIL, CYL. 2, T6152 1210.20-02. . . . . . . . . . . . . . . . . . . . .
IGNITION COIL, CYL. 3, T6153 1210.20-02. . . . . . . . . . . . . . . . . . . . .
IGNITION COIL, CYL. 4, T6154 1210.20-02. . . . . . . . . . . . . . . . . . . . .
IGNITION SWITCH, S2 0670.2-03. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IGNITION SWITCH, S2 6211.0-05. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IHKS CONTROL SWITCH, S530 6450.6-01. . . . . . . . . . . . . . . . . . . . .
INDEX 0100.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INSTRUMENT CLUSTER 6211.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INSTRUMENT CLUSTER, A2w 6211.0. . . . . . . . . . . . . . . . . . . . . . . . .
INTAKE AIR RESONANCE CHANGEOVER VALVE,
Y6131 1210.20-01. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INTAKE AIR TEMPERATURE SENSOR, B6205 1210.20-04. . . . . .
INTEGRATED HEATING–
AND CLIMATE CONTROL MODULE, A107 6450.6. . . . . . . . . . . . .
INTEGRATED HEATING– AND CLIMATE CONTROL 6450.6. . . . .
INTERIOR ACCESSORIES 6332.0. . . . . . . . . . . . . . . . . . . . . . . . . . . .
INTERIOR LIGHTS 6330.3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INTERMEDIATE PRESSURE SWITCH, B9 6450.6-03. . . . . . . . . . . .
INTRODUCTION 0110.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
JET HEATER THERMOSWITCH, S198 6169.0-00. . . . . . . . . . . . . . .
KICK–DOWN SWITCH, S8507 2460.2-04. . . . . . . . . . . . . . . . . . . . . .
KNOCK SENSOR, B6240 1210.20-04. . . . . . . . . . . . . . . . . . . . . . . . . .
LICENSE PLATE LIGHT, LEFT, E43 6320.0-00. . . . . . . . . . . . . . . . . .





2.5 VI/SW
0110.0 INTRODUCTION








P90
FRONT POWER
DISTRIBUTION
BOXF115A
GROUND
DISTRIBUTION
0670.46160.0-02 2.5 VI/SW 4 8P91
REAR POWER
DISTRIBUTION
BOX
F4430A
X29326
X293
FUSE DETAILS
0670.3
4 VI/SW 86
8530
87
X452
CENTRAL
BODY
ELECTRONICS
(ZKE)
6100.0 K11
WIPER RELAY
FUSE DETAILS
0670.3
X493
Schematics
The schematics divide the entire vehicle electrical system into individual circuits. Interacting
electrical components are shown on one common schematic.
Switches and other components are represented in such a way that their general layout and
function are self–explicit. They are arranged on the sheet such that the current path can be
followed from positive (top) to negative (bottom).
Important: The components and wires are not drawn to scale. For instance, a lead with a length
of over 1m can be shown as a lead that is only a few cm long. To ensure clear arrangement , all
connectors, lines branches and connected components from the fuses to the component and
from the component to ground connection are not shown within the individual cells. If required,
reference can be made to cells 0670.3 Fuse Details and 0670.4 Ground Distribution where all
lines are illustrated with all plug connections, line branches and connected components.
All circuit sysmbols used are listed and explained in cell 0140.0 Symbols.
In cell 7000.0 Component Location Chart all important connectors, ground points and
components are listed in tabular form. It provides a precise description of the component
locations in the vehicle.
In cell 7100.0 Component Location Views the location of connectors and components which
are difficult to locate are shown in line arts or illustrations. In cell 8000.0 Splice Location Views
all splices are listed in numerical order and illustrations are provided to assist in locating splices
on larger harnesses. In cell 8500.0 Connector Views diagrams of connectors with more than 2
pins are illustrated.
Included in this ETM are foldout block diagrams. These are overviews of the entire system (EGS,
ABS, AC etc.) which helps understand the relationships between various components and control
unit of the system being diagnosed.

Example
General conventions can be explained based on the following schematic example.


K6304
SECONDARY AIR
PUMP RELAY
11 12 13456 78 9
38
37
35
34
33
32
31 42
41
40
39 43 44


FRONT POWER DISTRIBUTION BOX
0670.0 POWER DISTRIBUTION CHART








K2
HORN RELAYK47
FRONT FOG LIGHT
RELAYK48
LOW BEAM LIGHT
RELAYK16
HAZARD FLASHER
RELAYK4
BLOWER RELAY
K13
REAR DEFOGGER
RELAYK125
ABS PUMP MOTOR
RELAY, TIMEDK22
HIGH SPEED
RELAYK19
COMPRESSOR
CONTROL RELAYK21
NORMAL SPEED
RELAY K6301w
FUEL PUMP RELAY K6300
ENGINE CONTROL
MODULE RELAY
X56X44X45X64X58
X292X11393
X53X51X52
X6304X6301X630046
45
3612 3 10
14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30
FUSES FUSES
X0


5133.0ZKE POWER WINDOWS (FH)

5203.0
5410.4HEATED SEATS
ELECTRIC FOLDING SUNROOF




6100.0
6133.0
6160.1CENTRAL BODY ELECTRONICS (ZKE IV)
HORN
WIPER/WASHER MODULE (WWM)






5126.0
ZKE CENTRAL LOCKING (ZV)

6135.1DRIVE–AWAY PROTECTION (EWS III)

6169.0WINDSHIELD WASHER JET HEATERS

5410.1POWER TILT/SLIDE SUNROOF (SHD)





0670.1 FUSE CHART



FUSES 1 TO 29





FUSE NUMBER
12345 10 206 7 8 9 11 12 13 14 15 16 17 18 19 21 22 23 24 25 26 27 28 29
1230.0
2460.2
3234.0
3450.1
5116.0
30A 5A 30A 15A 30A 30A 5A 30A 7.5A 7.5A 5A 15A 5A 5A 5A 10A 5A 7.5A


20A 15A 30A 5A 5A
CHARGING SYSTEM
ELECTRONIC TRANSMISSION CONTROL (EGS A4S 270R)
POWER MIRRORS SLIP CONTROL (ABS/ASC)
30A 15A 10A
SUPPLEMENTAL RESTRAINT SYSTEM (AIR BAG) 1210.20ENGINE CONTROL SYSTEM (DME M5.2, 4–CYLINDER M44)












1240.0START






5200.0POWER SEATS

6211.0
INSTRUMENT CLUSTER

6213.0CLOCK

5A 5A




FUSE CHART



FUSES 1 TO 29




FUSE NUMBER
12345 10 206 7 8 9 11 12 13 14 15 16 17 18 19 21 22 23 24 25 26 27 28 29
30A 5A 30A 15A 30A 30A 5A 30A 7.5A 7.5A 5A 15A 5A 5A 5A 10A 7.5A20A 15A 30A 5A30A 15A 10A
6314.0PARK/TAIL/UNDERHOOD LIGHTS
6350.0CRASH CONTROL MODULE 6325.0
6330.3
6332.0BRAKE LIGHTS
INTERIOR LIGHTS
INTERIOR ACCESSORIES 6322.0BACK UP LIGHTS


6320.0LICENSE PLATE/LUGGAGE COMPARTMENT LIGHTS
6410.7
6450.6
6510.0
6510.1INTEGRATED HEATING– AND CLIMATE CONTROL HEATING CONTROL (HS)
RADIO/CD PLAYER (PROVISIONS)
RADIO/HIFI
6561.0CELLULAR TELEPHONE (PROVISIONS)
6571.0CRUISE CONTROL (TEMPOMAT)










6300.0
6312.0
6313.0





LIGHT SWITCH DETAILS
HEADLIGHTS/FOG LIGHTS
TURN/HAZARD LIGHTS











6575.2ANTI–THEFT SYSTEM (ALPINE)


6424.0REAR WINDOW DEFOGGER



6581.3BOARD COMPUTER (BC – LOW)




FUSE CHART



FUSES 30 TO 48




FUSE NUMBER
39
7.5A 5A 30A 10A 15A 25A 30A 7.5A 30A 15A 7.5A 15A30A 10A

40






   
38 37 36 35
5A7.5A

15A







1230.0
2460.2
3234.0
5116.0CHARGING SYSTEM
ELECTRONIC TRANSMISSION CONTROL (EGS A4S 270R)
POWER MIRRORS SUPPLEMENTAL RESTRAINT SYSTEM (AIR BAG)
5133.0ZKE POWER WINDOWS (FH)
5203.0
5410.1HEATED SEATS
POWER TILT/SLIDE SUNROOF (SHD)
6100.0
6133.0
6160.1
6169.0CENTRAL BODY ELECTRONICS (ZKE IV)
HORN
WIPER/WASHER MODULE (WWM)
WINDSHIELD WASHER JET HEATERS 5126.0ZKE CENTRAL LOCKING (ZV) 1240.0START









6135.1DRIVE–AWAY PROTECTION (EWS III)



40A






3450.1SLIP CONTROL (ABS/ASC)
5410.4ELECTRIC FOLDING SUNROOF


5200.0POWER SEATS

6211.0INSTRUMENT CLUSTER


6213.0CLOCK


1210.20ENGINE CONTROL SYSTEM (DME M5.2, 4–CYLINDER M44)






FUSE CHART







FUSE NUMBER

40





   
   





FUSES 30 TO 48

7.5A 5A 30A 10A 15A 25A 30A 7.5A 30A 15A 7.5A 15A30A 10A 5A7.5A

15A




















6314.0PARK/TAIL/UNDERHOOD LIGHTS
6350.0CRASH CONTROL MODULE 6325.0
6330.3
6332.0BRAKE LIGHTS
INTERIOR LIGHTS
INTERIOR ACCESSORIES 6322.0BACK UP LIGHTS 6320.0LICENSE PLATE/LUGGAGE COMPARTMENT LIGHTS
6410.7
6450.6
6510.0
6510.1INTEGRATED HEATING– AND CLIMATE CONTROL HEATING CONTROL (HS)
RADIO/CD PLAYER (PROVISIONS)
RADIO/HIFI
6561.0CELLULAR TELEPHONE (PROVISIONS)
6571.0CRUISE CONTROL (TEMPOMAT) 6312.0
6313.0HEADLIGHTS/FOG LIGHTS
TURN/HAZARD LIGHTS





6575.2ANTI–THEFT SYSTEM (ALPINE)


40A




6424.0REAR WINDOW DEFOGGER





6581.3BOARD COMPUTER (BC – LOW)

6300.0LIGHT SWITCH DETAILS




COMPONENT LOCATION CHART









COMP.8500.0 7100.0LOCATION DESCRIPTION
P90 . . FRONT POWER DISTRIBUTION BOX rear LH side of engine compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0


P95 . .

AUXILIARY FUSE BOX . . . . . . . . . . . . . .

below LH side of dash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .


0


P97 . . AUXILIARY FUSE BOX . . . . . . . . . . . . . . below LH side of dash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0
R11 . . BLOWER RESISTORS . . . . . . . . . . . . . . behind center of dashboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0


R6252
THROTTLE POSITION SENSOR . . . . .
LH side of engine compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
0


R6255z

THROTTLE POSITION SENSOR (ASC)

LH side of engine compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .


0


S2 . . . . IGNITION SWITCH . . . . . . . . . . . . . . . . . . LH side of dash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0


S3 . . . .

AUTOMATIC TRANSMISSION RANGE
SWITCH . . . . . . . . . . . . . . . . . . . . . . . . .
center console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

0


S4 . . . . HORN SWITCH . . . . . . . . . . . . . . . . . . . . . on steering wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0

S5 . . . .

WIPER/WASHER SWITCH . . . . . . . . . . .

LH side of dash RH side of steering column above




S6 . . . . ASC SWITCH . . . . . . . . . . . . . . . . . . . . . . center console
S7 . . . . COMBINATION SWITCH . . . . . . . . . . . . . LH side of dash LH side of steering column above . . . . . . . . . . . . . . . . . . . . 0

S8 . . . .
LIGHT SWITCH . . . . . . . . . . . . . . . . . . . . .
LH side of dash



S13 . . PASSENGER’S DOOR JAMB SWITCH RH front door jamb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
0
S14 . . DRIVER’S DOOR JAMB SWITCH . . . . . front LH door pillar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
0
S17 . . MIRROR CONTROL SWITCH . . . . . . . . in upper LH front door

S18 . .

HAZARD SWITCH . . . . . . . . . . . . . . . . . .

below front of console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

0


S21w . ENGINE HOOD SWITCH . . . . . . . . . . . . front RH side of engine compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0
S28 . . CRUISE CONTROL SWITCH . . . . . . . . . LH side of dash RH side of steering column above . . . . . . . . . . . . . . . . . . . . 0

S29 . .
BRAKE LIGHT SWITCH . . . . . . . . . . . . .
LH footwell on brake pedal support bracket behind LH footwell trim . . . . . .
0
