roof rack BMW 323Ci CONVERTIBLE 2000 E46 Owner's Manual
[x] Cancel search | Manufacturer: BMW, Model Year: 2000, Model line: 323Ci CONVERTIBLE, Model: BMW 323Ci CONVERTIBLE 2000 E46Pages: 199, PDF Size: 1.77 MB
Page 45 of 199
45n
IndexDataTechnologyRepairsCar careControlsOverview
Manual convertible topThe fabric top offers perfect weather
protection, and can easily be opened
and closed by one person.
Here are a few tips to ensure that you
get the most enjoyment out of driving
your convertible. It is advisable to close
the convertible top when the vehicle is
parked. The closed convertible top not
only protects the passenger compart-
ment from unforeseeable damage from
the weather, it also provides a certain
degree of theft protection.
In addition, keep valuables only in the
locked luggage compartment, even
with the convertible top closed.
Never mount a roof-mounted luggage
rack on the convertible top.
To close the power side windows
while driving: be sure to close
either the rear windows first, or all win-
dows at the same time, otherwise, they
may not close all the way at higher
speeds.c
To open the convertible top
Operate the convertible top only
when the vehicle is stationary.
To prevent damage, the convertible top
compartment lid can not be opened if
the luggage compartment lid is open.c
1 Flip the locking handle out and turn
it until it hits the end stop
2 Raise the convertible top slightly
(reduces the tension)
46cde064
3 Press the button to unlock the top.
The lid locks for the convertible top
are unlocked and the side windows
lower slightly
If the convertible top compartment
lid has been raised, then the lid
locks for the convertible top will be
blocked. If the indicator lamp lights up
when you press the button, then you
cannot unlock. Flip the convertible top
compartment lid down; refer to page 41,
and close the luggage compartment
lid.c46cus003
Page 49 of 199
49n
IndexDataTechnologyRepairsCar careControlsOverview
The fully automatic convertible top
*
The fully automatic convertible top
combines assured protection from the
weather with a one-touch operation.
Here are a few tips to ensure that you
get the most enjoyment out of driving
your convertible.
It is advisable to close the convertible
top when the vehicle is parked. The
closed convertible top not only protects
the passenger compartment from un-
foreseeable damage from the weather,
it also provides a certain degree of theft
protection. In addition, keep valuables
only in the locked luggage compart-
ment, even with the convertible top
closed.
Never mount a roof-mounted luggage
rack on the convertible top.
To prevent damage, do not operate the
convertible top at temperatures below
14 7 (–10 6).
To conserve the battery, operate the
convertible top only with the engine
running if at all possible.
The convertible top operation is
completely automatic. In rare in-
stances, some manual support may be
necessary (see Note in next column
but one).
Operate the convertible top only when
the vehicle is stationary. Do not start to
drive while operating it, either, because
the procedure could be interrupted
when the top hits certain positions.
A partially open convertible top can
lead to damage or injury.
If you initiate convertible top operation
with the vehicle stationary and then
start driving, e.g. at a traffic light, you
can completely carry out the initiated
operation. To do this, press and hold
the corresponding button again.
Give the respectively applicable traffic
rules preference during convertible top
operation, as otherwise you will be in
violation of the law.
Remove any foreign objects from the
windshield frame before closing the
convertible top, otherwise, they could
hinder the opening and closing of the
convertible top.
Do not place any objects on the con-
vertible top, since they would fall off
when the convertible top is operated
and cause damage or injuries.
While driving, always close the rear
power windows first, or close all 4 win-
dows at the same time, otherwise the
windows may not shut tightly at higher
speeds.cDo not reach into the convertible
top mechanism during opening
and closing. Keep children away from
the moving parts of the convertible top
during operation.
The automatic process is immediately
interrupted if the button for actuating
the convertible top is released. The pro-
cess can be continued in the direction
desired by pressing the switch.c
If the convertible top has been
stored in the convertible top com-
partment for an extended period of
time, e.g. during the winter months be-
cause the hardtop
* has been used, it
may be necessary to manually support
the top when closing it automatically for
the first time:
Should the convertible top stop shortly
before it reaches the end of the closing
operation, press from outside against
the front of the convertible top frame
while pressing the switch to help the
top along until it begins moving again
on its own.c
Page 108 of 199
108n
Luggage rack for the hardtop
*
Mounting pointsAccess to the mounting points:
To open the covers (arrow), please
use the tool included with the luggage
rack system.
A special roof-rack system is available
for your BMW as an optional extra.
Please observe the precautions in-
cluded with the installation instructions.
Because roof racks raise the center of
gravity of the vehicle when loaded, they
exercise a major effect on its handling
and steering response.
You should therefore always remember
not to exceed the approved roof weight,
the approved gross vehicle weight or
the axle weights when loading the rack.
You will find the specifications under
"Technical Data" on page 184.46cde097
Make sure that the load is not too heavy,
and attempt to distribute it evenly.
Always load the heaviest pieces first (on
the bottom). Make sure nothing projects
into the luggage compartment lid's
opening and closing path.
Secure the roof luggage correctly and
securely to prevent it from shifting or
being lost during driving (danger to fol-
lowing traffic).
Drive smoothly and avoid sudden ac-
celeration or braking. Do not corner at
high speeds.
The roof load increases aerodynamic
resistance, resulting in increased fuel
consumption and additional stresses on
the vehicle body.
Page 193 of 199
Everything from A to Z
193n
IndexDataTechnologyRepairsCar careControlsOverview
Manual transmission73
Manually controlled
recirculated-air97
Memory57
MFL (Multifunction steering
wheel)24
Mirror memory57
Mirrors58
Mobile phones120
Modifications,
technical6, 148
Multifunction steering wheel
(MFL)24NNavigation system, refer to
the Radio Owner's ManualOOBD interface socket149
Odometer82
Oil
additives133
capacity185
consumption133
dipstick133
quality134
specifications134
viscosity134
Oil change intervals, see the
Service and Warranty
Information BookletOil filter change185
Oil level
check133
Indicator lamp20
Oil pressure, indicator
lamp20
OILSERVICE83
Onboard computer85
also refer to separate
Owner's Manual
Onboard tool kit152
Opening and closing
from inside38
from outside34
Operating the convertible
top
manual convertible top45
Outlets, ventilation94
Outside temperature
display85
PPaint blemishes140
Paint, care140
Paintwork, minor
repairs141
Paintwork, waxing141
Park Distance Control
(PDC)87
Parking brake72
Parking help87
Parking lamps92Parking, winter119
PDC (Park Distance
Control)87
Performance182
Pocket lamp99
Pollen98
Power seats53
Power steering120
Power windows44
Pressure monitoring,
tires89, 177
Pressure, tires27, 123
RRadiator185
Radio Data System
(RDS)174
Radio reception120, 174
Radio, refer to the separate
Owner's Manual
Rain sensor78, 176
RDC (Tire Pressure
Control)89, 177
RDS (Radio Data
System)174
Reading lamps93
Rear lamp155
Rear window
defroster79, 98
Rearview mirror58, 59
Reclining seat53
Refueling26Remote control35
Remote control key32
Remove condensation,
windows97
Replacement key32
Reporting safety defects7
Restraint system61, 66
Reverse17, 73
Rollover protection
system68, 179
lowering68
Roof load capacity184
Roof luggage rack108
Roof-carrier assembly121
Rubber parts118
SSafety belt tensioners174
Safety belts61
Safety buttons38
Seat heating99
Seat memory57
Seat-integrated safety belt
system56
Seats
sitting properly53, 64
Securing cargo107
Securing loads107
Selector lever, automatic
transmission74
Self-defrosting mirrors59
Self-diagnostics178
