BMW 325I 2001 Owners Manual
Manufacturer: BMW, Model Year: 2001, Model line: 325I, Model: BMW 325I 2001Pages: 203, PDF Size: 2.07 MB
Page 101 of 203

101n
IndexDataTechnologyRepairsCar careControlsOverview
HiFi system Ð harman kardonSpecial acoustical effects are activated
or deactivated every time you press the
button.
When the system is activated, the
impression of a significantly larger
passenger compartment is created at
all seating areas, together with an
improvement of the stereo effect.
When reception is weak, the system
frequently switches between stereo
and mono operation. Switch off if this
occurs.460us287
To open Pull the handle. The lamp comes on.To closingFold the door up.To lockLock with one of the master keys. A
master key can also be used for
unlocking.
If you turn over only your door and
ignition keys for valet parking
(refer to page 32), for instance, access
to the glove compartment is not
possible.<460de041
To prevent injury in the event of
a crash, close the glove compart-
ment immediately after use.<
Rechargeable flashlightThe flashlight is located on the left-
hand side of the glove compartment.
It features integral overload-protection
so it can be left in its holder continu-
ously.
Be sure that the flashlight is
switched off when it is inserted
into its holder. Failure to comply with
this precaution could lead to over-
charging and damage.<
HiFi system
*
Glove compartment
Page 102 of 203

102n
Storage compartments Open the storage compartment in the
front center armrest
*: press the button
(arrow) and lift upward.
You will find additional storage areas in
the front doors and in the center
console above the ashtray. Storage
nets
* are located on the backs of the
front seats.
460us043
Beverage holder, coin box A coin box and two beverage holders
are provided in the center console.460us251
Rear center armrestThere is a storage compartment, a
beverage holder (for two drinks) and a
garbage bag holder located in the rear
center armrest.
1 Storage compartment: pull upward (1)
2 Beverage holder: press (2)463de050
Page 103 of 203

103n
IndexDataTechnologyRepairsCar careControlsOverview
Storage compartments Cellular phone
*
Storage package
*
For your convenience, there are:
>Two flip-out sockets on the rear
center console (arrows).
>An eyeglasses compartment
* (not
shown in the illustration) in the front
center console above the ashtray.
460de299
Additional storage areas are located
under both the cargo area and under
the spare wheel/space-saver tire panel.
Hands-free systemOn vehicles that are wired for a tele-
phone
*, the cover for the hands-free
microphone is located in the headliner
near the interior lamp.
For further information on the cellular
phone, refer to the separate Owner's
Manual.
463us012
Page 104 of 203

104n
Ashtray, front Cigarette lighterTo open Press briefly in the direction indicated
by the arrow.
To extinguish a cigarette, tap off the
ash and gently press the tip into the
funnel.460us288
To emptyOpen the lid and press down (arrow):
You can now pull the ashtray upward
for removal.460us289
Press the lighter in. It can be remove as
soon as it pops up.
Hold or touch the hot cigarette
lighter by the knob only. Holding
or touching it in other areas could result
in burns.
The cigarette lighter remains opera-
tional when the ignition key has been
removed. For this reason, children
should never be left in the vehicle
unattended.
appliances up to approx. 200 watts at
12 volts. Avoid damaging the socket due
to inserting plugs of different shapes or
sizes.460us290
Page 105 of 203

105n
IndexDataTechnologyRepairsCar careControlsOverview
Ashtray, rear Power outlet To open Push the cover open.To emptyPress on the edge of the raised cover
in the opening direction (arrow). You
can now pull the ashtray upward for
removal.460de104
A flip-out socket (12 V) is located in the
luggage compartment.463us008
Page 106 of 203

106n
Ski bag
*
The ski bag allows the safe and clean
transport of up to four pairs of standard
skis or up to two snowboards.
The length of the ski bag and the addi-
tional space provided in the luggage
compartment make it possible to carry
skis up to 6.8 feet long (2.1 0 meters).
Because of the tapered shape of the
bag, the ski bag can only accommodate
two pairs of skis that are 6.8 feet
(2.1 0 meters) long.
Loading1 Fold the center armrest outward.
Loosen the trim from the upper
Velcro¨ fastener and place it on the
armrest.
2 Press the button (arrow 1) from inside
the passenger compartment: the cover
panel will fall to the luggage compart-
ment floor.
3 Press the detent lever (arrow 2)
downward and fold the cover to the
front.
4 Extend the ski bag between the front
seats. The zipper provides conve-
nient access to the inside of the bag,
and can also be left open to promote
drying.
To store the ski bag, perform the above
steps in reverse sequence.463de048
Secure the skis or other objects in
the bag by tightening the strap
with the buckle.<
Please be sure that the skis are clean
before loading them into the bag. Be
careful to avoid damage from sharp
edges.
380de070
Page 107 of 203

107n
IndexDataTechnologyRepairsCar careControlsOverview
Cargo areaRear backrest that can be folded
forwardReach into the recess and pull forward
(arrow).
The backrest of the rear seat is divided
into two portions, one-third and two-
thirds of the seat respectively. You can
fold either section of the backrest down
separately in order to increase the
capacity of the luggage compartment.
When you close the backrest, be
sure that the catch engages
securely. The red warning indicator
disappears into the recess.<392de161
Roll-up coverPull the roll-up cover out and hook it
into the brackets.
The cover will support light objects
such as items of clothing.
Never put any heavy or hard
objects onto the roll-up cover,
otherwise, vehicle occupants could be
injured during braking or in an accident.
Do not allow the cover to snap back,
since this could damage it.<392de162
Partition net
*
Pull the partition net out by the straps.
Hold the bar on both sides and insert it
into the holder. It is easiest to do this
from the back seat.
Do not allow the partition net to
snap back. Doing so could cause
injury and the partition net could be
damaged.<
When the rear backrests are folded
down, you can store the cassette on
the back of the seats, pull the partition
net out from there and insert it in the
front holders (refer to the next page).392de163
Page 108 of 203

108n
Cargo areaRemove the roll-up cover and
partition net1 Press the side buttons simulta-
neously (arrow 1).
2 Pull the cassette out the back
(arrow 2).InstallationSimply slide the cassette forward in the
two side holders until it engages.463de046
Store with rear backrest folded
downThe take-up guides for the cassette are
attached to the back sides of the seat-
backs (arrows 1).
As shown in the illustration, push the
cassette in from the right side until it
clicks into place (arrow 2). When doing
this, the roll-up cover must always point
in the direction of travel, and the strap
for the partition net must point upward.
You can pull the partition net out and
insert it in the holders above it in the
upper roof area.463de047
The cassette always has to be
pushed all the way into both guide
rails from the right side, or else it might
be jammed in asymmetrically. In addi-
tion, the door's interior paneling could
be damaged when shutting the door.<
Page 109 of 203

109n
IndexDataTechnologyRepairsCar careControlsOverview
Cargo areaFloor panelTo raise and secure the floor panel, lift
it by the ring and hook it into the rubber
seal of the run-off gutter with the
hanger (arrow).463de008
Side coversOpen the side covers by pressing the
button.463de038
Page 110 of 203

110n
Cargo loadingStowing cargo If you are transporting a load in your
BMW:
>Load heavy cargo as far forward as
possible Ð directly behind the back-
rests or the luggage compartment
partition Ð and as low as possible.
>Cover sharp edges and corners.
>Do not pile objects higher than the
top edge of the backrest.
>Pull the partition net
* out (refer to
previous page). Be sure that items
carried in the rear cannot slip through
the partition net
*.
>If you are transporting very heavy
loads when the rear seat is not occu-
pied, secure the outer safety belts in
the opposite buckles.
463de002
Securing the load >Secure smaller, light pieces with the
retaining straps or a luggage net
*, or
use luggage straps (refer to page 40).
>For large, heavy pieces, see your
BMW center for load-securing
devices
*. Use the lashing eyes
(arrow) affixed to the four inside
corners in the luggage compartment
for securing the load.
>Comply with the information enclosed
with the load-securing devices.
463de032
Always position and secure the
load correctly. If you do not, it can
endanger the passengers during
braking or evasive maneuvers.
Do not exceed the permissible gross
vehicle weight and the permissible axle
loads (refer to page 186). If you do, safe
operation of the vehicle is no longer
ensured, and you are in violation of
the law.
Do not carry hard or heavy objects
unsecured in the passenger compart-
ment. If you do so, they may be
projected through the air during braking
and evasive maneuvers, thus endan-
gering vehicle occupants.<
