BMW 325i TOURING 2002 E46 Owner's Guide

21n
OverviewControlsMaintenanceRepairsDataIndex

Multifunction steering wheel (MFL)

*
The buttons integrated in the multifunc-
tion steering wheel are provided so that
you can operate a number of accesso-
ries quickly and without being
distracted from traffic conditions. You
may operate:

>

Selected radio functions

>

The cruise control

>

Selected cellular phone functions.
The controls are active only when
the corresponding systems and
accessories are switched on.

<

Press briefly:
Receive a phone call, initiate dialing,
terminate a call.

Switch between phone, radio, cassette
and CD.
Forward:

>

Radio
Press briefly: station scan in FM band
Extended pressure: search function

>

CD
Press briefly: jump to next track
Extended pressure: search function
in track

>

Cassette
Press briefly: stop track scan or fast
forward
Extended pressure: fast forward

>

Phone
Scan personal phone book.
Rewind/reverse: functions as fast
forward.

Volume
Cruise control: select a stored setting.
Cruise control: store and accelerate (+)
or decelerate and store (Ð).
Cruise control: activate/interrupt/deac-
tivate.

22n

Hazard warning triangle

*
Refueling

The warning triangle is located on the
left side of the cargo area behind the
cover panel.
To open: press the button (arrow) and
remove the cover.
Always observe all legal regula-
tions requiring a warning triangle
to be carried in the vehicle.

<

Fuel filler door

Before filling the tank, switch off
the engine. If you do not, fuel
cannot be filled into the tank and the
SERVICE ENGINE SOON lamp may
come on.

<

Press on the rear edge of the fuel filler
door to open and close it.
Manual release: undo the trim panel on
the right side of the cargo area. Pull the
knob with the fuel pump symbol.

Always observe all safety precau-
tions posted at the service station
when handling fuel. Never carry spare
fuel containers in your vehicle. Whether
empty or full, these containers can leak,
cause an explosion, or lead to fire in the
event of a collision.<

23n
OverviewControlsMaintenanceRepairsDataIndex
Refuel Fuel specificationsSimple and environmentally
friendly
Open the fuel filler cap carefully to
prevent fuel from spraying out.
Fuel spray may cause injury.<
Put the filler cap in the bracket (arrow)
attached to the fuel filler door.
When refueling, insert the filler nozzle
completely into the filler pipe. Pulling
the nozzle out of the pipe during refu-
eling
>results in premature pump shutoff
>and will reduce the effectiveness of
the vapor recovery system on the
pump.
As long as the filler nozzle is used prop-
erly, the fuel tank is full whenever the
nozzle shuts off the first time.
Refill early to avoid damaging the
catalytic converter; never attempt
to drive to the last drop of fuel in the
tank.<
Close the fuel filler cap carefully
after refueling until a click is
heard. While closing, be sure not to
squeeze the strap which is fastened to
the cap. A loose or missing cap will
activate the CHECK FILLER CAP lamp
or the SERVICE ENGINE SOON lamp.<
Tank capacity: approx. 16.6 gal.
(63 liters), incl. a reserve capacity of
approx. 2.1 gal. (8 liters).
The engine uses lead-free gasoline
only.
Required fuel:
>Premium Unleaded Gasoline,
min. 91 AKI.
AKI = Anti Knock Index
Never use leaded fuel, as it would
cause permanent and irreversible
damage to the oxygen sensor and the
catalytic converter.<

24n
Tire inflation pressures The specified inflation pressures are
provided on a sticker attached to the
B-pillar and visible with the driver's
door open.Checking tire pressuresAll pressures are specified in the stan-
dard units of pressure for your country,
psi or kilopascal, and apply to cold tires
(tires at ambient temperature, refer to
tire pressure table on the following
page).
Vehicles with Tire Pressure Monitor
(RDC)/Flat Tire Monitor:
After correcting the inflation pressures,
reactivate the system, refer to
pages 78, 80.
Another instruction plate regarding
inflation pressures on the door pillar
indicates which system is equipped on
your vehicle.
Check the tire pressures on a
regular basis Ð at least twice a
month Ð and before every extended
journey. Otherwise, incorrect tire pres-
sure can lead to driving instability, tire
damage and accidents.
Remember to check the inflation pres-
sure in the space-saver or standard
spare tire.

Inflate the spare tire to the highest infla-
tion pressure of any tire on your
vehicle.<
Comply with tire approval
specificationsThe inflation pressures in the table
apply to BMW approved tire sizes and
tire manufacturers. Your BMW center is
familiar with these pressures. Higher
pressures may be specified for tires
made by other manufacturers.
Your vehicle is equipped with tires that
not only meet US standards, but also
European standards. We recommend
the exclusive use of BMW approved
tires.

25n
OverviewControlsMaintenanceRepairsDataIndex
Tire inflation pressuresBMW Tires
All pressure specifications in the table are
indicated in psi (kilopascal) with cold tires
(cold = ambient temperature)
325i
325xi205/55 R 16 91 H M+S
205/55 R 16 91 H
225/50 R 16 92 W (not 325xi)
225/45 R 17 91 W32 (220) 38 (260) 38 (260) 45 (310)
225/45 ZR 17
245/40 ZR 1732 (220)
ÐÐ
38 (260)38 (260)
ÐÐ
45 (310)
205/50 R 17 93 V M+S extra load
205/50 R 17 93 W extra load
205/55 R 16 91 Q M+S
225/50 R 16 92 Q M+S (not 325xi)
205/50 R 17 93 Q M+S extra load
225/45 R 17 91 Q M+S35 (240) 41 (280) 41 (280) 48 (330)
Space-saver spare tire in cargo area 61 (420)

26n

27n
Overview
Controls
Maintenance
Repairs
Data
Index
Overview
Controls in detail
Operation, maintenance
Owner service procedures
Index
Technical data

28n
Keys Central locking systemThe key set1 Master keys with remote control unit,
determine the functions of the Key
Memory, refer to page 54.
You can mark individual keys for
subsequent identification by applying
the colored decals that you received
when accepting delivery of your
vehicle.
Each master key is equipped with
an extended-life battery. This
battery is recharged in the ignition lock
during normal operation.
For this reason, if you have master keys
that are not being used you should use
those keys approx. once a year while
driving for an extended period to
charge the battery, refer also to
page 29.<
2 Spare key for storage in a safe place,
such as in your wallet. This key is not
intended for constant use
3 Door and ignition key
The lock for the glove compartment
cannot be operated with this key Ð
this is useful for valet parking, for
instance.
The conceptThe central locking system is ready for
operation whenever the driver's door is
closed. The system engages and
releases the locks on the
>doors
>tailgate and rear window
>fuel filler door.
The central locking system can be
operated
>from outside via the remote control
as well as via the driver's door lock
>from inside by pressing a button.
Operating it from inside does not lock
the fuel filler door, refer to page 32.
When the system is operated from the
outside, the anti-theft system is acti-
vated simultaneously. Both the door
locks and release handles remain
locked. The alarm system is also armed
or disarmed.
If locked from the inside, the central
locking systems unlocks automatically
in the event of an accident, but only
doors which were not locked separately
with the door lock buttons, refer to
page 32. In addition, the hazard
warning flashers and interior lamps
come on.

29n
OverviewControlsMaintenanceRepairsDataIndex
Opening and closing Ð via the remote controlThe conceptThe remote control gives you an excep-
tionally convenient method for
unlocking and locking your vehicle.
Furthermore, it provides two additional
functions which you can only execute
via the remote control:
>To switch on interior lamps, refer to
page 30.
With this function, you can also
search for the vehicle, when parked
in an underground garage, for
instance
>Opening the rear window, refer to
page 30.
The rear window will open slightly,
regardless of whether it was previ-
ously locked or unlocked.
Whenever you unlock (lock) the vehicle,
you simultaneously deactivate (activate)
the anti-theft system, disarm (arm) the
alarm system and switch the interior
lamps on (off).
You can have a signal set to
confirm that the vehicle's locks
have engaged securely.<
Since children might be able to
lock the doors from the inside,
always take the vehicle keys with you
so that the vehicle can be opened again
from the outside at any time.<
If it is no longer possible to lock
the vehicle via the remote control,
the battery is discharged. Use this key
while driving for an extended period in
order to recharge the battery.
To prevent unauthorized use of the
remote control, surrender only the door
and ignition key or the spare key when
leaving the vehicle for valet parking, for
example, refer to page 28.
In the event of a system malfunction,
please contact your BMW center. You
can also obtain replacement keys
there.<
1 Unlock and convenience opening
mode
2 Lock and secure, switch on interior
lamps, deactivate tilt alarm sensor
and interior motion sensor
3 Open rear windowTo unlockPress the button once to unlock the
driver's door.
Press the button a second time to
unlock all vehicle locks.

30n
Opening and closing Ð via the remote controlConvenience opening modePress and hold button: the power
windows and sliding/tilt sunroof are
opened.To lock and securePress button.
Do not lock the vehicle if anyone
will be remaining inside, as it
would then be impossible for the occu-
pant(s) to disengage the locks from the
inside.< To switch on the interior lampsAfter locking the vehicle, press button
again.To switch off tilt alarm sensor
*
and interior motion sensor
*
Press button a second time immedi-
ately after locking. For additional infor-
mation refer to page 36.
To open the rear windowPress button.
The rear window opens slightly. It can
now be tilted up.
Before and after a trip, be sure
that the rear window has not been
opened unintentionally.<
If you prefer, the tailgate will open
instead of the rear window. seconds, the alarm system can be trig-
gered in the event of danger, if it is
armed.
Press the button to cancel the alarm.External systemsThe remote control system's operation
may be affected by other units or
equipment operating in the immediate
vicinity of your vehicle.
If this should occur, you can still open
and close the vehicle using the master
key in the door lock.For US owners onlyThe transmitter and receiver units
comply with part 15 of the FCC (Federal
Communication Commission) regula-
tions. Operation is governed by the
following:
FCC ID: LX8EWS
LX8FZVS
LX8FZVE
Compliance statement:
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
>This device may not cause harmful
interference, and
>this device must accept any interfer-
ence received, including interference
that may cause undesired operation.
Any unauthorized modifications to
these devices could void the
user's authority to operate the equip-
ment.<
