Page 6 of 159
Contents
Owner service procedures
Technical data
Index
Replacement procedures:
Onboard tool kit130
Windshield wiper blades130
Lamps and bulbs130
Changing a wheel135
Battery139
Fuses139
Assistance, giving and
receiving:
Jump-starting140
Towing the vehicle141Engine data144
Dimensions145
Weights146
Capacities147Everything from A to Z150
Page 130 of 159
130n
The onboard tool kit is located in the
luggage compartment lid.
Loosen the wingnut to open.
1. Fold the wiper arm completely out
from the windshield
2. Position the wiper blade at an angle
and pull the release spring (arrow)
3. Fold the wiper blade down and
unhook it toward the windshield
4. Pull the wiper blade past the wiper
arm toward the top
5. Insert a new wiper blade and apply
pressure until you hear it engage.
Use only wiper blades which have
been approved by BMW.<
The lamps and bulbs make essential
contributions to the safety of your
vehicle. Therefore, comply fully with the
following instructions during bulb
replacement. If you are not familiar with
any of the procedures, consult your
BMW center.
Do not touch the glass portion of
a new bulb with your bare hands
since even small amounts of impurities
burn in to the surface and reduce the
service life of the bulb. Use a clean
cloth, paper napkin, or a similar mate-
rial, or hold the bulb by its metallic
base.<
A replacement bulb set is available from
your BMW center.
Before working on the electrical
system, switch off the electrical
accessory you are working on or
disconnect the cable from the negative
terminal of the battery. Failure to
observe this precaution could result in
short circuits.
To prevent injuries and damage,
comply with any instructions provided
by the bulb manufacturer.<
Onboard tool kit Windshield wiper blades Lamps and bulbs
Page 154 of 159
Everything from A to ZManual transmission66
Manually controlled recircu-
lated-air95
Master keys28
MFL (Multifunction steering
wheel)22
Microfilter92, 96
Mirror defrosting55
Mirror memory53
Mirrors55
Mobile phone, refer to
cellular phone100
Modifications,
technical10, 126
Motion sensor, refer to
interior motion sensor36
Mounting the roof rack110
Multifunction steering wheel
(MFL)22 O
OBD interface socket127
Odometer74
Oil
additives121
capacity147
consumption121
quality122
specifications122
viscosity122 Oil change intervals, refer to
the Service and Warranty
Information Booklet (US
models) or the Warranty
and Service Guide Booklet
(Canadian models)
Oil dipstick121
Oil filter change147
OIL SERVICE75
Onboard computer76
refer also to the "Owner's
Manual for Onboard
Computer"
Onboard tool kit130
Opening and closing
from the inside32
via the door lock31
via the remote control29
Original hand-held
transmitter97
Outside temperature
display77
P
Paint care, refer to the
"Caring for your vehicle"
manual
Park assistant79
Park Distance Control
(PDC)79 Parking aid79
Parking brake66
Parking lamps
bulb replacement131
PDC (Park Distance
Control)79
Phone, refer to cellular
phone100
Pocket light96
Power windows38
Q
Quality Grades, tires114 R
Radiator147
Rain sensor70
RDC (Tire Pressure
Monitor)83
Reading lamps
front89
rear89
Rear fog lamps
bulb replacement133
Rear lamps133
Rear reading lamps89
Rear window
defroster91, 95 Rearview mirror55
Recirculated-air mode91
Refueling22
Remote control29
Remove window
condensation92, 94
Replace windshield wiper
blades130
Replacement keys28
Replacing lamps and
bulbs130
Reporting safety defects11
Reverse66
Rollover protection
system61
Roof weight146
Roof-mounted luggage
rack105
S
Safe with safety belts48
Safety belts48, 52
seat-integrated51
Safety defects, reporting11
Safety tires115, 138
Seat heating54
Seat memory53
Seat-integrated safety belt
system (SGS)51
